HT2000W Wi-Fi Module
User Manual
H57555
Revision A
November 4, 2016
11717 Exploration Lane, Germantown, MD 20876
Phone [phone] Fax [phone]


Copyright © 2016 Hughes Network Systems, LLC
Allrightsreserved.ThispublicationanditscontentsareproprietarytoHughesNetworkSystems,
LLC.Nopartofthispublicationmaybereproducedinanyformorbyanymeanswithoutthe
writtenpermissionofHughesNetworkSystems,LLC,11717ExplorationLane,Germantown,
Maryland20876.
HughesNetworkSystems,LLChasmadeeveryefforttoensurethecorrectnessand
completenessofthematerialinthisdocument.HughesNetworkSystems,LLCshallnotbeliable
forerrorscontainedherein.Theinformationinthisdocumentissubjecttochangewithout
notice.HughesNetworkSystems,LLCmakesnowarrantyofanykindwithregardtothis
material,including,butnotlimitedto,theimpliedwarrantiesofmerchantabilityandfitnessfor
aparticularpurpose.

Trademarks
HUGHESandHughesNetworkSystemsaretrademarksofHughesNetworkSystems,LLC.All
othertrademarksarethepropertyoftheirrespectiveowners.


User Manual
H57555 Revision A 3
Overview
EthernetSwitch:QualcommQCA8337
2.4GHzModule:QCA9563
5GHzModule:QCA9882
AntennaInterface:3xU.FLPCBAntennafor2.4GHz,2xU.FLPCBAntennafor5GHz
I/OInterface:MDI
Features
DualBandWi‐FiAccessPoint
2.4GHz:IEEE802.11N,B,G
50Mbpsminimumatanunobstructeddistanceof20feet
20Mbpsminimumatarangeof50metershorizontaland15metersvertical
Maxpowerof23dBm
5GHz:IEEE802.11A,N,AC
200Mbpsminimumatanunobstructeddistanceof20feet
50Mbpsminimumatarangeof50metershorizontaland15metersvertical
Maxpowerof20dBm


4 User Manual
H57555 Revision A
Compliance information
FCCCaution:Anychangesormodificationsnotexpresslyapprovedbytheparty
responsibleforcompliancecouldvoidtheuser’sauthoritytooperatethis
equipment.
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothe
followingtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)
thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay
causeundesiredoperation.
ForproductavailableintheUSA/Canadamarket,onlychannel1~11canbe
operated.Selectionofotherchannelsisnotpossible.
Thisdeviceisrestrictedforindooruse.
IMPORTANTNOTE:
FCCRadiationExposureStatement:
ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforan
uncontrolledenvironment.Thisequipmentshouldbeinstalledandoperatedwith
minimumdistance20cmbetweentheradiator&yourbody.
IMPORTANTNOTE:
ThismoduleisintendedforOEMintegratoronlyandlimitedtohostwithbrand:
HUGHESandmodel:HT2000W.TheOEMintegratorisstillresponsiblefortheFCC
compliancerequirementoftheendproduct,whichintegratesthismodule.
USERSMANUALOFTHEENDPRODUCT:
Intheuser’smanualoftheendproduct,theenduserhastobeinformedtokeepat
least20cmseparationwiththeantennawhilethisendproductisinstalledand
operated.TheenduserhastobeinformedthattheFCCradio‐frequencyexposure
guidelinesforanuncontrolledenvironmentcanbesatisfied.
Theenduserhastoalsobeinformedthatanychangesormodificationsnot
expresslyapprovedbythemanufacturercouldvoidtheuser'sauthoritytooperate
thisequipment.
LABELOFTHEENDPRODUCT:
Thefinalendproductmustbelabeledinavisibleareawiththefollowing:"Contains
TXFCCID:RAXHT2000W".
TheFCCpart15.19statementbelowhastoalsobeavailableonthelabel:This
devicecomplieswithPart15ofFCCrules.Operationissubjecttothefollowingtwo
conditions:(1)thisdevicemaynotcauseharmfulinterferenceand(2)thisdevice
mustacceptanyinterferencereceived,includinginterferencethatmaycause
undesiredoperation.



User Manual
H57555 Revision A 5

Gain(dBi)
SetAntBrandModelNumberAntennaTypeConnector
2.4GHz5GHz
1YageoANTA0ZZ10511WLAN1PCBI‐PEX3.2
2YageoANTA0ZZ10511WLAN2PCBI‐PEX3.69
3YageoANTA0ZZ10511WLAN3PCBI‐PEX3.6
4YageoANTA0ZZ10511WLAN4PCBI‐PEX 3.9
1
5YageoANTA0ZZ10511WLAN5PCBI‐PEX 3.1
6AirgainN24011HU‐T6L‐PK1‐G165UPCBI‐PEX3.2
7AirgainN24011HU1‐T6L‐PK1‐B90UPCBI‐PEX1.8
8AirgainN24011HUN1‐T6L‐PK1‐W125UPCBI‐PEX1.6
9AirgainN5X011HU2‐T6L‐PK1‐A45UPCBI‐PEX 4.4
2
10AirgainN5X011HU1‐T6L‐PK1‐R120UPCBI‐PEX 4.0
Figure1:Antennalist
