Husqvarna LP 9505 User manual

LP 9505
EN Operator's manual 2-49

Contents
Introduction..................................................................... 2
Safety............................................................................14
Operation...................................................................... 19
Maintenance................................................................. 30
Transportation, storage and disposal........................... 41
Technical data.............................................................. 44
EC Declaration of Conformity....................................... 48
Supplier's declaration of Conformity............................. 49
Introduction
California Proposition 65
WARNING!
The engine exhaust from this
product contains chemicals known
to the State of California to cause
cancer, birth defects or other
reproductive harm.
Product description
The product is a trench compactor with articulation
joints. The product has a combustion engine and it is
operated with a remote control.
Intended use
The product is for professional operation only. The
product is used for compaction of moderately thick
layers to layers of larger depth of granular soils. Use the
product to make the surface smooth. Examples of such
work are in trenches and on roads.
21423 - 002 - 03.04.2020

Product overview
3
2
8
5
4
10
1
7
9
11
6
12
1. Fuel filters. Refer to Product overview, fuel filters on
page 4 .
2. Front machine distance sensor (MDS)
3. Front cover
4. Front parts. Refer to
Product overview, front parts on
page 5 .
5. Scrapers
6. Tie-down bracket
7. Rear hatch. Refer to Product overview, rear hatch on
page 6 .
8. Warning light
9. Rear cover
10. Rear parts. Refer to
Product overview, rear parts on
page 7 .
11. Lifting eye
12. Operator's manual
1423 - 002 - 03.04.2020 3

Product overview, fuel filters
2
1
3
1. Fuel filter
2. Drain plug for the water separator
3. Fuel prefilter
41423 - 002 - 03.04.2020

Product overview, front parts
7
9
1
45
6
10
3
2
8
1. Radiator coolant cap
2. Radiator coolant tank
3. Sight glass for radiator coolant level
4. Engine oil cap
5. Oil dipstick
6. Loudspeaker
7. Air filter
8. Vacuator valve
9. Muffler
10. Engine oil filter
1423 - 002 - 03.04.2020 5

Product overview, rear hatch
3
56
4
8
1
7
2
1. Remote control. Refer to Product overview, remote
control on page 8 and Symbols on the remote
control on page 12 .
2. Electrical panel. Refer to Symbols on the electrical
panel on page 13
.
3. Battery charger for remote control battery
4. Fuse box
5. 12 V power socket
6. Battery switch
7. Remote control belt
8. CAN bus cable
61423 - 002 - 03.04.2020

Product overview, rear parts
6
7
2
8
9
5
3
4
10
1
2
1. Sight glass for hydraulic oil level
2. Antenna
3. Cover for the hydraulic oil filter
4. Hydraulic oil tank
5. Cap for the hydraulic oil tank and breather filter
6. Fuel tank cap
7. Fuel tank
8. Buzzer
9. Starter battery
10. Receiver. Refer to Product overview, receiver on
page 9
.
1423 - 002 - 03.04.2020 7

Product overview, remote control
9
16
15
14
13
12 11 10
3
8
16
2
17
7
45
1. Button to make selections in the menus
2. ON/OFF button
3. Display
4. Indicator for front machine distance sensor
5. Indicator for rear machine distance sensor
6. Button to scroll in the menus
7. Indicator for main contactor
8. Indicator for battery voltage
9. Joystick, move forward/rearward
10. Emergency stop button
11. Switch for high/low amplitude for vibration
12. Switch for manual/automatic vibration
13. Switch for engine start/stop
14. Switch for engine speed
15. Switch for operation speed
16. Joystick, move left/right
17. Horn button/radio communication button
81423 - 002 - 03.04.2020

Product overview, receiver
STATUS LED RX
PWR CAN CABLE PAIRING
ANT
FSK12
21 3
7 6 5
4
1. Antenna
2. Status indicator
3. "RX" indicator
4. Pairing operation button
5. Connector for cable remote control
6. Connector for CAN bus cable
7. Connector for power
1423 - 002 - 03.04.2020 9

Product overview, fuses
1
37
5
11 10 9
12
8
64
2
1. F1: 7.5 A, electronic control unit
2. F2: 7.5 A, electronic control unit
3. F3: 7.5 A, electronic control unit
4. F4: 7.5 A, electronic control unit
5. F5: 7.5 A, electronic control unit
6. F6: 5 A, fuel pump and fuel level switch
7. F7: 5 A, charger for the remote control battery
8. F8: 10 A, 12 V power socket
9. F9: 40 A, throttle solenoid
10. F10: 30 A, starter and shut-off solenoid
11. F11: 30 A, glow plugs
12. F0: 150 A, starter
Symbols on the product
WARNING: This product can be dangerous
and cause serious injury or death to the
operator or others. Be careful and use the
product correctly.
Read the manual carefully and make sure
that you understand the instructions before
you use the product.
Use a protective helmet in locations where
objects can fall on you. Use approved
hearing protection. Use approved eye
protection.
10 1423 - 002 - 03.04.2020
