Huawei VPT300 Operating and safety instructions

VPT300 Intelligent Camera
V500R003C10
Product Overview
Issue 02
Date 2017-04-10
HUAWEI TECHNOLOGIES CO., LTD.

Copyright © Huawei Technologies Co., Ltd. 2017. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written
consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and the
customer. All or part of the products, services and features described in this document may not be within the
purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,
and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://e.huawei.com
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
i

About This Document
Purpose
This document describes the positioning, features, application scenarios, and technical
specifications of the VPT300, an intelligent camera developed by Huawei.
Intended Audience
This document is intended for:
lEnd users
lHuawei agents
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Conventions
Symbol Description
Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to
personal injury.
VPT300 Intelligent Camera
Product Overview About This Document
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii

Symbol Description
Calls attention to important information, best practices
and tips.
NOTE is used to address information not related to
personal injury, equipment damage, and environment
deterioration.
Change History
Changes between document issues are cumulative. The latest document issue contains all the
changes made in earlier issues.
Issue 02 (2017-04-10)
This issue is the second official release.
Issue 01 (2017-01-05)
This issue is the first official release.
VPT300 Intelligent Camera
Product Overview About This Document
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii

Contents
About This Document.....................................................................................................................ii
1 Product Positioning.......................................................................................................................1
2 Product Highlights........................................................................................................................ 2
3 Application Scenarios...................................................................................................................3
4 Product Structure........................................................................................................................... 6
4.1 Appearance..................................................................................................................................................................... 6
4.2 Front Panel and Rear Panel............................................................................................................................................ 6
5 Features............................................................................................................................................9
5.1 Automatic Tracking........................................................................................................................................................ 9
5.2 Manual Tracking.............................................................................................................................................................9
5.3 AutoFrame...................................................................................................................................................................... 9
5.4 PiP Display................................................................................................................................................................... 10
5.5 Transmission of Infrared Signals..................................................................................................................................10
5.6 Sleep and Wake-up....................................................................................................................................................... 10
5.7 Security.........................................................................................................................................................................10
6 Operation and Maintenance......................................................................................................12
6.1 Maintenance Using the Web Interface..........................................................................................................................12
6.2 Remote Maintenance Using Command Lines.............................................................................................................. 12
6.3 Log Management..........................................................................................................................................................12
6.4 VPT300 and VPC600 Upgrade.................................................................................................................................... 13
6.5 Restoration to Factory Settings or Original Version.....................................................................................................13
7 Technical Specifications.............................................................................................................14
7.1 Physical Specifications................................................................................................................................................. 14
7.2 Ports and Protocols....................................................................................................................................................... 15
7.3 Standards Compliance.................................................................................................................................................. 16
A Glossary........................................................................................................................................17
VPT300 Intelligent Camera
Product Overview Contents
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iv

1 Product Positioning
The VPT300 is designed for conference rooms in enterprises and educational institutions.
Each VPT300 integrates two face detection cameras (a dual-camera system) and 16
microphones (a microphone array) to deliver optimal conferencing experience.
The microphone array detects sound and locates the sound source using a function known as
sound localization. The dual-camera system performs face tracking based on the captured
video images. Generally, the VPT300 supports speaker tracking with accurate localization and
fast focus, enabling a face-to-face communication experience.
VPT300 Intelligent Camera
Product Overview 1 Product Positioning
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1

2 Product Highlights
The VPT300 provides optimal video layouts with features such as fast localization and
speaker close-up, delivering an immersive conference experience.
Dual-Camera System, Implementing Fast Localization
The dual camera system:
lSupports 84-degree wide angle
lShoots video images for face detection.
lAutomatically detects two participants who are having a conversation and displays their
video images separately in two panes.
lTakes close-up video images of objects within the detection range and calculates their
depth of field (DoF) for fast localization.
lUses a facial recognition algorithm to provide accurate positioning and flexible tracking.
AutoFrame, Providing Optimal Video Layouts
lThe VPT300 automatically adapts to conference scenarios to present best-quality video
images.
lBased on the number, location, and motion of participants, the VPT300 can be
automatically adjusted to provide a dynamic overview of the entire conference room.
Panoramic and Close-up Video Images Displayed in PiP Mode
The panoramic view and close-up video images can be displayed in Picture in Picture (PiP)
mode. That is, the panoramic view is displayed in full-screen mode and the close-up video
images in the small window. This allows you not to miss any details and helps improve
communication efficiency.
SDI Port, Addressing Long-Distance Transmission of Video Images
The SDI port transmits video images taken by the VPT300 to an endpoint that is up to 60 m
away without any distortions. Compared with the analog port, the SDI port does not have any
attenuation when transmitting RGB and YPbPr video signals, providing quality video at lower
costs.
VPT300 Intelligent Camera
Product Overview 2 Product Highlights
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2

3 Application Scenarios
The VPT300 works in a conference room smaller than 50 m2 in conjunction with Huawei's
VPC600 HD camera and Huawei's TE40/TE50/TE60/TX50 videoconferencing endpoint. It
intelligently tracks speakers within a 140-degree range of 10 m radius. A VPT300 can be
equipped with two VPC600s to implement intelligent tracking. The two VPC600s are
connected to the VPT300 through the HD-VI input ports on both sides at its back (shown in
Figure 3-1). The video output resolutions of both VPT300 and two VPC600s are 1080p 50/60
fps.
Figure 3-1 Two VPC600s installed on a VPT300
VPT300 Intelligent Camera
Product Overview 3 Application Scenarios
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3

The VPT300 is connected to a TE40/TE50/TE60/TX50 endpoint through the HD-VI or 3G-
SDI cable. Use the 3G-SDI cable if your VPT300 is remotely away from that endpoint.
Figure 3-2 shows how a VPT300 is connected to a TE40 using the HD-VI cable. Connect the
VPT300 to a TE50, TE60, or TX50 in the same way.
Figure 3-2 Connecting a VPT300 to a TE40 using the HD-VI cable
Connecting is performed as follows:
lUse the HD-VI cable delivered with the TE40 to connect the HD-VI output port on the
VPT300 to video input port 1 (that is, HD-VI input port) on the TE40.
lUse the audio cable delivered with the VPT300 to connect the LINE IN audio input port
on the VPT300 to audio output port 1 on the TE40.
Figure 3-3 shows how a VPT300 is connected to a TE50 using the 3G-SDI cable. Connect
the VPT300 to a TE60 or TX50 in the same way.
VPT300 Intelligent Camera
Product Overview 3 Application Scenarios
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4

Figure 3-3 Connecting a VPT300 to a TE50 using the 3G-SDI cable
Connecting is performed as follows:
lConnect the 3G-SDI input port on the VPT300 to video input port 3 (that is, 3G-SDI
input port) on the TE50.
lUse the audio cable delivered with the VPT300 to connect the LINE IN audio input port
on the VPT300 to audio output port 1 on the TE50.
lConnect one end of the HD-VI to DVI/Serial cable (delivered with the TE50) to the HD-
VI output port on the VPT300 and connect the other end of the cable to the COM 1 or
COM 2 port on the TE50 through a network cable.
VPT300 Intelligent Camera
Product Overview 3 Application Scenarios
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5

4 Product Structure
4.1 Appearance
Figure 4-1 shows the appearance of the VPT300.
Figure 4-1 VPT300 appearance
4.2 Front Panel and Rear Panel
Figure 4-2 shows the front panel of the VPT300.
VPT300 Intelligent Camera
Product Overview 4 Product Structure
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6

Figure 4-2 VPT300 front panel
Table 4-1 describes the VPT300 indicator status.
Table 4-1 VPT300 indicator status
When the indicator is... The VPT300 is...
off powered off
blinking green twice per second powering on
blinking green four times per second upgrading
steady green working properly.
blinking yellow once per second encountering an IP conflict
blinking green (on for 1s, off for 2s) on standby
steady red faulty (hardware)
steady yellow faulty (software)
blinking yellow twice per second overheating
Figure 4-3 shows the rear panel of the VPT300.
VPT300 Intelligent Camera
Product Overview 4 Product Structure
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7

Figure 4-3 VPT300 rear panel
VPT300 Intelligent Camera
Product Overview 4 Product Structure
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8

5 Features
5.1 Automatic Tracking
The VPT300 automatically detects and identifies the conference status, takes panoramic and
close-up video images, and tracks speakers. The VPT300 also supports PiP to enhance
interaction experience. Specifically, the VPT300:
lAutomatically detects two participants who are having a conversation and displays their
video images separately in two panes.
lEnters the AutoFrame mode and automatically presents optimal video images when no
participant is speaking.
lTakes close-up video images of the speaker when only one participant is speaking or
multiple participants are speaking in turn.
lTakes close-up video images of several participants when they are speaking at the same
time or in turn.
lTakes a panoramic view when many participants are speaking at the same time or in turn.
5.2 Manual Tracking
After the VPT300 that has two VPC600s installed is connected to an endpoint, you can use
the endpoint's remote control to control the VPC600s. However, only one VPC600 can be
controlled at a time, which can be specified on the endpoint's web interface.
5.3 AutoFrame
The VPT300 automatically adjusts its dual cameras to:
lCapture new participants who come into the conference room.
lDisplay video images of remaining participants at the center of the display after some
participants leave the conference room.
lDetect moving participants and adjust to the optimal angle after detecting no more
movement.
VPT300 Intelligent Camera
Product Overview 5 Features
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9

5.4 PiP Display
The PiP mode can be configured for the VPT300 on the web interface of the connected
endpoint and takes effect immediately. However, this mode is available only when the
VPT300 has automatic tracking enabled.
If the PiP mode is enabled, the VPT300 will display panoramic and close-up video images in
PiP mode. When a participant is speaking, the VPT300 displays the panoramic view in full-
screen mode and the close-up video of the speaker in a small window at any of the four
corners. When the participant stops speaking, the small window disappears.
If the PiP mode is disabled, close-up video images will be displayed in full-screen mode.
5.5 Transmission of Infrared Signals
The VPC600 on the VPT300 can transmit infrared signals received from the remote control of
the TE40/TE50/TE60/TX50 endpoint to the VPT300. Subsequently, the VPT300 transmits
signals to the endpoint, and as a result, the endpoint can be controlled by the remote control.
This function is required when the endpoint is placed inside a cabinet and cannot directly
receive infrared signals from the remote control.
5.6 Sleep and Wake-up
You can put the VPT300 and its VPC600 in sleep mode and wake them up from the
connected TE40/TE50/TE60/TX50 endpoint.
lThe VPT300 in sleep mode will wake up if you upgrade the VTP300 or use the VPT300
to upgrade the VPC600.
lThe VPT300 can be put in sleep mode, so can its connected VPC600.
lWhen putting a VPC600 in sleep mode, the VPT300 rotates the VPC600 to the sleep
position and makes it enter the low-power-consumption state.
lWhen you use the remote control of the TE40/TE50/TE60/TX50 endpoint to wake up
the VPC600 in sleep mode, the VPC600 will transmit the infrared signals to the
VPT300. As a result, both VPC600 and VPT300 will have woken up.
lAfter being woken up, the VPC600 will rotate to its initial position.
5.7 Security
The VPT300 provides a variety of security features, such as authentication of debug users,
whitelist, and protocol anti-attack.
System Layer Security
Security maintenance of the system layer ensures a smooth running of the operating system
and supports stable services at the application layer.
The VPT300 uses a customized Android operating system, which delivers enhanced security
and immunity to viruses.
VPT300 Intelligent Camera
Product Overview 5 Features
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10

The Android operating system that the VPT300 has installed has been hardened and does not
allow any third-party applications.
Network Layer Security
The VPT300 IP address is configured by the administrator using command lines. It must be
deployed on the private network and completely isolated from the public network.
Protocol Anti-Attack Measures
The communication port matrix is provided in the product documentation. Only services and
ports mentioned in the communication port matrix can be enabled.
The communication port matrix contains the following information:
lOpen ports
lTransport layer protocols used by the ports
lNetwork elements (NEs) that use the ports to communicate with peer NEs
lApplication layer protocols used by the ports and description of the services at the
application layer
lWhether services at the application layer can be disabled
lAuthentication modes adopted by the ports
lPort functions (such as data traffic control)
Robustness testing tools are used to scan protocols to ensure that there are no high-risk
vulnerabilities.
Protection of Sensitive Data
To prevent sensitive data from being disclosed, the VPT300 checks the complexity of the
default password and user-defined passwords. A password is displayed as dots (.) or asterisks
(*) when entered in the password input box, and entered passwords cannot be copied.
Sensitive data such as passwords and other encrypted contexts is displayed as asterisks (*) in
logs.
No proprietary encryption algorithms are used.
System Management and Maintenance Security
Software packages (including patch packages) are released after being scanned by at least one
type of mainstream antivirus software with no alarms generated. In special cases, an
explanation is provided for alarms.
Scanning records (including antivirus software name and version, virus library version,
scanning time, and scanning results) are archived and released with the software package
(including patch packages) to customers.
All account access operations and system abnormalities are logged.
VPT300 Intelligent Camera
Product Overview 5 Features
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11

6 Operation and Maintenance
6.1 Maintenance Using the Web Interface
The VPT300 and its VPC600s can be maintained by the web interface of the TE40/TE50/
TE60/TX50 endpoint of V600R006C00 or later. The web interface allows you to:
lExport configuration data of the VPT300 with just one click.
lSave and change the VPT300's upgrade password.
lSpecify the sensitivity of speaker tracking, which can be: low, medium (default), or high.
lSet video parameters.
lConfigure the tracking mode, including automatic, AutoFrame, and manual.
lEnable or disable PiP and specify the position of the small window.
lSet the IP address, subnet mask, and gateway address of the VPT300.
6.2 Remote Maintenance Using Command Lines
You can use Telnet/SSH command lines to:
lQuery the VPT300 and VPC600 version numbers, serial numbers, and electronic labels.
lRestart the VPT300.
lSpecify the sensitivity of speaker tracking.
6.3 Log Management
User operations and system events are logged, which help engineers maintain the VPT300
and locate faults. Logs are saved as files.
Users can log in to the VPT300 by Telnet or SSH and run specific commands to query all or
some log records. However, VPT300 logs cannot be queried or exported from the web
interface of the TE40/TE50/TE60/TX50 endpoint.
Logs are classified into system logs and user logs, which have three levels: information,
alarm, and error.
VPT300 Intelligent Camera
Product Overview 6 Operation and Maintenance
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
12

Neither system logs nor user logs can exceed 5 MB. If logs reach 5 MB, the latest logs will
overwrite the earliest logs.
6.4 VPT300 and VPC600 Upgrade
You can upgrade the VPT300 to the latest version to fix its vulnerabilities, and then enjoy new
functions provided in the latest version. Information regarding the upgrade is as follows:
lThe VPT300 can be upgraded using the upgrade tool released with it or using the TE40/
TE50/TE60/TX50 upgrade tool.
lThe VPC600 can be upgraded using the upgrade tool released with the VPT300 or using
the TE40/TE50/TE60/TX50 upgrade tool.
lA password is required for starting the upgrade.
lThe VPT300 can continue its upgrade after a pause.
lThe upgrade starts only after the upgrade package is verified. The upgrade request will
be rejected if the system detects that the upgrade package provided is not the required
upgrade package.
lVPT300s can be upgraded in batches (10 at most) or one by one.
6.5 Restoration to Factory Settings or Original Version
If the VPT300 encounters some problems and is unrecoverable, contact the administrator or
Huawei technical support engineers for assistance.
To restore the VPT300 to the factory settings, push the reset button for 10 seconds when the
VPT300 is running. This operation is irrevocable.
To restore the VPT300 to the original version, push the reset button for 10 seconds when the
VPT300 is powering on. This operation is irrevocable.
VPT300 Intelligent Camera
Product Overview 6 Operation and Maintenance
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
13

7 Technical Specifications
7.1 Physical Specifications
Table 7-1 lists physical specifications of the VPT300.
Table 7-1 Physical specifications
Item Specification
Electricity Supply Requirements
Input voltage range 100 V AC to 240 V AC
Output voltage 19 V DC, 7.89A
Working frequency 50 Hz to 60 Hz
Typical power consumption of a VPT300
not equipped with any VPC600s
23 W
Maximum power consumption of a VPT300
not equipped with any VPC600s
35 W
Typical power consumption of a VPT300
equipped with two VPC600s
61 W
Maximum power consumption of a VPT300
equipped with two VPC600s
88 W
Working State Environment Requirements
Ambient temperature 0°C to 40°C
Relative humidity 10% to 90%
Non-Working State Environment Requirements
Ambient temperature –40°C to +70°C
Relative humidity 0% to 95%
VPT300 Intelligent Camera
Product Overview 7 Technical Specifications
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
14

Item Specification
Dimensions and Weight
VPT300 dimensions (H x W x D) 40 mm (without the sound pickup pole)/418
mm (with the sound pickup pole) x 530 mm
x 170 mm
Package dimensions (H x W x D) 405 mm x 755 mm x 285 mm
VPT300 net weight l6.2 kg (including the two VPC600s)
l2.8 kg (excluding the two VPC600s)
Built-in Camera Features
Exposure mode Automatic and manual
White balance Automatic and manual
Built-in Microphone Features
Sound pickup capabilities lSound pickup distance: 10 m
lSound pickup range: 140°
7.2 Ports and Protocols
Table 7-2 lists ports provided and protocols used by the VPT300.
Table 7-2 Port description
Port Quantity and
Description
Protocols
Compliance and
Standards
Remarks
Video input
port
2 x HD-VI DVI Revision 1.0
TMDS
Connect to two VPC600s to
provide video input and power
supplies.
2 x Built-in
camera
- -
Video
output port
1 x HD-VI DVI Revision 1.0
TMDS
Connects to an endpoint and
converts HDMI signals to DVI
signals but not to YPbPr
signals.
1 x SDI SMPTE296M/
SMPTE274M/
SMPTE292M/
SMPTE424M
Connect to an endpoint that is
far away in a large conference
or training room.
Audio
input port
1 x 3.5 mm - Connects to an endpoint.
VPT300 Intelligent Camera
Product Overview 7 Technical Specifications
Issue 02 (2017-04-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
15
