HTC TOUCH PRO 2 User manual

Quick Start Guide

Please Read Before Proceeding
THE BATTERY IS NOT FULLY CHARGED WHEN YOU TAKE IT OUT OF THE BOX.
DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.
YOUR WARRANTY IS INVALIDATED IF YOU DISASSEMBLE OR ATTEMPT TO DISASSEMBLE
THE DEVICE.
PRIVACY RESTRICTIONS
Some countries require full disclosure of recorded telephone conversations, and stipulate that you must
inform the person with whom you are speaking that the conversation is being recorded. Always obey the
relevant laws and regulations of your country when using the recording feature of your PDA Phone.
LIMITATION OF DAMAGES
To the maximum extent permitted by applicable law, in no event shall HTC or its providers be liable to user or
any third party for any indirect, special, consequential, incidental or punitive damages of any kind in contract
or tort, including, but not limited to, injury, loss of revenue, loss of goodwill, loss of business opportunity,
loss of date, and/or loss of profits arising out of, or related to, in any manner, or the delivery, performance
or nonperformance of obligations, or use of the weather information, stock data, data or documentation
hereunder regardless of the foreseeability thereof.
FOR MORE INFORMATION
For health, safety, and regulatory information, see “Appendix: Safety and Other Notices”.

Table of Contents
Contents
1. Welcome to the HTC Touch Pro2 Quick Start Guide .................5
2. Inside the Box .........................................................................................5
3. Getting to Know Your HTC Touch Pro2..........................................6
4. Installing the Battery and Storage Card........................................8
5. Charging the Battery..........................................................................10
6. Starting Up.............................................................................................10
7. The Home Screen................................................................................11
8. Lock Screen............................................................................................13
9. Using the Start Screen.......................................................................15
10. Making Your First Call.........................................................................16
11. Straight Talk™........................................................................................17
12. Entering Information..........................................................................19
13. Basic Settings........................................................................................20
14. Adding Favorite Contacts.................................................................23
15. Viewing Conversations......................................................................25
16. Using Facebook....................................................................................26
17. Sending Text Messages.....................................................................29
18. Sending an MMS Message...............................................................29
19. Setting Up an Internet Email Account.........................................30
20. Using Wi-Fi .............................................................................................31

Table of Contents
21. Mobile Internet ....................................................................................32
22. Bluetooth................................................................................................33
23. Keeping Track of Appointments ....................................................34
24. Capturing Photos and Recording Videos....................................35
25. Viewing Photos and Videos .............................................................36
26. Connecting Your Phone to a Computer......................................37
27. Synchronizing Your Phone with Your Computer......................38
28. Copying Files to the Storage Card.................................................39
29. Synchronizing Music Files ................................................................39
30. Listening to Music on Your Phone.................................................40
31. Resetting Your Phone.........................................................................41
32. Troubleshooting Tips .........................................................................42
Appendix: Safety and Other Notices....................................................43

Quick Start Guide 5
1. Welcome to the HTC Touch Pro2 Quick Start Guide
Congratulations on your purchase of the HTC Touch Pro2!
This Quick Start Guide will help you get started with your HTC Touch Pro2. This guide will
walk you through the features we feel you will want to learn right away when you use your
HTC Touch Pro2.
For a more complete guide in using your HTC Touch Pro2, please refer to the User Manual
PDF that is on the Getting Started Disc.
2. Inside the Box
You should find the following items inside the box.
HTC Touch Pro2
Battery
AC adapter
Screen protector
•
•
•
•
Wired stereo headset
USB sync cable
Quick Start Guide
•
•
•
Extra stylus
Getting Started Disc
•
•

6 Quick Start Guide
3. Getting to Know Your HTC Touch Pro2
VOLUME UP
POWER
Sync Connector/Earphone
Jack/TV Out
Microphone 3.5 mm Audio Jack
VOLUME
DOWN
Stylus
Microphone
Strap Holder
Back Cover
3.2 Megapixel
Camera
MUTE
Dual Speaker
Earpiece
Touch Screen
END
BACK
Zoom
Bar
TALK/SEND
Hardware
Keyboard
START
Light
Sensor
Notification LED

Quick Start Guide 7
Opening the hardware keyboard
To use the hardware keyboard, slide the screen panel to
the right to reveal the keyboard.
The screen orientation automatically switches to
landscape mode when the keyboard is opened.
Adjusting the LCD screen angle
50° angle
The maximum tilting angle is 50
degrees. Do not force the screen
to tilt further than the maximum
angle as it will break the device.
Before you retract the screen, be
sure to adjust the screen angle
back to the original horizontal
position.

8 Quick Start Guide
4. Installing the Battery and Storage Card
You need to remove the back cover before you can install the battery or storage card. Also,
make sure to always turn off the power before installing or replacing the battery.
Note Your Global Phone accommodates a GSM SIM card for global coverage on GSM networks
outside of the United States. Refer to the User Manual PDF on the Getting Started Disc for
instructions on inserting a SIM card. SIM cards must be purchased from a carrier in the
country you wish to use the phone and are not sold or supported by U.S. Cellular.
To remove the back cover
Make sure your phone is turned off.
Remove the stylus.
Note You need to temporarily remove the stylus to
be able to remove or replace the back cover.
Firmly hold the phone with both hands and the
front panel facing down.
Push the back cover up with your thumbs until
it disengages from the phone and then slide it
up to remove.
1.
2.
3.
4.

Quick Start Guide 9
To install the battery
Align the battery’s exposed copper
contacts with the battery connectors
at the bottom part of the battery
compartment.
Insert the contacts side of the battery
first and then gently push the battery
into place.
Replace the back cover and insert the
stylus back into the stylus compartment.
To remove the battery
Lift out the battery from the groove at the
upper right side of the battery compartment.
1.
2.
3.
RESET
Groove
To install the microSD card
Remove the stylus and then remove the
back cover.
Locate the microSD card slot on the
exposed right panel.
Insert the microSD card into the slot
with its gold contacts facing down until
it clicks into place.
Note To remove the microSD card, press to eject
it from the slot.
1.
2.
3.
RESET
Storage
card slot

10 Quick Start Guide
5. Charging the Battery
New batteries are shipped partially charged. Before you start using your phone, it is
recommended that you install and charge the battery.
To charge the battery
Connect the USB connector of the AC adapter to the sync connector at the bottom
of your phone.
Plug in the power adapter to an electrical outlet to start charging the battery.
Note Only the AC adapter and USB sync cable provided with your phone must be used to charge
the battery.
6. Starting Up
After installing and charging the battery, you can now power on and start using your
phone.
To turn on the phone
Press the POWER button.
When you turn on your phone for the first time, Windows Mobile starts up and prepares
your phone for first time use.
To turn off the phone
Press and hold the POWER button for a few seconds.
Tap Yes when prompted.
1.
2.
1.
2.

Quick Start Guide 11
7. The Home Screen
The Home screen of your phone allows finger-touch access to the most widely-used functions,
such as People, Messages, Internet, and more. The Home screen has the following tabs:
Home Music Settings
WeatherInternet
Stocks
Photos and
Videos
People
CalendarMessages
Mail Programs
To switch between the tabs of the Home screen
Do any of the following:
Tap the desired tab on the Home screen.
Press and hold your finger
on the active tab, and then
slide your finger right or
left over the tabs. Release
when you have selected
the desired tab.
Swipe left across the screen
to move to the next tab,
and swipe right across
the screen to move to the
previous tab.
•
•
Tip Press the END button anytime to return to the Home tab.
•

12 Quick Start Guide
To display the Home screen in landscape view
When you slide out the hardware keyboard, the Home screen automatically changes to
landscape view and temporarily hides the tabs. Tap at the bottom left side of the
Home screen to display the tabs.
The following sections in this Quick Start Guide will show you how to use some of the
Home screen tabs. For complete information about using the Home screen, refer to the
User Manual PDF.

Quick Start Guide 13
8. Lock Screen
The Lock screen is displayed whenever your phone is locked. You can lock your phone to
prevent accidental button or touch screen presses when the phone is in your bag or pocket.
Locking your phone
Your phone automatically locks when your phone is password protected, and the set idle
time has elapsed. Your phone locks itself and requires the correct password entry to unlock
it. For more information about setting a password and idle time for your phone, see the
“Protecting your phone with a password” chapter of the User Manual PDF.
You can also lock the phone manually. Tap Start and then tap Lock in the lower left corner
of the Start screen, or long press the END button until the phone vibrates.
Tap Lock
Long press
END/POWER
Unlocking your phone
When you see the Lock screen, slide the Lock button ( ) left or right to unlock your phone.
Checking notifications when the phone is locked
When your phone is locked, you are still notified of missed calls, new messages, and
upcoming appointments. The Lock screen shows the next upcoming appointment and the
Lock button shows the number of notifications.

14 Quick Start Guide
To view the notifications
On the Lock screen, tap the Lock button ( ). Notification buttons representing
each type of received information, such as missed calls, new email, and new text
messages, are then displayed below the Lock button.
Slide a notification button right or left to view the respective information. For
instance, slide the Missed Call button to access the Call History and view missed calls.
Upcoming
appointment
Note If a phone password is set, you are prompted for the password before you can view the
notification item. See the “Managing Your Phone” chapter in the User Manual PDF for
information on setting a phone password.
Receiving a call when the phone is locked
You can receive and answer calls even when your phone is locked. For more information
about answering calls, see the“Using Phone Features“ chapter of the User Manual PDF.
After you end the call, your phone remains locked and the Lock screen is displayed. You
need to unlock to use your phone.
1.
2.

Quick Start Guide 15
9. Using the Start Screen
The Start screen gives you one-touch access to the programs and settings of your phone.
To open the Start screen, tap Start ( ) at the top left corner of the screen, or press the
START button ( ).
On the Start screen:
Swipe your finger up or down to scroll
through the screen.
Tap the Today icon to return to the Home
screen.
Tap a program icon to open the
corresponding program.
Tap the Settings icon to access the
settings of your phone.
Tap Lock at the bottom-left corner of the
Start screen to lock your phone. See “Lock
Screen” earlier in this Quick Start Guide
for details.
Press the START button twice to close the
Start screen.
•
•
•
•
•
•
To move an icon to the top of the Start screen
You can move often used icons to the top of the Start screen for easy access.
Press and hold the icon that you want to move.
Tap Move to Top.
The icon is moved to the top of the Start screen.
To return an icon to its original location, press and hold the icon and then tap Move Down.
1.
2.

16 Quick Start Guide
10. Making Your First Call
On the Home screen, tap Phone.
Tap the keys on the keypad to enter the phone
number.
Tip If you tapped a wrong number, tap to erase
each subsequent digit of a number. To erase the
entire number, press and hold .
Tap Talk to place the call.
Tip When in a call, use the VOLUME UP/DOWN
buttons on the side of the phone to adjust the
phone volume.
When a call is in progress, tap End Call or press
END to hang up.
1.
2.
3.
4.
Accepting or rejecting an incoming call
To answer a call
Press the TALK/SEND button, or fully slide the center
button of the Answer/Ignore bar to the left.
To reject a call
Press the END button, or fully slide the center button of
the Answer/Ignore bar to the right.
To mute the ring without rejecting the call
Tap Mute Ring or press the VOLUME DOWN button.
To reject the call and automatically send a preset text message to the caller
When you receive a phone call, tap Send Text to reject the call and automatically send a
preset text message to the caller.

Quick Start Guide 17
11. Straight Talk™
Your phone features Straight Talk™, a technology that integrates messaging, voice, and
three-way calling. With a dual microphone and speaker that enhance voice quality and
reduce noise, Straight Talk turns your phone into a conference room speakerphone system.
Making a voice call from a message
When you select or view a text or email message, you can directly call the sender of the
message.
On the Messages tab, Mail tab, or the Inbox, select a message and then press
TALK/SEND. The Phone screen opens with the sender’s phone number automatically
filled in and ready to be dialed. Tap Talk or press TALK/SEND again to call the sender.
Open a received email. You can tap the Talk icon ( ) that is displayed to the right
of the sender name to call the sender, if this sender is a stored contact.
Tapping a phone number that is displayed in the body of the message also allows
you to call that number.
Tip If you made a call from an email message, an email indicator will be shown on the Keypad
button ( ). Tap this button to view the email content directly on the Phone screen.
Starting a three-way call in CDMA mode
Press the TALK/SEND button to open the Phone screen.
Make the call to the first participant.
When the first call is connected, make a call to the second participant. The first call is
put on hold when you dial the second call.
When the second call is connected, tap Flash to start the three-way call. The screen
displays Call in progress.
•
•
•
1.
2.
3.
4.

18 Quick Start Guide
Tap Flash
to start the
three-way call.
Caller 1
Caller 2
Tap Flash to cycle between the three-way call, Caller 1 only, and Caller 2 only.
To turn on the speakerphone
While a call or a three-way call is in progress, you can turn on the speakerphone by simply
placing your phone face down.
Featuring Straight Talk™ technology, your phone provides crystal-clear sound quality and
voice reception during three-way calls. When the speakerphone is on, your phone also
enables the dual microphone to enhance your voice quality and reduce noise.
To end the three-way call
Tap End Call or press END.
For more information about three-way calling including how to make a three-way call in
GSM mode, refer to the“Using Phone Features” chapter in the User Manual PDF.

Quick Start Guide 19
12. Entering Information
When you start a program or select a field that allows you to enter text or numbers, a
keyboard icon will be displayed at the bottom center of the screen to indicate that the on-
screen keyboard is available for use. Tap the keyboard icon to display or hide the on-screen
keyboard.
Tap the Input Selector arrow that appears next to the keyboard icon to open a menu from
which you can select different keyboard layouts and customize text input settings. You can
choose from these keyboard layouts: Full QWERTY, Compact QWERTY, and Phone Keypad.
Input Panel
(Full QWERTY)
Input Selector arrow
Keyboard icon Text input methods
To enter text, simply tap the keys on the onscreen keyboard. Depending on the keyboard
layout selected, you may need to tap the same key more than once to select the desired
character.
For more information about using the different input methods, refer to the “Entering Text”
chapter in the User Manual PDF.

20 Quick Start Guide
13. Basic Settings
Customize your phone settings to suit your personal needs.
Ringtone
Tap Start > Settings, and then tap Sound.
Tap Ringtone, select the desired ringtone in the list, and then tap Done.
Phone profile
A profile is a preset that determines how your phone will alert you when there are
incoming phone calls. To select a profile:
Tap Start > Settings, and then tap Sound.
Under Profiles, choose one of the following: Normal, Vibrate, Silent, or Automatic.
Notes •Automatic sets your phone to vibrate only when you receive phone calls during scheduled
appointments in your Calendar.
• If you have set an alarm and you select the Vibrate or Silent profile, you will not hear the
alarm sound when the alarm goes off.
Wallpaper
You can change the background image of the Home tab.
Tap Start > Settings, and then tap Wallpaper. The Album program opens.
Tap an image to set it as the Home tab wallpaper. If the image you want to use is not
displayed, tap Albums and navigate to the folder where the image is located.
1.
2.
1.
2.
1.
2.
