Hunter X-CORE Operating instructions

Residential Irrigation Controller
Owner’s Manual and Programming Instructions
Compatible with Hunter Remotes and Solar Sync
SEASONAL ADJUSTMENT WATER DAYS
START TIMES
SYSTEM OFF CURRENT TIME/DAY
RUN TIMES
ACTIVE
SENSOR BYPASS
RUN
NEW
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

SEASONAL ADJUSTMENT
WATER DAYS
START TIMES
SYSTEM OFF
CURRENT TIME/DAY
RUN TIMES
ACTIVE
SENSOR BYPASS
RUN
MANUALSINGLE STATION
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

X-C OR E C OMPO NENTS ................................................................... 2
MOU NT IN G THE CO NT ROLL E R TO WALL ...................................... 6
CO NNE C TIN G VALV ES A N D TRA NS FORM E R ................................. 7
A CTIVA TIN G T HE B ATTE RY .............................................................. 8
RE PLACI N G T HE B ATTE RY ............................................................... 8
CO NNE CTIN G A M ASTE R V ALV E .................................................... 9
CO NNE CTIN G A PUMP STAR T R E LAY ........................................... 10
CO NNE CTIN G A H UNTE R “C LIK” W E ATHE R SENS OR ................. 11
Testing the Weather Sensor ........................................................ 11
Manually Bypassing the Weather Sensor .................................... 11
CO NNE CTIN G A H UNTE R SOLAR SYN C ET SENS OR ................... 12
Installing Solar Sync Sensor ......................................................... 12
Installing the Wireless Solar Sync ................................................ 12
Solar Sync Settings ...................................................................... 12
Region .................................................................................. 13
Water Adjustment ................................................................. 14
Uninstalling a Solar Sync Sensor .................................................. 14
Calibration/Setup ........................................................................ 15
CO NNE CTIN G A H UNTE R RE MO TE .............................................. 16
Connecting to a Hunter Remote (not included) .......................... 16
To install the SmartPort connector .............................................. 16
POW E R F AILUR ES ........................................................................... 16
PROGRAMMI N G T HE CO NT ROLL E R ............................................. 17
Setting the Date and Time ..................................................... 17
Setting the Program Start Time(s) ......................................... 18
Eliminating a Program Start Time ................................................ 18
Setting Station Run Times ...................................................... 18
Setting Days To Water ........................................................... 18
............................ 19
Selecting Odd or Even Days to Water ........................................ 19
Selecting Interval Watering .................................................. 19
Setting Event Day(s) O .............................................................. 20
Automatic Watering ................................................................ 20
System O ............................................................................. 20
Programmable Rain O ............................................................... 20
Seasonal Adjustment ............................................................. 21
Manually Run a Single Station 1............................................... 22
One Touch Manual Start and Advance ........................................ 22
A DVA N C E D FE ATUR ES ................................................................... 23
Programmable Sensor Override .................................................. 23
Test Program of All Stations ........................................................ 23
Hunter Quick Check™ Diagnostics ............................................. 23
Easy Retrieve™ Program Memory ............................................... 24
Programmable Delay Between Stations ...................................... 24
Clearing the Controller’s Memory/
Resetting the Controller .............................................................. 24
TROUBL ES HOO TIN G GUID E .......................................................... 25
SP E CIFICA TIO NS ............................................................................. 28
............................................................. 28
............................................................... 28
Explanation of Symbols ............................................................... 28
CE RTIFICA TE OF C O N FORMI TY T O EUROP E A N DIR E C TIV ES ...... 29
TABL E OF CO NTENT S
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

2
X-COR E COMPO NENT S
Terminal
block for -E
(International
models only)
N ote: Plug may
look dierent from
illustration
Indoor M odel
O utdoor M odel
(Internal Transformer
Included)
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

3
X-COR E COMPO NENT S
LCD Display
1Run Times Allows user to set each valve station run time from 1 minute to 4 hours
2Start Times Allows 1 to 4 start times to be set in each program
3 Station N umber Indicates currently selected station number
4 Program Designator
5 Day of the Week
6 Interval Watering
7 Odd/ E ven Watering
8 Flashing Sprinkler Indicates that watering is taking place
9System O Allows user to discontinue all programs and watering. Also allows the user to set the programmable
“rain o,” which stops watering for a period from 1 to 7 days.
10 Umbrella Indicates that the rain sensor is active
11 Seasonal Adjustment
Allows the user to make run time changes according to the seasons without reprogramming the controller.
Bars on the left allow quick visual reference to the seasonal adjustment percentage. When using Solar Sync
ET Sensor, will display seasonal adjust updated daily by sensor.
12 Rain Drop Indicates watering will occur on the selected day
13 Crossed Rain Drop Indicates the watering will NOT occur on the selected day
14 Calendar Indicates interval watering schedule has been programmed. Icon also appears when programming the
current day
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

4
X-COR E COMPO NENT S
Wiring Compartment
15 Lithium Battery
The replaceable lithium battery (included) allows the controller to be programmed in the absence
of AC power. In addition, the battery will provide power for backup timekeeping in the event of a
power outage.
16 Internal Junction Box Junction box in outdoor models for making AC power connections
17 Terminal Strip Use to attach transformer, sensor, and valve wires from their source to the controller
18 Reset Button Use to reset the controller (located on side of controller)
19 R E M Allows for connection of Hunter SmartPort ®and Hunter Remote Controls
20 Sensor Bypass Switch Ignores “Clik” weather sensor input when in Bypass position
Control B uttons
Button
Button
Button
Button
Button Selects program A, B, or C for dierent watering zone requirements
NEW
NEW
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

5
X-COR E COMPO NENT S
Dial Settings
Run Normal dial position for all controller automatic and manual operation
Current Time/DayAllows current day and clock time to be set
Start Times Allows 1 to 4 start times to be set in each program
Run Times Allows user to set each valve station run time from 1 minute to 4 hours
Water Days Allows the user to select interval days to water
Seasonal AdjustmentAllows user to make run time changes according to the seasons without reprogramming the controller.
Bars on the left allow quick visual reference to the seasonal adjustment percentage.
1Manual-One StationAllows user to activate a one-time watering of a single valve
System O Allows user to discontinue all programs and watering. Also allows the user to set the programmable
“rain o,” which stops watering for a period from 1 to 7 days
SettingsAllows user to program settings when using Solar Sync ET Sensor
External Transformer (Indoor Model Only)
A plug in transformer is provided to supply AC power to the controller
NEW
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

6
MO UNTING THE C O NT ROLL E R T O W ALL
Note:The indoor version of the X-Core is not water-
proof or weather resistant, and must be installed indoors
or in a protected area.
1. Secure one screw into the wall. Install screw anchors if attaching
to drywall or masonry wall.
2. Slide the keyhole on top of the controller over the screw.
3. Secure the controller in place by installing screws in the holes
below the terminal strip.
Do not plug transformer into power source until
controller is mounted and all valve wiring has
been connected.
For XC - x01 - A: If the supply cord is damaged, it
must be replaced by the manufacturer or service
avoid hazard.
C
A
B
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

7
CO NNECTING V AL VE S A ND T RA N SFORM E R
Installationof the X-Core should only be done by trained personnel.
1. Route valve wires between the control valve location and controller.
2. At valves, attach a common wire to either solenoid wire on all
valves. This is most commonly a white colored wire. Attach a
separate control wire to the remaining wire of each valve. All wire
connections should be done using waterproof connectors.
3. Route the valve wires through the conduit. Attach the conduit
through the bottom right side of the controller.
4. Secure the white valve common wire to the C (Common) screw on
the terminal strip. Attach each of the individual valve control wires
to the appropriate station terminals and tighten their screws.
5. Indoor Models: route the transformer cable through the hole on
the left side of the controller and connect the wires to the two
screws marked 24VAC.
Outdoor Models: transformer wires are already connected to the
AC terminals so all that is required is to connect primary power to
the junction box (see below).
N O TE: X-Core outdoor models are water and
weather resistant. Connecting the outdoor X-Core
to primary AC power should only be done by a
licensed electrician following all local codes. Improper
BA T
High Voltage Wiring (Outdoor Model only)
1. Route AC power cable and conduit through the ½" (13 mm)
conduit opening on the left side bottom of the cabinet.
2. Connect one wire to each of the two wires inside the junction
box. The ground wire should be connected to the green wire.
Wire nuts are provided to make these connections.
N ote: For – E models only: Connect the wires to the AC
terminal block inside the junction box. AC supply wires must
be 14 AWG (1.85 mm) or larger with appropriate circuit
breaker for the wire size. A switch or circuit-breaker shall be
included in the building installation (in close proximity to the
controller, within easy reach of the operator) and marked as
the disconnecting device for the equipment.
3. Replace the junction box cover.
Connectthe two transformer
wires to the two A C Terminals
Valve Common Wire
Valve 4
Valve 3
Valve 2
Valve 1
Valve
Wires
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

8
ACTIV ATING THE B ATTE RY
After installing your X-Core, make sure to remove the battery
contact insulator to allow the X-Core to keep time in the event of
a power outage.
C A UTI O N:
RI SK OF E XPLO S IO N IF BA TTE RY I S R E PLAC E D B Y
AN I N CORR EC T TY PE. DI SPO SE OF U SE D BA TTE RI ES
ACCORDI N G TO T HE I NST RUC TIO NS .
RE PLA CING THE B ATTE RY
A high-energy lithium battery is included with your X-Core
controller. The battery allows the user to remotely program the
controller without connecting AC power. It is also used to keep
the current time and day during power outage conditions.
To replace the battery:
1. Remove the screw from the battery holder.
2. Slide the battery holder down to access the battery.
3. Remove and replace the new battery into the battery holder
and reinstall the battery holder.
N O TE: This positive(+) side of the battery should face
the inside of the battery holder. Battery type: CR2032 3V
SEN C P 1 2 3 4 5 6 7 8
24VAC
BA T
Battery Compartment
Lithium Battery
Battery
Holder
(--) (+)
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

9
CO NNECTING A M AS TE R VAL VE
N O TE: Complete this section only if you have a
master valve installed in your irrigation system. A
master valve is a “normally closed” valve installed
at the supply point of the main line that opens only
when the controller initiates a watering program.
1.
At the Master Valve, attach the common wire to either solenoid
wire of the valve. Attach a separate control wire to the remaining
solenoid wire.
2. The common wire should be attached to the Cterminal inside
the controller. The other wire coming from the master valve
should be attached to the Pterminal inside the controller.
Tighten each terminal screw.
SEN C P 1 2 3 4 5 6 7 8
24VAC
BA T
M aster Valve
Valve 2
Valve 1
Valve 3
Valve 4
M aster
Valve Wire
Valve Common Wire
Valve Wires
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

10
PSR Series
Pump Start Relay
15 ft M inim um (4. 5 m )
To Pum p
STAR
T TIMES
SEASONALADJUSTMENT WATER DAYS
ALL
MANUAL-ALL STATIONS STARTTIMES
SYSTEM OFFCURRENT TIME/DAY
RUN TIMES
ACTIVE
SENSORBYPASS
RUN
N O TE: Complete this section only if you have a
pump start relay installed. A pump start relay is
a device that uses a signal from the controller to
actuate a separate electrical circuit to energize a
pump to provide water to your system.
The controller should be mounted at least a 15 ft (4.5 m) away from
both the pump start relay and pump to minimize any potential
electrical interference.
1. Route a pair of wires from the pump relay into the controller.
2. Connect a common wire to the C(Common) terminal inside the
controller and connect the remaining wire from the pump start
relay to the P(Pump) terminal.
Relay holding current draw must not exceed 0.3 A. Do not connect
the controller directly to the pump or damage to the controller will
result.
CO NNECTING A PUMP STAR T R E LAY
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

11
CO NNECTING A H UNTE R “CL IK” WE ATHE R SEN SOR
A Hunter weather sensor or other micro-switch type weather
sensors can be connected to the X-Core. The purpose of this sensor
is to stop automatic watering when weather conditions dictate.
1. Remove the metal jumper plate that is attached across the two
SEN terminals inside the controller.
2. Connect one wire to one SEN terminal and the other wire to the
other SEN terminal.
When the weather sensor has
deactivated automatic watering,
the OFF, and icon will appear
on the display.
Testing the Weather Sensor
sensor is wired into the sensor circuit. You can manually test proper
operation of the rain sensor by running a MA N UAL C Y CL E or by
activating the system using the One Touch M A N UAL STAR T (see
page 22). During the Manual cycle, pressing the test button on the
Mini-Clik ®will interrupt watering.
M anually B ypassing the Weather Sensor
If the rain sensor is interrupting irrigation,
you can bypass it by using the bypass
switch on the front of the controller. Slide
the switch to the SENS OR B YPA SS position
to disable the rain sensor from the system
to allow for controller operation. You can
also bypass the weather sensor for manual
operation by using the MA N UAL – O NE STATIO N function.
The Bypass switch does not aect the Seasonal Adjust update
when using Solar Sync sensor.
SEN C P 1 2 3 4 5 6 7 8
REM
24VAC
BA T
/DAY
ACTIVE
BYPASS
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

12
CO NNECTING A H UNTE R SOLAR SYNC ET SEN SOR
The X-Core is compatible with the Solar Sync and Wireless Solar
Sync systems. Solar Sync is a sensor system that will automatically
adjust the X-Core controller’s watering schedule (based on
changes in local climate condition) by using the Seasonal Adjust
function. The Solar Sync uses a solar and temperature sensor to
determine evapotranspiration (ET), or the rate at which plants and
turf use water, and also includes Hunter Rain Clik and Freeze Clik
technology that will shut down irrigation when it rains and/or during
freezing conditions.
N O TE: Solar Sync will apply a default seasonal adjust
of weather measurements have been received from
the sensor.
N O TE: E nabling the Sensor Bypass switch has no
eect on the seasonal adjust updates from the Solar
Sync sensor. It will, however, bypass the Rain Clik and
Freeze Clik functionality of the sensor.
Installing Solar Sync Sensor
Connect the Green and Black wire from the Solar Sync Sensor to
the “SEN” wiring terminals on the X-Core controller, similar to
picture on page 11. It does not matter which wire connects to which
terminal. Turn the dial to the “Solar Sync Settings” position. The
display will initially show dashed lines
and then will show the default Region
setting (3) on the left and the default
Water Adjustment setting (5) on the
right. Adjust the Region as needed
by using the and buttons (refer to page 13 for explanation
of Solar Sync Region setting). Use the button to advance to the
right to adjust the Water Adjust setting as needed (see page 14 for
explanation of Water Adjust setting).
Installing the Wireless Solar Sync
Connect the Green and Black wire from the Wireless Solar Sync
Receiver to the “SEN” wiring terminals on the X-Core controller. It
does not matter which wire connects to which terminal. Turn the dial
to the “Solar Sync Settings” position. The display will initially show
dashed lines and then will show the default Region setting (3) on
the left and the default Water Adjustment setting (5) on the right.
Adjust the region as needed by using the and buttons (refer
to page 13 for explanation of Solar
Sync Region setting). Use the button
to advance to the right to adjust the
Water Adjust setting as needed (see
page 14 for explanation of Water
Adjust setting).
Solar Sync Settings
Once the Solar Sync sensor is connected to the X-Core controller,
two numbers will appear in the display when the dial is turned to
the Solar Sync Settings position. The number on the left of the
screen is the Region setting, and the number on the right on the
screen is the Water Adjustment setting (as shown above).
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

13
CO NNECTING A H UNTE R SOLAR SYNC ET SEN SOR
Region
For accurate Solar Sync measurements, the controller needs to
be programmed for the average peak season ET for your region.
Use the table below to determine your region.
The table will assist you in identifying the type of region you live
in. There are four basic ET regions, each with descriptions of the
region, along with typical ET and temperature characteristics. It is
recommended that, if possible, the region be chosen based upon
average July ET or peak summer ET (inches/mm per day).
Use the following table for choosing your region (reference below).
You can use methods A, Bor Cto help you choose which region is
best for your area:
A: Based upon the ET of your region using the average July ET
or peak summer ET (inches/mm per day). This is the preferred
option when selecting your region.
B: Based upon the temperature for your region using the average
July or the driest month high temperature (not the highest
temperature for July).
C: Based upon the general description of your region.
• U.S. Northern States
• Coastal Regions
If the average July ET is
< 0.17" (4.3 mm) per day
If the average temperature for July is
65° – 75°
(18°C – 2 4°C)
If the average temperature for July is
75° – 85°
(24°C – 29 °C)
• Mountains
• U.S. Northern Inland States
If the average July ET is 0.18" – 0.23"
(4.6 mm – 5.8 mm) per day
• U.S. Southern States
• Inland/High Desert
If the average July ET is 0.24" – 0.29"
(6.1 mm – 7.4 mm) per day
If the average temperature for July is
85° – 9 5°
(29°C – 35°C)
• Deserts
If the average July ET is > 0 .30"
(7.6 mm) per day
If the average temperature for July is
95° – 10 5°
(35°C – 41°C)
* For Southern hemisphe re l ocations, use the mo nth of Janua ry.
Regio n
1
Regio n2
Regio n3
Regio n 4
IF ANY OF THE CHOICES IN THE ROWS APPLY TO YOUR SITUATION, THEN THAT IS YOUR REGION SETTING CHOICE.
A B C
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

14
CO NNECTING A H UNTE R SOLAR SYNC ET SEN SOR
Water A djustment
The Water Adjustment is a 1 to 10 scale that allows for easy
adjustment of the Seasonal Adjust value from the Solar Sync
ET Sensor. Upon installation of the Solar Sync ET Sensor, it is
recommended that the Water Adjustment setting stay at the default
adjust value is lower or higher than expected, the Water Adjustment
See Calibration/Setup on page 15 for explanation of how to use
N O TE: If an individual zone is “wetter” or “drier”
than the rest of the system, simply increase or
decrease the amount of run time on the controller.
Uninstalling a Solar Sync Sensor
If a Solar Sync sensor has been installed on the X-Core controller
then the seasonal adjust value used by the controller will be
calculated from the weather data supplied by the Solar Sync sensor.
If it is decided that the Solar Sync sensor will no longer be used
with the X-Core controller, it must be uninstalled. If the Solar
Sync sensor is not uninstalled, the controller will not allow the
seasonal adjust value to be manually changed. For example, if the
seasonal adjust value shown on the controller was 50% when the
Solar Sync sensor was removed, it will remain 50% until the Solar
Sync sensor is uninstalled.
To uninstall the Solar Sync sensor, simply disconnect the green and
black wires from the controller terminal and then turn the dial to the
“Solar Sync Settings” position. The display should show dashes,
indicating that the controller no longer recognizes the Solar Sync
sensor for calculation of seasonal adjustment. Now the seasonal
adjust value can be changed manually by turning the knob to the
“Seasonal Adjust” position and using the or button to adjust
the value.
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

15
CO NNECTING A H UNTE R SOLAR SYNC ET SEN SOR
Calibration/ Setup
After Solar Sync has been installed and programmed, it is recommended to allow the system to run for a few days at the initial setting.
surrounding structures, etc), the initial setting may require adjustment in order to arrive at the desired performance. The calibration
of the Solar Sync to a particular site can easily be accomplished by adjusting the Region and/or Water Adjustment settings. The instructions
below outline this process:
1. Install Solar Sync sensor
2. Program Region and allow system to operate at initial setting for a minimum of 3 days (see page 13 for instructions on how to determine
proper Region setting).
3. Observe the Seasonal Adjust on the controller. If the Seasonal Adjust amount appears to be lower or higher than expected for that time
of year, the Solar Sync settings need to be adjusted.
a. S easonal Adjust too low: Turn the dial to the Solar Sync settings position. Increase the value on the Water Adjustment scale (10 is max).
Once the setting is changed, the controller will immediately be updated with the new Seasonal Adjust %. Increase the Water Adjustment
setting until the desired Seasonal Adjust % is shown. If you max out the Water Adjustment scale at 10 and still require more Seasonal
Adjust, move down to the next lower Region (from Region 4 to 3, for example).
b. S easonal Adjust too high: Turn the dial to the Solar Sync settings position. Decrease the value on the Water Adjustment scale (default
setting is 5). Once the setting is changed, the controller will immediately be updated with the new Seasonal Adjust %. Decrease the Water
Adjustment setting until the desired Seasonal Adjust % is shown. If you minimize the Water Adjustment scale down to 1 and still require
a reduction in Seasonal Adjust, move up the next Region (from Region 2 to 3, for example).
Station Run Times: It is important to understand that Solar Sync provides a global seasonal adjustment to the controller. This means that
entered that represent peak season watering schedules. If the Solar Sync is adjusting to the appropriate seasonal adjust value but the run
time for a particular station appears to be too long/short, adjust the station run time in the controller program.
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

16
CO NNECTING A H UNTE R RE MO TE
Connecting to a Hunter Remote (not included)
The X-Core Controller is compatible with Hunter Remote Controls
(not included). The SmartPort ®wiring harness (included with all
Hunter Remotes) allows for fast and easy use of the Hunter controls.
The Hunter remotes make it possible for you to operate the system
without having to walk back and forth to the controller.
To install the Smart Port connector
1. Install a 1⁄2" female threaded
approximately 12" below the X-Core.
2. Feed the red, white, and blue wires
of the harness through the base of
the “Tee” and into the wiring
compartment as shown.
3. Screw the SmartPort harness
housing into the “Tee” as shown.
4. Attach the red, white, and blue SmartPort wires to the
controller terminal as shown below:
•Red wire to left side “24VAC” terminal
•White wire to right side “24VAC” terminal
•Blue wire to “REM” terminal
1/2" Thread
To Controller
Pre-assembled Assembled
PO WE R FA ILUR E S
Due to the possibility of power failures, the controller has non-volatile memory. Programmed information will never be lost due to a power
outage. The lithium battery will keep the correct time without AC power. Normal watering will resume when AC power is restored.
SEN C P 1 2 3 4 5 6 7 8
24VAC
red
white
blue
N O TE: P/ N 258200 can be used as
an alternate method to mount the
SmartPort connector.
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

17
N O TE: A basic programming rule is that whatever
when setting the time, the hour can be changed or
programmed. For illustration purposes in this manual,
Y type.
The X-Core display shows the time and day when the controller is
idle. The display changes when the dial is rotated to indicate the
or
or
Three programs A, B, and C, each with the ability to have four daily
start times, permit plants with dierent watering requirements to be
separated on dierent day schedules.
PRO G RAMM ING THE C O NT ROLL E R
Setting the Date and Time
1. Turn the dial to the CURR ENT T IM E /DA Y position.
2. or buttons to
change the year. After setting the year, press the button to
proceed to setting the month.
3. The month and day will be in the display. The month will be
icon will be displayed. Use the or
buttons to change the month. Press the button to proceed
to setting the day.
4. icon will be displayed. Use
the or buttons to change the day. Press the
button to
proceed to setting the time.
5. The time will be displayed. Use the and buttons to select
AM, PM, or 24 hour. Press the button to move to hours. Hours
and buttons to change the hour
shown on the display. Press the button to move to minute.
and buttons to change
the minutes shown on the display. The date, day, and time have
now been set.
CURRENT TIME/DAY
CURRENT TIME/DAY
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]

18
Setting the P rogram Start Time(s)
1. Turn the dial to the STAR T TIM ES position.
2. The factory preset is set onprogram
A. If necessary, you can select program
B, or C by pressing the button.
3. Use the or button to change
the start time. (The start times
advance in 15 minute increments).
4. Press the button to add an
additional start time, or button
for the next program.
N O TE: One start time will activate all stations
sequentially in that program. This eliminates the
need to enter each station’s start time. Multiple
start times in a program can be used for separate
morning, afternoon, or evening watering cycles.
Start times may be entered in any order. The X-Core
will automatically sort them.
Eliminating a P rogram Start Time
With the dial set to STAR T TIM ES
position, push the or button until
you reach 12:00 AM (Midnight). From
here push the button once to reach
the OFF position.
PRO G RAMM ING THE C O NT ROLL E R
Setting Station Run Times
1. Turn the dial to RUN TIM ES position.
2. The display will show the last program
selected (A, B, or C), the station number
selected, icon, and the station will be
program by pressing the button.
3. Use the or button to change the
station run time on the display. You can
set the run times from 0 to 4 hours.
4. Press the button to advance to the
next station.
Setting Days To Water
1. Turn the dial to the WA TE R DA YS position.
2. The display will show the last program
selected (A, B, or C). You can switch to
another program by pressing the button.
3. The controller will display the seven days
of the week (MO, TU, WE, TH, FR, SA, SU).
Each day will have a icon or a icon
above the day. The icon would represent
an “On” water day, while a icon would
represent an “O” watering day.
WATER DAYS
START TIMES
RUN TIMES
START TIMES
Unit A110, Riverside Business Centre,
Bendon Valley, London, SW18 4UQ Email: [email protected] | Phone: [phone]
