Huler Relax 250W User manual

ManualManual

Assembly
Unpacking
Use
Information for Parents
Terms of Use
Preparing to ride
Protection
Driving away from the place
Ride
Braking
Parking and transport
Safety zone
Ride inconsistent with the intended
Contents:
Remember:
This instruction is inform about the correct use of Our Huler electric kick
scooter..
Following the guidance contained in this manual will prolong durability,
aesthetics, and allow for safe and lawful use(!!!).
Before buying a scooter, and the first time, carefully read the instructions.
Scooter Support
Battery
Charging the battery
Engines
Specifications
Construction
Version Parameters
Battery Parameters
Specifications and performance
Battery indicator
Maintenance
Washing and cleaning scooters
Protecting the environment
Battery Disposal
Warranty
Information
Producer
Adress

Assembly
Unpacking
After removing the electric scooters from the box and set it in a safe position on the foot,
remove from the packaging a key tool to the assembly and securing the steering wheel.
Set the steering wheel according to your preference and security policies according to the terms
of use, growth, driving skills, long arms, legs.
After setting the height and position of the steering wheel, tighten the bolt stem and handlebars.
Set the saddle to Your preferences in accordance with the principles of safety, so as to freely
rate based on the ground. Check the quality of housing and level of depreciation.
Secure the saddle latch bracket located on the saddle. Properly adjusted the latch bolt should
close with a big resistance.
!
!
!
!
!
Remember:
At the time of delivery the scooters battery is usually charged, but before
the first use, it should be completely recharged. Information on battery
charging are given later in this manual.
Use
For Parents
Scooter is designed for people aged over 14.
Electric scooter is designed to move, so you may lose control, fall and/or finding themselves in
a dangerous situation.
If the user's knowledge about the conditions of use and safety rules and the maturity and
common sense is not enough, it can lead to serious injury or death, even while maintaining the basic
safety rules.
This manual contains warnings and important safety precautions and warnings about the
consequences of lack of control or not in accordance with instructions for use of electric scooters.
As a Parent you are responsible for the proper understanding of your children, the
information contained in the instructions and make sure that all users understand all
warnings, instructions and safety rules. If you're not sure you can be sure that your children
are able to safely and responsibly use the electric scooters.
To ensure the safety perform frequent inspections of all moving parts of electric scooters as
described in the manual.
User weight, height, age and social maturity and ability to adhere to safety rules in the
instructions has a significant impact on the degree of safety when driving an electric scooter. Each
user has to perform before the horse and try to repeat it several times to gradually discover and
learn the correct behaviors and reactions, while riding on a scooter electricity.

Terms of Use
Remember:
The vehicle is designed to drive tourism and recreation and sports are not
professionally.
Electric scooter is not suitable for children under 14 years of age.
Do not exceed the maximum total weight of 160kg.
Always check and comply with all local laws and regulations which may
affect the place of use of electric scooters and define the technical
conditions of vehicles that can be put into service on public roads.
Preparing to ride
!The vehicle is not ready to ride, not used in accordance with the instructions, may cause failure
or loss of health.
!Make sure the key is in "OFF" - disabled. Only in this position, you can safely prepare for the
ride.
!Set the vehicle on foot.
!Check all possible to check the mechanical components and terminals.
!Check the meter and battery level.
!Check the position of the steering wheel and set it according to your preferred driving style, and
in accordance with the principles of safety.
!Check the strength of the bracket holding the saddle and handlebar stem.
!Check the steering wheel, moving it left and right investigate whether there is backlash.
!Check the pressure in the tires and tread condition.
!Adjust the mirrors if they are mounted.
!Turn on the lights and check the performance tone.
!Replace and fasten your helmet.
Remember:
The vehicle is not ready to ride, not used in accordance with the
instructions, may cause failure or loss of health.
Remember:
Electric scooter should be kept away from children and remember that it is
intended for use only by persons who can meet the demands posed by the
user during operation.

Protection
!While driving, we recommend the use of conservation measures that meet the requirements
covered by the Directive 89686/EWG
!While driving, we recommend the use of protectors on elbows and knees, and absolute safety
helmet with CE Certificate. Helmet may be legally required by local laws or regulations.
!We recommend the use of clothing with long sleeves, pants and shirts during the long ride and
gloves.
!Always wear athletic shoes (shoes with rubber soles). Shoelaces must always be carefully tied
and away from the wheels and drivetrain. Long scarves, coats and other clothing items can not
be waving loosely in the wheels.
!Never get on an electric scooter barefoot or in sandals.
!We recommend the use of bicycle safety glasses
Driving away from the place
!
!
!
!
!
!
!
!
Sit back for pre-set saddle and make sure you have done all the steps to prepare for the ride.
Learn to ride without using the engine, pushing the scooter down as usual, do the right turns
and left.
Learn to respond to emergencies resulting from excessive free riding. Learn to prop their feet
on the ground and place his feet on the board.
Assess your skills of control a scooters. Try standing on a scooter as long as possible so as to
remain upright.
Establish a secure leg position on the board, within the safety zone of the user (details later in
this manual.)
Check brake operation. Meet the braking force front and rear brake. Find out how to inhibit only
one brake on the straight stretch of road and the bend, and as both at once.
All tests do with caution, both for your safety and the environment in an open area where there
are no obstacles and pedestrians.
When your skills will be in your assessment sufficient to drive with the engine, turn the
ignition to "ON" position
Remember:
Driving without a fastened helmet can lead to serious damage to the head,
permanent disability and even death.
Note:
Never move from place rapidly. The rapid addition of gas can result in falls
and injuries.

IMPORTANT:
Do not start riding after entering the engine at high speed,on the foot (!!!)
Sudden, unusual stopping the engine, can damage the engine or battery. If
you use LiFePO4 batteries may result in the Start of BMS protection
operations,against sudden load batteries, which will cut the power. In the
case of gel batteries, it can result in damage to the battery and motor.
!Put Your feet off the ground, place your right hand on the speed controller (right handlebar
grip), and gently turn down (to the left grip of the user).
!After reaching a safe speed and stabilize the track, support the legs on wood floor.
!Always keep at least one hand on the brake. Quick response to the threat, it can protect you
from falling.
Ride
For safety, always follow the following precautions:
User weight, height, age and social maturity and ability to adhere to safety rules in the instructions
has a significant impact on the degree of safety when driving an electric scooter.
!Always keep driving on the special interests of security of your and other users.
!If you do not feel up to it, never take a ride in a standing position.
!To ensure the safety perform frequent inspections of all moving parts of electric scooters as
described in the manual.
!
!Do not distract while driving to rapidly reverse, there is a risk of losing control of the vehicle.
!In a situation where you have concerns about whether you have been spotted, Declare their
presence via a bell.
Driving in the standing
position is always very dangerous and threatens to collapse.
While driving both legs must be on the floor
Remember:
Never turn the ignition "ON" position, while keeping a hand on the lever
speed controller. During such an event, you can hand tighten even more on
the speed controller which will lead ultimately to uncontrolled engine start,
electric scooters rollover and/or dangerous consequences of falling.

Remember:
Driving in the standing position is always very dangerous and threatens to
collapse.
!Never let go the wheel while driving in standing or sitting. Loss of balance may end up in very
serious consequences of falling.
!On the scooter can not go more than one person at a time.
!Do not use a scooter to haul or tow anything.
!When driving, always wear a fastened helmet head.
!Fast ride is always associated with great danger. Always ride slowly, safely and carefully.
!Use Caution when driving near pedestrian or in a place or residence of children's playground.
!When driving watch out for slow running around wild and domestic animals.
!Watch out for insects. When driving, use of protective glasses.
!While driving the vehicle does not lean at an angle greater than 25 degrees. Scooters
with larger deflection angle obliteration threatens edge of the frame resulting in the
destruction of paint and a sudden stop scooter. Any such abrasion threatened very
serious consequences for the fall.
!Always keep the increased caution when approaching a curb, uneven pavement, down,
puddle, the difference surface.
!When driving in a sitting position his hands to be free based on a steering during a full turn, this
may not cause any difficulties. During the ride never turns the wheel to sudden
!Only the correct aspect ratio setting saddle height and distance from the steering wheel, safe
use of electric scooters.
!
!After finish ride, pull off the key and take it with you. Doing this will prevent use of scooters by
unauthorized persons, especially children.
!Riding a scooter power pushing their foot with the system can lead to electrical collapse.
!
While driving, do not expose the legs out of the foot board.
Scooter is equipped with additional safety element. Whenever you press the brake lever
controller automatically turns off the engine, so you can stop safely. When you release
the brake lever, the engine turns on again when throttle is still in the active position.
During such breaks do not add gas.
Remember:
Never let go the handlebar while driving in standing or sitting position.
Loss of balance may end up in very serious consequences of falling.

!Keep the wheels proper air pressure (280 kPa = 40Psi = 2.7 BAR). Low tire pressure unduly
burdening the engine, causing rapid wear on the tires and also clearly reduces the driving
range. Low pressure in the wheels can also be the cause of the collapse and damage to the
scooter.
!Never put a different key, or other objects into the ignition, the ignition risk of damage or short
circuit electrical system
!Never lean on walls scooters or other items, this may damage the electrical system or other
components or parts of the vehicle.
!
!
!
!Never turn on / turn off the lights while driving. Swinging forward or backward in danger of very
serious consequences of falling.
!Do not add gas to a situation in which the vehicle is not possible to drive to the front. Excessive
engine load and the controller can damage the motor, controller and batteries.
!Never knowingly driving for fun, do not enter the vehicle vibrations by moving the steering
wheel quickly to the right and left. Such games can lead to very serious consequences of
falling.
!Do not follow the sudden movements driving wheel
!Never ride under the influence of alcohol, drugs or strong drugs.
While riding in a standing position, do not add gas rapidly. Rapid acceleration can lead
to very serious consequences of falling.
After finishing the journey or at a standstill, turn off the ignition switch to "OFF" (!!!)
Before turning on the ignition to the “ON” position, never hold hands on manetce gas in
the position "MAX." The inclusion of ignition in such a position can cause uncontrolled
start, which could result in serious consequences fall.
Remember:
Never ride under the influence of alcohol, drugs or strong drugs. Driving
under the influence of hazardous chemicals is limited ability to concentrate
and is the cause of many accidents.
Remember:
After finishing the journey or at a standstill, turn off the ignition switch to
"OFF" position.
Remember:
Always switch the key to the “OFF” position if you're going to ride with
Your legs!

Braking
For safety, always follow the following precautions:
!
!
!
!
!
!
!
!
!
!
Always when braking keep in mind primarily the safety - of your own and other users.
Always keep the increased caution when the brake against the curb, a pit, puddle, or the
difference surface.
During braking, never to sudden turns the wheel.
The vehicle is equipped with additional safety element. Whenever you press the brake lever
controller automatically turns off the engine, so you can stop safely, but when you release the
brake lever, the engine turns on again.
Never put a different key to lock the rear brake. Damage to the ignition key lock brakes and
threatens to damage.
In order to ensure a prompt response to the threat, always have at least one hand on the brake
lever located. Where possible, inhibit both brakes at once.
On slippery surfaces always brake carefully.Acute inhibition of the danger of slipping.
Do not brake for curves. Tackle corners after prior reduction of speed to a speed safe for its
defeat.
Do not brake when negotiating sharp turns.
During braking, I never lean forward. This can cause loss of balance and, consequently,
serious consequences fall.
Parking and transport
For safety, always follow the following precautions:
!
!
!
!
The correct position of the vehicle parking provides security when parked. Review the basic
principles that describe the process of parking.
Scooter can be lifted with one hand grabbing for the "neck" of the frame and the second hand
on the rear fork, or the Seat tube.
Do not lift the vehicle by holding one or both hands for the saddle. The saddle is not designed
to carry such loads. When parking, we can only pull the saddle back in a horizontal line.
Excessive load on continuous improvement of the saddle may cause damage or loosening.
Always keep the increased caution when parking. Check you have the conditions for safe
parking (even and dry surface, safe space.
Be careful when parking on surfaces with high grip rubber. This can lead to rupture of silicone
gaskets footrests
Remember:
Always keep the increased caution when the brake against the curb, a pit,
puddle, or the difference surface.

Safety zone
For safety, always follow the following precautions:
!Never while driving based on safety features leg circles - fenders.
!
!Do not rely leg while driving on the elements of the frame (the frame neck).
!Do not bend over while driving backwards or forwards or in a different direction
!You can not put your fingers in the space between the brake lever and brake lever handle. This
can lead to skin damage.
!Do not rely leg while riding on the wings. This can lead to rupture fenders and other damage
!Do not you drive based on the steering wheel. Excessive overloading can lead to loosening the
mounting screws, and consequently to the accident.
!Do not put the foot while driving, or other body parts and objects in a circle.
!Never remove guards that are on wheels. Removing covers can result in very serious injuries
(screwing feet, scarf, jacket, lace, belt, hair, etc.)
Do not expose the leg while driving out of the board.
Remember:
Quick ride in a seated or standing, always associated with a high danger.
Drive slowly and safely and wisely.
Ride inconsistent with the intended
For safety, always follow the following precautions:
!
!Driving high-performance framework can cause cracks and damage to mechanical and
electrical components.
!Driving over sharp rocks can cause the tire to rupture or loss of stability and consequently to
the collapse.
!Driving high-performance can lead to falls and injuries.
On the electric scooter you can not jump curbs, ramps or stairs.
Remember:
While driving the vehicle does not lean at an angle greater than 25 degrees.
Scooters with larger deflection angle obliteration threatens edge of the
frame resulting in the destruction of paint and a sudden stop scooter.Any
such abrasion in serious danger of collapse nipples.

Scooter Support
Battery
The scooters are installed two types of maintenance-free batteries for electric vehicles.
SLA Batteries Gel - gel batteries are widely used in UPS, telephone exchanges, electric
mopeds and scooters as well as electric toys, alarm systems, emergency lighting, medical
equipment, cash registers and many others. SLA gel batteries, can be recharged about 400 times,
which allows for intensive use by at least about 3 years (average 150 charges per year).
Lithium-ion batteries - LiFePO4 batteries Modern tech security system with BMS. They
guarantee you several times longer life compared with acid batteries. Light weight makes them
virtually undetectable to the user. Lithium-ion batteries can be recharged about 1200 times, which
allows for intensive use by at least about 8 years. (150 charges per year)
General principles of the battery
!If a longer period of time not using the battery (longer than 1 month), it must first be fully
charged and then disconnected from the system. Charge on a regular basis at least once a
month.
!Be careful when increasing the battery charging. Do not charge in rooms where there is high
humidity. Charge only in areas where good ventilation is the air. When loading the vehicle
should be in the reach of children.
!If you notice that the cable is damaged in any way, do not use the vehicle or charger. In this
case, contact an authorized service center.
!The battery must not be used for other equipment and instruments.
!
!The battery can be charged only on cassette by a suitable battery charger supplied with a set
of batteries.
For safety, always follow the following precautions:
Use only the original battery, which was part of the set. Use of any other battery may not
only damage the product and cause a fire.
Remember:
48V DC battery voltage, the environmental conditions do not exceed the
permissible touch voltage long-term and does not constitute a direct threat
to human life, but in certain circumstances may be dangerous (artificial
valves, medical pacemakers, etc.).

Do not:
!Use only the original battery, which was part of the set. Use of any other battery may not only
damage the product and cause a fire.
!The battery can be charged only in the cassette battery.
!Destroy, modify or disassemble or reconstruct battery.
!Short-circuit the positive and negative battery terminals.
!Use and leave the battery near the fire, stove or heated place.
!Immerse batteries in water or left in a humid environment.
!Charge the battery near fire or in the blazing sun.
!Use other than those chargers that were supplied with batteries for the battery version.
!Hammer sharp objects into the battery, hit with a hammer, drill, throw, etc..
!Use battery with visible damage or deflection.
!Soldered directly on the battery or near it.
!Lead to excessive load or battery.
!Conversely, the opposite charge or connect the charger to the battery.
!Connect the battery to the 12V car socket.
!Use the battery for unspecified equipment specifications.
!Smoke or heat the battery. Explosive.
!Touch the battery terminals with bare hands.
Remember:
Do not use chargers other than those that were supplied with batteries for
the battery version.
Warnings:
!Do not put batteries in a microwave oven or high-pressure containers.
!Do not use batteries with a visible leak, near the fire.
!Do not use batteries with irregularities in its operation.
!Perform frequent inspections of the connections.
!When working with batteries attached, wear rubber gloves.
!Remove personal items, such as, watches, necklaces and rings, when working with batteries.
Keep the battery away from children.
!Dipping the battery in water or in damp can cause the battery will be exposed to corrosion and
cause electrocution.
!Destroying, altering, dismantling or reconstruction of the battery fluid may leak and explosion

Note:
!Use only a dedicated charger for the battery type and capacity. Different charging
characteristics can lead to leakage, excessive heat generation or explosion as well as batteries
for a clear weakening of her life.
!Bad connection terminals may cause skin burns, damage to the battery and cause fire.
!Be careful when using metal tools like; screwdrivers and keys. Keys should be insulated.
!Keep batteries away from any ignition sources and high temperatures.
!It is as far as possible to control the charging process. Check the temperature of the battery
and charger.
!If you notice the battery leakage. Do not touch it bare hand. If the skin or cloth is smeared with
liquid from battery, wash with water and never touch the area of the face, eyes or mouth. Do
not use or leave the battery in the blazing sun. The battery can smoke, heat and smoke. This
may cause deterioration of its functional characteristics and the number of cycles of life.
!Do not use near the site of occurrence of static electricity (over 64V) Do not charge batteries
outside the recommended temperature range from 0 ° C to 60 ° C.
!Do not use the battery and charge its battery when it is rust, odor. In this situation, take the
battery to the place where it was purchased.
!When children use the battery and load it themselves, their parents should teach them the use
of batteries in accordance with the instruction manual.
Battery Disposal
!Defective or weak batteries contain an electrolyte that is hazardous waste.
!Old or defective batteries are toxic and harmful to humans and the environment.
!According to international regulations, imposed restrictions on the movement of hazardous
waste. Used batteries must be recycled.
!SLA used batteries still have power. Short circuit between the terminals may cause a fire or
other damage.
Remember:
If a longer period of time not using the battery (longer than 1 month), it
must first be fully charged and then disconnected from the system. Charge
on a regular basis at least once a month.

Charging the battery
1. Plug the XLR cable (connector) into the slot in the frame Huler.
2. Connect the charger DC output cable to XLR cable.
3. Plug the cable into the AC to 220V AC network
• 10Ah SLA Battery - 48V 1Ah charger
• 14Ah SLA Battery - 48V 2A charger
• 10Ah LiFePO4 Battery - 48V 3A charger
• 20Ah LiFePO4 Battery - 48V 6A Charger
For charging, you can only use chargers supplied with batteries.
Remember:
Keep the charger away from children. Never use chargers other than those
that were supplied with batteries. Using high-power chargers can damage
both the battery and charger.
LED2 LED1
LED2 LED1
LED2 LED1
- Connected network 220V: LED1 Red
- Charging in progress: LED2 Red
- Batteries charged: LED2 Green
Charging Identity
Remember:
Charger turns off automatically if the time of 1-3 minutes is not connected
to the battery or when the batteries are charged.

General safety
!The charger is an electric device, and despite the many safeguards and warning information on
the packaging, the cables and charger, with no proper support, can become a source of electric
shock. If the user's knowledge about the conditions of use and safety rules and the maturity
and common sense is not enough, it can lead to serious injury or death.
!Do not expose charger to water, gas or flame.
!Charge in well ventilated area.
!Charger housing can be nothing obscured.
!
!Always carefully read the instruction manual.
!Charger should be included in at least 1 time a month.
!Perform maintenance on all elements loaders and in particular of the outer covering of cables.
!When not in use, keep the charger in pude³ku.Temperatur. -40 ~ 70 degree C, relative humidity
and is about 5 ~ 95%.
!Avoid harmful gases flammable, explosive, corrosive and chemical products.
!Strong mechanical vibration, shock and strong magnetic field may damage the charger
oprowadziæ.
!Charger during storage bag should be above the ground at least 20 cm high and 50 cm from
the wall in a well ventilated and warm environment
For safety, always follow the following precautions:
Keep the charger away from children.
Battery indicator
To check the current battery, turn the ignition to "ON" position. LED display on the counter, you
are misinterpreting the scale at which the battery charge level. The scale has 10 lines and each line
voltage is about 1V. The scale reads the voltage value between 40 and 50V.
When drivingk scale may decline dramatically as a result of transient load associated with the
battery load that arises during the rapid addition of gas and long drive at full throttle. After turning
“OFF”, the ignition and turned “ON” again ("OFF" - "ON") scale reads the instantaneous voltage
value.
When the batteries are discharged during driving the engine begins to also stop working. At the
beginning of the breaks are very short and usually appear when a horse is very dynamic. In time,
when the scale is only a flashing line, repeated often break and are getting longer up to fully
discharge the battery and the motor stops.
When the batteries are discharged there is only one stroke. When it starts to blin, it
means that to fully discharge the battery is left up to a few kilometers drive. It should then
reduce to a minimum speed to safely complete the trip.
Remember:
Driving at full throttle is always strongly reduces the range of the Huler.
Try to drive economically, and use the legs to push.

Remember:
When the batteries are discharged during driving the engine begins to stop
working. At the beginning, this stop working are very short and usually
appear when a horse is very dynamic. In time, when the scale is only a
flashing line, repeated often break and are getting longer up to fully
discharge the battery and the motor stops.
Engine
Operating Environment:
The engine can be used normally under the following conditions:
In Huler are mounted brush DC motors POLARIS brand model R198. The electric motor is
located in the rear wheel, which makes it all the generated torque is available immediately to the rear
wheel axle. Nominal motor power ranges from 0.25 to 0.85 kW. The motor is maintenance-free
!Temperature: -25 ° ~ 60 °
!Relative Humidity: 0 ~ 100%
!Atmospheric pressure: 86 ~ 106Kpa
!Degree of protection: Motor protection class GB / T, are consistent with the provisions of
4942.1 IP57.
!Insulation class: level B
!Water resistance: level IP7
Brush DC motor life in normal conditions is no less than 2000 hours!.
Remember:
Do not add power throttle-gas in a situation in which the vehicle is not
possible to ride the front. Excessive long-term motor load can damage the
motor, controller and batteries.

Specifications
Construction
1) Brake levers - the brake levers are made of aluminum and its shape ensures a good and
reliable braking.
2) Sensor power cut - cut off the power switch is integrated with the brake lever. During
braking, turns off the motor.
3) Throttle speedl - In Huler was installed speed control type "twist". Twisting the throttle to the
left, increasing the Maximum speed.
4) Digital Metter LED - Huler has a modern digital meter, installed on the handlebar stem. On
the large LED can be seen, current speed, mileage (km), and battery status.

5) Handlebar - A large wide (75cm) and comfortable steering wheel ensures a safe ride
standing up and sitting down.
6) Handle Stem - Stem length 30cm height adjustment allows the position of the steering
wheel.
7) Headset - Huler have a bearing fork semicartrige type, used for high-performance bikes and
road cycling. High quality product, provides reliable operation in all conditions.
8) Frame Seal - Frame seal protects against moisture inside the frame and covers the space in
which there are electrical connectors connecting the navigation items from the main beam of the
system.
9) Front Lamp - The lamp is powered by 1.5 V batteries (2 x AA). Large convenient button lets
you quickly turn on and off the light.
10) Drum brakes - Strong, modern drum brakes provide safe and reliable braking in all
conditions. Rear brake has avery funcional lock on the key.
11) Tyres - The basic version of the tire are mounted on special 20-inch (20 x 2.125),
manufactured to specifications for electric vehicles. They have increased the strength factor and the
additional reinforcement. The permissible maximum load per tire is 80 kg and the allowable pressure
in the tires is 280kpa (40psi).
12) Key switch - To improve the functionality and safety in use, the frame is installed Huler
ignition. It has two options for the location. "OFF" - the system off, "ON" - the system turned on. In
both positions, you can recharge the batteries.
13) The vehicle's frame - frame construction is made of aluminum PA11. Special reinforced
fork is made of steel. Optimal ratio of individual elements provide a framework for driving people
from about 150 cm tall.
14) Charger Plug - External charger plug is made of plastic and hermetically seal protects the
contacts closed flip "C".
15) Saddle - The nice and safe saddle, with a very modern shape makes riding on Huler in the
sitting position is a pure pleasure.
16) Seatpost - Suspension bracket saddle is adjustable cushioning force.
17) Rear Lamp - Modern LED lamp with 2 AAA batteries, with three options for lighting, with a
special handle for tying in the saddle, shining a very strong red light, providing the user with basic
security.
18) Universal Handle - At this point it is placed universal mounting bracket and a rear rack for
mounting truck freight, as well as other additional items of equipment or arrangement Huler.
19) Fenders - Fenders made of strong, flexible ABS material that is at the same time light and
resistant to cracking.
20) Engine - Brushless DC motor is located in the rear wheel with him, filmed the drum brake.
Life is about 2000 engine hours.
21) Footboard - is a combination of rubber used in automotive aluminum. Protects the interior
of the vehicle in which the electrical system, batteries and controller system.
22) Footstep - Strong, foldable footsrep spring, provides secure parking in an upright position.
At the ends of the footstep are mounted silicone gaskets that protect both surface and ground pegs
against scratches. It is made of steel.
23) Bell - Loud ringer provides you with security.
24) Secure the saddle - User friendly latch allows for quick configuration of the saddle to the
desired setting.

Engine parameters
Drive: Electric
Voltage: 48VDC
Rated Power: 250W
Torque [Nm / r / min]: 52 / 25
Motor Power [HP / r / min]: 0.78/157
Maximum speed [km / h]: 25
Acceleration from 0 - Max. [S]: 10
Brakes - Front and Rear: Drum
C02 Emissions [g / km]: 0
Minimum turning radius [m]: 1.5
The maximum angle of inclination [°]: 25 °
Vehicle weight [kg]: 36
Gross vehicle weight [kg]: 160
HULER „Relax” 250W
Drive: Electric
Voltage: 48VDC
Rated Power: 550W
Torque [Nm / r / min]: 54 / 9
Motor Power [HP / r / min]: 1.12/283
Maximum speed [km / h]: 35
Acceleration from 0 - Max. [S]: 15
Brakes - Front and Rear: Drum
C02 Emissions [g / km]: 0
Minimum turning radius [m]: 1.5
The maximum angle of inclination [°]: 25 °
Vehicle weight [kg]: 36
Gross vehicle weight [kg]: 160
HULER „Life” 550W
Drive: Electric
Voltage: 48VDC
Rated Power: 850W
Torque [Nm / r / min]: 51 / 84
Motor Power [HP / r / min]: 1.38/369
Maximum speed [km / h]: 45
Acceleration from 0 - Max. [S]: 20
Brakes - Front and Rear: Drum
C02 Emissions [g / km]: 0
Minimum turning radius [m]: 1.5
The maximum angle of inclination [°]: 25 °
Vehicle weight [kg]: 36
Gross vehicle weight [kg]: 160
HULER „Extreme” 850W

Battery parameters
Gel Battery 48V 10Ah SLA
Output voltage: 48V DC
Charging voltage: 58V DC
Charging time: 7 hours
Weight of casket: 13 kg
The amount of charge and discharge cycles: 400 - 600
Specifications: http://hpgbatteries.com/pdf/HPG120100.pdf
Gel Battery 48V 14Ah SLA
Output voltage: 48V DC
Charging voltage: 58V DC
Charging time: 7 hours
Weight of casket: 20 kg
The amount of charge and discharge cycles: 400 - 600
Specifications: http://hpgbatteries.com/pdf/HPG120140.pdf
Lithium Ion Battery 10Ah 48V LiFePO4
Output voltage: 48V DC
Charging voltage: 58V DC
Charging time: 3 hours
Weight of the casket: 4 kg
The amount of charge and discharge cycles: 1200 - 1400
Specifications: ...
Lithium Ion Battery 20Ah 48V LiFePO4
Output voltage: 48V DC
Charging voltage: 58V DC
Charging time: 3 hours
Weight of the casket: 9 kg
The amount of charge and discharge cycles: 1200 - 1400
Specifications: ...
