Hunter Hunter Ceiling Fan User manual

www.HunterFan.com 1.888.830.1326
Table of Contents
Congratulations on purchasing
your new Hunter® ceiling fan! It will
provide comfort and performance
in your home or ofce for many
years. This installation and operation
manual contains complete
instructions for installing and
operating your fan.
We are proud of our work and
appreciate the opportunity to
supply you with the best ceiling fan
available anywhere in the world.
To register your fan, please visit:
www.HunterFan.com/register
Save your receipt for proof of purchase.
1
M0080-01 • 05/14/14 • © Hunter Fan Company
PAGE
7
PAGE
10
PAGE
5
PAGE
19
PAGE
6
30 inches
7 feet
PAGE
2
What to Expect with
Your Installation Ceiling Bracket
Ladder
PAGE
3
Tools Needed
Wiring Canopy
Troubleshooting
DownrodPreparation
?
?
?
PAGE
11
PAGE
17
Mounting Options
PAGE
13
PAGE
14
Blades Switch Housing Light Kit
PAGE
12
PAGE
4
Remote Control
PAGE
16
Operation,
Maintenance & Cleaning

www.HunterFan.com 1.888.830.1326
M0080-01 • 05/14/14 • © Hunter Fan Company
What to Expect with Your Installation
Know your wiring
If you are unfamiliar
with wiring, use a
qualied electrician.
You may need a
friend to help you.
Check box to see
fan weight
Assess location
30 inches
from blade tip
to nearest wall
or obstruction 7 feet
from bottom
edge of blade
to the oor
Select a downrod length
Assess ceiling angle
Must be able to
secure the fan to
building structure or
fan-rated outlet box
1
2
3
Standard Downrod
for ceilings 8-10 feet high
Shorter Downrod
for fans installed close to ceiling
Longer Downrod
for ceilings 10 feet or higher
2
Ceiling angles greater
than 34° will require an
Angled Mounting Kit.
See page 4 for details.
Read and Save These Instructions
This product conforms to UL Standard 507.
WARNINGS
CAUTIONS
w.1 - To reduce the risk of re, electrical shock, or personal
injury, mount fan directly from building structure and/or an
outlet box marked acceptable for fan support of 70 lbs (31.8 kg)
and use the mounting screws provided with the outlet box.
w.2 - To avoid possible electrical shock, before installing or
servicing your fan, disconnect the power by turning off the
circuit breakers to the outlet box and associated wall switch
location. If you cannot lock the circuit breakers in the off
position, securely fasten a prominent warning device, such as a
tag, to the service panel.
w.3 - To reduce the risk of re, electrical shock, or motor damage,
use only Hunter Speed Controls.
w.4 - To reduce the risk of personal injury, do not bend the blade
brackets when installing the blade brackets, balancing the blades,
or cleaning the fan. Do not insert foreign objects in between
rotating fan blades.
c.1 - All wiring must be in accordance with national and local
electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring,
use a qualied electrician.
c.2 - Use only Hunter replacement parts.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and if not
installed and used in accordance with the instructions may cause
harmful interference to radio communications.

www.HunterFan.com 1.888.830.1326
Tools Needed
Ladder
Power Drill
(optional)
9/64” Drill Bit
(optional)
Screwdrivers
Pliers Wire Strippers
If mounting to a support structure, you will also need these tools.
3
M0080-01 • 05/14/14 • © Hunter Fan Company

www.HunterFan.com 1.888.830.1326
4
M0080-01 • 05/14/14 • © Hunter Fan Company
If you have an angled ceiling:
1. You will need a longer downrod (sold separately).
2. If your ceiling angle is greater than 34°, you will
also need an Angled Mounting Kit (sold separately).
Guide Touches
BOTH Ceiling & Wall
S
I
T
U
A
T
I
O
N
1
Guide Touches Wall
but NOT Ceiling
S
I
T
U
A
T
I
O
N
2
You need BOTH
a Longer
Downrod &
an Angled
Mounting Kit
You need ONLY
a Longer
Downrod
*most common
If you have a at ceiling:
Hang your fan by a standard downrod (included).
Mounting Options
Use Standard Mounting
or Low-Prole Mounting
to hang the fan from a at ceiling.
Use Angled Mounting
to hang the fan from a
vaulted or angled ceiling.
34OCEILING
WALL
OPTION
1
Standard
Mounting
OPTION 2
Angled
Mounting
2 3
SLIDE
toward ceiling
PLACE
against wall
1
FOLD
on dotted line
34°
Use the three steps below to determine if your ceiling angle is greater than 34°
Support
Structure
Ceiling
Outlet Box
(required)
Angled
Mounting
Style
Standard
Mounting
Style
Support
Structure
Ceiling
Outlet Box
(required)

www.HunterFan.com 1.888.830.1326
Ceiling Bracket
Refer to warning w.1 on pg. 2
To avoid possible electrical shock, before
installing your fan, disconnect the power by
turning off the circuit breakers to the outlet
box associated with the wall switch location.
For angled ceilings, point
opening toward peak.
If you are unable to do this,
call Technical Support at
1-888-830-1326.
Make sure all four bumpers are
still attached.
Use wood screws
(included) when securing
to support structure with
approved electrical outlet
box. Drill 9/64” pilot holes
in support structure to aid
in securing ceiling bracket
with hardware found in
the hardware bag.
Use machine screws
(provided with outlet
box) when securing to
existing ceiling fan-rated
outlet box. Make sure
it is securely installed
and is acceptable for fan
support of 31.8 kg (70 lbs)
or less.
OFF
Turn Power
5
M0080-01 • 05/14/14 • © Hunter Fan Company

www.HunterFan.com 1.888.830.1326
Preparation
D
I
S
C
A
R
D
K
E
E
P
!
Remove the shipping blocks from the
motor. Save the screws. They will be
needed for blade iron installation.
Note: Some fans will have a shipping
ring instead of shipping blocks. Please
remove the ring and save the screws.
Time Saver Tip: Get a helper
to insert grommets, found in
the hardware bag, into the
blades while you’re doing the
next couple of steps.
If you are installing multiple remote-controlled
fans on the same circuit breaker,
you may need to perform a few extra steps to
prevent interference or faulty operation of your
remote controls.
Go to www.HunterFan.com/FAQs and click
“How do I properly install multiple remote-
controlled fans?” for more information.
6
M0080-01 • 05/14/14 • © Hunter Fan Company

www.HunterFan.com 1.888.830.1326
7
M0080-01 • 05/14/14 • © Hunter Fan Company
Downrod
Slide
Slide
1 2 3 4 5
678910
Sold Separately
Included
Longer
Downrod
for angled
ceilings or
ceilings 10’ or
higher
Shorter
Downrod
for fans installed
close to ceiling
Standard
Downrod
for ceilings 8-10’ high
Option 1Option 2
Option 3
skip to next page
If you need a different downrod length follow these steps:
Steps 1-5 to remove standard downrod pipe
Steps 6-10 to reassemble with new pipe
Included (pre-assembled)

www.HunterFan.com 1.888.830.1326
8
M0080-01 • 05/14/14 • © Hunter Fan Company
KEEP!
8”
3/8”
C
U
T
&
S
T
R
I
P
(not to scale)
Remove the pre-installed
setscrew so that the downrod
can be inserted.
Hand tighten the downrod (at
least 4-5 full turns) until it stops.
The wires can be cut, but
leave at least 8” extending
from the top of the downrod.
Downrod (continued)
8” 3/8”
Tighten the setscrew
with pliers. DO NOT
HAND TIGHTEN.
If the setscrew is not tightened
securely, the fan may fall.
K
E
E
P
!

www.HunterFan.com 1.888.830.1326
Downrod (continued)
DO NOT PICK THE FAN UP BY THE
CANOPY OR WIRES. Place the downrod
ball into the slot in the ceiling bracket.
Put the wires and downrod through
the canopy. Let the canopy sit loosely
on top of the fan.
9
M0080-01 • 05/14/14 • © Hunter Fan Company

www.HunterFan.com 1.888.830.1326
Wiring
Turn the splices upward and push them carefully back through the hanger bracket
into the outlet box. Spread the wires apart, with the grounded wires on one side of
the outlet box and the ungrounded wires on the other side of the outlet box.
Refer to CAUTION c.1 on pg. 2
Using an orange wire
connector from
the hardware
bag, connect the
3 grounding wires
(green, green/yellow
stripe, or bare copper)
coming from the
ceiling, downrod, and
hanging bracket.
F
R
O
M
R
E
C
E
I
V
E
R
F
R
O
M
C
E
I
L
I
N
G
F
R
O
M
C
E
I
L
I
N
G
B
R
A
C
K
E
T
green/yellow stripe (grounding)
green/yellow stripe
green/yellow stripe
black blue
yellow blue
Note: To connect the
wires, hold the bare
metal leads together and
place a wire connector
over them, then twist
clockwise until tight.
Using the orange
wire connectors
from the remote
control hardware
bag, connect the blue
wire from the receiver
to the blue wire (or
possibly black with
white stripe wire) from
the fan. Connect the
yellow wire from the
receiver to the black
wire from the fan.
F
R
O
M
F
A
N
F
R
O
M
F
A
N
F
R
O
M
R
E
C
E
I
V
E
R
Using the orange wire
connectors from
the hardware bag,
connect the black wire
(ungrounded) from
the ceiling to the black
wire from the receiver.
Connect the white
wire (grounded) from
the ceiling to both the
white wire from the
receiver and the white
wire from the fan.
F
R
O
M
C
E
I
L
I
N
G
black (ungrounded) white (grounded)
black white
F
R
O
M
F
A
N
white
10
M0080-01 • 05/14/14 • © Hunter Fan Company

www.HunterFan.com 1.888.830.1326
Canopy
Lift the canopy into place so that
the screw holes are aligned.
Position the canopy so that, when
lifted into place, the canopy ts into
the hanging bracket as shown.
Screw
Holes
Insert the two canopy screws
found in the hardware bag.
Note: Fan style may vary.
11
M0080-01 • 05/14/14 • © Hunter Fan Company

www.HunterFan.com 1.888.830.1326
Blades
Your blades are shielded with Dust Armor® which
is a nanotechnology coating that repels dust. For
cleaning the fan, use soft brushes or cloths to prevent
scratching. Cleaning agents may damage the nishes.
Insert grommets found in the hardware
bag into the holes in the blades, then
secure each blade to a blade iron with
screws found in the hardware bag.
Remember the screws that
you kept after removing the
shipping blocks (page 6)? You
need them for this step.
Lightly attach the blade irons to the
motor with the blade iron armature
screws, then securely tighten after both
screws are attached.
12
M0080-01 • 05/14/14 • © Hunter Fan Company

www.HunterFan.com 1.888.830.1326
Switch Housing
Feed the wire plug through the center
hole of the upper switch housing, then
wrap keyhole slots around the screws and
twist counterclockwise.
Screw two housing assembly screws
from the hardware bag halfway into
the motor housing. It does not matter
which two screw holes you choose.
Insert the third screw, found in
the hardware bag, into place and
then tighten all three screws.
Make sure the upper switch housing is securely
attached to the mounting plate. Failure to properly
secure all 3 assembly screws could result in the switch
housing xture falling.
13
M0080-01 • 05/14/14 • © Hunter Fan Company

www.HunterFan.com 1.888.830.1326
14
M0080-01 • 05/14/14 • © Hunter Fan Company
Connect the plugs from the upper and
lower switch housings. Make sure to line
up the colored markings on
the connectors.
Partially install two of the switch housing
screws found in the bag. Align the notches
in the sides of the lower switch housing with
the screws on the upper switch housing. Twist
the lower switch housing clockwise to lock
into place.
Light Kit
Install the third switch housing screw.
Tighten all three screws securely.
Switch
Housing
Screw
Notch
Make sure the lower switch housing is securely attached to
the upper switch housing. Failure to properly secure all three
assembly screws could result in the light xture falling.
Want to install your fan without a light kit?
Go to www.HunterFan.com/FAQs and click
“How do I install my fan without the light kit?”

www.HunterFan.com 1.888.830.1326
Light Kit (continued)
Install a bulb into each of
the sockets. When necessary,
replace with bulbs of the same
type and wattage.
Note: Glass shade style and number of lights may vary.
Connect the appropriate pull
chain pendant to each of the
short chains coming from the
switch housing.
To install the shade, rst loosen
the thumbscrews. Raise the
shade to the light xture. Tighten
all thumbscrews securely.
Shade
Thumbscrew
Note: In compliance with US federal energy regulations, this ceiling fan
contains a device that restricts its light output. Exceeding the wattage
limit marked on the MAX wattage sticker afxed to the light socket(s)
may result in re hazard or improper operation.
Fan
Pull
Chain
Light
Pull
Chain
Bulb
CONGRATULATIONS!
YOU’RE DONE!
See next page for remote
operation instructions.
15
M0080-01 • 05/14/14 • © Hunter Fan Company

www.HunterFan.com 1.888.830.1326
Remote Control
Note: The remote must be paired before
the fan will operate.
Within 3 minutes of restoring power to
the fan, press both the Fan OFF button and
the Fan ON button for at least 4 seconds.
Your fan will turn on to indicate successful
syncing. If it does not, turn off power to
your fan, wait 1 minute then try again. If
using the transmitter with multiple fans,
repeat this process for each fan.
Fan OFF Fan ON
To access the battery compartment, remove
the small Phillips head screw that secures the
battery door to the transmitter assembly. The
battery should be installed with the positive
(+) side up. Replace with a CR2032 battery
when necessary.
Phillips
Head
Screw
Battery
Door
If you are installing multiple remote-controlled fans on
the same circuit breaker, you may need to perform a few
extra steps to prevent interference or faulty operation of
your remote controls.
Go to www.HunterFan.com/FAQs and click
“How do I properly install multiple remote-controlled fans?”
for more information.
Turn Power
ON
16
M0080-01 • 05/14/14 • © Hunter Fan Company

www.HunterFan.com 1.888.830.1326
17
M0080-01 • 05/14/14 • © Hunter Fan Company
Fan Operation:
Press and quickly release the ON or OFF button on the
remote control to turn the fan OFF or ON.
To change the fan speed, slowly pull the fan pull-chain
switch to select the desired speed.
Light Operation:
Press and quickly release the ON or OFF button on the
remote control to turn the light OFF or ON. (Light will
come on at maximum brightness.)
Operation, Maintenance, & Cleaning
Safe-Exit
• Press the Fan Off button for at least three
seconds to initiate the Safe-Exit Mode.
• The lights will ash for visual conrmation.
• The lights will stay on 50% brightness for 15
seconds and then begin to dim. After a total
of 30 seconds, the lights will be completely
off.
The Safe-Exit Program gives you about
thirty seconds of light when you turn the
lights off to exit the room before the lights
go out.To use Safe-Exit:
Light
Control
Fan
Control

www.HunterFan.com 1.888.830.1326
For cleaning the fan, use soft brushes or
cloths to prevent scratching. Cleaning
products may damage the nishes.
To switch the direction of air ow, move
the reverse switch to the opposite position.
Reverse
Switch
The fan pull chain controls the speed:
from high to off.
The light pull chain controls the light
xture: on and off.
Operation, Maintenance, & Cleaning (continued)
18
M0080-01 • 05/14/14 • © Hunter Fan Company
For questions regarding removing a light kit, call
customer service 1-888-830-1326.

www.HunterFan.com 1.888.830.1326
Troubleshooting
Excessive wobbling
• Tighten all of the blade and
blade iron screws until they
are snug.
• Turn the power off, support
the fan carefully, and check
that the hanger ball is
properly seated.
• Use the provided balancing
kit and instructions to balance
the fan.
Noisy Operation
• Tighten the blade and blade
iron screws until they are snug.
• Check to see if any of the
blades are cracked. If so, replace
all of the blades.
Fan doesn’t work
• Make sure power switch is on.
• Pull the pull chain to make sure
it is on.
• Push the motor reversing switch
rmly left or right to ensure that
it is engaged.
• Check the circuit breaker to
ensure the power is turned on.
• Make sure the blades spin freely.
• Turn off power from the circuit
breaker, then loosen the canopy
and check all the connections
according to the wiring diagram
on page 10.
• Check the plug connection in
the switch housing.
Lights dim when turned on or
do not turn on at all.
• Make sure the wattage of the
light bulbs installed matches
the specications on the light
sockets.
Remote control of fan is erratic
• Make sure the battery is
installed correctly.
• Install a fresh battery.
If you have multiple remotes or
multiple remote-controlled fans
installed on the same circuit
breaker and you are experiencing
interference or faulty operation of
your remote controls, please go to
www.HunterFan.com/FAQs
and click “How do I properly install
multiple remote-controlled fans?”
for information on how to correct
this issue.
19
M0080-01 • 05/14/14 • © Hunter Fan Company
