About This Document
Purpose
A battery circuit breaker (BCB) box controls the connection and disconnection between
battery strings and a UPS and protects batteries. This document describes the BCB box in
terms of its structure, installation, troubleshooting, and technical specifications.
Intended Audience
This document is intended for:
Sales engineer
Technical support engineer
System engineer
Hardware installation engineer
Commissioning engineer
Data configuration engineer
Maintenance engineer
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.

PDU8000-(0125, 0250, 0400, 0630, 0800)
DCV8-BXA001 Battery Circuit Breaker Box
User Manual
About This Document
Issue 03 (2019-05-20)
Copyright © Huawei Technologies Co., Ltd.
iii
Symbol
Description
NOTICE is used to address practices not related to
personal injury.
Calls attention to important information, best practices
and tips.
NOTE is used to address information not related to
personal injury, equipment damage, and environment
deterioration.
Change History
Changes between document issues are cumulative. The latest document issue contains all the
changes made in earlier issues.
Issue 03 (2019-05-20)
Adjusted the document structure.
Added description about a new BIB board.
Issue 02 (2018-07-13)
Deleted the section "Jumper Cap Settings."
Issue 01 (2013-12-26)
This is the first release.

PDU8000-(0125, 0250, 0400, 0630, 0800)
DCV8-BXA001 Battery Circuit Breaker Box
User Manual
Contents
Issue 03 (2019-05-20)
Copyright © Huawei Technologies Co., Ltd.
iv
Contents
About This Document.................................................................................................................... ii
1 Safety Precautions.........................................................................................................................1
2 Overview.........................................................................................................................................3
2.1 Exterior.........................................................................................................................................................................3
2.2 Structure........................................................................................................................................................................5
2.2.1 Interior .......................................................................................................................................................................5
2.2.2 BIB Board................................................................................................................................................................10
3 Installation....................................................................................................................................12
3.1 Unpacking and Checking............................................................................................................................................12
3.2 Installation Preparations .............................................................................................................................................12
3.2.1 Tools ........................................................................................................................................................................12
3.2.2 Environment ............................................................................................................................................................13
3.2.3 Cables ......................................................................................................................................................................14
3.2.4 Cable Connection Precautions.................................................................................................................................17
3.3 Mechanical Installation...............................................................................................................................................18
3.4 Connecting Cables......................................................................................................................................................23
3.4.1 Installing a PE Cable................................................................................................................................................23
3.4.2 Installing a Power Cable..........................................................................................................................................24
3.4.3 Installing a Signal Cable..........................................................................................................................................28
4 Setting Parameters ......................................................................................................................37
5 Troubleshooting..........................................................................................................................40
6 Replacing the Old BIB Board with the New BIB Board......................................................41
7 Technical Specifications ............................................................................................................44
A Acronyms and Abbreviations..................................................................................................46

PDU8000-(0125, 0250, 0400, 0630, 0800)
DCV8-BXA001 Battery Circuit Breaker Box
User Manual
1 Safety Precautions
Issue 03 (2019-05-20)
Copyright © Huawei Technologies Co., Ltd.
1
1 Safety Precautions
Only qualified and trained personnel are allowed to operate and maintain the BCB box.
To ensure human safety and normal BCB box operation, ground the BCB box before use.
The ground cable must be capable of bearing fault currents.
Components under the isolation board inside the BCB box are not operable. Do not open
the cover. Otherwise, electric shocks may occur, and the resulting faults are beyond the
warranty scope.
During battery installation, ensure that the positive, neutral, and negative copper bars are
not short circuited. Short circuits can cause a fire and result in personal injury.
Before operating batteries, carefully read the safety precautions for battery handling and
connection.
The BCB box may cause electric shocks and high short-circuit currents. Therefore, before
operating the BCB box, get tools insulated, and take off metal articles such as watches and
rings.
In case of fire, use a dry power fire extinguisher to put out the fire. Using a fluid fire
extinguisher may cause electric shocks.
Do not install a switch and other disconnection devices on the ground cable.
Correctly set the dual in-line package (DIP) switch on the control board; otherwise, the
BCB box cannot work properly.
Correctly connect the signal cables on the control board; otherwise, the BCB box cannot
work properly.

PDU8000-(0125, 0250, 0400, 0630, 0800)
DCV8-BXA001 Battery Circuit Breaker Box
User Manual
1 Safety Precautions
Issue 03 (2019-05-20)
Copyright © Huawei Technologies Co., Ltd.
2
The operating and storage environments affect the BCB box service life and reliability.
Therefore, the environments must meet the requirements specified in this document.
Install the BCB box in compliance with the local laws and regulations.
Reserve sufficient space in front of the BCB box to facilitate maintenance.
Prevent liquid or other foreign matter from entering the BCB box. Do not place containers
with liquid near the BCB box.
Perform electrical connection to a specified torque.
To avoid damages, move the BCB box gently.

PDU8000-(0125, 0250, 0400, 0630, 0800)
DCV8-BXA001 Battery Circuit Breaker Box
User Manual
2 Overview
Issue 03 (2019-05-20)
Copyright © Huawei Technologies Co., Ltd.
3
2 Overview
2.1 Exterior
A BCB box controls the connection and disconnection between a single battery string and a
UPS and protects batteries. It has the following models:
PDU8000-0125DCV8-BXA001
PDU8000-0250DCV8-BXA001
PDU8000-0400DCV8-BXA001
PDU8000-0630DCV8-BXA001
PDU8000-0800DCV8-BXA001
The five models of BCB boxes have the similar appearance. The following uses
PDU8000-0250DCV8-BXA001 as an example.

PDU8000-(0125, 0250, 0400, 0630, 0800)
DCV8-BXA001 Battery Circuit Breaker Box
User Manual
2 Overview
Issue 03 (2019-05-20)
Copyright © Huawei Technologies Co., Ltd.
4
Figure 2-1 PDU8000-0250DCV8-BXA001
(1) Silk screen
(2) Lock
(3) Handle
(4) Signal cable outlet
(5) Power cable outlet
Signal cable and power cable inlets are located at the bottom of the BCB box.

PDU8000-(0125, 0250, 0400, 0630, 0800)
DCV8-BXA001 Battery Circuit Breaker Box
User Manual
2 Overview
Issue 03 (2019-05-20)
Copyright © Huawei Technologies Co., Ltd.
5
2.2 Structure
2.2.1 Interior
Figure 2-2 PDU8000-0125DCV8-BXA001 interior
(1) Positive wiring terminals
(connecting to batteries)
(2) Neutral wiring terminals
(connecting to batteries)
(3) Negative wiring
terminals (connecting to
batteries)
(4) Ground terminals
(5) BIB control board
(6) Circuit breaker
(7) Negative wiring terminals
(connecting to the UPS)
(8) Neutral wiring terminals
(connecting to the UPS)
(9) Positive wiring
terminals (connecting to
the UPS)
