Hughes HX200 User manual

1038054-0001
Revision B
July 7, 2011
HX System
HX200 Satellite Router
Installation Guide

Copyright © 2008, 2011 Hughes Network Systems, LLC
All rights reserved. This publication and its contents are proprietary to Hughes Network Systems, LLC.
No part of this publication may be reproduced in any form or by any means without the written
permission of Hughes Network Systems, LLC, 11717 Exploration Lane, Germantown, Maryland 20876.
Hughes Network Systems, LLC has made every effort to ensure the correctness and completeness of
the material in this document. Hughes Network Systems, LLC shall not be liable for errors contained
herein. The information in this document is subject to change without notice. Hughes Network Systems,
LLC makes no warranty of any kind with regard to this material, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose.
Trademarks
Hughes and Hughes Network Systems are trademarks of Hughes Network Systems, LLC. All other
trademarks are the property of their respective owners. This product is compatible with the Hughes
SPACEWAY system.

• Understanding safety alert messages
1038054-0001 Revision B iii
Understanding safety alert messages
Safety alert messages call attention to potential safety hazards
and tell you how to avoid them. These messages are identified by
the signal words DANGER, WARNING, CAUTION, or
NOTICE, as illustrated below. To avoid possible property
damage, personal injury, or in some cases possible death, read
and comply with all safety alert messages.
Messages concerning
personal injury
The signal words DANGER, WARNING, and CAUTION
indicate hazards that could result in personal injury or in some
cases death, as explained below. Each of these signal words
indicates the severity of the potential hazard.
Messages concerning
property damage
A NOTICE concerns property damage only.
DANGER
DANGER indicates a potentially hazardous situation which,
if not avoided, will result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury.
CAUTION
CAUTION indicates a potentially hazardous situation which,
if not avoided, could result in minor or moderate injury.
NOTICE
NOTICE is used for advisory messages concerning possible
property damage, product damage or malfunction, data loss, or
other unwanted results—but not personal injury.

• Understanding safety alert messages
iv 1038054-0001 Revision B
Safety symbols The generic safety alert symbol
calls attention to a potential personal injury hazard. It appears
next to the DANGER, WARNING, and CAUTION signal words
as part of the signal word label. Other symbols may appear next
to DANGER, WARNING, or CAUTION to indicate a specific
type of hazard (for example, fire or electric shock). If other
hazard symbols are used in this document they are identified in
this section.

• Contents
1038054-0001 Revision B v
Contents
Understanding safety alert messages . . . . . . . . . . . . . . . iii
Messages concerning personal injury. . . . . . . . . . . . . . . . . . . . . iii
Messages concerning property damage . . . . . . . . . . . . . . . . . . . iii
Safety symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Chapter 1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Scope and audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
HX200 satellite router overview . . . . . . . . . . . . . . . . . . . . . . . . .1
HX200 for stabilized platforms . . . . . . . . . . . . . . . . . . . . . . . .2
HX200 features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Transmission types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
DVB-S2 compliant outroute. . . . . . . . . . . . . . . . . . . . . . . . . . .4
Mobility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Signal and data interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
HX200 specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Physical, satellite, and mechanical specifications . . . . . . . . . .5
Transmitter and receiver specifications . . . . . . . . . . . . . . . . . .6
DVB-S2 compliant outroute rates and ratios . . . . . . . . . . . . . .7
Installation and commissioning . . . . . . . . . . . . . . . . . . . . . . . . . .7
Contact information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Chapter 2
Assembling and connecting HX200 hardware . . . . . . .11
Preparing for the installation . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Items required for installation . . . . . . . . . . . . . . . . . . . . . . . .11
Items required for stabilized platforms. . . . . . . . . . . . . . . . . .11
Seatel antenna. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Azimuth antenna. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Confirming installer laptop and site requirements . . . . . . . . .12
Installer laptop requirements . . . . . . . . . . . . . . . . . . . . . . .12
Remote site requirements . . . . . . . . . . . . . . . . . . . . . . . . . .12
Conducting the site survey . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Connecting the receive and transmit cables . . . . . . . . . . . . . . . .13
Connecting radio cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Connecting the Ethernet and power cables . . . . . . . . . . . . . . . .14
Serial port interface connections . . . . . . . . . . . . . . . . . . . . . . . .15
Connecting the hardware for stabilized platforms . . . . . . . . . . .16

• Contents
vi 1038054-0001 Revision B
Powering up and observing the LEDs . . . . . . . . . . . . . . . . . . .18
Stabilized platforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Chapter 3
Commissioning the HX200 satellite router . . . . . . . . . .21
Manual commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Accessing the manual commissioning interface. . . . . . . . . . .22
Entering Satellite Parameters . . . . . . . . . . . . . . . . . . . . . . .27
Entering VSAT Parameters . . . . . . . . . . . . . . . . . . . . . . . .28
Entering LAN Parameters . . . . . . . . . . . . . . . . . . . . . . . . .29
Entering Management Parameters . . . . . . . . . . . . . . . . . . .30
Entering Receive Radio Parameters . . . . . . . . . . . . . . . . . .31
Entering Transmit Radio Parameters . . . . . . . . . . . . . . . . .32
Set Maximum Tx Power/Minimum Attenuation . . . . . . . . . .33
NOC override . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Error checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Antenna pointing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Satellite-based commissioning . . . . . . . . . . . . . . . . . . . . . . . . . .37
Obtaining an IP address from the HX200 satellite router . . .37
Uploading the SBC configuration file to the HX200 . . . . . . .39
Commissioning the HX200 . . . . . . . . . . . . . . . . . . . . . . . . . .41
Chapter 4
Completing the installation . . . . . . . . . . . . . . . . . . . . . . .55
Confirming that all files are current . . . . . . . . . . . . . . . . . . . . . .55
Connecting the HX200 satellite router to a computer . . . . . . . .56
Unable to access enterprise resources . . . . . . . . . . . . . . . . . .56
Printing the System Information page . . . . . . . . . . . . . . . . . . . .57
Creating a shortcut to the System Control Center . . . . . . . . . . .58
Chapter 5
The System Control Center . . . . . . . . . . . . . . . . . . . . . .61
Accessing the System Control Center . . . . . . . . . . . . . . . . . . . .61
System Control Center Home page . . . . . . . . . . . . . . . . . . . . . .62
System indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
System Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Diagnostic Utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
System Status page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Reception Information page . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Receive status messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Transmission Information page . . . . . . . . . . . . . . . . . . . . . . . . .70
Transmit status messages . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
System Information page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

• Contents
1038054-0001 Revision B vii
Connectivity Test page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Optional Features Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Firewall Configuration page. . . . . . . . . . . . . . . . . . . . . . . . . .78
Understanding how the firewall works. . . . . . . . . . . . . . . .80
Firewall rule restrictions. . . . . . . . . . . . . . . . . . . . . . . . .80
Creating firewall rules . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Modifying and deleting firewall rules . . . . . . . . . . . . . . . .82
Enabling and disabling the firewall . . . . . . . . . . . . . . . . . .83
The Firewall Statistics page . . . . . . . . . . . . . . . . . . . . . . . . . .83
Viewing firewall statistics . . . . . . . . . . . . . . . . . . . . . . . . .84
Resetting firewall statistics counters . . . . . . . . . . . . . . . . .84
Port Forwarding Configuration page . . . . . . . . . . . . . . . . . . .85
Understanding port forwarding . . . . . . . . . . . . . . . . . . . . .85
Port forwarding rule restrictions. . . . . . . . . . . . . . . . . . .86
Creating port forwarding rules . . . . . . . . . . . . . . . . . . . . . .86
Modifying and deleting port forwarding rules . . . . . . . . . .87
Help page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
Advanced pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Chapter 6
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
HX200 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
LED appearances during normal operation . . . . . . . . . . . . . .92
Connectivity problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Cannot access the System Control Center . . . . . . . . . . . . . . . . .96
Computer is connected directly to the satellite router . . . . . .96
Satellite router is connected to an Ethernet device. . . . . . . . .97
Cannot access network resources . . . . . . . . . . . . . . . . . . . . . . . .97
Accessing the System Control Center . . . . . . . . . . . . . . . . . .98
Confirming that the satellite router is commissioned. . . . . . .98
Checking the receive signal . . . . . . . . . . . . . . . . . . . . . . . . . .98
Weather and signal strength . . . . . . . . . . . . . . . . . . . . . . . .98
Checking the transmit signal . . . . . . . . . . . . . . . . . . . . . . . . .98
Checking that TCP Acceleration is operational . . . . . . . . . . .99
Checking that Web Acceleration is operational . . . . . . . . . . .99
Checking system gateway connectivity . . . . . . . . . . . . . . . .100
Checking enterprise network connectivity . . . . . . . . . . . . . .101
Checking DNS settings. . . . . . . . . . . . . . . . . . . . . . . . . . .102
Checking for viruses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
No browsing issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Hot cable connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Slow transmission speed or intermittent operation . . . . . . . . .104

• Contents
viii 1038054-0001 Revision B
Appendix A
Configuring a Windows computer to support
DHCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Windows XP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
Appendix B
Updating the satellite router software . . . . . . . . . . . . .111
Saving the utility on the installer laptop. . . . . . . . . . . . . . . . . .111
Configuring the TCP/IP properties on the installer laptop. . . .112
Windows XP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115
Updating the fallback.bin file. . . . . . . . . . . . . . . . . . . . . . . . . .117
Troubleshooting the update . . . . . . . . . . . . . . . . . . . . . . . . . . .119
Appendix C
Disabling a Web browser proxy connection . . . . . . . .121
Internet Explorer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
Firefox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
Appendix D
Azimuth antenna setting and software version. . . . . .125
Antenna setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Software version. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126
Appendix E
Seatel antenna settings and software version . . . . . . .129
Software version. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .130
Appendix F
Troubleshooting NMEA and TX mute/RX lock
cable issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .133
Appendix G
LNB selection reference. . . . . . . . . . . . . . . . . . . . . . . . .135
Appendix H
Conforming with standards and directives . . . . . . . . .139
TIA IPoS standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139
Certifications and cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . .139
Safety-operating conditions for Canada . . . . . . . . . . . . . . . .140
Repairs in Canada. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .140
Safety, emission, and immunity standards . . . . . . . . . . . . . .140
Canada Class B warning. . . . . . . . . . . . . . . . . . . . . . . . . .141
FCC part 15 notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .141
R&TTE notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142

• Contents
1038054-0001 Revision B ix
Material compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
RoHS compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
RoHs compliance with exemptions . . . . . . . . . . . . . . . . . . .142
Acronyms and abbreviations . . . . . . . . . . . . . . . . . . . .145
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .147

• Contents
x1038054-0001 Revision B

Chapter 1 • Introduction
1038054-0001 Revision B 1
Chapter 1
Introduction
Scope and audience This manual explains how to install, commission, and service the
Hughes HX200 satellite router.
This manual is intended for use by the following audiences:
•Professional installers
•Installer trainers, who prepare separate instructions for the
installers
•Call center operators, who respond to customers’ calls
•Call center trainers, who train call center operators
HX200 satellite router
overview
The HX200, as shown in Figure 1 on page 2, is a
high-performance satellite router designed to support provide
carrier-grade IP services using dynamically assigned
high-bandwidth satellite IP connectivity. The HX200 supports
high-bandwidth links with star capability and quality of service
(QoS) features such as Min/Max CIR together with dynamic
allocation of bandwidth. With integrated IP features including
RIPv1, RIPv2, BGP, DHCP, NAT/PAT, and DNS Server/Relay
functionality, together with a high-performance satellite modem,
the HX200 is a full-featured IP router. The HX200 enables
superior IP connectivity for a variety of applications including:
•Cellular backhaul
•MPLS extension services
•Virtual leased line
•Maritime, air, and ground-based mobile networks
The HX200 satellite router provides two 10/100 LAN ports. The
Ethernet LAN port and the 10/100 LAN ports can be connected
via a straight-through or crossover Cat-5 cable to a single
computer or to an Ethernet hub/switch port.
The HX200 is completely self-contained requiring no external PC
to host any functions or software. The software is automatically
updated from the Network Operations Center (NOC).

Chapter 1 • Introduction
21038054-0001 Revision B
An optional rack mount kit is available for the HX200, which
allows the HX200 to be installed in an industry standard 19”
(0.45 m) rack.
HX200 for stabilized
platforms
An enhancement to the HX200 supports stabilized platforms for
the Coastal Maritime Service. In this capacity the HX200 uses
either the Seatel DAC 220 antenna or the Azimuth KNS-150
antenna.
HX200 features A low cost self-hosted device HX terminal with MIPS processor.
•Transmission types:
– Linear Ku-band
– Linear C-band
Figure 1: HX200 satellite router (front and back)

Chapter 1 • Introduction
1038054-0001 Revision B 3
– Saturated Ku-band
– Saturated C-band
•DVB-S and DVB-S2 compliant outroutes
•Mobility
The HX200 satellite router provides support for the following
capabilities:
•L-band transmitter
•Serial NMEA interface to global positioning system (GPS)
•Inroute spreading
– 256 Ksps X 2
– 256 Ksps X 4
– 512 Ksps X 2
– 512 Ksps X 4
– 1024 Ksps X 2
– 1024 Ksps X 4
– 2048 Ksps X 2
Transmission types The HX200 supports both saturated and linear transmit outdoor
units (ODUs).
Table 1: Radios and LNBs
Description Vendor Hughes product
number
Saturated Ku-Band Radios
TG 2W, 2M. DOM HNS 1500192-0221
TG 2W, 1M, EUT HNS 1500192-0122
TG 2W, 1M, INT HNS 1500192-0123
1W Pure Anubis/LNB/Tria HNS 1500172-0101
2W Pure Anubis/LNB/Tria HNS 1500172-0102
Saturated C-Band Radios
2W MTI (India-C) HNS 1028050-0006
2W MTI (Extended-C) HNS 1036720-0001
Linear Ku-Band Radios
1W Linear BUC NJRC / NJT5115F 9506265-0001
2W Linear BUC NJRC / NJT5037F 9506221-0001
3W Linear BUC NJRC / NJT5116F 9506252-0001
4W Linear BUC NJRC / NJT5017FL 9502667-0002
4W Linear BUC/Tria/LNB Andrew Corp /
DRU15F16HX
1502302-0001
6W Linear BUC NJRC / NJT5127N 9505264-0001
8W Linear BUC NJRC / NJT5118N 9506220-0001

Chapter 1 • Introduction
41038054-0001 Revision B
DVB-S2 compliant outroute The HX200 receives a single Digital Video Broadcast - second
generation (DVB-S2) compliant outroute.
Mobility The HX200 provides doppler compensation for radial speeds up
to 150 mph.
Signal and data interfaces The following signal and data interfaces are supported:
•Dual 10/100 Ethernet LAN ports with Auto-MDIX support,
configurable as a two-port switch or as two independent LAN
segments
•EIA-232 receive and transmit ports for control signaling in
Maritime applications
•EIA-232 receive and transmit ports for communication to a
GPS terminal
•10MHz reference circuitry allows simultaneous receive and
transmit of 10MHz reference to/from the rear panel
– 10 MHz reference clock output
– 10 MHz reference clock input
Linear C-Band Radios
5W Linear BUC NJRC / NJT5669F 9502666-0001
10W Linear BUC NJRC/ NJT5762N 9506222-0001
Ku-Band Low Stability LNBs
Dom/Intl LNB MTI 1500320-0006
Intelsat MTI 1500287-0001
AsiaSat/Eutelsat MTI 1500287-0003
Universal Ku-Band LNB Invacom 1501882-0002
C-Band Low Stability LNBs
Extd C-Band LNB MTI 1024573-0001
India C-Band LNB HNS (MTI) 1024573-0002
Ku-Band Internal PLL (High Stability) LNBs
Universal Ku Band HS LNB ASC / 1501654-0001
Ku-Band External Reference PLL LNBs
Domestic Ku Band PLL LNB Invacom / SPV-65SM 1502442-0002
Intelsat Ku Band PLL LNB Invacom / SPV-55SM 1502442-0001
Asia/Eutelsat Ku Band PLL LNB Invacom / SPV-75SM 1502442-0003
C-Band External Reference PLL LNBs
C Band PLL LNB Norsat / 3020XF 1502443-0001
Table 1: Radios and LNBs (Continued)
Description Vendor Hughes product
number

Chapter 1 • Introduction
1038054-0001 Revision B 5
•100 to 253 V AC input through detachable power cord
•48 V power supply DC voltage input port for supporting > 5
W radios
HX200 specifications
Physical, satellite, and
mechanical specifications
Table 2 lists the physical, satellite, and mechanical specifications
for the HX200 satellite router.
Table 2: HX200 satellite router specifications
Product element Specification
Physical Interfaces
Two 10/100 BaseT Ethernet LAN RJ45 ports (independent subnets)
One Serial Port (RS-232)
Satellite Specifications
Outbound Channel DVB-S2 with Adaptive Coding and Modulation
Outbound Rate 1-45 Msps (in 0.5 Msps steps)
Outbound Modulation QPSK, 8PSK (Adaptive Modulation)
Outbound Coding BCH with LDPC 3/5, 1/2, 2/3, 3/4, 5/6, 8/9, 9/10 (Adaptive Coding)
Inbound Channel IPoS (FDMA/TDMA)
Inbound Channel Rate 256, 512, 1024, 2048, 4096, 6144 ksps
Inbound Channel
Modulation
OQPSK
Inbound Channel
Coding
Rate 1/2, 2/3, 4/5 with TurboCode (Adaptive Coding)
Bit Error Rate (Receive) 10-7 or better
Bit Error Rate
(Transmit)
10-5 or better
Interface to ODU Industry standard BUC qualified by Hughes (L-Band)
or Hughes saturated carrier BUC
Mechanical and Environmental
Weight 5.5 lb (2.5 kg)
Height 1.5 inches (3.8 cm)
Width 12.5 inches (32 cm)
Depth 15 inches (38 cm)
Safe operating
temperature range
5 to 40°C (Above 5000 ft altitude, reduce maximum temperature by 1°C per
1000 ft)
Safe operating humidity
range
5% to 95% non-condensing
Safe altitude 10,000 ft
Cooling method Dual fan
Protocol support TCP/IP (Transmission Control Protocol/Internet Protocol) protocol suite

Chapter 1 • Introduction
61038054-0001 Revision B
Transmitter and receiver
specifications
Tables 3 and 4 list the HX200 transmitter specifications and
receiver specifications, respectively.
Table 3: HX200 Transmitter Specifications
Property Value
Linear transmit radio
L-band output frequency range 950 — 1700 MHz
L-band output with OQPSK modulation
Supported inroutes Up to 6 MSPS turbo coded inroutes
Designed to operate with commercially off-the-shelf L-band
linear BUCs qualified by HNS
IPoS output frequency ranges • 107.42187 - 113.28125 MHz inclusive
• 81.25 - 89.236 MHz inclusive
• 105.078125-109.765625 MHz
• 230.46875 - 234.375 MHz inclusive
Frequency step size 100 Hz
Maximum RF output power 0 dBm at 0 dB TX attenuation
IF coaxial Interface F-type female connector
IF impedance 75 ohm
Transmit power control range 40 dB in 0.5 dB increments
Table 4: HX200 Receiver Specifications
Property Value
IFL cable Accepts block down-converted TDM signal via the IFL cable
Input frequency range 950 MHz - 2150 MHz
QPSK and 8PSK with DVB-S2
DVB-S2 reception up to 45 Msps BCH and LDPC decoding
IF coaxial interface F-type female connector
IF impedance 75 ohm
Minimum input level -74 dBm (per carrier at 1 Msps)
Maximum input level -20 dBm (per carrier at 45 Msps); -8 dBm (composite)
(When using a 1.8m or larger antenna with this indoor unit
(IDU), use 100 ft minimum of RG-11 IFL cable.)

Chapter 1 • Introduction
1038054-0001 Revision B 7
DVB-S2 compliant outroute
rates and ratios
The HX200 receives a single Digital Video Broadcast - second
generation (DVB-S2) compliant outroute as defined in Table 5.
The HX200 supports Constant Coding and Modulation (CCM)
and Adaptive Coding and Modulation (ACM) on the outroute.
Installation and
commissioning
The installation and commissioning of the HX200 satellite router
is a multi-step process. The workflow and chapter reference
numbers for the process steps follow.
1. Preparing the satellite router for installation
Chapter 2 on page 11
2. Assembling the HX200 satellite router
Chapter 2 on page 11
3. Commissioning the HX200 satellite router
Chapter 3 on page 21
4. Connecting the satellite router to a computer
Chapter 4 on page 55
Table 5: Outroute rates and ratios
Encap-
sulation
Signaling
Rates Modulation FEC Mode Rate BER/PER
Acquisi-
tion
(sec)
DVB-S2 1 – 4 Msps
(in 1 Msps
steps)
• QPSK
• 8-PSK
LDPC/BCH
Short and
Normal FEC
frame
• 1/2, 3/5, 2/3,
3/4, 4/5, 5/6,
8/9, 9/10**
• 3/5, 2/3, 3/4,
5/6, 8/9,
9/10**
QEF PER < 1E-7 10
DVB-S2 5-35 Msps
(in 1 Msps
steps)
• QPSK
• 8-PSK
LDPC/BCH
Short and
Normal FEC
frame
• 1/2, 3/5, 2/3,
3/4, 4/5, 5/6,
8/9, 9/10**
• 3/5, 2/3, 3/4,
5/6, 8/9,
9/10**
QEF PER < 1E-7 1
DVB-S2 35-45 Msps
(in 1 Msps
steps)
• QPSK
• 8-PSK
LDPC/BCH
Short FEC
frame
• 1/2, 3/5, 2/3,
3/4, 4/5, 5/6,
8/9
• 3/5, 2/3, 3/4,
5/6, 8/9
QEF PER < 1E-7 1
DVB-S2 35-45 Msps
(in 1 Msps
steps)
• QPSK LDPC/BCH
Normal FEC
frame
• 1/2, 3/5, 2/3,
3/4, 4/5, 5/6,
8/9, 9/10
QEF PER < 1E-7 1
** 9/10 supported for Normal codeblock only.

Chapter 1 • Introduction
81038054-0001 Revision B
Commissioning is the process of registering an HX200 satellite
router for service. During the commissioning process you may
use auto selection or manual entry of parameters.
•Auto Selection - Allows you to choose the Network Access
Provider (NAP) from a predetermined list of providers. Many
of the commissioning parameters are automatically
configured for the provider chosen.
•Manual Entry - This mode requires you to enter all
parameters manually.
Contact information If you experience installation problems with the HX200 satellite
router, try the Diagnostic Utilities on page 64.
For warranty or repair support, the contact information varies
depending on the location. If the customer needs service,
warranty or repair support, they should contact their customer
service representative in accordance with their service agreement.
Table 6: Radios and LNBs
Description Vendor Hughes product
number
Saturated Ku-Band Radios
TG 2W, 2M. DOM HNS 1500192-0221
TG 2W, 1M, EUT HNS 1500192-0122
TG 2W, 1M, INT HNS 1500192-0123
1W Pure Anubis/LNB/Tria HNS 1500172-0101
2W Pure Anubis/LNB/Tria HNS 1500172-0102
Saturated C-Band Radios
2W MTI (India-C) HNS 1028050-0006
2W MTI (Extended-C) HNS 1036720-0001
Linear Ku-Band Radios
1W Linear BUC NJRC / NJT5115F 9506265-0001
2W Linear BUC NJRC / NJT5037F 9506221-0001
3W Linear BUC NJRC / NJT5116F 9506252-0001
4W Linear BUC NJRC / NJT5017FL 9502667-0002
4W Linear BUC/Tria/LNB Andrew Corp /
DRU15F16HX
1502302-0001
6W Linear BUC NJRC / NJT5127N 9505264-0001
8W Linear BUC NJRC / NJT5118N 9506220-0001
Linear C-Band Radios
5W Linear BUC NJRC / NJT5669F 9502666-0001

Chapter 1 • Introduction
1038054-0001 Revision B 9
10W Linear BUC NJRC/ NJT5762N 9506222-0001
Ku-Band Low Stability LNBs
Dom/Intl LNB MTI 1500320-0006
Intelsat MTI 1500287-0001
AsiaSat/Eutelsat MTI 1500287-0003
Universal Ku-Band LNB Invacom 1501882-0002
C-Band Low Stability LNBs
Extd C-Band LNB MTI 1024573-0001
India C-Band LNB HNS (MTI) 1024573-0002
Ku-Band Internal PLL (High Stability) LNBs
Universal Ku Band HS LNB ASC / 1501654-0001
Ku-Band External Reference PLL LNBs
Domestic Ku Band PLL LNB Invacom / SPV-65SM 1502442-0002
Intelsat Ku Band PLL LNB Invacom / SPV-55SM 1502442-0001
Asia/Eutelsat Ku Band PLL LNB Invacom / SPV-75SM 1502442-0003
C-Band External Reference PLL LNBs
C Band PLL LNB Norsat / 3020XF 1502443-0001
Table 6: Radios and LNBs
Description Vendor Hughes product
number

Chapter 1 • Introduction
10 1038054-0001 Revision B
