Clarin Portable Seating
Page 1
Table of Contents
Page
2 Maintenance and Cleaning Instructions
3 2000S, 2617, 3400 Prole Drawings
4 3400, 4010, 4400 Prole Drawings
5 4400, Club, VIP Prole Drawings
6 Wide Chair Prole Drawings
7 Storage Carts
8 Storage Cart Capacity Matrix

Clarin by Hussey Seating
38 Dyer Street Ext. nNorth Berwick, ME 03906 USA
tel [phone] nfax +1 207.676.2222
www.husseyseating.com [e-mail]
10/11
Clarin Portable Seating
Page 2
Maintenance and Cleaning
Portable Seating Maintenance and Cleaning Instructions
Tablet surfaces require minimum maintenance. To clean laminates, use mild solution of water and
detergent. Wipe clean with a dry cloth. Dicult stains such as coee or tea can be removed using a
mild household cleaner/detergent and a soft bristle brush, repeating as necessary. If a stain persists,
use a paste of baking soda and water and apply with a soft bristled brush. Light scrubbing for 10-20
strokes should remove most stains. Dry thoroughly. Do not scrub excessively. Occasionally apply a
light coat of wax to maintain bright, attractive surface.
Clarin portable seating Products all steel frames can be kept clean with a mild soap and water solu-
tion. Dry thoroughly.
Clarin recommends professional upholstery cleaning for best overall results. The following cleaning
methods can be used for regular care with upholstery fabric:
˙Vacuuming or light brushing is recommended to prevent dust and soil buildup.
˙Clean with water-based cleaning agents, foam or pure water-free solvents.
Clarin recommends the following cleaning methods for upholstery vinyl:
˙Prompt and energetic washing using a mild soap solution.
˙Regular cleaning using mild soap and water, then fresh water rinse.
Note: The information provided above should be viewed only as a service or guideline, not as a war-
ranty.

Clarin by Hussey Seating
38 Dyer Street Ext. nNorth Berwick, ME 03906 USA
tel [phone] nfax +1 207.676.2222
www.husseyseating.com [e-mail]
10/11
Clarin Portable Seating
Page 3
2000S, 2617, 3400
2000S All Steel Folding Chair
181
4"
383
8"
21"
17"
327
8"
2
7
8"
14"
2617B Folding Chair
381
4"
181
4"
1
7
8"
325
8"
207
8"
17"
3400B Folding Chair
397
8"
221
2"
321
2"
181
4"
161
2"
4"
19"
CLARIN
3400C Contour Folding Chair
181
4"
19"
22 1/2"
32 1/4"
18"
FRAME
397
8"
51
4"
CLARIN
3400FLX Flex Seat Folding Chair
24"
17"
32"
3"
181
4"
39"
CLARIN
CLARIN
3400B-HD Heavy Duty Folding Chair
321
2"
221
2"
CLARIN
19"
CLARIN
181
4"
41
4"
397
8"
18"
FRAME
CLARIN

Clarin by Hussey Seating
38 Dyer Street Ext. nNorth Berwick, ME 03906 USA
tel [phone] nfax +1 207.676.2222
www.husseyseating.com [e-mail]
10/11
Clarin Portable Seating
Page 4
3400, 4010, 4400
397
8"
19"
32 1/4"
181
4"
18"
FRAME
22 1/2"
281
2" OPEN
221
2"FOLDED
235
8"
12"
63
8"
CLARIN
181
4"
397
8"
321
2"
181
4"
221
2"
4" 221
2"
CLARIN
3400B Tablet Arm Folding Chair 3402B 2-Arm Folding Chair
181
4"
381
2"
3"
313
4"
211
2"
17"
18"
181
4"
381
2"
33
4"
313
4"
211
2"
17"
221
2"
4010B Uplift Seat Folding Chair 4012B Uplift Seat w/Arms Folding Chair
4400B Folding Chair
21"
323
4"
19"
181
4"
FEET
43
4"
393
4"
18"
FRAME
4402B Folding Chair
221
2"
ARMS
181
4"
FEET
19"
323
4"
21"
393
4"
51
2"

Clarin by Hussey Seating
38 Dyer Street Ext. nNorth Berwick, ME 03906 USA
tel [phone] nfax +1 207.676.2222
www.husseyseating.com [e-mail]
10/11
Clarin Portable Seating
Page 5
4400, Club, VIP
4400 Contour Seat Folding Chair
18 1/4"
6"
39 1/2"
211
2"
32 3/4"
18"
FRAME
19"
4400FLX Flex Seat Folding Chair
32"
20"
23"
17"
181
4"
39"
31
2"
5400B Club Folding Chair
39°
31°
181
4"
7"
361
2"
231
4"
151
2"
431
2"
2.5°
18"
5402B Folding Chair
221
2"
18"
161
2"
18"
151
2"
231
4"
361
2"
431
2"
151
2"
7"
35400B Wide Club Folding Chair
191
2"
7"
361
2"
231
4"
151
2"
431
2"
18"
151
2"
5300 VIP Folding Chair
151
2"
25"
37"
44"
FOLDED HIGHT
181
2"
19"
57°"
101
2"

Clarin by Hussey Seating
38 Dyer Street Ext. nNorth Berwick, ME 03906 USA
tel [phone] nfax +1 207.676.2222
www.husseyseating.com [e-mail]
10/11
Clarin Portable Seating
Page 6
Wide Chairs
33400E Wide Folding Chair 33400E Folding Chair
33400E Contour Seat Folding Chair
321
2"
221
2"
CLARIN
CLARIN
153
4"
151
2"
397
8"
193
4"
FEET
4"
(2.5" FOAM) 191
2"
FRAME
CLARIN
325
8"
393
4"
22 1/2"
181
2"
191
2"
393
4"
18"
191
2"
24"
4"
193
4"
181
2"
22 1/2"
32 1/4"
397
8"
41
2"191
2"
FRAME
CLARIN
321
2"
221
2"
CLARIN
CLARIN
19"
397
8"
193
4"
41
4"
191
2"
FRAME
CLARIN
33400E-HD Heavy Duty Folding Chair
34400E Wide Uplift Seat Folding Chair 34400E Contour Seat Folding Chair
19"
323
4"
21"
191
2"
FRAME
193
4"
FEET
393
4"
43
4"
391
2"
211
2"
32°
32
1
2
"
40°
181
2"
191
2"
18"
51
2"
191
2"
FRAME

Clarin by Hussey Seating
38 Dyer Street Ext. nNorth Berwick, ME 03906 USA
tel [phone] nfax +1 207.676.2222
www.husseyseating.com [e-mail]
10/11
Clarin Portable Seating
Page 7
Storage Carts
Detachable Arm Cart Studio Cart
WHENLOADING
WHENUNLOADING
UNEVENLOADINGORUNLOADINGMAYCAUSETHETRUCKTO TIP
OVER
CAUTION CAUTION
CAUTION
-LOADBOTHSIDESOFTHEBOTTOMRACKS FIRST -UNLOADBOTHSIDESOFTHETOPRACK
FIRST
311
4" REF.
771
4"
REF.
79" REF.
-LOADBOTHSIDESOFTHEBOTTOMRACKS
FIRST
-UNLOADBOTHSIDESOFTHETOPRACK
FIRST
CAUTION CAUTION
CAUTION
UNEVENLOADINGORUNLOADINGMAYCAUSETHETRUCKTO TIP
OVER
WHENLOADING
WHENUNLOADING
-LOADBOTHSIDESOFTHEBOTTOMRACKS
FIRST
-UNLOADBOTHSIDESOFTHETOPRACK
FIRST
CAUTION CAUTION
CAUTION
UNEVENLOADINGORUNLOADINGMAYCAUSETHETRUCKTO TIP
OVER
WHENLOADING
WHENUNLOADING
53"
40"
21"
REF
HT-301 Hanging Chair Cart
-LOADBOTHSIDESOFTHEBOTTOM RACKS FIRST -UNLOADBOTHSIDESOFTHETOPRACK
FIRST
CAUTION CAUTION
CAUTION
UNEVENLOADINGORUNLOADINGMAYCAUSETHETRUCK TO TIP
OVER
WHENLOADING
WHENUNLOADING
-LOADBOTHSIDESOFTHEBOTTOM RACKS FIRST -UNLOADBOTHSIDESOFTHETOPRACK
FIRST
CAUTION CAUTION
CAUTION
UNEVENLOADINGORUNLOADINGMAYCAUSETHETRUCK TO TIP
OVER
WHENLOADING
WHENUNLOADING
CAUTION CAUTION
CAUTION
UNEVENLOADINGORUNLOADINGMAYCAUSETHETRUCK TOTIP
OVER
WHENLOADING
WHENUNLOADING
-LOADBOTHSIDESOFTHEBOTTOM RACKS FIRST -UNLOADBOTHSIDESOFTHETOPRACK FIRST
79" REF. 311
4" REF.
743
8"
REF.
CT-311 Flat/Edge Cart
102 1
4" REF.
261
4"
REF.
24"
REF.
185
8"
CPT-360 Stacking Cart
117"
113 3
4" TOP OUTSIDE
403
8"
REF.
521
2"
481
4"
50"
321
8"
REPLACEMENTPARTSMUSTBESUPPLIEDBYMANUFACTURER
CAUTION WARNING
DANGER
FAILURETOCONFORMTO all STICKERSMAYRESULT IN
PRODUCTDAMAGE,EQUIPMENTDAMAGEAND/ORPERSONAL
INJURY
IFSTACKINGTRUCKS,A
STARTERBLOCKISREQUIRED
-
MAXIMUM3TRUCKSPER
STACK.
CAUTION WARNING
DANGER
Additional storage cart models are available.
See Storage Cart Matrix on the next page.

Clarin by Hussey Seating
38 Dyer Street Ext. nNorth Berwick, ME 03906 USA
tel [phone] nfax +1 207.676.2222
www.husseyseating.com [e-mail]
10/11
Clarin Portable Seating
Page 8
Storage Cart Capacities
