Quidway® S6500 Series High-end Multi-service Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/
1
Quidway® S6500 Series High-end Multi-service
Switches Product Specification
Attribute S6502 S6503 S6506 S6506R
Number of Slots 2 4 7 8
Number of Slots for Interface
Modules
2 3 6 6
Salience™ Series Switch and
Route Engines
Integrated in
interface
module1
Salience™ III
Edge
Salience™ III
Salience™ III
Plus
Salience™ III
Edge
Salience™ III
Salience™ III
Plus
Salience™ III
Edge
Salience™ III
Salience™ III
Plus
Switching Capability LS8M1T12PE/
LS8M1P12TE:
48Gbps
Other MCUs:
192Gbps
Salience™ III
Edge: 56Gbps
Salience™ III:
144Gbps
Salience™ III
Plus: 312Gbps
Salience™ III:
Edge: 96Gbps
Salience™ III:
192Gbps
Salience™ III
Plus: 336Gbps
Salience™ III
Edge: 96Gbps
Salience™ III:
384Gbps
Salience™ III
Plus: 768Gbps
Throughput LS8M1T12PE/
LS8M1P12TE:
36Mpps
Other MCUs:
144Mpps
Salience™ III
Edge: 42Mpps
Salience™ III:
90Mpps
Salience™ III
Plus: 216Mpps
Salience™ III
Edge: 72Mpps
Salience™ III:
126Mpps
Salience™ III
Plus: 216Mpps
Salience™ III
Edge: 72Mpps
Salience™ III:
198Mpps
Salience™ III
Plus: 432Mpps
Interface Modules2GEBUS Uplink:
LS8M1T12PE: 12-port 10/100/1000BASE-T RJ-45 and 4-port
1000BASE-X SFP
LS8M1P12TE: 12-port 1000BASE-X SFP and 4-port
10/100/1000BASE-T RJ-45
LS8M1T12P: 12-port 10/100/1000BASE-T RJ-45 and 4-port
1000BASE-X SFP
LS8M1P12T: 12-port 1000BASE-X SFP and 4-port
10/100/1000BASE-T RJ-45
LS8M1FT48E: 48-port 10/100BASE-TX Ethernet Interface Module,
RJ45
1The switch and route engines of S6502 include LS8MiT12PE, LS8M1P12TE, LSM1GP48-XG,
LS8M1T16P-XG, LS8M1T32P-XG, LS8M1TGX2-XG, LS8M1TGX4-XG
2All Salience™ III series engines can support GEBUS. But only Salience™ III and Salience™ III Plus
engine can support XGBUS, this means that Salience™ III Edge engine cannot cooperate with XGBUS
uplink interface modules.

Quidway® S6500 Series High-end Multi-service Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/
2
Attribute S6502 S6503 S6506 S6506R
LS8M1FP48: 48-port 100BASE-FX Ethernet Optical Interface Module,
SFP Req.
LS8M1GT20A: 20-port 10/100/1000BASE-T Ethernet Interface
Module, RJ45
LS8M1GT48: 48-port 10/100/1000BASE-T Enhanced Ethernet
Interface Module, RJ45
LS8M1GP20A: 20-port 1000BASE-X Ethernet Optical Interface
Module, SFP Req.
LS8M1TGX1C: 1-port 10GE Interface Module, Xenpak Req.
LS8M1GT48A-POE: 48-port 10/100/1000BASE-T Ethernet Interface
Module, RJ45 (PoE)
LS8M1FT48F-POE: 48-port 10/100BASE-TX Ethernet Interface
Module, RJ45 (PoE)
LS8M1GT8UE3: 8-port 10/100/1000BASE-T Ethernet Interface
Module, RJ45
LS8M1GP8UB: 8-port 10/100/1000BASE-X Ethernet Optical Interface
Module, RJ45
XGBUS Uplink4:
LS8M1GP48-XG: 48-port 1000BASE-X Ethernet Optical Interface
Module, SFP Req.
LS8M1T16P-XG: 16-port 10/100/1000BASE-T RJ45 and 8-port
1000BASE-X SFP
LS8M1T32P-XG: 32-port 10/100/1000BASE-T RJ45 and 16-port
1000BASE-X SFP
LS8M1TGX2-XG: 2-port 10GE Interface Module, XFP Req.
LS8M1TGX4-XG: 4-port 10GE Interface Module, XFP Req.
Intelligent Service Module:
LS8M1VSNP: Versatile Network Processing Service Module
3LS8M1GP8UB and LS8M1GT8UE only work with Salience™ III and Salience™ Edge and cannot be
configured in the last slot of S6506 and S6506R..
4The interface modules with XGBUS uplink only work with Salience™ III and Salience™ III Plus, they
can only be configured in the last two slot of S6503, S6506, and S6506R when the SRPU is Salience™
III.
5The Versatile Network Processing (VSNP) Service Interface Module only cooperate with Salience™ III
and Salience™ III Plus engine. But when S6502 Main Control Unit is XGBUS uplink, it can support VSNP
Service Interface Module also.
6At present, EPON OLT modules only support GEBUS uplink, so they can compliant with LS8M1P12TE
or LS8M1T12PE on S6502. For S6503, S6506, S6506R, LS8M1PT8GA is only compliant with Salience
III or Salience III Edge and should not be installed in the last slot of S6506, S6506R.

Quidway® S6500 Series High-end Multi-service Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/
3
Attribute S6502 S6503 S6506 S6506R
(PBR/NAT/NetStream) with XGBUS uplink5
OLT Interface Module6:
LS8M1PT8GA: 8-Port Gigabit Passive Optical Line Interface
Module(10km, SFF)
LS8M1PT4GA: 4-Port Gigabit Passive Optical Line Interface
Module(10km, SFF)
Port-based
VLAN (802.1Q)
YES(4K)
Protocol-base
d VLAN (IP,
IPX and etc)
YES
SuperVLAN YES(up to 64)
SubVLAN YES (127 SubVLAN per SuperVLAN, totally 1024 SubVLAN per
System)
MAC table
number
16K/module, 16K/chassis
IEEE802.3x
flow control
YES
IEEE802.1p YES
IEEE802.3ad
link-aggregati
on
YES. MAX. 8 ports/link group, MAX. 64 groups
Link-aggregati
on across
boards
YES7. MAX. 8 ports/link group, MAX. 32 groups
LACP YES
GVRP/GMRP/
GARP
YES
Port mirroring YES8
STP YES
RSTP YES
MSTP YES (support 16 instances)
Layer 2
Switching
Broadcast YES
78GT (LS8M1GT8UE), 8GP(LS8M1GP8UB), GE ports on the Salience™ III series engine and all the
interface modules with XGBUS uplink support the link aggregation across boards. These ports above can
be aggregated together no matter they are GEBUS uplink or XGBUS uplink.
88GT(LSM81GT8UE), 8GP(LS8M1GP8UB), GE ports on the Salience™ III series engine and all the
interface modules with XGBUS uplink can be mirrored between boards. It can be mirrored between these
ports above no matter they are GEBUS uplink or XGBUS uplink.

Quidway® S6500 Series High-end Multi-service Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/
4
Attribute S6502 S6503 S6506 S6506R
storm
suppression
Q-in-Q YES
Jumbo-frame YES (support MAX. 9216 bytes)
Middle frame YES (support MAX. 1600 bytes)
Port auto
negotiation
YES
IGMP
snooping (v1,
v2)
YES
L2 static
unicast
addresses
YES
LPM (Longest
prefix match)
YES
Static route YES(5K)
RIPv1/v2
OSPF
IS-IS
BGP
RIPv1/v2: 1K
OSPF: 64K
IS-IS: 64K
BGPv4: 32K
VRRP YES (14 virtual routers per switch; each virtual router supports 16 IP
addresses)
ARP YES(8K)
Local ARP
proxy
YES
DHCP relay YES
DHCP server YES
IGMP (v1, v2) YES
PIM-DM,
PIM-SM
YES
ECMP 4
Switched
virtual
interfaces
1K
Traceroute YES
IPX(software
switched)
YES
Layer 3
Switching
Multicast
groups
YES(1K)
Security 802.1x 2K 3K 4K 4K

Quidway® S6500 Series High-end Multi-service Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/
5
Attribute S6502 S6503 S6506 S6506R
Guest VLAN YES
ACL 3K
SSHv1.5/2.0 YES
RADIUS,
HWTACACS
YES
Unicast MAC
filter
YES
Per-port QoS
configuration
YES
ACL capacity 10-GE: 900 rules/port
GE: 100 rules/port
FE: 200 rules shared by 8 ports
CAR YES (granularity: 64kbps)
Queues per
port
8
QoS
Traffic
Classification
Strict Priority Queuing
WRR (Weighted Round Robin) provided through bandwidth
Supports priority queue based on VLAN port, IEEE802.1P
Supports up to 8 FIFO, SP, WRR queues for each port
Remarking of packets based on priority:
• Auto classification
• Selectable prioritization
• DSCP priority
• Type of Service (ToS)
• IEEE 802.1p Class of Service (CoS)
• IP precedence
Local precedence: physical port, source/destination MAC address,
VLAN information, Ethernet type, Layer 3 protocol, source/destination
IP address, datagram type, IP Layer 4 protocol, IP Layer 4 ports Flows
identified through Access Control Lists (ACLs)
Number of IP
addresses
32 IP pools and 8,000 IP addresses
NAPT 32 IP pools and 3 IP addresses per pool
Number of ISP 32
NAT
Concurrent
connection
number
100,000/s
3Gbps (64bytes/packet, ingress PBR)
Throughput
3Gbps (64bytes/packet, egress PBR)
Policy Based
Routing
(PBR) Forwarding 4.5Mpps (64bytes/packet, ingress PBR)

Quidway® S6500 Series High-end Multi-service Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/
6
Attribute S6502 S6503 S6506 S6506R
rate 4.5Mpps (64bytes/packet, ingress PBR)
Number of
stream
statistics
entry per
interface
module
300,000
Throughput 3.8Gbps(single direction, 64bytes/packet)
Forwarding
rate
5.7Mpps(single direction, 64bytes/packet)
NetStream
Format of
output packet
V5/V8/V9
Configuration
through
CLI Console,
Telnet and
modem
YES
FTP/TFTP YES
Other Provides system logs
Provides user-level alarming
Optional CF card
System
Configuration
/System
Management
Management
VLAN
YES
AC power
distribution
box with two
inputs,
each with a
separate
ON/OFF
switch
100-120V/220-240V AC; 50-60Hz; 9.0A/5.0A
Power
Distribution
Box
DC power
distribution
box
Rated voltage: -48V to -60V DC
Maximum tolerance: -36V to -72V DC
PoE input voltage -46V to -55V; 55.0A
Operating temperature 0oC to 45oC
Operating humidity
(non-condensing)
10% to 90%

Quidway® S6500 Series High-end Multi-service Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/
7
Attribute S6502 S6503 S6506 S6506R
MTBF (Mean Time Between
Failures)
218,000h 185,000h 160,000h 221,000h
MTTR (Mean Time to Repair) ≤1h
Weight (maximum in full
configuration)
≤20kg ≤50kg ≤70kg ≤80kg
Maximum power consumption
(all slots inserted with
boards)
AC: 300W
DC: 300W
AC: 350W
DC: 300W
AC: 650W
DC: 550W
AC: 800W
DC: 700W
Physical dimensions (W×H×D) 436×130.5×400
mm
(17.17×5.14×1
5.75 in.)
436×352.8×480
mm
(17.2×13.9×18.
9 in.)
436×486.2×480
mm
(17.2×19.1×18.
9 in.)
436×530.6×480
mm
(17.2×20.9×18.
9 in.)
