Hussmann Elite Series User manual

Service Merchandisers
Fresh Meat, Delicatessen, and Seafood Merchandisers
(Includes Wedge Installation)
NSF®Certied
Installation &
Operation Manual
Shipped With Case Data Sheets
P/N 0453549_M
Elite Series
August 2018
Spanish 0486359
French 0521927
MANUAL- I/O SERVICE ELITE
IMPORTANT
Keep in store for
future reference!

INSTALLATION
NSF Certification ..................... 1-1
Location ............................. 1-1
Shipping Damage ..................... 1-1
Exterior Loading ...................... 1-2
Merchandisers Shipped
with End Installed ...................... 1-2
Shipping Braces ....................... 1-2
Shipping Rider ........................ 1-2
Case Leveling ......................... 1-3
Front Glass Positioning ................ 1-4
Joining Instructions .................... 1-8
Installing Bumpers .............................. 1-10
Installing Partitions .............................1-11
REFRIGERATION / ELECTRICAL
Refrigerant ........................... 2-1
Refrigerant Piping ..................... 2-1
Insulation ........................... 2-2
Suction Line .......................... 2-2
Liquid Line .......................... 2-2
Control Settings ....................... 2-2
Refrigeration Thermostat ............... 2-3
Defrost Termination Thermostat ......... 2-3
Merchandiser Electrical Data ............ 2-4
Electrical Connections . . . . . . . . . . . . . . . . . . 2-4
Field Wiring .......................... 2-4
Identification of Wiring ................ 2-4
DRIP PIPING AND SPLASHGUARDS
Waste Outlet and Water Seal ............ 3-1
Installing Drip Piping .................. 3-1
Installing Lower Front Panels ........... 3-2
Installing Bottom Rear Panel ............ 3-3
START UP / OPERATION
Start Up ............................. 4-1
Load Limits .......................... 4-1
Load Limit Profiles .................... 4-1
Stocking ............................. 4-2
Installing Shelves ...................... 4-2
Multi-Deck Shelf Alginment ............ 4-3
Shelf Maximum Weight Limits ........... 4-3
LED Light Fixtures .................... 4-4
Fluorescent Fixtures ................... 4-5
Procedure for Installing Lighted Shelves.... 4-5
Installing FDA/NSF Required
Thermometer ......................... 4-6
MAINTENANCE
Care and Cleaning ..................... 5-1
Interior Cleaning Steps ................. 5-2
Cleaning Coils ........................ 5-5
Maintaining Fluorescent Lamps ...........5-7
SERVICE
Replacing Fan Motors and Blades ........ 6-1
Replacing Ambient Fan and
Ambient Heater ....................... 6-2
Removing Rail Lamp Cover ............. 6-3
Electrical Service Receptacles ............ 6-3
Replacing Fluorescent Lamps ........... 6-3
Replacing Lamp Holders and End Caps ... 6-4
Replacing Electronic Ballast ............. 6-4
Replacing LEDs ....................... 6-5
Replacing Power Supply(s) ...............6-6
Replacing Cylinders —
Single Pane Glass .................... 6-7
Replacing Glass Hand Grip ............. 6-8
Replacing Front Glass ................. 6-8
Replacing Damaged Drain Fitting ........ 6-9
Repairing Aluminum Coils .....................6-10
WARRANTY
P/N 0453549_L iii
CONTENTS
IMPORTANT
KEEP IN STORE FOR FUTURE REFERENCE
Quality that sets industry standards!
12999 St. Charles Rock Road • Bridgeton, MO 63044-2483
U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900
www.hussmann.com
© 2018 Hussmann Corporation

* * * * * * * * * * * * * * * * * * * * * * * * * *
ANSI Z535.5 DEFINITIONS
• DANGER – Indicate[s] a hazardous
situation which, if not avoided, will
result in death or serious injury.
• WARNING –Indicate[s] a hazardous
situation which, if not avoided, could
result in death or serious injury.
• CAUTION –Indicate[s] a hazardous
situation which, if not avoided, could
result in minor or moderate injury.
• NOTICE – Not related to personal injury –
Indicates[s] situations, which if not avoided,
could result in damage to equipment.
REVISION HISTORY
REVISION M — AUGUST 2018
1. Proposition 65 Warning - supercedes prior
Proposition 65 Warning
REVISION L — OCTOBER 2015
1. Loctite for set screws; 6-9
REVISION K — NOVEMBER 2014
1. Proposition 65 Warning Page 1-1
2. no sealer on Drain Fitting, Page 6-7, note on 3-2
REVISION H — JULY 2013
1. Added photo Page 1-7; removed all Allen bolt
references
2. Added Page 6-5 and 6-6, LED replacement;
Power Supply Replacement
REVISION G— APRIL 2013
1. Revised Horizontal and Vertical Glass Adjustment,
page 1-5 to 1-7
2. Added Warning statement “flammable materials”,
Page 1-2 and Page 4-2
REVISION F— NOVEMBER 2012
1. Added Installing Shelves, page 4-2
2. LED Light Fixtures, page 4-4
3. Added cleaning coils, page 5-5
REVISION E— DECEMBER 2011
1. New Ambient Heater Drawings, page 6-2
REVISION D— APRIL 2011
1. Added boxed note, page 4-1
REVISION C— AUGUST 2010
1. Added shelf weight limits table, page 4-1
2. Added wedge joining notice, page 1-6
REVISION B— FEBRUARY 2010
1. Updated electrical information, page 2-4
2. Revised drip piping pitch, page 3-1
3. Updated fluorescent lamp disposal, page 6-3
4. Added back page
REVISION A
1. Added Optional Wrapping Board, page 1-9
2. Added Optional Scale Stand, page 1-11
3. Added NSF Thermometer, pages 4-4, 4-5
4. Updated acceptable water temperature,
pages 5-1 and 5-5
5. Added information on cleaning anti-reflective glass,
page 5-6
6. Updated warning, caution, and notice boxes
throughout
7. Added Call Center telephone numbers to bottom of
each page
U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
iv Contents
P/N 0453549_L




P/N 0453549_M 1-1
Elite Service Merchandisers
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
NSF LISTING
These merchandisers are manufactured to
meet ANSI / UL 471 standard requirements
for safety. Proper installation is required to
maintain this listing. Near the serial plate,
each case carries a label identifying the type of
conditions for which the merchandiser was
tested.
ANSI/NSF-7 Type I – Display
Refrigerator / Freezer Intended for 75°F /
55%RH Ambient Application
ANSI/NSF-7 Type II – Display
Refrigerator / Freezer Intended for 80°F /
55%RH Ambient Application
ANSI/NSF-7 – Display Refrigerator
Intended for Bulk Produce
FEDERAL / STATE REGULATION
These merchandisers, at the time they are
manufactured, meet all federal and state /
provincial regulations.
LOCATION
These merchandisers are designed for dis-
playing products in air conditioned stores
where temperature is maintained at or below
the ANSI/NSF-7 specified level and relative
humidity is maintained at or below 55%.
Placing refrigerated merchandisers in direct
sunlight, near hot tables or near other heat
sources could impair their efficiency.
Like other merchandisers, these are sensi-
tive to air disturbances. Air currents passing
around merchandisers will seriously impair
their operation. Do NOT allow air condition-
ing, electric fans, open doors or windows, etc.
to create air currents around the merchandisers.
Product should always be maintained at proper
temperature. This means that from the
time the product is received, through storage,
preparation and display, the temperature of
the product must be controlled to maximize
the life of the product.
SHIPPING DAMAGE
All equipment should be thoroughly exam-
ined for shipping damage before and during
unloading. This equipment has been carefully
inspected at our factory. Any claim for loss
or damage must be made to the carrier. The
carrier will provide any necessary inspection
reports and/or claim forms.
Apparent Loss Or Damage
If there is an obvious loss or damage, it must
be noted on the freight bill or express receipt
and signed by the carrier’s agent; otherwise,
carrier may refuse claim.
Concealed Loss Or Damage
When loss or damage is not apparent until
after equipment is uncrated, retain all packing
materials and submit a written request to the
carrier for inspection, within 15 days.
INSTALLATION

1-2 InstallatIon
P/N 0453549_M U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
MERCHANDISERS SHIPPED
WITH END INSTALLED
Important:Be careful not to damage the
factory installed end while moving the case.
Make sure that tools are positioned past the
end and beneath the merchandiser’s support
bar.
SHIPPING BRACES
Move the fixture as close as possible to its
permanent location and then remove all pack-
aging and shipping braces. Check for damage
before discarding packaging. Remove all
separately packed accessories such as kits, and
shelves.
Remove all nut retainers used with shipping
braces. NSF certification requires the use of
ANSI Standard nuts and bolts with not more
than two (2)threads showing after installa-
tion.
SHIPPING RIDER
Each case is shipped on a rider to protect
factory-installed legs, and to make position-
ing the case easier. Remove the rider after the
case has been positioned.
Note: Once the rider is removed, the case
must be lifted –NOT PUSHED– to repo-
sition. To remove the rider, remove screws
attaching each leg to rider. Remove screws
holding rider cross-members, then slide
cross-members out from between sides. Once
cross-members are out, slide the sides out.
Do NOT stand or walk on top of
merchandiser because. Do not place items
or flammable materials atop the unit.
Cross-Members
Screws
(each leg)
Sides
Leg
Shipping Rider
for 8 ft Case Screws
(two each end
of each
cross-member)
Do NOT remove shipping braces until
the merchandisers are positioned for
installation. Frames may be damaged.
This warning does not mean that Hussmann products
will cause cancer or reproductive harm, or is in
violation of any product-safety standards or
requirements. As clarified by the California State
government, Proposition 65 can be considered more of
a‘right to know’ law than a pure product safetylaw.
When used as designed, Hussmann believes that our
products are notharmful. We provide the Proposition
65 warning to stay in compliance with California State
law. It is your responsibility to provide accurate
Proposition 65 warning labels to your customers when
necessary. For more information on Proposition 65,
please visit the California State government website.
August 31, 2018

P/N 0453549_M 1-3
Elite Service Merchandisers
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
CASE LEVELING
Merchandisers must be installed level to
ensure proper operation of the refrigeration
system and to ensure proper drainage of
defrost water. During all steps of setting, join-
ing and leveling cases, close attention to glass
position and operation must be maintained.
Please review all steps and photos before
making any adjustments. DO NOT make any
glass adjustments until individual case is set
and level.
Preparation
1. Using store blueprints, measure off and
mark on floor the exact dimensions/loca-
tions of the case footprint.
2. Snap a chalk line for the front and rear
positions of the base legs.
3. Mark the location of each joint from front
to back lines.
4. FLOORS ARE NOT LEVEL!!! When
working with two or more cases to be
joined, the whole lineup must be leveled
on the same plane, left to right and front
to back. This means that the entire line-
up must be brought up to the level of the
highest case in the lineup.
Along the lines previously marked, find
the highest point of the floor by:
• Walking the floor and noticing any
dips or mounds;
• Using a string level; and
• Using a transit.
The top cylinders, which allow the raising
and lowering of this glass, have been carefully
installed and tested for the proper tension
before shipment. However, during shipment
and storage, the lubricant inside the cylinders
may have settled. This settling can cause ex-
cessive or uneven tension on the glass to the
point of breakage.
To avoid any damage, please do the fol-
lowing before completely raising the front
glass.
1. Slowly raise and lower each glass section
6 times to a height of 6 in. (152 mm).
2. Increase the height to about 12 in. (305
mm) and raise and lower the glass 6
times.
3. Then raise the glass to the full extension
and lower.
This should release any settled lubricant in
the cylinders and prevent any stress on the
front glass. Leveling and adjustment proce-
dures begin on Page 1-3.
Read before raising front glass to prevent
injury from broken or falling glass.
in.
6 in.
6 in.
6 in.

1-4 InstallatIon
P/N 0453549_M U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
Leveler Adjustment
Position the first case at the highest
point. Set a long level (4 ft [1220 mm] or
more) on the upper front panel of the
case. Use an open-end wrench to turn leg
levelers until the case is level from end to
end and from front to back. Check all 6
legs on 8 ft (2438 mm) cases, or 8 legs on
12 ft (3658 mm) cases.
Note: To avoid removing concrete floor-
ing, begin lineup leveling from the highest
point of the store floor.
Attention to glass position is critical during
the leveling process.
Adjusting leg levelers will affect the posi-
tion of the glass. Make certain that the
glass is square with the case, and does not
interfere with other glass or case ends.
If the glass is still out of alignment, refer
to the following Front Glass Positioning
instructions.
FRONT GLASS POSITIONING
U
Level on
Upper Front
Panel
MINIMUM
HEIGHT
MAXIMUM
HEIGHT
MINIMUM
HEIGHT
MAXIMUM
HEIGHT
Adjustable
Leg Leveler
Adjustable
Leg Leveler
Turn Leg Leveler clock-wise to raise case
Base Stand
Bracket
Set
Screw
Raise Lower
Raise Lower
Glass
Movement
Glass
Leg
Leveler
To prevent injury from falling
glass during adjustment, one
person must support glass
while a second person makes
adjustments.
Do not adjust glass until case is level.
In many instances, proper leveling will align
glass without further adjustment.

P/N 0453549_M 1-5
Elite Service Merchandisers
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Vertical Adjustment
The position of the front edge of the glass is
vertically adjustable to ensure proper fit. Do
not attempt to make glass adjustments before
leveling the case. All steps of setting, joining
and case leveling are critical to glass position.
Glass alignment may be affected if merchandisers
are not leveled.
Check for level:
1. In a lineup position, first case is posi-
tioned at the highest point in the floor.
2. All 8 legs must be adjusted or shimmed to
level case.
3. Check case level with a 4ft minimum level,
also front to back. Place level on front glass
contact point (top rail).
Front glass is adjusted from the factory.
However, there may be instances when the
glass may need adjustment in the field.
Joined or with ends
Check that glass is square with the case and
does not interfere with other glass or case
ends.
ESBD
COIL
FA N
Gasket
Gasket
Minimum Space
3/4in. (20mm)
To prevent injury from falling glass during
adjustment, one person must support glass
while a second person makes adjustments.
Adjust all hinge assemblies on each case
at the same time to prevent glass binding
and breakage.
Minimum Space
3/4-in (20 mm)

1-6 InstallatIon
P/N 0453549_M U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
The front glass adjustment brackets are locat-
ed and accessed at the rear of the case. To
raise or lower the front edge of the glass:
1. Loosen the two side bolts.
2. raIse front edge of glass. Loosen top
extended bolt 1/2inch turn.
3. Tighten bottom bolt until edge of glass is
level.
tolower the front edge, reverse rais-
ing glass process.
DO NOT tighten one before loosening
the other!
4. Tighten all bolts before installing back
panel.
Side Bolts Bottom
Bolt
Top
Extended
Bolt

P/N 0453549_M 1-7
Elite Service Merchandisers
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Horizontal Adjustment
Set screws at each end of
the glass, and at center are
shown below.
Loosen tension on set
screws, and reposition glass
as necessary.
Tighten set screws.
Check the following to improve opening or
closing of the case front glass.
1. Has the case been leveled according to the
installation instructions. If not, level the case.
2. Is the glass handle installed correctly?
3. Verify the glass is bottomed out in the
handle. The handle should not be bowed
along its length. Bowing is an indication the
handle is not properly installed.
If the handle is not positioned correctly, it
must be removed. The handle is held in place
with silicone. Remove the handle by pulling
it away from the glass. Do not use tools to
pry handle from glass. Old silicone must be
cleaned off the handle and glass. Apply new
silicone into the handle, and firmly press han-
dle onto the glass.
Set Screw
GLASS MUST
BE BOTTOMED
OUT IN HANDLE
Set Screw location
(Curved Glass)

1-8 InstallatIon
P/N 0453549_M U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
JOINING INSTRUCTIONS
Sectional construction means that two or
more merchandisers may be joined in line
yielding one long continuous display requir-
ing only one pair of ends.
All joints must be Air-tight to prevent
formAtion of ice or condensAtion.
Prep Case
1. Check to be sure that merchandisers are
level and that the factory-installed nut
retainers and alignment pins are in place.
Locate Joining Kit and check contents
against parts list.
2. Remove shelves (if installed), display
racks, pans, front shelf supports and
front air grilles from the right end.
Apply Front Silicone Gasket Pad
1. Apply a
continuous
bead of sili-
cone around
the front join-
ing hole.
2. Remove
paper back-
ing from
gasket pad
and position
the pad as
shown.
Add
Gasket Pad
Apply
Silicone
1.
2.
A wedge is not to be joined to another wedge.
Wedges are designed for proper operation
when joined to a parent case.

P/N 0453549_M 1-9
Elite Service Merchandisers
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
3. Apply anoth-
er continuous
bead of sili-
cone on the
gasket pad.
Apply Silicone to
Canopy and Strut
1. Apply a
continuous
bead of sili-
cone around
the canopy.
2. Apply a
continuous
bead of sili-
cone around
the
strut.
There should
be no gaps in
the silicone
bead from the
canopy to the
gasket chan-
nel below the
strut.
Apply Gaskets
1. Apply
1/2in.
(13mm) gasket in the recess across the
bottom of the case as shown.
2. Apply silicone across bottom to ensure
no gaps from front of canopy around
back and bottom to front gasket pad.
Fasten Cases
1. Move the second case into position
against the first. Match the alignment pin
with the corresponding hole.
2. Fasten fronts together using 5/16-18
joining bolt, flat washer, lock washer
and nut. Tighten only until front panels
touch.
3. Use the 5/16-18 joining bolts, flat washers,
lock washers and nuts provided to draw
the cases together at rear brackets as
shown.
Apply foam
Gaskets
Apply more
Silicone
3.
4.
Apply
Silicone
to
Struts
Apply Silicone
at Canopy
1.
2.
No Gasket
Alignment Pin
Front Gasket Pad
Gasket
Silicone
Joining Bolt
Joining BoltJoining Bolt
IMPORTANT
• Do not stretch gasket,
especially around corners.
• Do not butt gaskets;
always lap them as shown.
• Remove paper backing
after gasket has been applied.

1-10 InstallatIon
P/N 0453549_M U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
Seal Merchandisers
1. Apply butyl tape across the bottom joint.
Be sure to extend the tape up the back
and front of the case.
2. Use field-supplied silicone to fill any gaps
between the front support brackets.
INSTALLING BUMPERS
Elite bumpers are shipped as a continuous
roll. Once installed the continuous bumper
helps to disguise the joint locations, giving the
lineup a smoother look.
1. Unroll the bumper and allow it to rest at
room temperature for 24 hours prior to
installation to minimize bumper shrinkage
after installation.
2. Slide end caps onto retainer at right and
left ends of lineup. Align with slot in
retainer, then fasten with screws provided.
3. Measure the distance between inside end
of caps and add 1/8inch (3mm) for each
4ft (1220mm). Adding the additional
material will compensate for stretching
which occurs during installation.
4.
Cut the bumper to length with a miter saw
for a precise, right-angle cut.
5. Lubricate the inside of the vinyl with
soapy water or silicone spray.
6. Starting at the left end of the line up, butt
end of the vinyl bumper against end cap.
While applying pressure, bend back vinyl
top so that vinyl legs are positioned with-
in the base grooves. Roll vinyl bumper
over full length of retainer, then tap with
rubber mallet to ensure vinyl is securely
locked into retainer.
7. If necessary wipe clean with any house-
hold cleaning product.
Miter Box
Bumper
Butyl Tape
Retainer
End Cap
Screw
Bumper
Miter Box
Butyl Tape

P/N 0453549_M 1-11
Elite Service Merchandisers
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
INSTALLING PARTITIONS
To join same temperature fixtures on differ-
ent defrost cycles, an acrylic partition kit is
required.
To join unlike fixtures, or like fixtures
operating at different temperatures, a 1 in.
(26mm) insulated connecting partition kit is
required.
Instructions for installing these partitions are
included with the kits.
2.668
TYP
19.327
TYP
Backup
7.562
12-Ft 36.717 40.193 36.717
8-Ft 36.668 –– 36.668
6-Ft 24.656 –– 24.656
4-Ft 33.125 –– ––
7.874 7.874 7.562
Notes:
1. All dimensions given in inches.
2. For location of Backups on cases with add-on wedge, start measuring from
the square end of the case opposite the wedge end. Use corresponding case
size dimensions.
3. For location of Backups on 7-Ft cases (facing rear of case)
use 6-Ft case dimensions on the left and 8-Ft case dimensions on the right.

1-12 InstallatIon
P/N 0453549_M U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
Installing Optional Wrap Board
MOA 0470438
1. Turn off power to case.
2. Determine location by positioning the
wrap board on the rear of the case between
door frames.
3. Align the assembly on the back of the case
as shown below.
4. Using holes in wrapping board bracket
as a template, mark hole locations on rear of
case.
5. Remove wireway cover; make sure there are
no wires behind hole locations.
6. Drill
3/8-inch (0.1875) diameter holes for
three 1/4-20 thread cutting screws through
stainless steel and structural members.
7. Securely fasten brackets to case.
8. Adjust wrapping board as needed. The
attach points for hinging brackets on wrap-
ping board is determined by which position
the assembly is to be mounted. Refer to fig-
ures for LH, RH or Center mounting positions.
Screw - 1/4-20 x 0.75-in.
Flange Thread Cutting
(3 required for each bracket)
Screw - #8 x 1/2
PHILAB SMS
(3 required for
each bracket)
Bracket Spacer
(2 required)
Mounting Holes
Bracket - Adj
(2 required)
Screw - 1/4-20 x 0.5-in.
Hex Head Zinc Plate
(2 required for each bracket)
Wrap Board Panel
Wrapping Board Assembly for Mounting to Right Hand Side of Case
(Facing Front of Case)
Screw - 1/4-20 x 0.75-in.
Flange Thread Cutting
(3 required for each bracket)
Screw - #8 x 1/2
PHILAB SMS
(3 required for
each bracket)
Bracket Spacer
(2 required)
Mounting Holes
Bracket - Adj
(2 required)
Screw - 1/4-20 x 0.5-in.
Hex Head Zinc Plate
(2 required for each bracket)
Wrap Board Panel
Wrapping Board Assembly for Mounting to Center of 12-Ft Case
or Mounting in Positions Other Than Left, Right or Center of Case
(Facing Front of Case)
Screw - 1/4-20 x 0.75-in.
Flange Thread Cutting
(3 required for each bracket)
Screw - #8 x 1/2
PHILAB SMS
(3 required for
each bracket)
Bracket Spacer
(2 required)
Mounting Holes
Bracket - Adj
(2 required)
Screw - 1/4-20 x 0.5-in.
Hex Head Zinc Plate
(2 required for each bracket)
Wrap Board Panel
Wrapping Board Assembly for Mounting to Left Hand Side of Case
(Facing Front of Case)
8.969 for 36-in. Board
8.656 for 48-in. Board
REF
8.969 for 36-in. Board
8.656 for 48-in. Board
REF
0.125-in.
Diameter
Drill 6 additional holes 0.5-in. deep
if not already existing in wrapping board.
3.25
REF
0.812 0.812
Bottom View of Wrap Board Panel

P/N 0453549_M 1-13
Elite Service Merchandisers
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
9. Replace wireway cover.
10. Restore power.
Installing Optional Scale Stand
MOA 0458960
1. Turn off power to case.
2. Determine location by positioning the
scale stand on the rear of the case between
door frames.
3. Using holes in scale stand bracket as a
template, mark hole locations on rear and top
of case.
4. Remove scale stand. Drill 1/8-inch diam-
eter pilot holes through metal liners at the
marked locations.
NOTE: Metal liners are less than 1/8-
inch thick-- do not drill beyond Metal
liners.
5. Move top panel away from back of case.
Remove center rear door trim and remove
LH Upright wireway cover to allow routing
of receptacle harness.
6. NOTE: Receptacle haRness wiRing must
have insulation sleeve installed pRioR to
Routing.Leaving about 12 inches of harness
hang out of case, route receptacle harness
wiring from the 3/4-in. bushing, down the
LH upright wireway through hole and into
case wireway.
NOTE: coMMunication cable wiring can
be routed siMilarly.
Case Wireway
Screw - SM #8-18 x 3/8
Truss Head
Insulation in this area to be notched
as needed for wire harness routing.
Install strain relief connector where
Communication Cable exits scale
stand assembly. Use plug button if
Communication Cable is not required.
Connect after routing wiring through case.
Isolated Ground Sticker
(If required)
Convenience Outlet
Screw - SM #8-18 x 3/8
Truss Head
(3 required)
3/4 Bushing
LH Upright
Wireway
Harness -
Receptacle
Scale Stand Upright Cover
Rear Door Center Trim
Screw - SM #8-18 x 3/8 Hex Head
(2 required)
Communication Cable
Route cable with 12-in.
outside the strain relief
connector in the scale stand

1-14 InstallatIon
P/N 0453549_M U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
7. Install the rear door center trim with
3/4-in. bushing by routing wire harness
through 3/4-in. bushing and attach with #8
truss head screws.
8. Reposition top over rear door center trim
and attach using #8 truss head screws.
9. Reposition scale stand and attach using
#8 truss head screws.
10. Install scale stand upright cover with #8
blunt tip sheet metal screws.
11. Connect wiring to power in wireway.
12. Restore power. Check for proper opera-
tion.
Some stores specify an isolated ground for
scale stand convenience outlets. If required,
apply the following:
• Isolated ground sticker to scale stand.
• Isolated ground tag to ground wire in
case wireway.
Mount Junction Box at this
location when scale stand
is mounted at Center Mullion.
Communication Cable
Route Communication
Cable to Junction Box
as shown. Coil excess
cable in Junction Box.
Case
Wireway Receptacle
Harness

P/N 0453549_M 2-1
Elite Service Merchandisers
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
REFRIGERANT
The correct type of refrigerant will be
stamped on each merchandiser’s serial plate.
The case refrigeration piping is factory sealed,
pressurized and leak tested. Before making
refrigeration hookups, depress universal line
valve to ensure that coils have maintained
pressure during shipment.
REFRIGERANT PIPING
Connection Location
The refrigerant line connections are at the
right- hand end of the merchandiser (as
viewed from the front) beneath the display
pans. A sticker marks the location of the con-
nection “pod.” The installer must saw a hole
through the pod to exit the case. After con-
nections have been made, seal this outlet thor-
oughly. Seal both the inside and the outside.
We recommend using an expanding polyure-
thane foam insulation.
Multiplexing
Piping of merchandisers operating on the
same refrigeration system may be run from
merchandiser to merchandiser. donot run
refrIgerant lInes through merchandIsers
that are not on the same refrIgeratIon
system branch as this may result in poor
refrigeration control and compressor failure.
Interconnecting piping inside the merchandis-
er must be located as shown below to allow
room for lifting the hinged fan plenums and
for clearance beneath the display pans. The
interconnecting piping may be run outside the
merchandiser.
REFRIGERATION / ELECTRICAL
Piping Location
Display Pan
Refrigerant vapor is hazardous to your health
and can cause death.
Avoid breathing refrigerant and lubrication
vapor or mist. Exposure may irritate eyes,
nose and throat. If accidental system dis-
charge occurs,ventilate work area before
resuming service.
Always wear safety goggles and protective
gloves when working with refrigerants.
Contact with refrigerant may cause injury.
Disconnect hoses with extreme caution! All
hoses may contain liquid refrigerant under
pressure.
Be sure that any room where you are working
is thoroughly ventilated, especially if a leak
is suspected.
Read all safety information regarding the
safe handling of refrigerant and refrigerant
oil, including the Material Safety Data Sheet.
MSDS sheets can be obtained from your
refrigerant supplier.
Refrigeration lines are under pressure
and should be depressurized before
attempting to make any connections.
When brazing pipes, be sure to use the
insulation blanket shipped with the
merchandiser to prevent fire or damage
to the plastic case bottom.
Display Pan
Piping Location

P/N 0453549_M
Line Sizing
Refrigerant lines should be sized as shown on
the refrigeration legend that is furnished for
the store or according to ASHRAE guidelines.
Refer to the information on the next page for
branch line piping of Hussmann Equipment.
Oil Traps
P-traps (oil traps) must be installed at the base
of all suction line vertical risers.
Pressure Drop
Pressure drop can rob the system of capacity.
To keep the pressure drop to a minimum, keep
the refrigerant line run as short as possible
using a minimum number of elbows. Where
elbows are required, use long rAdius elbows
only.
INSULATION
The suction and liquid lines should be clamped
or taped together and insulated for a minimum
of 30ft (9144mm) from the merchandiser.
Additional insulation for the balance of the
liquid and suction lines is recommended wher-
ever condensation drippage is
objectionable or lines are exposed to ambient
conditions.
SUCTION LINE
• Pitch in direction of flow.
• May be reduced by one size at one third of
case run load and again after the second
third. Do not reduce below the case suction
line size.
• Case suction
lines should enter
at the top of the
branch line.
LIQUID LINE
• May be reduced by one size after one half
the case run load. Do not reduce below the
case liquid line connection size.
• Take-offs to case liquid lines should exit
the bottom of the branch liquid line.
Provide an expansion loop for each evap-
orator take-off. (Minimum 3in. [76mm]
loop.)
CONTROL SETTINGS
Merchandiser data sheets are shipped with this
manual. The data sheets provide case control
settings and defrost data.
An evaporator pressure regulator or EPR (pri-
mary control) and a 3–5ºF (1.7– 2.7ºC) dif-
ferential thermostat (secondary control) must
control refrigeration temperature. The EPR
must be set to maintain the proper saturated
evaporator temperature as listed in the data
sheets. The thermostat must be set a couple
degrees colder than the discharge air tempera-
ture specified in the data sheets. The ther-
mostat will prevent product freezing should
the EPR temperature drift downward during
reduced load periods (lights off, lower ambi-
ent). The thermostat will be wired to control
the compressor motor contactor (single com-
pressor) or a liquid line solenoid valve (parallel
compressor systems).
2-2 RefRIgeRatIon / eleCtRICal
U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
Suction Line Return
Minimum Loop
3-in. (76 m m)
Liquid Line Take Off
Liquid Line Take Off
Suction Line Return
Minimum Loop
3-in. (78 mm)
