HUHD HW-399M User manual

Optical wireless gaming headset instruction manual
Item name : 2.4G optical wireless gaming headset Model : HW-399M
A、For PS4 console
B、Product & accessories :
A、Headset ------------------------1PCS
B、Transmitter---------------------1PCS

C、Detachable Microphone----------1PCS
D、Micro USB-USB short cable -----1PCS
E、Micro USB-USB long cable -----1PCS
F、Optical cable------------------1PCS
C , Connection ports function ：
Transmitter
1、Optical port
2、MICRO USB port
3、Working indicating light（Flashing during pairing , solid blue light paired in use , solid
red light while mic muted ）
Headset
1、3.5mm Microphone port
2、3.5mm XBOX port
3、Working indicating light（Flashing during pairing , solid blue light paired in use , solid
red light while mic muted ）
4、Power button ( long press 3 seconds to power on )
5、Mic mute + pairing button
6. Game sound volume switch
7. Chatting sound volume switch
8、USB charging port
9、Charging indication （red light on during charging ,red light off after fully charge ）
D、Connection method ：
1、First of all , connect Micro USB-USB long cable to DC 5V charging adaptor USB port to charge
headset for around 5 hours, red light on during charging and off after fully charge .

2、Connect PS4 optical port with Transmitter optical port using Optical cable
（protection cover must be removed ) ；Using Micro USB short cable to connect PS4 USB
port with Transmitter USB port as below ：
3、Detail connection diagram ：

E、PS4 console setting :
1、After power on PS4 , choose setting
2、Choose Sound and Screen and press Enter

3、Choose Audio Output Settings and press Enter
4、Choose Primary Output Port and press Enter

5、Choose DIGITAL OUT (OPTICAL) and press Enter
6、Remove √tick mark in front of “Dolby Digital 5.1ch”及“DTS 5.1ch”。

7、Choose Audio Format (Priority) and press Enter
8、Choose“Linear PCM and press Enter

9、Then choose setting and choose Devices and press Enter
10.Choose Audio Devices and press Enter

11、Choose Output to Headphones and press Enter
12、Choose Chat Audio and press Enter

F、Operation method ：
1、Connect transmitter and PS4 console USB port using the short USB cable ,light flashing .
2、Long press power button for 3 seconds to power on the headset , the headset should auto
pair with the transmitter and solid blue light light up , if the headset light keep flashing ,
please pair them once again .
3、During pairing , please power on PS4 and do not play audio , place headset close to transmitter
within 50 cm and long press mute button on headset for 5 seconds and release your finger when
light keep fast flashing , then the light on transmitter and headset will become solid blue.
4、Default setting for mute is off ( chat on ), if you want to mute your chat voice , please
press the mute button once and transmitter light will become red
5、Volume adjusting switch allow you to adjust the game background and chat volume .
G、Specification :
Transmitter ：
Working voltage ：5V
Working current : 75mA
Frequency range ：2.4-2.483 GHz
Transmission delay ：2MHz
Transmission power : 8 dBm
Transmission distance: ≥10M , 360°
Receiving frequency ：-85dBm
Headset ：
Working voltage ：3.5-4.2V
Working current: 75 mA
Li battery capacity ：1200 mAh
Continuous working hours ：15h
Charging hours ：≈5h
Frequency range ：2.400-2.483 GHz
Transmission delay ：2MHz
Transmission power: 3dBm
Receiving frequency ：-85dBm
Speaker diameter ：Ф40mm
Speaker impedance ：32Ω
Speaker frequency response : 20～20KHz
Microphone specification :6*2.7mm
Microphone sensitivity : -52dB
Microphone direction : OMNI directional
Microphone frequency response : 100Hz-8KHz
H , Common issue and solution
Common issue
Solution
1) Can’t power on
headset
2) Charging light off
1、Long press power on button for 3 seconds
2、Using USB cable to charge the headset , charging red indicating
light on during charging and off after fully charge at about 5 hours

charging
Power off after 10 mins
Fully charge headset for 5 hours before use
No background sound
1.Optical cable not connected correctly , please remove protection
cover and connect with right direction
2.please make sure console setting will be :-Use HDMIcable to connect
with PS4 and TV-Use fiber-optical cable to connect with PS4 and
transmitter;- Use the USB cable to connect with the transmitter and
USB port of PS4；make sure the console setting is right also :
Settings--Sound and Screen--Audio Output Settings-- ①Primary
Output Port--DIGITAL Out(OPTICAL)--Delete √“Dolby Digital 5.1ch”
and “DTS 5.1ch”②Audio Format(Priority)--Linear PCM
Settings -- Devices -- Audio Devices -- Output to
Headphones-- Chat Audio
No mic sound
1. Plug in microphone for headset
2、Use short USB cable for audio transmission
3、Setting issue : Settings-Accessory Settings-Audio
Device Settings-Input Device and Output Device
Select all options: 2.4G Wireless headset---OK
4、Mic being muted , press the mute/pair button to active mic sound
