HULALA HOME SBSD0787 User manual

HULALA
H O M E
01/26
NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for future
reference.
ITEM NO.SBSD0787

MAINTAINANCE AND WARNING
1.Keep furniture away from heat sources.
2.Do not clean furniture with harsh cleaner or polishes.Do not use
detergents,solvents,abrasives,spray packs or leather cleaner.
Use non-color mild soa with warm water to clean spills(Mix 1:10
soap to water).
3.Do not place furniture under direct sunlight,material will possibly
fade over time.
4.Do not use on site dry cleaning machine.Children should not climb
or jump on the furniture.
5.Do not write on furniture that is not protectedby a padded barrier.
6.Not for commercial use,only for residential use.
Weight Limitation
150 LBS
02/26

EXPLOSIVE VIEW
2PEOPLE
03/26
A
B
C
D
E
D
F
G
G
G
G
H
H
I
J
K
H
H
L
M
I
J

PARTS LIST
A B CDx2
E F GH x4
I J K L x1
M
x1
x4
x1
x1
x1
x2
x1
x1
x2
x4
04/26

HARDWARE LIST
HARDWARE SPARE LIST
#1 x88 #2 x10 #3 #4 #5 #6 x10 x20 x10 x4
#7 #8 #9 #10 #11 #12
TOOL LIST
#13 #14 #16 #17
#18 #19x1 x1
x22 x1 x24 x10 x2 x4
x4 x4 x4 x16
M4
05/26
M3.5*14 M7*50 ∅6*35mm ∅8*30mm ∅15*11mm M4*35
M6*50 M6*40 ∅20
#15 x4
#3 x1
∅6*35mm
#1 x8 #2 x1
M3.5*14 M7*50
#7 x2
M6*50
#8 x1
M6*40
#6 x1
M4*35

ASSEMBLY INSTRUCTIONS
STEP-1
06/26
A
#3 #4 x10 x10
∅6*35mm ∅8*30mm
#18 x1
1.Insert wooden dowel #4 into the corresponding hole of panel
(A)，and then screw bolt#3 into the corresponding hole of panel (A)
，tighten bolt#3 with screwdriver#18.

ASSEMBLY INSTRUCTIONS
STEP-2
07/26
A
The rear protrusion of the
rebound member should face
in the direction of the back
panel.
#1 x8
M3.5*14
#13 x4 #18 x1
1.Use screw#1 to attach part#13 to the corresponding hole of top
panel(A),tighten screw#1 with screwdriver#18.And then slide the
rebounder#13 into the rebounder base as picture show.

ASSEMBLY INSTRUCTIONS
STEP-3
08/26
AA
A
C&D&E&F
A
C
D
E
D
F
C&D&E&F C&D&E&F C&D&E&F
#5 x10
∅15*11mm
#18 x1#10 x10
∅20
1.Insert panel(C)&(D)&(E)&(F) into the corresponding hole of top
panel(A) and then insert cam bolt #5 into the corresponding hole of
panel(C)&(D)&(E)&(F),tighten cam bolt#5 with screwdrive#18,finally
stick paster to it for look nice.

ASSEMBLY INSTRUCTIONS
STEP-4
09/26
C
D
E
D
F
G
G
G
G
A
1.Carefully align and slide panel (G) into the groove along rear edge of
pre-assemble unit at step 3,slide the panel (G) into the bottom.

ASSEMBLY INSTRUCTIONS
10/26
B
C
D
E
D
F
G
G
G
G
#2 x10
M7*50
#19 x1
M4
#4 x10
∅8*30mm
1.Insert wooden dowel #4 into the corresponding hole of panel
(C)&(D)&(E)&(F)，and then use bolt #2 to attach panel(B) to the
preassemble unit step 4,tighten bolt #2 with allen key#19.

ASSEMBLY INSTRUCTIONS
STEP-6
11/26
K
L
L
M
M
#8 x1
M6*40
#19 x1
#7 x8
M6*50
#8
#19
#7x8
#19
#7
#7
K
M4
1.Use bolt #8 to attach leg(L) to part(K),tighten bolt #8 with
allen key #19,and then use bolt #7 to attach leg(M) to part(K),make
sure all holes aligned and tighten bolt #7 with allen key #19.

ASSEMBLY INSTRUCTIONS
12/26
STEP-7
G
G
G
G
K
B
C
#19 x1
M4
#7 x14
M6*50
#7
#7
#7
#7 #7
#7
#7
#7
#7
#7
#7
#7
#7
#7x14
#19
#7
#7
1.Use bolt #7 to attach the preassemble step 6 to the corresponding
hole of bottom panel (B),make sure all holes aligned and tighten bolt #7
with allen key #19.

ASSEMBLY INSTRUCTIONS
13/26
STEP-8
Attention:
After installation, adjust the adjustable leveler
to keep the cabinet balanced .
Be sure to check all packing material carefully
for small parts, which may have come loose
inside the carton during shipment.
Attention:
Before the next step, adjust
the feet of the locker to keep
it level.

ASSEMBLY INSTRUCTIONS
14/26
STEP-09
#1x24
#18
#9x24
#9x16
A
F
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1 x24 #9 x24
M3.5*14
#1
#1
#1
#1
#1
#1
#1
#1
1.Use screw #1 to attach part#9 to corresponding panel as picture
show ，tighten screw #1 with screwdriver #18.

ASSEMBLY INSTRUCTIONS
15/26
STEP-10
#17
#17
#17
#17
#17
#17
#17
#17
#17x16
Shelf holder can be
adjusted up or
down
H
H
H
H
#17
#17
#17
#17
#17
#17
#17
#17
#17 x16
1.Insert shelf holder #17 into the corresponding hole of panel as picture
show,and then attach panel (H) to it.

ASSEMBLY INSTRUCTIONS
16/26
STEP-11
#18
#1x8
#14x4
#14 x4 #18 x1
#1 x8
M3.5*14
Attention:
Pay attention to the model of
hinge！
#14
1.Use screw #1 to attach hinge #14 to the corresponding hole of
door(I)&(J),make sure all holes aligned and tighten screw#1 with
screwdriver#18.

#13
ASSEMBLY INSTRUCTIONS
17/26
STEP-12
#13x2
#18
#1x2
#1
#13 x2 #18 x1 #1 x2
M3.5*14
#13
#1
1.Use screw #1 to attach part #13 to the corresponding hole of
door (I)&(J) as picture show ，tighten screw#1 with screwdriver#18.

ASSEMBLY INSTRUCTIONS
18/26
STEP-13
#18
C&F
C&F
I&J
A
A
#1 x16
M3.5*14
#18 x1
I
J
#14
1.Use screw #1 to attach hinge #14 to the corresponding hole of
panel(C)&(F) as picture show ，make sure all holes aligned and
tighten screw#1 with screwdriver#18.
C
F
#14

#15
ASSEMBLY INSTRUCTIONS
19/26
STEP-14
#18
#1x8
#15x4
#15 x4 #18 x1
#1 x8
M3.5*14
Attention:
Pay attention to the model of
hinge！
1.Use screw #1 to attach hinge #15 to the corresponding hole of
door(I)&(J) as picture show ，make sure all holes aligned and
tighten screw#1 with screwdriver#18.

#13
ASSEMBLY INSTRUCTIONS
20/26
STEP-15
#13x2
#18
#1x2
#1
#13 x2 #18 x1 #1 x2
M3.5*14
#13
#1
1.Use screw #1 to attach part #13 to the corresponding hole of
door (I)&(J) as picture show ，tighten screw#1 with screwdriver#18.
