HUHD HW-S2 User manual

Instruction Manual
Description: virtual 7.1 channel surround sound 2.4Ghz wireless gaming
headset
Model: HW-S2
1. Product accessories:
Headset (S2) -------------------------------------------1PCS
Transmitter -------------------------------------------1PCS
Micro USB-USB connecting line -------------------1PCS
3.5(4P)-3.5(4P) sound signal connecting line------1PCS
2. Function overview:
Transmitter:
1) Operating indicator light
2) Mute indicator light
3) USB plug
-When the headset is not paired with the transmitter, the red and blue lights are
flashing to prompt the user to pair;
-When they are paired well, the blue light(1) is on;
-When activate the mute function, the red light (2) is on;
-When the headset battery is low, the red light(1) is flashing quickly.

Headset
1) USB charging port
2) Charging indicator light
3) 3.5mm audio port
4) Power on/off switch
5) 2.0/7.1/mute switch:
- Turn upward: virtual 7.1 surround sound
- Turn downward: stereo sound
- Middle: mute on/off
6) Volume/pairing switch:
-Turn upward +: increase the volume
-Turn downward -: reduce the volume
-Middle: to press the middle to pair the headset and transmitter.
Warning:
-When charge the headset, the indicator light is red;after finished charging, the
LED light is off.
-When the headset is not paired with transmitter, the LED light on headset is
flashing in blue; when they are paired well, the blue LED light is on.
-When the blue light on headset is flashing slowly and the red light on
transmitter is flashing fast, it means the battery is low and please charge the
headset promptly.

3.Charging method
Please use Micro USB-USB ( )cable to connect the headset ( )and the USB
power source (DC 5V) for charging; when it is charging , the charging indicator light
is on; it takes around 5 hours to complete charging; when it is fully charged, the red
light is off.
4.Pairing:
1). Unplug the transmitter and power off the headset.
2). Power on the headset, LED indicator light is flashing.
3). Press and hold the pairing button on the headset, the LED lighting is fast
flashing.
4). Plug transmitter into PC for pairing
5). When pairing is successful, the transmitter will restart and headset will
power off automatically.
6). Power on the headset, the headset and transmitter finish pairing.

5. Operation:
1）Insert the transmitter into the USB port of the device,the operation indicator
light is flashing;
2）Power on the headset, if the headset and transmitter were paired , they are
connected automatically; If the headset and transmitter were never paired, the
indicator lights of both headset and transmitter are flashing slowly. Then
please follow up above pairing procedure.
3)To turn upward/downward the Volume/pairing switch ( ) to adjust the
volume of headset；
4) 2.0/7.1 /mute switch:
- Turn upward: virtual 7.1 surround sound
- Turn downward: stereo sound
-The default for microphone is on. Press Mute button once, the microphone
is mute;press again to activate the microphone（The transmitter is on in
blue)
6. Work with XBOX ONE:
1）Connection:
Use 3.5mm-3.5mm audio cable ( ) to connect the headset and 3.5mm port of
controller of Xbox one.
Warning: when use 3.5mm audio cable to connect with the headset, the headset is
switched to a wired headset, the function keys on headset are disabled.

7. Specifications:
Transmitter:
Operating voltage: 5V
Frequency range: 2.403-2.478GHz
Delay time: 24mS
Transmitting power: +2 dBm
Transmit-receive distance: 10M
Receive sensitivity: -85dBm
Headset:
Continuous operating time: ≥6h
Charging time: ≈5h
Frequency range: 2.403-2.478GHz
Delay time: 24mS
Transmitting power: +2 dBm
Transmit-receive distance: 10M
Receive sensitivity: -85dBm
Diameter of loudspeaker: Ф50mm
Loudspeaker impedance: 32Ω
Frequency response: 20～20KHz
Specification of microphone: 6*2.7mm
Microphone sensitivity: -58dB
Microphone directivity: all directional
Frequency response of microphone: 100Hz-8KHz
Warm tip: the product is kept updated, any differences between the manual
and the actual product, please refer to the actual product. The instruction
manual may be revised in the future, please understand we will not notify it
additionally.
