Hubbell PS Series User manual

INSTALLATION, OPERATION AND
MAINTENANCE MANUAL FOR
POINT OF USE STEAM FIRED WATER HEATER
ELECTRIC HEATER COMPANY
BASE MODEL “ PS ”
Edition 2019

2
HUBBELL
ELECTRIC HEATER COMPANY
P.O. BOX 288
STRATFORD, CT 06615
PHONE: [phone]
FAX: [phone]
INTERNET: http://www.hubbellheaters.com/
-- IMPORTANT --
Always reference the full model number and serial number when calling the factory.
WARNING / CAUTION
1. Tank is to be completely filled with water and all air is to be vented before energizing.
2. Due to the rigors of transportation, all connections should be checked for tightness before
heater is placed in operation.
3. Safety relief valve must be installed in tapping provided.
4. KEEP AWAY FROM LIVE ELECTRICAL CIRCUITS.
Do not perform any maintenance, make any adjustments, or replace any components
inside the control panel with the high voltage power supply turned on. Under certain
circumstances, dangerous potentials may exist even when the power supply is off. To
avoid casualties, always turn the power supply safety switch to off, turn the charge or
ground the circuit before performing any maintenance or adjustment procedure.
5. Generalized instructions and procedures cannot anticipate all situations. For this reason,
only qualified installers should perform the installations. A qualified installer is a person
who has licensed training and a working knowledge of the applicable codes regulation,
tools, equipment, and methods necessary for safe installation of a steam fired water
heater. If questions regarding installation arise, check with your local plumbing and
electrical inspectors for proper procedures and codes. If you cannot obtain the required
information, contact the company.

SECTION TITLE PAGE No.
I GENERAL DESCRIPTION AND CONSTRUCTION 4
II INSTALLATION 5
III INSTALLATION AND OPERATION OF STERLCO TEMPERATURE CONTROL VALVES 8
IV OPERATION 9
V SCHEDULED MAINTENANCE AND SERVICING 10
VI TROUBLESHOOTING 14
VII MISCELANEOUS CHARTS AND FORMULAS 15
3

SECTION I - GENERAL DESCRIPTION AND CONSTRUCTION
GENERAL DESCRIPTION
This book describes a packaged steam powered water heater that is a stationary, self-contained
unit.
The complete assembly on a standard unit consists of the storage tank, immersion heating coil,
steam drip trap, condensate trap, steam strainer, and an ASME rated combination temperature
and pressure safety relief valve. Optional equipment may be supplied with your unit. Please
consult the product drawing for details specific to your assembly. The unit is factory assembled,
insulated, jacketed, primed, painted, piped, tested, and ready for service connections. The
maximum allowable rating for this unit is 200,000 BTU/Hr.
CONSTRUCTION
TANK
The storage tank is constructed of all welded carbon steel, and internally lined with specially
formulated Hydrastone cement to a ½-inch minimum thickness for superior protection and tank
longevity. The tank is designed for a maximum allowable working pressure of 150 psi (225 psi
TP).
TANK CONNECTIONS
The heater is supplied with separate cold water and hot water connections. Water entering the
cold water inlet is deflected by means of a baffle within the tank. A ¾-inch FNPT connection is
provided for mounting a combination safety temperature and pressure relief valve. An overflow
line should be utilized from the relief valve outlet to a floor drain. See drawing for locations and
sizes.
STEAM HEATING COIL
The water heater is supplied with a high quality
factory installed finned U-tube heating coil
constructed from 7/8-inch O.D. single wall
copper tubing designed for a maximum working
pressure of 150 psi. The tubing is installed in a
heavy-duty fabricated steel head with threaded ¾-
inch MNPT steam and condensate connections.
Each assembly is fastened to a corresponding
tank flange using a rubber gasket "boot" and hex head steel bolts and nuts.
OUTER SHELL, INSULATION, AND SUPPORTS
The tank is encapsulated in 2-inch thick polyurethane foam insulation. The insulation is
protected by a high impact non-corroding colorized composite protective jacket. The entire
vessel is supported on heavy-duty integrally welded steel supports for sturdy floor mounting.
STEAM OPERATING CONTROLS
4
The steam operating controls are factory selected, sized, piped,
and tested to ensure reliable operation. Steam controls are
shipped loose for in the field installation by others.
Steam Control Valves
A fully modulating self-contained control valve (sometimes
referred to as a temperature regulator or a steam regulator) should
be installed to regulate the flow of steam through the heating coil.
No quick opening or snap-acting valve should be used as these
can cause surges in pressure or thermal shock to the coil.
Standard temperature range is 105° - 145° F. Optional ranges of
55° - 95° F, 80° - 170° F, 110° - 190° F, and 175° - 225° F are available.
Strainers
A cast iron ‘Y’ strainer with 20 mesh screen protects the steam controls and coil from dirt
and debris in the steam supply.

Traps
Two traps should be utilized in the immediate steam piping system of the water heater. The first
trap in the system is a thermostatic drip trap that is designed to collect condensate from the main
steam line before entering the control valve. Additionally, a main condensate cast iron float and
thermostatic trap should be located in the condensate line after the steam coil. This trap ensures
that the steam remains in the coil and releases its energy before exiting the coil and traveling
down the condensate line.
OPTIONS
The following optional features may be included in your water heater. Reference included
drawing specific to your heater for further details.
Single Solenoid Safety System
A single solenoid safety system closes the steam supply to the control valve should the
temperature in the tank reach the high limit set point. This option requires 120-volt, 5-amp
electrical service.
Double Solenoid Safety System
A double solenoid safety system dumps over heated water in the storage tank to drain in
addition to closing the steam supply to the control valve. This option requires 120-volt, 5-
amp electrical service.
Backup Electric Heating Elements
Backup electric heating elements may be installed in various wattages and voltages to heat
the water when the steam supply is turned off.
Circulating Pump Package
An intra-tank circulation pump package with On/Off switch to
continuously circulate water within the tank and thereby reduce
stratification may be installed. An all bronze circulator pump, rated 1/25
HP, 120V, 1Ph, is used.
Dial Temperature and Pressure Gauge
A combination temperature (70° - 270° F) and pressure (0 – 200 psi)
gauge with 3-inch dial may be factory installed in the tank.
Steam Pressure Reducing Valve
An optional steam pressure reducing valve, to reduce the steam
supply pressure to the control valve, may be included.
Double Wall Heating Coil
A Double Wall Heat Exchanger consists of two copper tubes,
one inside the other, wound into a coil. The outer tube is
soldered into the fitting that mates into the tank. The inner tube
is soldered into the fitting that mates with the hot water supply.
The gap between the two tubes is open to the air, allowing
visible detection of any leaks, as well as preventing any leaks
from mixing into the other liquid.
SECTION II –INSTALLATION
WARNING / CAUTION
DO NOT TURN ON THE STEAM SUPPLY to this unit until heater is completely filled
with water and all air has been released. If the heater is NOT filled with water when the
steam supply is turned on, damage to the heating coil may result.
For protection against excessive pressures and temperatures, local codes require the
installation of a temperature-and-pressure (T&P) relief valve certified by a nationally
recognized laboratory that maintains periodic inspection of production of listed equipment of
materials, as meeting the requirements for Relief Valves and Automatic Gas Shutoff for Hot
Water Supply Systems. ANSI Z21.22-1971. THE CUSTOMER IS RESPONSIBLE TO
5

PROTECT PROPERTY AND PERSONNEL FROM HARM WHEN THE VALVE
FUNCTIONS.
All water heaters have a risk of leakage at some unpredictable time. IT IS THE
CUSTOMER'S RESPONSIBILITY TO PROVIDE A CATCH PAN OR OTHER
ADEQUATE MEANS, SO THAT THE RESULTANT FLOW OF WATER WILL NOT
DAMAGE FURNISHINGS OR PROPERTY.
Never operate unit in excess of design conditions.
The tank should be fully drained in the event the steam has been turned off and if there is
danger of freezing.
WATER HEATER PLACEMENT
1. Place the heater on a solid foundation in a clean, dry location nearest to the point of
most frequent hot water use. If the heater is to be raised off the floor, the entire bottom
of the heater should be supported by a solid surface.
2. Adequate space should be provided for removal of heating element.
3. Unit should be level to permit proper drainage
INSTALL THE HEAT EXCHANGER COIL
1. Remove the access panel.
2. Apply the included o-ring lubricant to o-rings.
3. Insert the o-rings into the grooves on the plastic o-ring housing.
4. Insert heat exchanger and align holes in cover plate with holes in flange.
5. WARNING: Plastic o-ring housing must be properly installed. Failure to do this
will void the warranty.
6. Insert and secure the bolts to the nuts one at a time in the following manner:
•Place the nut behind the flange opening.
•Hold the nut in place with one hand – insert the bolt with washer with the other.
•Thread the bolt through the washer and into the nut and tighten.
•NOTE: Be sure to place bolts in all of the openings.
6

PIPING INSTALLATION
NOTE: The most effective means for preventing deterioration from accelerated corrosion
due to galvanic and stray current is the installation of dielectric fittings/unions. The
installation of these fittings is the responsibility of the installing contractor.
1. All integral components have been properly sized to meet design conditions. Piping to
the unit should not be smaller than the size of pipe connections furnished by Hubbell.
2. Install the heating coil in the mating flange using the rubber boot gasket, nuts, bolts,
and inserts as supplied. Install the coil with the steam Inlet/Condensate Outlet
connections in the most vertical position (12 o'clock and 6 o'clock).
3. If the steam components are factory pre-piped, assemble the piping to the unions as
shown in the drawing. If the steam components are shipped loose, pipe them as
shown in the drawing.
4. Install the bulb of the control valve in the tapping provided.
5. Steam supply should be piped to the steam inlet strainer. Condensate outlet should be
piped to your condensate line.
6. Condensate lines must be run downhill to get proper drainage. A condensate pump
can be used if it is impossible to run the line downhill . If there is adequate steam
pressure, this may push the condensate uphill, 1 psi steam will lift condensate 1 foot.
7. Install the combination temperature and pressure safety relief valve in the tapping
provided. Note that this is required by law for safety considerations.
Outlet to floor drain
Installintoprovidedtapping
Manual Release
Lever
Temperature Probe
Install a relief valve overflow pipe to a nearby floor drain. CAUTION: No valve of any type
should be installed between the relief valve and tank or in the drain line.
ELECTRICAL INSTALLATION
1. Refer to Hubbell drawing for any electrical requirements.
2. Enter electric enclosure with properly sized feeder leads. Install these power leads
into the box lugs on the terminal block or magnetic contactor.
3. All other electrical connections are made at the factory; therefore, no other electrical
connections are necessary.
FILLING THE HEATER
1. Begin with all steam, condensate, and water valves closed.
Open the isolation valves on the integral circulator line ,if supplied.
2. Open cold water valve, fill unit with cold water. Lift lever on relief valve to relieve
trapped air. Release relief valve lever when all traces of air have been vented from the
unit. Leave cold water valve open.
7

8
SECTION III –INSTALLATION AND OPERATION OF STERLCO
TEMPERATURE CONTROL VALVES
WARNING / CAUTION
HANDLE GENTLY. Temperature control valves are instruments, not pipe fittings. A dent in
the body or a sharp bend in the capillary may prevent them from operating. Do not use pipe
wrenches. Do not subject controls to water-hammer conditions or excessive pressures.
BULB LOCATION
This is perhaps the most important factor in good installation. The entire bulb, not just part
of it, must be exposed to the fluid of which the temperature is to be controlled. In a tank, it
must be in a representative location not in a comer which may be warmer or cooler than the
rest of the tank. The temperature at the bulb is the only one which can be controlled.
VALVE LOCATION (HEATING OR DIRECT ACTING CONTROL)
In supply line close to inlet. When heating with steam always use a float and thermostatic
trap at the condensate outlet from the heating equipment. Do not install the control valve at
the condensate outlet; water-hammer or poor control may result.
VALVE POSITION
Preferably with adjusting screw at top but can usually be used in any other position. If
possible, let capillary run downward from valve to bulb. All valve bodies have arrows
showing direction of flow. If installed backward, they will be noisy or inoperative.
CAPILLARY LOCATION
Not next to a steam line or in a cold draft. If the capillary is exposed to extreme
temperatures, it may be desirable to wrap it with insulating material.
STRAINERS
A ‘Y’ Strainer should always be installed just ahead of the control valve to protect it from
large particles of dirt and the system must be kept free of sediment, scale, etc.
ADJUSTMENT
Temperature adjustment within the range of the control is made by simply turning an
adjusting screw in the direction indicated on the valve body or nameplate. Turn the screw
only a little at a time, then let temperatures reach equilibrium before adjusting further.
OPERATION
Remember that this is a modulating control. It does not alternately open wide and shut tight
like an electrical control device. Rather, it opens gradually wider and wider in relation to the
difference between the actual bulb temperature and the bulb temperature at which the valve
is closed. In normal operation, the control valve remains in a constant, partially open
position which is automatically adjusted whenever conditions require it.
MAINTENANCE
The only servicing normally required is to keep the control clean. The valve can be inspected
and cleaned by access through the inlet and outlet, without disassembly. The bulb must not
become coated with any substance which interferes with the transmission of heat.
If repairs are needed, we recommend that these controls be returned to our factory for
reconditioning. Skilled workmen, with proper tools, replacement parts, and testing facilities
will do a good job more economically than it can be done in the field. These controls are
simple to disassemble and assemble for a person who is familiar with them. An
inexperienced worker will sometimes damage them by incorrect handling, and usually
replacement parts, which are not available in the field, will be required. If for any reason it is
necessary to disassemble one of these controls, please write us for detailed assembly
drawings and instructions.
If a control has to be returned for repairs, please tell us as much as possible about what
appears to be wrong, and ship it "as is" without disassembling it and possibly damaging
good parts. This will help us to do the best and most economical work, and to advise you
how to avoid further trouble.

TROUBLESHOOTING
If the control does not appear to be holding temperature steady, or if not enough heating or
cooling is obtained, first check for external conditions which may prevent the control from
operating correctly. Examples are: low or fluctuating steam or water supply pressure;
damaged or obstructed valves, traps, strainers or other accessories; supply piping too small;
dirty bulb or poor bulb location.
If the valve will not close, check for dirt or foreign matter between disc and seat. The valve
can be inspected through the inlet and outlet openings without disassembly, and can usually
be cleaned out with an air hose.
If overheating results because a direct-acting (heating) valve stays open or a reverse-acting
(cooling) valve stays closed regardless of the temperature at the bulb, the thermostat may
have lost its fill and become inoperative. To check this, remove valve and bulb from the line,
set the control at about the middle of the range, and insert the bulb in water hotter than the
maximum of the range. If the direct-acting control does not close or the reverse-acting
control does not open; factory repairs to the thermostat are required.
If there is a leak to the exterior of the body, some part may be loose or partially
disassembled. Otherwise, a seal bellows may be damaged requiring factory replacement.
If the valve chatters, this usually means a loose or disassembled interior part. Chattering is
sometimes caused by other devices near the control, and can sometimes be eliminated by
changing piping arrangements, valve position, or supply pressure.
Typical Sterlco Control Valve
SECTION IV –OPERATION
STARTUP
1. Begin with all steam, condensate & water valves closed.
2. On systems with a factory supplied intra-tank circulation pump, open the two gate
valves.
3. Fill unit with cold water. Lift lever on relief valve to relieve trapped air. Release
valve lever when all traces of air have been vented from the unit. Leave cold water
valve open.
4. Turn pump switch to the "On" position.
9

10
5. Set the control valve to the desired temperature. Please see Section III for details on
the control valve. There is no temperature indicator on the control valve. Rather, by
turning the calibrating screw on the top of the valve clockwise you increase the
temperature and by turning it counter-clockwise you lower the temperature.
6. If unit has a solenoid safety system, set hi-limit thermostat to desired temperature.
(This thermostat must be set at a higher temperature than the control valve setting or
the unit will continually go off on hi-limit and will never reach the desired
temperature.)
7. Gradually open valve to allow steam to enter the heating coil. Monitor the tank
temperature until desired temperature is reached. If the control valve shuts off before
the desired temperature is reached or if overshoot occurs, adjustment of the control
valve will be required. Adjust the calibrating screw clockwise for hotter water and
counter-clockwise for colder water temperatures.
8. After unit has reached desired temperature, and adjustments have been made, open
gate valve on the hot water outlet and the building recirculation line.
9. Gaskets may require tightening after water is heated.
10.Never operate unit in excess of design conditions.
11.Never break any joint, (gasketed or screwed), until the pressure in the unit has been
reduced to zero and the unit drained.
SHUTDOWN
1. Close entering steam valve.
2. Close hot water outlet.
3. Close building recirculation line.
4. Close cold water inlet.
5. Turn intra-tank circulation pump OFF.
6. Unit can be drained at this point. (1) Lift lever on relief valve to vent tank. (2) Open
drain valve.
SECTION V -SCHEDULED MAINTENANCE AND SERVICING
WARNING / CAUTION
Before performing any maintenance procedure,make certain steam supply and electrical
power supply is OFF and cannot accidentally be turned on.
QUARTERLY INSPECTION
1. Monitor thermostat
a. Let water heater completely heat to a designated thermostat setting.
b. After thermostat satisfies (that is, when the thermostat actually clicks off), draw water
from heater.
c. Compare water temperature of drawn water to the temperature setting of the
thermostat when it satisfies. Normal variation between the two points is
approximately + 5°F.
d. If these two readings do not coincide within acceptable tolerances and verification has
been made of the accuracy of the temperature-reading gauge, replace the thermostat.
2. Lift test lever on relief valve and let water run through valve for a period of
approximately 10 seconds. This will help flush away any sediment that might build up
in water passageways.
ANNUAL INSPECTION
1. Units subject to fouling or scaling should be cleaned periodically. A marked increase
in pressure drop and/or reduction in performance usually indicates cleaning is
necessary.
2. To clean inside of tubes, remove all heads and covers. (Caution: Do not loosen heads
until you are sure all pressure is off the equipment, and the unit is drained.)
3. In cleaning a tube bundle, tubes should not be hammered on. If it is necessary to use

scrapers, care should be taken to insure that the tubes are not damaged.
4. Before it is necessary to apply mechanical means for cleaning, try to clean the unit
using the following methods.
a. Circulate hot fresh water at a reasonable velocity.
b. Try spraying with water hose.
c. Consult with manufacturers of cleaning compounds and chemicals. They will
check the nature of the deposit, recommend the right cleaning compound, and in
many cases provide equipment and personnel for a complete cleaning job.
5. Do not clean tubes by blowing steam through individual tubes.
6. If the unit is dismantled for any reason, it should be reassembled using new gaskets.
7. Do not tighten bolts until gaskets are properly seated.
8. When tightening bolts in the element head, tighten the bolts in a criss-cross pattern.
This will evenly distribute pressure around the flange, and help prevent warping. See
diagram below.
9. Convection packages may be equipped with an integral circulator. This circulator
should be serviced per the enclosed pump O&M manual.
10.Packing on valves and regulators should be checked for leaks and repaired or replaced
as necessary.
11.Drain and flush tank as follows. Perform annually or more often , if required.
a. Shut down unit as described in Section II.
b. Close valve on hot water outlet piping.
c. Open valve on drain piping.
d. Cold water inlet line pressure will be strong enough to flush sediment from the
bottom of the tank out through the drain. Let water run for 3-4 minutes.
e. Clean strainer filter, see below.
f. Close drain valve.
g. Open hot water valve.
h. Re-start unit as described in Section II.
12.Clean strainer filter. Perform annually or more often , if required.
a. Remove blowoff bushing (E) or cap (F), as required.
b. Remove gasket (B), if required.
c. Remove, clean, and re-install screen (A).
d. Replace gasket (B).
e. Re-install blowoff bushing (E) or cap (F), as required.
11

SINGLE SAFETY SOLENOID SYSTEM (if installed)
12

DOUBLE SAFETY SOLENOID SYSTEM (if installed)
13

14
SECTION VI –TROUBLESHOOTING
(See Section III for troubleshooting of Control Valve.)
Symptom Probable Cause Corrective Action / Remedy
Gradual loss of
heating capacity. Tubes are fouled. Clean tubes per Section III, annual scheduled maintenance.
Excess silt in bottom of tank. Drain and flush tank per Section
III , annual scheduled
maintenance.
Strainers clogged. Clean strainers per Section III,
annual scheduled maintenance.
Pump impellor deteriorated. Repair or replace per separate
O&M.
Overheating.
Temperature regulator has lost its charge, self contained
valves only.
Repair or replace per separate
O&M.
Ruptured tube(s) in heating
coil. Remove / replace heating coil.
Temperature regulator needs
adjusting. Adjust temperature regulator per Section IV.
Circulator not operating. Repair or replace per separate
O&M.
Debris under seat of
temperature control valve. Repair or replace per separate O&M.
Capillary tube pinched on
temperature control. Repair or replace per separate O&M.
Immediate loss of
heating capacity. Capillary tube pinched on temperature control. Repair or replace per separate O&M.
Defective steam trap. Repair or replace per separate
O&M.
Blockage in condensate line. Clean blockage from condensate
line.
Loss of steam pressure to
temperature regulator. Check steam pressure to temperature regulator. Verify
that it is within limits. Adjust as
necessary.
Excessive vibration. High rate of flow beyond
design conditions. Consult factory.
Under sized piping to the
unit. Re-pipe lines to unit using proper sized lines.
Water hammer. Defective steam trap. Repair or replace per separate
O&M.
Undersized condensate lines. Re-pipe condensate line using
proper sized lines.
Insufficient slope on
condensate lines causing
backup.
Increase slope on condensate
lines.
* Red symptom indicates that equipment should be shut down immediately and cause of
malfunction corrected before unit is re-started or serious damage may result.

SECTION VII – MISCELLANEOUS CHARTS AND FORMULAS
METRIC CONVERSIONS
15

P.O. BOX 288
STRATFORD, CT 06615-0288
PHONE: [phone]
FAX: [phone]
INTERNET: http://www.hubbellheaters.com/
16
