Hunter 33520 User manual

UltrasonicUltrasonicUltrasonic
Humidier
Owner’s Manual
Model
33520
English
20303-01
20141029

Important Safety Instructions .................................. 3
Using Your Humidier........................................................4
Maintenance ............................................................... 5
Troubleshooting.......................................................... 7
Technical Support....................................................... 8
22
Table of Contents
1-Year Limited Warranty.......................................... 9
20303-01 20141029

3
Important Safety Instructions
READ AND SAVE THESE INSTRUCTIONS!
Important Safety Instructions: Read all instructions before
• ALWAYS place this
• ALWAYS
and electrical appliances such as stoves, radiators, or heaters.
• ALWAYS
• DO
NOT use the product if the cord has been damaged.
• This product has a polarized plug (one blade is wider than the other) as a safety
DO
NOT attempt to defeat or override this safety feature.
• To reduce the risk of electric shock, ALWAYS UNPLUG AND EMPTY
it is being cleaned.
• DO NOT use hot water.
• Never add medication of any type to the Water Tank.
• You should never leave the unit unattended in a closed room. The room can become
saturated and leave condensation on walls and furniture. Always leave a door partially
open.
• DO NOT add water in humidity spout.
•
• DO NOT remove the funnel from the unit while it is turned on.
• DO NOT handle the plug with wet hands.
• Avoid placing the unit where the humidity is pointed directly at an electrical object.
• DO NOT directly inhale the humidity coming from the unit.
• DO NOT clean the unit with detergents or chemicals of any kind. Use only vinegar and
water, as directed.
comply with these warnings may result in electrical shock or serious injury.
20303-01 20141029

4
Initial Setup:
1.
2. Unravel and straighten the cord before use.
3. Remove the Water Tank from the Base by pulling straight up
4. Turn the Water Tank upside down and twist the Water Tank
5. Fill the unit with clean, cool tap water.
Warning:
6. Place the Water Tank Cap back on the Water Tank and turn
it clockwise until secure.
7. Place the Water Tank back into the Base, making sure it is
seated securely.
Note: Failure to ensure the Water Tank is seated correctly
could cause the unit to leak water.
8.
Figure 1
Figure 2
Using Your Humidifier
Tank
Spout
Figure 3
Figure 4
Operation:
1.
until you feel the knob click. At this time, the unit should be on.
Adjust the amount of mist/vapor the unit outputs by turning the
mist adjust knob clockwise. To turn the unit off, turn the power
2.
illuminate.
3.
Function and Features:
Humidity - should be illuminated when unit is running.
indicator on the front panel will light up.
Heat Mist -
Heat Mist button. The Heat Light will illuminate toindicate
will humidifyyour room quicker.
Mist Adjust - Turn dial to adjust the vapor/mist output.
Turn clockwise to increase the output.
360° Spout Rotation - The spout can rotate a full 360°.
Power
Tank
Heat
Mist
Adjust Heat Mist
Humidity
on Tank Handle. (Figure 1)
Cap counter-clockwise to remove. (Figure 2)
knob counter-clockwise until it clicks. (Figure 3)
(Figure 1)
Water
Water
Tank
Handle
o
p
e
n
Power - turns unit off and on. (Figure 3)
Knob
20303-01 20141029

5
Figure 5
Figure 7
Figure 8
Figure 6
Maintenance
Cleaning:
Note: ALWAYS
before cleaning. NEVER allow water to sit in the tank when not
in use.
selected. The remaining water may be hot. Do not submerse any
part of the unit other than the Water Tank.
Cleaning the Water Tank -
Fill the Water Tank with a mixture of one (1) gallon of water and
eight (8) ounces of white vinegar. Leave the mixture in the Water
Tank for 20 minutes, giving the Water Tank a shake every few
discard the mixture.
Cleaning the Water Basin -
Dampen a cloth with a solution of vinegar and water. Wipe
down the Water Basin (Figure 6) with the damp cloth. Rinse
with cool water. DO NOT IMMERSE the Water Basin or hold
Nebulizer (Figure 6) directly under the water tap.
Cleaning the Base -
Wipe all exteriors surfaces of the Base (Figure 5) with a soft, dry
cloth. Do not immerse the Base in water or use water to clean
the Base. As with any electrical appliance, an electrical shock
Cleaning the Nebulizer -
There may be some lime deposits in the Nebulizer (Figure 6),
particularly in areas with hard water. Overcome this by cleaning
the Nebulizer with water and vinegar on a soft cloth regularly
as follows:
•Dampen a cloth with vinegar and wipe the Nebulizer gently,
until the lime deposits disappear completely.
•Gently clean with a dry cloth and remove the residue from the
humidity/vapor.
Cleaning the Fan Vent -
It’s important that the Fan Vent area (Figure 7) is kept clean
and free of obstructions. Simply wipe the Fan Vent with a clean,
surface as the Fan Vent may become blocked and cause the unit
to overheat.
Cleaning the Water Level Sensor -
The Water Level Sensor is made up of the Plastic Cap, the
Water Float, and the Pin. Wipe the parts with a soft damp cloth.
Water
Basin
Nebulizer
Water Level
Sensor
Fan Vent
Plastic Cap
Phillips
Head
Screw
Water Float
Pin
Base
Spout Water
Tank
screwing the Plastic Cap onto the Pin. (Figure 8)
20303-01 20141029

6
Storage:
Follow the instructions for weekly maintenance before storing
the unit. Never store the unit with water in the tank. Allow the
cool, dry place.
Maintenance (continued)
Daily Maintenance:
1.
2. Remove the Water Tank from the unit by pulling it straight
3. Turn the Water Tank upside down and drain any water into
a sink or tub. Shake the unit gently to remove any remaining
4. Rinse the Water Tank thoroughly with water, empty, and
wipe with a clean, dry cloth.
5. Wipe the Base with a dry cloth if necessary.
6.
Figure 9
Figure 10
Water
Tank
Water
Tank
Handle
Weekly Maintenance:
1.
2. Remove the Water Tank from the unit by pulling it straight
3. Turn the Water Tank upside down and drain any water into
a sink or tub. Shake the unit gently to remove any remaining
4. Fill the Water Tank with a mixture of one (1) gallon of water
and eight (8) ounces of white vinegar. Leave the mixture in
the Water Tank for 20 minutes, giving the Water Tank a shake
every few minutes. After 20 minutes, give the Water Tank a
5. Rinse the Water Tank several times with clean water.
Leave the Water Tank Cap off to allow the Water Tank to
dry completely.
6. Wipe the surfaces of the humidier Base with asoft
damp cloth.
7. Once all the parts are clean and dry, reassemble the
Note: The Water Tank has built-in antimicrobial properties to
inhibit the growth of bacteria, mold, and fungi that may affect
the water in the tank. Daily and weekly maintenance is still
necessary to prevent the growth of bacteria, mold, and fungi.
off the Base. (Figure 9)
water. (Figure 10)
water. (Figure 10)
o
p
e
n
20303-01 20141029

7
Troubleshooting
Problem:
Excessive noise
Solution:
• Check the Water Tank to make sure it is properly seated on
the Base.
• Check the Water Tank to make sure there are no bubbles when
the Water Tank is full and running. If there are bubbles, turn
the unit OFF until the bubbling stops. When the bubbling has
stopped, set the unit to the desired speed.
Problem:
Humidier will not turn on
Solution:
• Make sure the unit is plugged in and Power Knob is set to ON
and the ON Light is illuminated.
Problem: Humidier shuts off
Solution:
• Make sure Water Tank has water in it.
• Clean Water Float. Refer to the “Cleaning” section on page 5.
Problem:
White dust or mineral build-up on the unit
Solution:
• Refer to the “Cleaning” section on page 5.
Problem:
Humidity output and water usage decreased
Solution:
• Check the Vapor Control to make sure it is set to the desired
humidity level and speed.
• Check the Water Tank to make sure there are no bubbles when
the Water Tank is full and running. If there are bubbles, turn
the unit OFF until the bubbling stops. When the bubbling has
stopped, set the unit to the desired speed.
• Clean any components that have mineral build-up. Refer to the
“Cleaning” section on page 5.
• Check the Fan Vent and remove any obstructions.
Problem:
Humidier produces a strange odor
Solution:
• Rell Water Tank with fresh water.
• Be sure to perform regular maintenance.
20303-01 20141029

8
If you need any assistance with setup, operation, or parts
support staff is ready to help!
Technical Support
Notes
USA: 1-888-880-3267
We open 24 hours a day, 7 days a week. You may also reach
us online at www.HunterHomeComfort.com.
20303-01 20141029

9
to the original residential user or consumer purchaser of the
ultrasonic humidier:
If any part of The ultrasonic humidier fails during the rst
material or workmanship, we will provide a replacement part
free of charge.
If no replacement part can be provided, we will replace your
Humidier.
IF THE ORIGINAL RESIDENTIAL USER OR CONSUMER
PURCHASER CEASES TO OWN THE ULTRASONIC HUMIDIFIER,
THIS WARRANTY AND ANY IMPLIED WARRANTY WHICH
THEN REMAINS IN EFFECT, INCLUDING BUT NOT LIMITED
TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, ARE VOIDED. THIS
WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES.
THE DURATION OF ANY IMPLIED WARRANTY, INCLUDING
BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
IS EXPRESSLY LIMITED TO THE PERIOD OF THE EXPRESS
WARRANTY SET FORTH ABOVE.
This warranty is voided if your ultrasonic humidier is not
This warranty excludes and does not cover defects, malfunctions,
or failures of the humidier which were caused by repairs by
persons not authorized by us, use of parts, or accessories not
authorized by us, mishandling, modications, or damage
to the humidier while in your possession, or unreasonable
use, including failure to provide reasonable and necessary
maintenance. This warranty does not cover humidiers used
in commercial applications. There are no express or implied
warranties as to commercial purchasers or users.
other transportation to our factory service center. We will return
the humidier freight prepaid to you. The humidier should be
properly packaged to avoid damage in transit since we will
not be responsible for any such damage. Proof of purchase
is required when requesting warranty service. The purchaser
must present the sales receipt or other document that establishes
proof of purchase.
The Hunter Home Comfort makes the following warranty
purchased and used in the USA.
-3267. You will be responsible for insurance and freight or
To obtain service, contact the nearest Hunter authorized service
center of the Hunter Home Comfort Service Department, 2260
Northwest Pkwy., Suite I, Marietta, Georgia 30067, 1-888-880
-Year Limited Warranty
1
Warranty
1 Year
1 (one) year from the date of purchase due to a defect in
20303-01 20141029

10
FOR DIRECT, INDIRECT, SPECIAL, CONSEQUENTIAL OR
INCIDENTAL DAMAGES IN EXCESS OF THE PURCHASE PRICE
OF THE HUMIDIFIER. YOUR SOLE REMEDY WILL BE REPAIR
OR REPLACEMENT AS PROVIDED ABOVE. SOME AMERICAN
STATES AND CANADIAN PROVINCES DO NOT ALLOW:
• LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS;
• THE EXCLUSION OR LIMITATION OF DIRECT, INDIRECT,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES;
• THE EXCLUSION OR INVALIDITY OF EXPRESS OR IMPLIED
WARRANTIES IF THE USER CEASES TO OWN THE HUMIDIFIER;
• THE LIMITATION OF THE REMEDIES AND RECOURSES
AVAILABLE TO THE PURCHASER; OR THE INVALIDITY OF AN
EXPRESS WARRANTY WHEN A PRODUCT IDENTIFIED BY
BRAND NAME IS NOT USED (UNLESS SPECIFIC CONDITIONS
ARE FULFILLED);
SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT
APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND
YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM
STATE TO STATE OR PROVINCE TO PROVINCE.
IN NO EVENT SHALL HUNTER HOME COMFORT BE LIABLE
Warranty
1 Year
-Year Limited Warranty
1
Hunter is a trademark of the Hunter Fan Company and
is used under license to Hunter Home Comfort.
2260 Northwest Pkwy., Suite I, Marietta, GA 30067
Printed in China
20303-01 20141029
