Hughes Network HT1000 User manual

INSTALLER PC & MODEM
1. Connect laptop to modem.
2. Open browser and enter 192.168.0.1
3. Click on Information icon that is located on right side of "System Information”.
4. On Advanced Configuration and Statistics page click on “Installation” (listed below Advanced Menu).
5. Click on “Install” on the sub menu.
6. The “Input Parameters” section will be displayed. Enter latitude and longitude. (Lat / Long must be
determined with an onsite GPS device. Do not use any “map” generated GPS location.)
7. Select the satellite, EchoStar-XVII.
8. Click Submit
9. On “Pointing” page, note Elevation, Azimuth, and Antenna Tilt and confirm Uplink Pol (polarization)
settings.
ANTENNA
1. Assemble antenna and set, antenna tilt, elevation, and polarizer as calculated by the modem.
2. Mount antenna and prepare for pointing.
POINTING / DAPT2
1. Connect DAPT2. Voltage display will be approximately 48 volts.
2. Press “3” button for the first time. DAPT2 will display software version, COMM Startup, logging
voltage and eventually “Pointing”.
3. Press “3” to access Pointing Screen. A tone will be audible.
4. Sweep the antenna to acquire satellite signal... The DAPT2 pointing screen will show two values. The
bottom left indicates the highest achieved SQF. The bottom right indicates the current SQF. A SQF
value of 30 or greater indicates acquisition of the satellite beacon. The tone from the DAPT2 will be
louder and the cadence will quicken as the beacon is acquired.
5. Continue to fine point the antenna to gain the highest signal possible by adjusting the fine elevation
and fine azimuth adjustments.
6. Once peaked, carefully lock down antenna by tightening all bolts. Check the SQF to ensure strength
of signal was not reduced during this step.
7. Press “3” and the DAPT2 will display “Store Results?”
8. Press “3” and the DAPT2 will display “Store Yes Adv=Yes?
9. Press “3” and the DAPT2 will display “Pointing Exit?”
10. Press “2” and the DAPT2 will display “Pointing Done”. (This is the only function for the “2” button.
11. Once pointing is done, the system will begin the ranging process; will automatically register the
HT1000 satellite modem and associates with the network. * If ranging fails contact installer support.
12. Depending on the installation site’s location in the Up Link Cell, SQF can vary from as much as 120 in
the center of the cell to 70 at the edge of the cell. The OVT target values can help identify the
expected SQF values for any particular install.
13.Press “NEXT” to continue to Registration. Registration takes place automatically no user
action needed.
Skip to section OVT TERMINAL ACTIVATION ON INSTALLER
HT1000 Quick Install Guide

POINTING / WIRELESS SMART DEVICE
This is a method of pointing using a smart device (phone, tablet, or laptop) connected to
satellite modem through a wireless router (Wi-Fi).
The instructions provided are specifically for the Netgear N150 Wireless Router model
WNR1000v2. The default settings were used and should work with most routers. You may
need to consult your router manufacturer if unable to access the satellite modem.
Perform the following steps to setup the router to work with the HT1000 and a wireless
laptop or smart mobile device. Do not use the Netgear set up disk. The initial setup
must be performed on a computer with a Ethernet Port so that the wireless router can be
wired to the computer. This process only needs to be performed once. Afterward the
Netgear router can be used with any smart mobile device or wireless laptop.
1. Plug in the Netgear wireless router to power.
2. Plug in Ethernet cable from any LAN port to the Ethernet port on a laptop or computer.
3. Access router built-in webserver by entering 10.0.0.1 in URL field of internet browser on
laptop.
4. Login to the Netgear router with username: “admin” and password: “password” (other routers
may use different values)
5. Click on “Wireless Settings” on left side of screen.
6. Change SSID to “HughesOasis”.
7. Click “Apply”, it may ask you to enter your username and password again. Use the same as
above and click “OK”
8. Disconnect Ethernet cable from laptop to wireless router.
Perform the following steps to use any mobile smart device to point and perform terminal
activation.
1. Plug Ethernet cable from satellite modem to WAN port on wireless router.
2. Plugin router to power.
3. On mobile smart device search for available Wi-Fi Signal. Connect to HughesOasis from Wi-
Fi search list.
4. Launch browser on mobile smart device and enter 192.168.0.1 in URL field. The System
Control Center (SCC) should now be displayed.
5. Click on Information icon that is located on right side of "System Information”.
6. On Advanced Configuration and Statistics page click on “Installation” (listed below Advanced
Menu).
7. Click on “Install” on the sub menu.
8. Shown will be the “Input Parameters” section. Enter latitude, longitude and EchoStar- XVII
and click “Submit”. (Lat / Long must be determined with an onsite GPS device. Do not use
any “map” generated GPS location.)
9. On “Pointing” page, note Elevation, Azimuth, and Antenna Tilt and confirm Uplink Pol
(polarization) settings.
10.The screen shows the Max SQF on left and the Current SQF on right.
11.Sweep the antenna to acquire satellite signal... You have found the right satellite when SQF
reaches 30 or higher.
14.Continue to fine point the antenna to gain the highest signal possible by adjusting the fine
elevation and fine azimuth adjustments.
15.Once peaked, carefully lock down antenna by tightening all bolts. Check the SQF to ensure
strength of signal was not reduced during this step.
16.Press “NEXT” to continue to Registration. Registration takes place automatically no user
action needed.

Continue to next section OVT TERMINAL ACTIVATION ON INSTALLER
OVT TERMINAL ACTIVATION ON INSTALLER PC
1. Once the HT1000 completes Registration, Ranging, and Association with the network, two links will
appear: “On Site Validation”and “Terminal Activation”.
Note: You will also see “Waiting for Configuration” and an In-Progress”indicator. Ignore this line.
Continue on with next step. Configuration will continue in the background - no user action is required.
2. Click “On Site Validation Tool”.You will automatically be directed to the Installation Portal.
3. Log into Consumer and Commercial Installation Portal using User Name and Password.
4. At Welcome Page, click "OnSite Validation Tool" link.
5. Enter SAN and FSO from Installation Reference Sheet and click "Submit".
6. Verify site information and enter antenna size and mount type and click “Proceed”.
7. System information including latest and target values being evaluated will be shown. If all values are
met, difference values are all green. Click "Sign Off" (If values are red, see below*).
8. Check box indicating "No Problem" and click" Save and Get Sign-off Code".
9. Record sign-off code on Installation Reference Sheet Click "Exit".
*If values are not met the difference values will appear in red. The OVT will display recommended
actions in the appropriate order helping you to troubleshoot the problem. For each recommended
action, one or two buttons are displayed. Click "Checked" if you checked the action and confirmed
that is not the issue Click "Repair" if you found any problem and completed the repair. The OVT will
update the latest values and recalculate the new difference values. Follow instructions until you obtain
a sign-off code.
10. Close OVT window and click on “Registration” tab (a new window was opened for OVT, you are now
returning to previously opened registration tab).
11. Click “Terminal Activation” link.
12. Enter SAN and PIN and click “Continue”.
13. Verify customer details, confirm if correct.
14. When Terminal Activation Completed is completed a page will be displayed indicating the Terminal
Activation was successful, that the modem will update with the latest software, and then reboot. The
whole process takes about 5 minutes.
15. Go to the System Status page and monitor Software Download Status. When it says “Up To Date”
proceed to the next step.
SERVICE ACTIVATION
1. Disconnect your laptop and connect the satellite modem to customers PC and have the customer
perform Service Activation by following steps below.
2. Enter www.systemcontrolcenter.com in URL field and press enter.
3. Click “Service Activation” Link. If Service Activation link is not visible on main page of SCC then
installer may have to wait up to several minutes to appear.
4. Customer clicks “I accept the Terms & Conditions” and clicks “Continue".
5. Account Registration page is displayed with a “Register” link. The customer will need to Click
“Register”and provide an existing email address or establish a new Hughes email address. Click
“Continue”.
6. Screen will show completing service activation and will, when complete, display the
“myhughesnet.com” home page. Customer can now browse the internet. (This step may a few
minutes to complete.)

7. To test browsing of an insecure website, the customer may open a new window in their browser, type
www.google.com and make sure you can visit this insecure website. Browsing to
www.bankofamerica.com confirms secure website access.
THIS GUIDE IS FOR QUICK REFERENCE ONLY. COMPLETE TECHNICAL INFORMATION IS
AVAILABLE IN THE " HT1000 SATELLITE MODEM INSTALLATION GUIDE” ACCESSABLE AT
THE CONSUMER AND COMMERCIAL INSTALLATION PORTAL.
