HTC Athena User manual

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 1 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
Athena
Service Manual
UHTC Proprietary
Confidential Treatment Requested
Rev. A02
2007/02/15
HTC Corp.
Engineering Mobility

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 2 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
Revision Control Table
Rev Date Contents Dept Revised Stage
A01 2007/2/6 First release PSE Justin _ Lai DVT
A02 2007/2/12
1. Modify L2.5 Audio jack
from 36H00446-00M to
36H00218-11M.
2. Revise Labeling plan.
3. Revise generic spare part
list.
4. Revise disassembly SOP
and caution.
5. Add power detect
program.
PSE Justin _ Lai MV

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 3 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
Table of Contents
CHAPTER 1–INTRODUCTION
1.1 Product Feature
1.2 Product overview
1.3 Using the Hardware Keyboard
CHAPTER 2–COSMETIC INSPECTION CRITERIA
2.1 Classes definition of inspective area
2.2 Display inspection
2.3 Main unit inspection
CHAPTER 3–DEVICE ASSEMBLING AND DISASSEMBLING PROCEDURE
3.1 Assembling procedure
3.2 Disassembling procedure
CHAPTER 4–DIAGNOSTICS PROGRAM AND WINCE TEST ITEM
4.1 Test Plan
4.2 Diagnostics Test Procedure
4.3 WinCE Test procedures
CHAPTER 5–LEAKAGE CURRENT MEASUREMENT
CHAPTER 6–OS RE-FLASH PROCEDURE
6.1 OS upgrade thru RUU
6.2 OS upgrade thru SD card
CHAPTER 7–GENERIC SPARE PART LIST AND PHOTOS
CHAPTER 8–GENERIC LABELING PLAN
CHAPTER 9–RFANTENNA TEST SPECIFICATION AND TEST EQUIPMENT P/N
CHAPTER 10 –BOARD LEVEL 2.5 REPAIRS
CHAPTER 11 –GENERIC TROUBLESHOOTING
CHAPTER 12 –BATTERY RUNDOWN TEST PROCEDURE

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 4 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
1.INTRODUCTION
This manual provides the technical information to support the service activities of Athena.
This document contains highly confidential information, so any or all of this document should not be revealed to
any third party.
1.1 Product Features
Platform
¾Mobile Power Pad with detachable & thin QWERTY keyboard
¾Microsoft Windows Mobile Pocket PC Phone Edition
Dimension
¾133.5 x 98 x 16 mm (additional 4mm for KB)
¾Less than 359g with battery and KB
Processor/Chipset
¾Qualcomm MSM 6275
¾Intel Bulverde 624 MHz
¾ATi Graphic Chip 2284
Memory
¾ROM: 256 MB
¾RAM: 128 MB SDRAM
¾HDD: 8GB with G sensor
LCD Module
¾5” 480x640 VGA resolution
¾65K-color TFT LCD with LED backlight
¾Sensitive Touch Screen
UMTS/HSDPA/GSM/EDGE Function
¾Internal antenna
¾HSDPA/UMTS Tri-mode (2100MHz for Europe and 850/1900MHz for USA) and GSM/GPRS/EDGE quad band
(850/900/1800/1900)
¾HSDPA/UMTS
¾850: 824-849, 869-894MHz
¾1900: 1850-1910MHz, 1930-1990MHz
¾2100: 1920-1980MHz, 2110-2170MHz

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 5 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
¾GSM / GPRS/EDGE
¾850: 824-849, 869-894MHz
¾900: 880-915, 925-960MHz
¾1800: 1710-1785, 1805-1880MHz
¾1900: 1850-1910, 1930-1990MHz
¾HSDPA / UMTS
¾UMTS: 3GPP Release 99 compliant
¾HSDPA: 3GPP Release 5 compliant
¾UE category 12, QPSK, 1.8Mbps peak rate
¾DL up to 1.8Mbps and UL up to 384Kbps
¾PS RAB on HSDPA channel and CS data call (VT call) simultaneously will be supported
¾Global roaming
¾Auto band switching
¾Handover and cell selection between GSM/EDGE and UMTS
¾Generic Services
¾Call Holding, Waiting, Forwarding
¾Call Barring
¾CLI (Calling Line Identity)
¾SMS (Short Message Service)
¾SMSMT, SMSMO, SM Reply, SM Replace, SM Acknowledgement, 8 Bits SMS Data
¾Concatenated messages, up to 640 characters
¾Display own number, telephone number storage capability in terminal and SIM card
¾Network selection
¾Cell broadcast
¾Multi-party conference capability
¾Phase 2 Unstructured Supplementary Service Data
¾Audio Codec: AMR/EFR/FR/HR
¾Network Lock
¾CPHS (Partial Compliance)
¾E-GPRS Function
¾EGPRS class B
¾Multi-slot standard class 10
¾MO/MT SMS over GPRS
¾PBCCH

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 6 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
¾USIM/SIM
¾1.8 / 3V of UICC
¾Mega SIM
¾USIM Application at least according to 3GPP TS 31.102
¾SIM Application Tool Kit release 96, 98 class 3 and 99 partial
¾Over the Air (OTA) programming
¾Abbreviation Dial Number (ADN)
¾Security Pin 1 & 2 control
Standalone GPS
¾Internal GPS antenna for UMTS & EDGE
¾Support NMEA 0183 version 3.0 or above
¾20 parallel channel GPS receiver
¾Acquisition time
¾Hot start: 8 seconds, typical TTFF
¾Warm start: 35 seconds, typical TTFF
¾Cold start: 45 seconds, typical TTFF
¾Update rate: user configurable once/1sec, once/10sec and once/30sec continuous
¾GPS Accuracy
¾Position: < 15 meters, 95% typical
¾Velocity: 0.05 meter/sec steady state
Digital Camera
¾Main Camera: 3 Mega pixel with Auto Focus
¾2
nd camera: Color CMOS VGA camera
¾High Power LED for camera flash
Keyboard/Button/Switch
¾POWER button (Side)
¾Short Press: Power On/Off
¾Long Press: Turn off system power totally
¾Comm. Manager / Voice Recorder
¾Camera capture button (Side)
¾Two step camera button for 3M pixel AF
¾Volume Up / Down control (Side)
¾5-way Navigation button (Left front in landscape)– key orientation shall be adjusted after view changed
¾Start button

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 7 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
¾OK Key
¾Portal Key / G control Key
¾Short Press: Launch IE
¾Short Press in PIE: Activate / Deactivate motion control
¾Built-in 48 keys QWERTY Keyboard (including two soft keys, one start button, one OK button, one send call key, one
end call key, and alphanumeric and symbol keys)
¾RESET switch (Back)
Notification
¾1
st lens - one-color (amber) LED for new message and notification
¾2
nd lens - bi-color (green and blue) LED for WiFi and bluetooth notification
¾3
rd lens –bi-color (green and red) LED for 3G & 2G network status & GPS indicator
¾4
th lens – bi-color (green and red) LED for charging status & low power indicator
¾Notification by Sound, and Message on the display
Audio
¾Built-in Microphone
¾Dual speakers with 3D surround sound
¾Loud speaker for Hands-Free supported
¾Audio sampling rate
¾16-bits with 8KHz, 11KHz, 22KHz, 44.1KHz
¾AMR/AAC/WAV/WMA/MP3 codec
Connectivity & Interface
¾Bluetooth
¾Compliant with v2.0 without EDR
¾Class 2 transmit power
¾Supported profiles:
¾GAP (generic access profile)
¾SPP (serial port profile)
¾OPP (object push profile)
¾DUN (dial-up networking profile)
¾GOEP (generic object exchange profile)
¾ActiveSync (legacy application via SPP)
¾HSP (headset profile)
¾HFP (handsfree profile)
¾A2DP (Advanced Audio Distribution profile)

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 8 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
¾AVRCP (Audio/Video Remote control Profile)
¾Service Discovery Application Profile
¾SIM Access Profile
¾HID (Human interface device profile)
¾FTP
¾Co-exist with WiFi
¾WiFi (manufacture option)
¾IEEE 802.11b/g compliant
¾Internal WLAN antenna
¾Data rate auto fallback for extended range
¾ELP mode
¾Security 802.11i and AES
¾WPA authentication – WEP, WPA, PSK, EAPTLS, PEAP, LEAP,
¾Signaling interfaces between the terminal device and the servers: mutually authenticated and encrypted
utilizing TLS (RFC 2246) with RC4 encryption with SGA1 used as the message integrity check
¾QoS
¾802.11 WME QoS
¾802.11e
¾HTC ExtUSB (11-pin mini-USB / audio jack in one)
¾USB 2.0 client
¾USB charging
¾mini SD card slot with hotswap feature
¾External Antenna (UMTS/GSM/CDMA) Connector
¾External GPS Antenna Connector
¾1.8 / 3 V USIM/SIM card slot
¾HTC Proprietary 16 Pin Port
¾USB 1.1 host (Support USB low power)
¾Thumb Memory
¾Card Reader
¾Keyboard
¾Mouse
¾VGA Out – VGA
¾TV Out – Composite & S-Video (4 pin)
¾3.5 Ø stereo audio jack with mic

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 9 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
Power
¾Battery
¾Removable and chargeable Lithium ion polymer battery, 2100mAh
¾Charging time: less than 4 hours
¾RTC: 5 min (min.) supported by golden capacitor
¾Battery life
¾Playing WMV: 8 hours
¾Playing WMA: 12 hours
¾Talk time: 330~360 minutes for GSM
¾Talk time: 180~300 minutes for UMTS
¾Video Talk time: >120 min
¾Standby time: 300+ hours for GSM
¾Standby time: 300 hours for UMTS
¾Talk time with GPS tracking mode (Backlight is in Max. level): 2.6 hour with 10dBm transmit power at WCDMA
band
¾WLAN time: 2.8 hours (Backlight level is 3)
¾AC adaptor
¾AC input: 100~240Vac, 50/60Hz
¾AC input current: 0.2Aac (max)
¾Output voltage: 5Vdc (typical)
¾Output current: 1A (typical)
Stylus
¾Lock Type in the main unit
Accessories
¾Travel Charger w/ mini-USB power plug
¾Attachable Keyboard and Screen Cover Carrying Case
¾Mini USB Cable (mini-USB/USB)
¾Battery (rechargeable and replaceable)
¾Stereo wired headset with microphone (button for voice command) for 3.5 Ø
¾User manual, Quick start guide, & Sync. software CD
¾HTC Proprietary 16 pin cable (one to many ports) [ optional ]
¾USB Standard A female port
¾VGA (15pin) port
¾Composite Video Out

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 10 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
¾S-Video (4 pin) Out
¾Cradle [optional]
¾VGA (15pin) port
¾Video Out port
¾S-Video (4 pin) port
¾3.5 Ø Audio jack (for External Speakers & Headset)
¾One miniUSB port for power charging
¾One miniUSB port for synchronization
¾2 x USB Standard A female port (USB Host)
¾2
nd Battery charging slot
¾3 LEDs Indicators – 2nd Battery, Power & Sync
¾Mono Bluetooth headset with microphone [optional]
¾Stereo bluetooth headset with microphone [optional]
¾Car Charger [optional]
¾Car Holder [optional]
¾Car Kit with car stereo mute function [optional]
¾TTY adaptor for USA market [optional]
¾External GPS antenna Cable [optional]
¾Keyboard (KB connector) [optional]
¾16pin to D-Sub/VGA cable [ optional ]
¾Bluetooth Keyboard [optional]
¾Traveling bag [optional]
¾Travel charger holder
¾Device with pouch holder
¾Bluetooth headset holder
¾Sync cable holder
¾4 port video cable holder
¾Business card holder
¾SD card holder
¾Stylus
¾Pen
Windows Mobile PPC Phone Edition 2005 Applications
¾Pocket Outlook
¾Calendar, Contacts, Messaging, Tasks, & Voice Notes

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 11 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
¾Push Mail
¾Internet Explorer Mobile
¾Office Mobile
¾Word, Excel, & PowerPoint Mobile
¾Windows Media Player 10 Mobile
¾Pictures & Videos
ActiveSync Client
¾Pocket MSN
¾Device Management
¾OTA Provisioning
¾Internet Sharing
¾Terminal Service Client
¾Calculator
¾Games
Value Added Applications
¾Camera / Camcorder
¾Camera Mode
¾Encoding format: JPEG
¾Resolution: QXGA 2048x1536, UXGA 1600x1200, SXGA 1280x960, VGA 640x480, QVGA 320x240, QQVGA
160x120
¾Night Mode
¾Digital Zooming: max. 8X
¾Camcorder Mode
¾15 fps encoding for CIF resolution
¾Encoding format
¾H.263 + AMR-NB/WB
¾MPEG4 + AMR-NB/WB
¾Ringtone
¾MIDI
¾40 polyphonic & Standard MIDI format 0 and 1 (SMF) / SP MIDI
¾MP3, AAC, AAC+, WMA, WAV and AMR-NB/WB
¾DirectShow Filters for WMP - Audio
¾Audio Playback format: AAC, AAC+, MP3, WMA, WAV, AMR-NB/WB
¾DirectShow Filters for WMP - Video

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 12 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
¾Video Playback format: H.263, MPEG4, & WMV
¾5~8 fps @ VGA decoding for H.263 & MPEG4
¾Min. 30 fps @ QVGA decoding for H.263 & MPEG4
¾Combined Bit Rate: 64Kbps (playback)
¾Video scaling up to full VGA display
¾Picture Enhancement for Pictures & Videos
¾Graphics: JPEG, GIF87a, GIF89a, PNG, WBMP
¾Video Thumbnail Preview: H.263, MPEG4, & Motion JPEG (AVI)
¾3G-324M Video Telephony
¾ZIP
¾Smart Dialing
¾Support of QWERTY Keyboard Input
¾Sub-display UI when keyboard is attached to LCD
¾VGA / TV Out Setting
¾MMS Client
¾Partial Compliant to MMS 1.2
¾Java virtual machine
¾JSR 75 File Access
¾JSR 118 MIDP 2.0
¾JSR 135 Mobile Media API 1.1
¾JSR 139 CLDC 1.1
¾JSR 185 JTWI 1.0
¾Voice Dial & Command
¾Speaker Dependent or Independent
¾Support on both wired and bluetooth headset
¾Document Viewer - PDF
¾DRM Engine: For all types of files (Pictures, audio, application etc.), and also all types of delivery method
(MMS, email etc.)
¾OMA 1.0 / 2.0 when available
¾Multi-DRM support : Microsoft DRM & OMA DRM
¾SIM Manager
¾Comm. Manager
¾STK
¾TTY for US Market

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 13 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
¾GPS Navigation SW
¾Quick GPS
¾Backup Tool
¾VueFLO (Motion control of G-Sensor)
¾Symbol Pad
¾Voice Recorder
¾Task Manager
¾HDD Format Tool
¾Audio Manager
¾Opera Browser
¾Support HTC VueFLO

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 14 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
1.2 Product overview
¾Front side
# Item Function
1 Navigation
Control/CENTER OK
button
Press this multi-directional control up, down, left, or right to move through
menus and program instructions; carry out the selection by pressing the
CENTER OK button.
2 Notification LED 1 This LED shows battery charging status.
3 Touch Screen Tap the screen with the stylus to write, draw, or make a selection.
4 Notification LED 2 This LED shows the GSM/UMTS standby/ network status (Green). and GPS
indicator (amber)
5 Notification LED 3
This LED shows the following:
¡¤ A flashing Blue light for Bluetooth system notification of powered-up and
ready to transmit radio fre quency signal.
¡¤ A flashing Green light for Wi-Fi status.

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 15 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
¡¤ When both Bluetooth and Wi-Fi are enabled, their lights flash alternately.
6 Notification LED 4 This LED shows messages and notifications.
7 Second Camera Use this camera for video call conversations or to take self landscape
photos.
8 OK Button Press to confirm your data entries, or to exit the program in use.
9 START Button Press to open the Start menu.
10 INTERNET EXPLORER
MOBILE/VueFLO Button Press to launch Internet Explorer Mobile. Press this button to activate
VueFLO when browsing the Web.
11 Battery Compartment Open this compartment to insert the SIM/USIM card, miniSD ™ card and
battery.
12 Keyboard Copper
Connector Attach the copper part of the keyboard tothis to be able to use the keyboard.

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 16 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
¾Back side
# Item Function
14 Stylus Use the stylus to write, draw, or select items on the touch screen.
15 CAMERA Button Press to launch the Camera; press again to take a photo or video clip,
depending on the specified capture mode.
16 Speaker Listen to audio files and voice calls here.
17 COMM MANAGER/VOICE
RECORDER button Press to open Comm Manager. Press and hold to open the Voice Notes
program.
18 POWER Button
¡¤ Press to turn off the display temporarily. This switches your device to
Sleep mode. You can still receive calls and messages when your device is in
Sleep mode.
¡¤ Press and hold (for about 5 seconds) to turn off the power completely. All
functions including the phone will be unavailable for use.

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 17 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
19 Volume Slider ¡¤ Slide up or down to adjust the speaker volume.
¡¤ During a call, slide up or down to adjust the earpiece volume.
20 VGA Out/USB port Use this connection to output the contents on the screen to an external device using the provided VGA out cable. This also acts as a USB 1.1 host to
connect USB peripherals.
21 HTC ExtUSB ™ port
Use this connector to synchronize data by connecting the provided USB
Sync cable or to recharge the b attery via the provided AC adapter. You can
also connect the provided USB stereo headset for hands-free conversation
or for listening to audio media.
22 3.5 mm Earphone Jack Lets you listen to audio media, use a hand-free kit or plug in a microphone.
23 Car Antenna Connector Connect your device to the car antenna while in a car to have better
reception quality.
24 RESET Button With the stylus, press the RESET button to soft-reset your device.
25 Camera Use the camera to take still photos and record video clips.
26 Flash Light When turned on, it illuminates your subject and allows you to capture clear photos or video even in a dark environmen t. It also flashes when a photo is
taken.
27 GPS Antenna Connector If you need better GPS signal reception, you can connect an external GPS
antenna.
28 QWERTY keyboard This is similar to a standard PC keyboard. Connect to the device to use the
keyboard. This also acts as a protective cover for the device screen.

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 18 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
¾Accessories
# Item Function
1 AC adapter Recharges the battery.
2 USB Sync cable Connects to a PC and synchronises data.
3 Stereo headset Provides a volume control slider and a Send/End button. Press the
Send/End button to pick up a call or put a call on hold; press and hold the
button to end the call.
4 VGA Out cable Connects to an external viewing device' s input cable. You can output the
contents on the device's screen to an external viewing device.
5 Carrying Case Acts as a protective carrying case.
6 Combo Stylus This Stylus doubles as a writing pen. Simply click the top of the stylus to
switch between the two functions.
7 Extra Stylus Use to tap items onscreen.

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 19 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
¾Install the USIM/SIM card
1. Make sure your device is turned off.
2. Open the Battery compartment at the bottom of the device.
3. Flip open the USIM/SIM card slot cover.
4. Insert the USIM/SIM card into the card holderwith its gold contacts facing up and then close the cov er. (The cut-off
corner of the USIM/SIM card should match the cut-off corner in the USIM/SIM card slot.)
5. Close the battery compartment.
¾Install the miniSD card
1. Make sure your device is turned off.
2. Open the battery compartment at the bottom of the device.
3. Insert the miniSD card into the card holder with its gold contacts facing up and close the battery co mpartment. To
remove the miniSD card, press it to pop it out of the slot.
¾To remove the battery
If you need to replace the battery, follow the procedure below to remove the battery from the device.
1. Make sure your device is turned off.
2. Open the Battery compartment at the bottom of the device.
3. Pull up the silver-coloured lock on the battery.
4. Draw out the battery from its slot.

Doc. No. DOC-00026040 REV.
Issued Date 2007/2/15
. Revised Date A02
Doc. Title Athena Service Manual Page 20 of 102
HTC CONFIDENTIAL
宏達國際電子股份有限公司
High Tech Computer, Corp.
¾To perform a soft reset
Use the stylus to press the RESET button found on the back of the device. Your device restarts and displays the
Today screen.
¾To perform a hard reset
Warning! Your device will be set back to factory default settings. Please ensure any additional installed programs
and/or user data have been backed up before a hard re set is performed.
1. Slide the Volume slider down and at the same time, use the stylus to press the RESET button at the back of your
device.
2. After a brief period of time, two choices will appear on-screen. Press the CENTER OK button to perform the hard
reset.
Note If you do not want to perform a hard reset, press the CAMERA button to exit.
3. Press the POWER button.
