HTC J ISW13HT Installation guide

Basic Manual
Getting ready
Basic operations and
character input
au 災害対策 (au Disaster
Countermeasure) app
Calling
Mail and the Internet
Tools and apps
Function settings
Appendix and index
Safety precautions

ii
Preface
Thank you for buying the HTC J ISW13HT
(simply called the 'product' from here on).
Before using the product, be sure to read
the 'Basic Manual' (this manual) to ensure
correct use. After you have finished reading
this manual, be sure to store it in a safe
place so that you can retrieve it whenever
needed. If you lose the 'Basic Manual',
contact an au shop or Customer Service
Center.
•In this manual, the term 'Instruction
Manual' is used collectively for the Basic
Manual and Setting Guide.
About operating instructions
■'Basic Manual' (this manual)
The Basic Manual handles only basic
operations for main features.
For detailed descriptions of various functions,
refer to the 'Instruction Manual' app that can
be used on your product or the 'Full Instruction
Manual (Japanese)' on the au homepage:
http://www.au.kddi.com/torisetsu/index.html
•Company names and product names referred
to in this manual are trademarks or registered
trademarks of their respective companies.
■'Instruction Manual' app
This product supports use of 'Instruction
Manual' app that can be used for detailed
information about operational procedures.
▶On the home screen, tap [ ] and then [取
扱説明書 (Instruction Manual)].

1
Safety precautions
Before you start using the product, be sure
to read the "Safety precautions" to ensure
correct use.
Before you assume that the product is
malfunctioning, check for possible remedies
in the following au Customer Support site on
the au homepage:
http://cs.kddi.com/support/komatta/kosho/index.html
When using the product
•Communication is not possible even
inside the service area in places where
the signal does not reach (e.g. tunnels
and basements). Also, communication is
sometimes not possible in poor reception
areas. Communication is sometimes
interrupted if you move into a poor
reception areas during communications.
•Since this product uses radio waves, the
possibility of communication intercepts
by third parties cannot be eliminated.
(Though the CDMA/GSM/UMTS
system has highly secure confidential
communication features.)
•This product is compatible with the
international roaming service. Each
network service described in this manual
varies depending on the area and service
content.

2
•Since this product is a radio station
under the Radio Law, you may be asked
to temporarily submit the product for
inspection in accordance with the Radio
Law.
•When the au IC-Card is inserted in your
product, the product number of the
product is automatically sent to KDDI
CORPORATION for maintenance and
monitoring operational status of your
product.
•Take care not to inconvenience people
around you when you use the product in a
public place.
•When the product is used by a child,
parents or guardians should thoroughly
read the 'Instruction Manual' and teach
the child how to use it.
■Use of the product is not
allowed in the following places!
•Do not use the product while driving a car
or riding a motorbike or bicycle. Doing so
may cause a traffic accident. Use of the
product while driving a car or motorbike
is prohibited by law. Use of the product
while riding a bicycle may be punishable
by some regulations.
•Do not use this product while you are
aboard an airplane. Use of electronic
devices transmitting radio waves in
airplanes is prohibited by law. Some
airline companies, however, allow their
passengers to use product. For details,
contact the airline company you use.

3
List of packaged items
Before you start using the product, make
sure that you have all the following items
packaged with the product.
■Main unit
ISW13HT
■Accessories
Battery pack
（HTI13UAA）
※1
Battery cover※1※2
Beats™ by Dr. Dre™ urBeats™ In-Ear
Headphones
(referred to as 'earphones' in this manual)

4
•Quick Start Guide (Japanese)
•Setting Guide (Japanese)
•Battery Cover Instruction Manual
（including warranty card）(Japanese)
•Beats™ by Dr.Dre™ urBeats™ In-Ear
Headphones Instruction Manual
（including
warranty card）(Japanese)
•Warranty card (main unit) (Japanese)
•microSD memory card (sample)※1
※1 Pre-installed before purchase.
※2 The model number depends on the color.
Battery cover Red (HTI13TRA)
Battery cover White (HTI13TWA)
Battery cover Black (HTI13TKA)
The following items are NOT included in the
package:
•AC adapter
•microUSB cable
memo
◎Purchase a specified charger (sold separately).
◎Illustrations of the product in this manual are
only for reference. They may look different from
the actual product.

5
Contents
Preface ...........................................................ii
Safety precautions ......................................... 1
When using the product................................. 1
List of packaged items ................................... 3
Contents ........................................................ 5
Safety precautions ......................................... 9
Regarding notations used in this manual ...... 10
Exemptions .................................................... 12
Safety precautions (observe strictly) ............. 13
Handling precautions .................................... 36
Available security codes................................ 48
About Bluetooth®/wireless LAN (Wi-Fi®)
functions ........................................................ 51
Notes on packet communication charge....... 56
Notes on Google Play/au Market/apps.......... 57
Getting ready ............................................... 59
Getting ready ............................................... 60
Names and functions of parts........................ 60
Opening/closing the connector cover and
stereo earphone jack cover........................... 63
Installing/removing the battery pack ............. 65
Installing/removing the au IC-Card................ 69
Installing/removing a microSD memory
card................................................................ 71
Charging........................................................ 73
Turning the power on/off................................ 77
About the sleep mode ................................... 78
Basic operations and character input .......... 79
Basic operations .......................................... 80
Using the touch panel.................................... 80
Using the home screen.................................. 82
Monitoring the product's status ..................... 90
Displaying a menu......................................... 92
Character input ............................................ 92
Inputting characters....................................... 92

6
au災害対策 (au Disaster Countermeasure) ap p... 99
Using the au災害対策
(au Disaster Countermeasure) app ........... 100
Using the 災害用伝言板
(Disaster Message Board)........................... 101
Using 緊急速報メール (Early warning mail) ... 102
Calling........................................................ 107
Making/receiving calls................................ 108
Making calls................................................. 108
Receiving calls............................................. 112
Checking your phone number..................... 112
Mail and the Internet .................................. 113
Sending and receiving mail........................ 114
Connecting to the Internet ......................... 115
Using a data communication service
(packet communication).............................. 116
Using the wireless LAN (Wi-Fi®) function..... 118
Using WiMAX............................................... 119
Browser...................................................... 120
Tools and apps .......................................... 121
Contacts..................................................... 122
Registering a contact................................... 122
Checking people entries.............................. 122
Camera ...................................................... 123
Before using the camera ............................. 123
Starting up the camera ................................ 127
Shooting photos........................................... 128
Recording videos......................................... 128
Android apps.............................................. 129
Downloading apps....................................... 129
One seg (TV) ............................................. 130
About One seg............................................. 130
About the TV antenna .................................. 132
Watching One seg....................................... 133
Exiting the One seg app.............................. 135
Osaifu-Keitai®............................................. 135
When using Osaifu-Keitai®........................... 136
Setting up Osaifu-Keitai®............................. 138
Communicating with a reader/writer............ 139

7
Function settings........................................ 141
Viewing the setting menu........................... 142
Setting the vibrate mode/silent mode ........ 144
Settings for using the product outside of Japan
145
Obtaining the PRL
(roaming area information) .......................... 147
Setting the area............................................ 147
Setting data roaming ................................... 148
Appendix and index ................................... 149
Appendix.................................................... 150
Peripheral equipment .................................. 150
Troubleshooting........................................... 151
Updating software ....................................... 158
After-sales service ....................................... 161
Main specifications...................................... 165
Specific Absorption Rate (SAR)
of cell phones .............................................. 169
FCC Notice .................................................. 172
FCC RF exposure information...................... 173
Body-worn operation ................................... 173
DECLARATION OF CONFORMITY.............. 174
Export Administration Regulations............... 177
Intellectual property rights........................... 178
Index .......................................................... 188

8

9
Regarding notations used in
this manual ..........................................10
Exemptions.......................................... 12
Safety precautions (observe strictly)... 13
Handling precautions ..........................36
Available security codes .....................48
About Bluetooth®/wireless LAN (Wi-Fi®)
functions ..............................................51
Notes on packet communication
charge .................................................56
Notes on Google Play/au Market/
apps ....................................................57
Safety precautions

10
Safety precautions
Regarding notations used
in this manual
■Button indications used in this
manual
In this manual, buttons are represented by
simplified illustrations as shown below.
■Indications used for the
operation of selecting items/
icons/buttons, etc.
Notations used for operation procedures in
this manual are as follows.
Tapping is to select a button or icon
displayed on the screen by lightly tapping it
with your finger (▶P.80).
Example Meaning
On the home
screen, tap [ ]
and then [Phone].
Input '141' and
then tap [Call].
On the home screen, tap ' '
and then 'Phone'. Next tap '1'
'4' '1', and then 'Call'.
Tap and then
tap the app you
want to start up.
Tap to display the most
recently used apps. Flick left
or right to select the app you
want to start up and then tap
the displayed app.

11
Safety precautions
※Unless specifically stated otherwise, all
operations in this manual are performed based
on portrait (vertical) screen orientation. Note
that menu items, icons, on-screen buttons, and
other elements may be different when landscape
(horizontal) screen orientation is being used.
memo
◎The explanations in this manual are based on
the initial default settings for the Red model.
Note that the fonts and shapes of the actual
buttons and screens on the product may be
different from those shown here. Also, some
elements may be omitted in this manual. Also,
illustrations of the product in this manual
may differ from the actual appearance of the
product.
◎In this manual, 'microSD™ memory card' and
'microSDHC™ memory card' are abbreviated
as 'microSD memory card' or 'microSD'.
◎This manual uses the abbreviation 'app' in
place of 'application'.
■Illustrations/screen displays
used in this manual
Screen illustrations shown in this manual
may look different from the actual screens.
In some cases, minor details or a part of a
screen may be omitted.
Icons at the top
of the screens
are omitted in
this manual.
Actual screen Example of screen
used in this manual

12
Safety precautions
Exemptions
◎The Company is not liable for any
damages arising from earthquakes,
lightning, storms, floods or other natural
disasters, as well as fires, actions by
third parties, other accidents, intentional
or mistaken misoperation by the
customer, or use under other unusual
conditions outside the responsibility of
the Company.
◎The Company is not liable for any
incidental damages (change/
disappearance of recorded content,
loss of business income, disruption of
business, etc.) arising from use of or
inability to use the product.
◎The Company is not liable for any
damages arising from failure to observe
the described content of the 'Instruction
Manual'.
◎The Company is not liable for any
damages arising, for example, from
malfunction caused by combination
with connected devices or software not
related to the Company.
◎Captured image data or downloaded
data may sometimes be altered or lost
due to faults, repair or other handling of
the product. The Company is not liable
for any damage or lost income resulting
from recovery of these data.

13
Safety precautions
◎It is recommended you keep a copy
of important data in your PC's hard
disk, etc. Whatever the cause of fault
or malfunction may be, the Company
assumes no responsibility for alteration or
loss of saved information.
◎The Company does not provide any type
of data restoration or recovery services
for data that is lost or corrupted through
the use of this phone.
※'The Company' as appears on the product refers
to the following companies:
Sold by: KDDI CORPORATION, Okinawa Cellular
Telephone Company
Manufactured by: HTC Corporation
■Information
◎Reproduction of the content of this manual in
part or in whole is prohibited.
◎The content of this manual is subject to
change without notice.
◎Every effort has been made in the preparation
of this manual. Should you notice any unclear
points, omissions, etc., feel free to contact us.
◎Wrong page order or missing pages will be
replaced.
Safety precautions
(observe strictly)
■Before using this product, thoroughly read
these safety precautions for proper use.
After reading, store the precautions in a
safe place.
●These "Safety precautions" describe
instructions that should be observed to
prevent damage to property or injury to
the customer or others using the product.

14
Safety precautions
●These instructions are divided into the
following categories.
■Explanation of indications used
in this manual
This symbol indicates the
potential and imminent
danger of death or serious
injury (※1) to a person.
This symbol indicates
the possibility of death
or serious injury (※1) to a
person.
This symbol indicates the
possibility of personal injury
(※2) to a person or physical
damage (※3).
※1 Serious injury: This refers to loss of sight,
injury, burns (high- and low-temperature),
electric shock, broken bones, injuries with
residual aftereffects from poisoning, etc.,
and injuries requiring hospital admission for
treatment or longterm hospital attendance as
an outpatient.
※2 Injury: This refers to injuries, burns (high- and
low-temperature), electric shock, etc. that do
not require hospital admission for treatment
or long-term hospital attendance as an
outpatient.
※3 Physical damage: This refers to extended
damage to buildings, furniture, livestock, or
pets.

15
Safety precautions
■Explanation of graphic symbols
used in this manual
Prohibited
Indicates an action that is not
allowed.
Wet hands
prohibited
Indicates that handling with wet
hands is not allowed.
Disassembly
prohibited
Indicates that disassembly is not
allowed.
Wetting with
water prohibited
Indicates that use in a place
where the product is likely to get
wet or allowing the product to get
wet is not allowed.
Instruction
Indicates an action that must be
done.
Disconnect plug
from power outlet
Indicates that the power plug
must be disconnected from the
power outlet.
■Precautions common to the
main unit, battery pack, battery
cover, charging equipment, au
IC-Card, peripheral devices
Be sure to read the
following before use.
Instruction
Be sure to use only the specified
peripheral devices. Use of other
peripheral devices might cause
overheating, fire, rupture, fault, or leakage
of liquid.

16
Safety precautions
Prohibited
Do not use, store or leave the product in
hot places (e.g. by the fire, near a heater,
under a kotatsu, in direct sunlight, in a
car in the hot sun). Doing so might cause
ignition, rupture, fault, fire or injury.
Instruction
Before entering an area where flammable
gas is generated such as a gas station,
be sure to turn off the product. Do not
charge the battery. Failure to observe
these precautions might cause the gas to
catch fire. In addition, when using Osaifu-
Keitai®at a gas station, be sure to turn
off the power in advance. (If Osaifu-Keitai
lock has been set, cancel the lock before
turning off the power.)
Prohibited
Do not put the product in a cooking
apparatus such as microwave oven or a
pressure vessel. Doing so might cause
ignition, rupture, fault, fire or injury.
Prohibited
Do not throw the product into a fire or
heat it. Doing so might cause ignition,
rupture or fire.
Prohibited
Do not short-circuit the connection
terminals. Do not allow conductive foreign
objects (metal fragments, pencil leads,
etc.) to come into contact with or get
inside the connection terminals. Doing so
might cause fire or a fault.
Prohibited
When using a metal accessory, make
sure the metal parts do not come in
contact with the connection terminals
or power outlet. Doing so might cause
electric shock, fire, injury or a fault.
Prohibited
Do not expose the camera lens to direct
sunlight for an extended period. Doing so
might cause ignition, rupture or fire by the
light-collecting mechanism of the lens.

17
Safety precautions
Disassembly
prohibited
The customer is not allowed to
disassemble, modify or repair the
product. Doing so might cause a
fault, fire, electric shock, or injury. The
Company is not liable even in the event
of any nonconformities arising on the
product or peripheral devices as a result
of modification, etc. Modification of the
product is in violation of the Radio Law.
Be sure to read the following
warnings before use.
Prohibited
Do not drop the product or subject it
to strong impact, such as by throwing
it. Doing so might cause rupture,
overheating, fire, or a fault.
Prohibited
Do not use outside when you can hear
thunder. Doing so may result in lightning
strikes and electric shock.
Prohibited
Do not let your hands, fingers or other
parts of your body touch the connection
terminals. Doing so might cause electric
shock, injury or a fault.
Prohibited
If the product is damaged because it is
dropped or something, and its display is
cracked or internal parts are exposed,
do not touch the cracked display or
exposed parts with your hands. Doing so
might cause electric shock or injury from
damaged parts. Contact an au shop or
Secure cell phone support center.

18
Safety precautions
Wetting with
water prohibited
Wet hands
prohibited
Do not splash the product with water or
other liquids. Also, never use it in places
subject to direct splashing with water or
pet urine, etc. or in humid places such
as bath areas, or use with wet hands.
Doing so might cause electric shock or
fault from short-circuiting or corrosion
of electronic circuits. In the event that
the product is splashed with liquid,
immediately disconnect the AC adapter's
power plug. Faults caused by water or
humidity are not covered by the warranty
and charges will be incurred for repair.
Prohibited
When removing the battery cover, do not
exert more than necessary force. The
battery pack might jump out, for example,
and cause injury or a fault.
Prohibited
Do not operate the product while driving
an automobile or motorized bicycle,
riding a bicycle or walking. Doing so may
compromise traffic safety and cause an
accident.
Prohibited
If charging is not complete after the
specified charging time, stop charging.
Failure to do so might cause leakage of
liquid, overheating, rupture or fire.
Prohibited
Do not leave in places within the reach
of small children. Small children might
swallow small parts, etc. by mistake and
choke on them, or might drop them by
mistake and cause accidents or injury.
