Hunter Institutional Series User manual

ON
I40
V
'JH
0QQPTJOH/P[[MF
"EKVTUNFOU4PDLFU
-JGU6Q
4PDLFU
4QFDJGJD
.PEFM
/P[[MF
3FUBJOFS
3BOHF
"EKVTUNFOU
4DSFX
*OEJDBUFT
74UBU
¡
4FMG
"EKVTUJOH
4UBUPS
®
I-40
ADS
'JH
8BUFS
'MPX
Correct Installation
ARC ADJUSTMENT
All I-40-36S-ON heads are 360˚ ONLY. There
is no arc adjustment. For less than 360˚ use
I-40-ADS.
RADIUS ADJUSTMENT
Insert the hex end of the Hunter wrench into the
nozzle-retainer/range-adjustment screw (Fig. 1).
Turn the screw clockwise into the stream of water
to decrease the radius, or counter-clockwise to
increase the radius.
PRECIPITATION RATE ADJUSTMENT
Where excessively wet or dry areas are a
problem, the precipitation rate may be adjusted.
Simply replace the existing nozzle with a larger
one to increase, or a smaller one to decrease the
rate of precipitation.
NOZZLE INSTALLATION
1. Insert the key end of the Hunter wrench into
the lifting socket of a pop-up sprinkler. Pull the
riser up to gain access to the nozzle socket.
2. Using the Hunter wrench, loosen the nozzle-
retainer/range-adjustment screw. If a nozzle is
already installed in the sprinkler, it may now be
removed by briey turning on the water.
3. Discard nozzle if removed with pliers.
Slip the desired nozzle into the nozzle socket.
Note that the socket is angled up 25˚ (see
Fig. 2). Tighten the nozzle-retainer/range-
adjustment screw.
4. Install like opposing nozzles.
Hunter Industries Incorporated • The Irrigation Innovators © 2007 Hunter Industries Incorporated
www.HunterIndustries.com P/N 700590 LIT-276 4/07
I-40-36S-ON
Institutional Series™ Gear-Driven Sprinklers

*40/NJOVUFTBQQSPY
I-41 Dual Opposing Nozzle
Performance Data – Metric
Nozzle
Pressure
Bars kPa
Radius
m
Flow
m3/hr l/min
Precip mm/hr
15
Gray
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
15.2
15.8
16.2
16.8
17.1
17.4
2.75
2.91
3.06
3.20
3.32
3.46
45.8
48.5
51.0
53.3
55.4
57.7
24
23
23
23
23
23
27
27
27
26
26
26
18
Red
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
17.4
17.7
18.0
18.0
18.3
18.9
2.90
3.15
3.38
3.61
3.82
4.05
48.3
52.5
56.4
60.1
63.7
67.5
19
20
21
22
23
23
22
23
24
26
26
26
20
Dk. Brown
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
18.9
19.2
19.5
20.1
19.8
20.1
4.26
4.54
4.80
5.08
5.32
5.55
71.1
75.6
80.0
84.7
88.7
92.5
24
25
25
25
27
27
28
28
29
29
31
32
23
Dk. Green
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
19.5
19.8
20.1
20.4
20.7
20.7
4.55
4.85
5.14
5.45
5.71
5.96
75.8
80.8
85.6
90.8
95.1
99.4
24
25
25
26
27
28
28
29
29
30
31
32
25
Dk. Blue*
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
20.1
20.4
20.7
21.0
21.3
21.3
4.92
5.23
5.52
5.84
6.10
6.36
82.1
87.2
92.0
97.3
101.7
106.0
24
25
26
26
27
28
28
29
30
30
31
32
28
Black
4.5
5.0
5.5
6.0
6.5
7.0
448
496
552
600
648
696
21.0
21.3
21.9
22.3
22.6
23.2
6.38
6.68
7.00
7.27
7.52
7.76
106.4
111.3
116.7
121.1
125.3
129.4
29
29
29
29
30
29
33
34
34
34
34
33
* Factory-installed nozzle
Note: All precipitation rates calculated for 360 degree operation.
* Factory-installed nozzle
Note: All precipitation rates calculated for 360 degree operation.
I-40 Dual Opposing Nozzle
Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
15
Gray
50
60
70
80
52'
54'
56'
57'
13.0
13.2
14.4
15.5
0.46
0.44
0.44
0.46
0.53
0.50
0.51
0.53
18
Red
50
60
70
80
58'
59'
60'
62'
13.7
15.2
16.6
17.8
0.39
0.42
0.44
0.45
0.45
0.49
0.51
0.51
20
Dk. Brown
60
70
80
90
63'
64'
66'
66'
19.1
20.9
22.3
23.9
0.46
0.49
0.49
0.53
0.53
0.57
0.57
0.61
23
Dk. Green
60
70
80
90
65'
66'
67'
68'
20.4
22.3
24.0
25.6
0.46
0.49
0.51
0.53
0.54
0.57
0.59
0.62
25
Dk. Blue*
60
70
80
90
66'
68'
69'
70'
22.0
24.0
25.9
27.2
0.49
0.50
0.52
0.53
0.56
0.58
0.60
0.62
28
Black
70
80
90
100
70'
72'
74'
76'
28.9
30.9
32.9
33.7
0.57
0.57
0.58
0.56
0.66
0.66
0.67
0.65
Performance Charts
Full Circle Rotation Speed
Data represent test results in zero wind. Adjust
for local conditions. Radius may be reduced up
to 25% with adjustment screw (this may alter the
uniformity of the spray pattern).
I-40-36S-ON
Institutional Series™ Gear-Driven Sprinklers
