HULALA HOME SCLS0844 User manual

HULALA
H O M E
01/20
NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for future
reference.
ITEM NO.SCLS0844

MAINTAINANCE AND WARNING
1.Keep furniture away from heat sources.
2.Do not clean furniture with harsh cleaner or polishes.Do not use
detergents,solvents,abrasives,spray packs or leather cleaner.
Use non-color mild soa with warm water to clean spills(Mix 1:10
soap to water).
3.Do not place furniture under direct sunlight,material will possibly
fade over time.
4.Do not use on site dry cleaning machine.Children should not climb
or jump on the furniture.
5.Do not write on furniture that is not protectedby a padded barrier.
6.Not for commercial use,only for residential use.
Weight Limitation
110 LBS
02/20

EXPLOSIVE VIEW
2PEOPLE
03/20
A
B
C
D
E
F
F
G
H
I
J

PARTS LIST
A B CDx1
E F GHx1
I
x1
x1
x1
x2
x1
x1
x1
04/20
J x4

HARDWARE LIST
HARDWARE SPARE LIST
#1 x6
#8
#2 #3 #4
x6
x8 x12 x4
#9 #10 #11
#5
#12
#13
TOOL LIST
#6
#14 #15
x1 x1 x4
x1 x1
x6 x4 x4
x32
x8
x2
M4
05/20
#7 x6
∅6x35mm
M7x50mm
M6x25mm M3.5x14mm ∅8x30mm
∅15x11mm ∅20mm
∅6x35mm M6x25mm M4x35mm
#1 #3 #5
#2 x1
∅8x30mm
#7 x1
M7x50mm
x4 x2
x4 x4
x4
x1
#8 x6
#9 x1
∅15x11mm
∅20mm
#13 x1

#1
#1x6
#1
#1
#1
#15
ASSEMBLY INSTRUCTIONS
STEP-1
06/20
#1 x6 #2 x4
∅6x35mm ∅8x30mm
#4 x2 #15 x1
#1
#5
#5
#4x4
#15
#4x2
Insert wooden dowel #2 into the corresponding hole of top panel（A）as picture show，
and then screw bolt #1 into the corresponding hole of top panel(A),tighten it with
screwdriver#15.
Use screw #4 to attach part #4 to the corresponding hole of top panel(A),tighten screw#4
with screwdriver#15.

ASSEMBLY INSTRUCTIONS
STEP-2
07/20
#8 x2
∅15x11mm
#15 x1
Insert panel(E) into the corresponding hole of panel(A),and then insert cam bolt #8 into
the corresponding hole of panel（E),tighten cam bolt #8 with screwdriver #15.

ASSEMBLY INSTRUCTIONS
STEP-3
08/20
C
D
#8 #9
#8 #9
#9
#9
#8
#8
#8 x4
∅15x11mm
#15 x1
#8 #15 #9
#9 x4
∅20mm
Insert side panel(C)&(D) into the corresponding hole of panel(A),and then insert
cam bolt #8 into the corresponding hole of panel(C)&(D),tighten cam bolt #8 with
screwdriver #15.

ASSEMBLY INSTRUCTIONS
STEP-4
09/20
C
D
E
F
F
#2 x4
∅8x30mm
#2
#2
#2
#2
Carefully align and slide panel (F) into the groove along rear edge of pre-assembled step 3,
and insert wooden dowel #2 into the corresponding hole of panel (C)&(D).

ASSEMBLY INSTRUCTIONS
10/20
C
D
F
#7 x6
M7x50mm
#7
#7
#7
#7
#7
#7x6
#14
#14 x1
M4
Use bolt #7 to attach panel (B) to side panel (C)&(D),make sure all holes aligned and
tighten bolt #7 with allen key#14.

ASSEMBLY INSTRUCTIONS
STEP-6
11/20
#14
C
D
#3 x12
M6x25mm
#14 x1
M4
#3
#3x12
Use bolt #3 to attach legs (J) to bottom panel (B),make sure all holes aligned and
tighten bolt #3 with allen key#14.

ASSEMBLY INSTRUCTIONS
12/20
STEP-7
#13
#15
#13
#13
#15 x1
#13
#13
#13
#13
#13
#13
#13
#13
#13 x8
Use screw #13 to attach part #13 to panel(A)&(B)&(C)&(D),tighten it with screwdriver#15.

ASSEMBLY INSTRUCTIONS
13/20
STEP-8
#10 x4
#10
#10
Insert part #10 into the corresponding hole of side panel(C)&(D)，and then attach panel(G)
to it.

ASSEMBLY INSTRUCTIONS
14/20
STEP-9
#4
#4
#5 #15 x1x20
M3.5x14mm
#11 x4
#5
#5
#5x12
#15
#5
Use screw#5 to attach part#11 to the corresponding hole of door(I)&(H) as picture show,
tighten it with screwdriver#15.
#4
#11
#11
#15
#15
#5
#4 x2

ASSEMBLY INSTRUCTIONS
15/20
STEP-10
#15 x1
#6
#6
#6
#15
#6x2
#6x2
#15
#6 x2
Use screw#6 to attach handle#6 to the corresponding hole of door(I)&(H) as picture show,
tighten it with screwdriver#15.

ASSEMBLY INSTRUCTIONS
16/20
STEP-11
#5x8
#15
#5 #15 x1x12
M3.5x14mm
Use screw#5 to attach preassemble door(H)&(I) to the corresponding hole of
side panel(C)&(D) as picture show,tighten it with screwdriver#15.

#15
③
①
ASSEMBLY INSTRUCTIONS
STEP-12
17/20
#15 x1
#12
x4 x2
x4 x4
x8
x1
Use screw③ to attach part① to the corresponding hole of
side panel(C)&(D) as picture show,tighten it with screwdriver#15.
①x2 ③x4
①
③

#15 x1
#15
④
①
④
①
Wall
ASSEMBLY INSTRUCTIONS
STEP-13
18/20
#12
x4 x2
x4 x4
x8
x1
Mark the position on the wall, that corresponds to
the location of part ① on the side panels C,D; Drill and insert the expandable screw ②
by hammer.
Assemble the part ① to the wall. Align the hole in the part ① with the expandable screw
②, use screw ④ to attach it and tighten by screwdriver #15.
①x2 ②x4
②
④x4

19/20
Wall
ASSEMBLY INSTRUCTIONS
STEP-14
#12
x4 x2
x4 x4
x8
x1
Let the plastic belt ⑤ pass through the both part ① and pull tightly.
⑤x2

WARRANTY
1.We strive to offer high-quality products,and we also try our
best to satisfy each and every customer that orders from
us with product or service as needed.
2.We provide 30 days warranty starting from the time you
receive the item.Each customer must provide a record of
their order such as the order number,or item receipt for any
items that are out of the warranty period you may also still
receive.
3.Replacement parts by purchasing them with our company
if they are available.
Are you having difficulty
With assembly?Missing parts?
Please send email with your order No to
[e-mail]
For return,please check the return policy with
the retailer or market place you bought from.
Appreciate your purchasing from us.
Pop up your life by our furniture piece!
20/20
