Huion Inspiroy Q11K v2 User manual

User Manual
For Windows and Macintosh OS

1/ 18 www.huion.com
Precautions
1. Please read this manual carefully before using, and keep it well for future reference.
2. Before cleaning the tablet please unplug the power cord and wipe with a soft damp cloth, do
not use any kind of detergents.
3. Don’t expose this product to water or other liquids. Take care to never spill liquids onto the
tablet and pen. Exposing this product to water or other liquids may cause product malfunction or
electrical shock.
4. Do not place the tablet on where is unstable or a height for children reaching easily in order to
avoid danger. Prevent children from swallowing the pen nib or side switch. The pen nib, side
switch, or other movable parts may accidentally be pulled out if children are biting on them.
5. Power off your tablet in locations where/when electronic devices is not allowed. Because the
tablet may cause other electronic devices to malfunction in some locations where/when the use
of electronic devices is not allowed, such as within an airplane, be sure to turn off the tablet.
6. To protect your tablet and save power, please switch off the power when it is not in use.
7. Do not disassemble the tablet and pen. Do not disassemble or otherwise modify the tablet or
pen. Such action may cause heat generation, ignition, electronic shock, or other damage,
including human injury. Disassembling the product will void your warranty.
8. While getting the components replaced, you are supposed to guarantee that the repairman is
using the substitute components specified by the manufacturer. Unauthorized component
replacement might cause fire, electric shocks or other dangers.
9. Do not insert foreign material into the USB port or any other opening of this product. If a metal
object or foreign material is inserted into a port or other opening of this product it may cause the
product to malfunction or burn out, or cause electronic shock.

2/ 18 www.huion.com
Contents
1. Product Overview............................................................................................................................3
1.1 Tablet Introduction................................................................................................................3
1.2 Product and Accessories.......................................................................................................3
1.3 Tablet Connection .................................................................................................................5
1.4 Driver Installation..................................................................................................................6
1.5 Pen Nib Replacement............................................................................................................6
2. Product Basic Operation .................................................................................................................7
2.1 Using The Pen........................................................................................................................7
2.2 Using the Tablet ....................................................................................................................9
3. Function Setting ............................................................................................................................10
3.1 Device Connection Prompt.................................................................................................10
3.2 Working Area Setting ..........................................................................................................10
3.3 Press Keys Function Setting ................................................................................................12
3.4 Pen Buttons Function Setting .............................................................................................12
3.5 Pressure Sensitivity Setting.................................................................................................13
3.6 Pen Pressure Testing ...........................................................................................................13
3.7 Enable the Windows Ink feature ........................................................................................14
3.8 Data Export and Import ......................................................................................................14
4. Specifications ................................................................................................................................15
5. Trouble Shooting ...........................................................................................................................16
5.1 Possible Breakdowns Related to TABLET ............................................................................16
5.2 Possible Breakdowns Related to SYSTEM...........................................................................16
6. CE and FCC Notice .........................................................................................................................17
7. After-service Contact ....................................................................................................................18

3/ 18 www.huion.com
1. Product Overview
1.1 Tablet Introduction
Thanks for choosing HUION®INSPIROY®Q11K V2 wireless graphics tablet. This is a
new generation of professional battery-free drawing tablet, which can greatly
improve your work efficiency of painting and creation, and full of fun. You can freely
painting and writing, depicting different lines and colors, just as the pen writes on
the paper, which brings you a real shock experience.
To give you a better understanding and using of your tablet, please read this user
manual carefully. The user manual only shows the information under Windows,
unless otherwise specified, this information applies to both Windows and
Macintosh systems.
1.2 Product and Accessories
1.2.1 Graphics Tablet
Press Keys
Work Area
Press Keys Lock
Anti-slip Mats
Name Plate
Micro USB
Power ON/OFF

4/ 18 www.huion.com
1.2.2 Stylus Pen
The stylus pen is a battery-free pen with 8192 levels pressure sensitivity and can
be used without battery.
1.2.3 Wireless Receiver
When using wireless mode, please insert the receiver into your computer and
unplug the USB cable in the same time.

5/ 18 www.huion.com
1.2.4 Accessories
Digital Pen Pen Holder Replacement Nibs
Quick Start Guide Micro USB Cable Pen Nib Clip
1.3 Tablet Connection
1.3.1 Wired Mode Connection
1. Connect the tablet to your computer with USB cable.

6/ 18 www.huion.com
1.3.2 Wireless Mode Connection
1. Insert the wireless receiver to your computer.
2. Toggle the switch down on the left side to power on the tablet.
3. When not using for 15mins, the tablet will enter sleep mode. In this case you
need to toggle the switch off- then switch on to wake the tablet up.
1.4 Driver Installation
1.4.1 OS Support
Windows 7 or later，macOS 10.12 or later
1.4.2 Install Driver
Please download the driver from our website: www.huion.com/download
After finishing installation, you can find the driver icon in the system tray area,
which means the driver was installed successfully; when you connect the tablet to
computer, the icon will change to color , which means the driver has already
recognized the tablet and you can start using it now.
Notice：
1. Before installing, you need to uninstall other driver of similar products, including
the old driver of this product.
2. Before installing, please close all graphics software and anti-virus software to
avoid unnecessary mistake.
1.5 Pen Nib Replacement
The nib will be wear out after using for a long time, then you need to replace a new
nib.

7/ 18 www.huion.com
2. Product Basic Operation
2.1 Using The Pen
2.1.1 Hold the pen
Hold the pen as you hold a normal pen or pencil. Adjust your grip so that you can
toggle the side switch easily with your thumb or forefinger. Be careful not to
accidentally press the switch while drawing or positioning with the pen.
Notice：When not in use, place the pen in the pen case or on the desk. Do not place
the pen on the surface of screen, which may interfere with the use of other screen
cursor positioning equipment, may also cause your computer can not enter the
sleep mode.
2.1.2 Position the cursor
Move the pen slightly above the active area without touching the screen surface,
the cursor will move to the new position accordingly.
Press the pen tip on the screen to make a selection. Tap the screen once with the
pen tip, or touch it to the screen with enough pressure to register a click.

8/ 18 www.huion.com
2.1.3 Click
Use the pen tip to tap once on the screen to register a click. Tap to highlight or
select an item on the screen and double-click to open it.
2.1.4 Move
Select the object, then slide the pen tip across the screen to move it.
2.1.5 Use the side buttons
The buttonson the pen can be set to two different customizable functions.
You can use the buttons whenever the pen tip is within 10mm of the tablet active
area.
You do not have to touch the pen tip to the tablet in order to use the switch.

9/ 18 www.huion.com
2.2 Using the Tablet
2.2.1 Power Switch
1. The power switch was placed on the top left side of the tablet, when you use the
tablet on wireless mode, you need to turn on the power switch before using.
2. When not use the tablet for 15 minutes or press the power button for 3 seconds,
it will enter sleep mode.
3. LED indicator:
When working: White-Detected pen or touch signal, Off-no pen or touch signal,
Red flashes-Voltage is low, need to be charged.
When charging:Red-Charging, Off-Full Charge.
2.2.2 Press Keys
There are 8 press keys on the top left side of the tablet, which you can set the
function on the driver interface according to your own habits, which will help to
improve your work efficiency.
2.2.3 Charging the Tablet
1. Before using the tablet for the first time in wireless mode, you should fully charge
the tablet battery. Do this by connecting the USB cable between tablet and a
primary USB port on your computer, or to a powered USB port.
2. The USB cable is used for charging the battery, and also for operating the tablet
as a wired USB tablet. The battery will charge whenever the USB cable is connected
and the battery is not fully charged.
3. It will take about 7 hours to fully charge an empty battery. The actual charge time
depends on current battery level and tablet use while charging. The battery status
indicator shows RED when charging, and will be OFF when fully charged.
4. Whenever the tablet is connected to computer with USB cable, the wireless mode
will be disabled.
