Hussmann impact Excel C5X-LE Instruction Manual

C
E
B
D
E
E
A
D
G
F
P/N 0473382_E
C5X-LE
Technical Data Sheet
P/N 0473382_E
NSF®Certified
March 2008
We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
Item Part # Description Wiring Item #
FAN ASSEMBLIES
4 Ft, 8 Ft, 10 Ft†& 12 Ft
A. 12W Standard Fan Assembly (1)
0047000 Fan Motor, Evaporator
(MO.4410103)
0461805 Fan Blade (FB.4780446)
12W Energy Efficient Fan Assembly (1)
0477655 Fan Motor, Evaporator
(MO.4410546)
0461805 Fan Blade (FB.4780446)
6 Ft and 10 Ft†Only
A. 7W Standard Fan Assembly (1)
0058698 Fan Motor, Evaporator
(MO.4410102)
0142780 Fan Blade (FB.0142780)
7W Energy Efficient Fan Assembly (1)
0477654 Fan Motor, Evaporator
(MO.4410545)
0142780 Fan Blade (FB.0142780)
†10 Ft uses both.
Item Part # Description Wiring Item #
THERMOSTATS
B. 0411744 Standard Non-adjustable (2)
Defrost Thermostat
(CT.0411744)
C. Optional Adjustable Refrigeration Thermostat (3)
LAMPS. BALLASTS, LED FIXTURES AND POWER SUPPLY
D. Ballast, Electronic (4)
0480130 2 lamps (BA.4481676)
0480131 3 lamps (BA.4481654)
0480132 4 lamps (BA.4481677)
E. Fluorescent Lamp (5)
Replace with like fixtures
F. 0501213 Power Supply (EP.4481861) (6)
G. LED Fixture (7)
Replace with like fixtures
©2008 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
Note: Revision E changes ballast (Page 1); adds optional LED lighting (Pages 1, 3, 4, 8); adds capacity and weight (Page 5).

2 of 8 C5X-LE Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Engineering
Plan Views
Dimensions shown as in. and (mm).
Convertible
09-2005
NOTE: Case-to-Case Electrical Connections
are made IN FRONT OF SPLASHGUARD.
4 3/4 (120)
Splashguard
31 5/8
(804)
42
(1064)
A
41 1/2
(1054)
3 In.
(77 mm)
Required
Air Gap
Refrigeration
Outlet
Electrical
Stub Up Area
6 x 6
(152x152) Waste Outlet
Waste Outlet
FRONT
26 1/4
(665)
B
D
8(203)
4 1/2 (115)
12 1/8 (307)
41 1/2
(1054)
43 7/8
(1114)
C
Wireway
4 3/4 (120)
26 1/2
(673)
4 1/4 (108)
24
(612)
33 1/2
(851)
Electrical
Field
Connection
30 1/4
(768)
C5X
4 ft 6 ft 8 ft 10 ft 12 ft
General
(A) Case Length (without ends or partitions) 48 3/8(1229) 72 3/8(1838) 96 3/8(2448) 120 3/8(3058) 144 1/2(3670)
(Each end and insulated partition adds 1 1/2 in. (38 mm) to case line up.)
Maximum O/S dimension of case back to front
(includes bumper) 42 (1064) 42 (1064) 42 (1064) 42 (1064) 42 (1064)
Back of case to front of splashguard 33 1/2 (851) 33 1/2 (851) 33 1/2 (851) 33 1/2 (851) 33 1/2 (851)
Back of case to O/S edge of front leg 30 1/4 (768) 30 1/4 (768) 30 1/4 (768) 30 1/4 (768) 30 1/4 (768)
Distance between edges of external legs and center legs NA 29 1/2 (750) 41 1/2 (1054) 29 1/2 (750) 41 1/2 (1054)
Distance between edges of center legs NA NA NA 43 7/8 (1114) 43 7/8 (1114)
Distance between front legs and splashguard 2 3/4(70) 2 3/4(70) 2 3/4(70) 2 3/4(70) 2 3/4(70)
Electrical Service (Electrical Field Wiring connection point)
(B) RH End of case to center of stub up area 36 1/4 (921) 60 1/4 (1530) 84 1/4 (2140) 108 1/4 (2750) 132 3/8 (3363)
Back of case to center of stub up area 24 (612) 24 (612) 24 (612) 24 (612) 24 (612)
Length of electrical wireway 26 1/2 (673) 26 1/2 (673) 26 1/2 (673) 26 1/2 (673) 26 1/2 (673)
(C) RH End of case to LH end of wireway 42 1/8 (1070) 66 1/8 (1680) 90 1/8 (2289) 114 1/4 (2092) 138 1/4 (3511)
Waste Outlets (One each end)
(D) RH End of case to the center of LH waste outlet 36 1/4 (921) 60 1/4 (1530) 84 1/4 (2140) 108 1/4 (2750) 132 3/8 (3363)
RH End of case to the center of RH waste outlet 12 1/8 (307) 12 1/8 (307) 12 1/8 (307) 12 1/8 (307) 12 1/8 (307)
Back O/S of case to center of waste outlets 31 5/8 (804) 31 5/8 (804) 31 5/8 (804) 31 5/8 (804) 31 5/8 (804)
Schedule 40 PVC drip pipe 1 1/4(32) 1 1/4(32) 1 1/4(32) 1 1/4(32) 1 1/4(32)
Refrigeration Outlet
Back of case to center of refrigeration outlet 26 1/4 (665) 26 1/4 (665) 26 1/4 (665) 26 1/4 (665) 26 1/4 (665)
RH end of case to center of refrigeration outlet 8 (203) 8 (203) 8 (203) 8 (203) 8 (203)
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1 1/4
Merchandiser Liquid Line (in.) 3/8
Merchandiser Suction Line (in.) 7/8
Wireway

REFRIGERATION DATA
Note: This data is based on store temperature and
humidity that does not exceed 75°F and 55% R.H.
C5X-LE Meat Produce Dairy
Discharge Air (°F) 29 31 31
Evaporator (°F) 21 24 24
Unit Sizing (°F) 19 22 22
Btu/hr/ft — Unlit Shelves
C5X-LE‡‡ Parallel Conventional
MEAT 1715 1820
PRODUCE 1650 1750
DAIRY 1590 1690
‡‡ Add 10 Btu/hr/ft per shelf row for LED fixtures.
Add 20 Btu/hr/ft per shelf row for fluorescent lamps.
DEFROST DATA
C5X-LE
Frequency Hrs 6
Defrost Water (lb/ft/day) 10.5
(± 15% based on case configuration and product
loading).
OFFTIME C5X-LE
Temp Term °F 48
Failsafe Minutes 30
ELECTRIC OR GAS Not Recommended
Standard Defrost Thermostat
Close on rise: close 48°F — open 33°F
CONVENTIONAL CONTROLS
Low Pressure Backup Control
CI/CO*C5X-LE
Meat Produce Dairy
14°F / 4°F 17°F / 7°F 17°F / 7°F
Indoor Unit Only, Pressure Defrost
Termination* 48°F
*Use a Temperature Pressure Chart to determine
PSIG conversions.
Estimated Charge (lb)** C5X-LE
4 ft 1.6
6 ft 2.2
8 ft 3.1
10 ft 3.8
12 ft 4.5
**This is an average for all refrigerant types.
Actual refrigerant charge may vary by
approximately half a pound.
3 of 8
P/N 0473382_E HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
31 5/8 (804)
4 3/4 (120)
30 1/4 (768)
42 (1064)
33 1/2 (851)
30 1/4
(768)
61
(1549)
42
(1064)
54 7/8
(1393)
FAN
C
O
I
L
C5X-LE
17 1/4
(438)
3 In. (77 mm)
Required
Air Gap
81 3/4
(2077)
7 1/4 (183)
19 5/8
(499) 3 5/8
(92)
26 1/4 (665)
Refrigeration
Outlet
4 7/8
(123)
Electrical
Case to Case
Connections
17 1/8
(436)
Impact Excel C5X-LE
All
Dimensions shown as in. and (mm).
Multi-deck, 5 Display Levels, Low Front
NSF Certification
This merchandiser model is manufactured to meet ANSI/NSF
(National Sanitation Foundation) Standard #7 requirements for
construction, materials & cleanability.

Electrical Data
4 ft 6 ft 8 ft 10 ft 12 ft
Number of Fans – 12W 2 — 4 2 6
Number of Fans – 7W —4—4—
Amperes Watts
4 ft 6 ft 8 ft 10 ft 12 ft 4 ft 6 ft 8 ft 10 ft 12 ft
Evaporator Fans
120V 60Hz Standard 1.30 2.00 2.60 3.30 3.90 100 156 200 256 300
120V 50Hz Standard 1.50 2.20 3.00 3.70 4.50 114 168 228 282 342
230V 60Hz Export 0.66 1.00 1.32 1.66 1.98 100 156 200 256 300
230V 50Hz Export 0.76 1.12 1.52 1.88 2.28 114 168 228 282 342
120V 60Hz Energy Efficient 0.60 0.76 1.20 1.36 1.80 36 56 72 92 108
230V 60Hz Energy Efficient 0.30 0.40 0.60 0.70 0.90 36 56 72 92 108
Minimum Circuit Ampacity
120V 60Hz Standard 1.50 2.20 2.80 3.50 4.10
120V 50Hz Standard 1.70 2.40 3.20 3.90 4.70
230V 60Hz Export 0.86 1.20 1.52 1.86 2.18
230V 50Hz Export 0.96 1.32 1.72 2.08 2.48
120V 60Hz Energy Efficient 0.80 0.96 1.40 1.56 2.00
230V 60Hz Energy Efficient 0.50 0.60 0.80 1.30 1.10
Maximum Over Current Protection 120V 20 20 20 20 20
Maximum Over Current Protection 230V 15 15 15 15 15
Standard Lighting (T-8 Fluorescent)
1 Row Canopy 0.26 0.51 0.51 0.77 0.77 30 59 59 85 85
Optional Lighting (T-8 Fluorescent)
Additional 1 Row Canopy 0.26 0.51 0.51 0.77 0.77 30 59 59 85 85
Additional 2 Row Canopy 0.51 1.02 1.02 1.54 1.54 59 118 118 170 170
Additional 3 Row Canopy 0.77 1.53 1.53 2.31 2.31 89 177 177 255 255
1 Row Rail Light 0.26 0.51 0.51 0.77 0.77 30 59 59 85 85
Optional Shelf Lighting (T-8 Fluorescent)
1 Row of Shelves 0.26 0.51 0.51 0.77 0.77 30 59 59 85 85
4 Rows of Shelves 1.02 2.04 2.04 3.08 3.08 118 236 236 340 340
5 Rows of Shelves 1.28 2.55 2.55 3.85 3.85 148 295 295 425 425
6 Rows of Shelves 1.53 3.06 3.06 4.62 4.62 177 354 354 510 510
Optional Always*Bright LED Lighting
1 Row of Shelves 0.15 0.19 0.26 0.30 0.38 18 23 31 36 45
4 Rows of Shelves 0.47 0.68 0.93 1.15 1.40 56 82 112 138 168
5 Rows of Shelves 0.57 0.83 1.13 1.38 1.69 68 99 136 166 203
6 Rows of Shelves 0.67 0.96 1.33 1.62 2.00 80 115 160 194 240
120V Lighting Circuit Total = Standard Lighting + Total Optional Lighting + Optional Shelf Lighting
230V Lighting Circuit Total = Multiply 120V Lighting Circuit Total by 0.52
4 of 8 C5X-LE Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Impact Excel C5X-LE
All

ESTIMATED SHIPPING WEIGHT 5
Case Solid End
4 ft 6 ft 8 ft 10 ft 12 ft (each)
lb (kg) 800 (363) 1000 (454) 1200 (544) 1300 (590) 1400 (635) 100 (45)
5Actual weights will vary according to optional kits included.
5 of 8P/N 0473382_E HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
Impact Excel C5X-LE
All
Product Data
ARI Refrigerated Volume 1 (Cu Ft/Ft) 11.93 ft3/ft (1.11 m3/m)
Recommended Usable Cube 2 (Cu Ft/Ft) 9.39 ft3 /ft (0.87 m3 /m)
ARI Total Display Area 3 (Sq Ft/Ft) 4.74 ft2/ft (1.44 m2 /m)
Shelf Area 4(Sq Ft/Ft) 9.88 ft2/ft (3.01 m2 /m)
1Computed using ARI 1200 standard methodology: Refrigerated Volume, ft3[m3]/Unit of Length, ft [m]
2ARI Refrigerated Volume less shelving and other unusable space: Refrigerated Volume/Unit of Length, ft3/ft [m3/m]
3Computed using ARI 1200 standard methodology: Total Display Area, ft2[m2]/Unit of Length, ft [m]
4Shelf surface area is composed of bottom deck plus standard shelf complement, as shown in the Hussmann
Product Reference Guide. The standard shelf complement for this model is (4) rows of 22-inch shelves.eparately from
fans.

Defrost
Termination
Thermostat
Refrigeration
Thermostat
Dark Blue
3
To
Condensing
Unit
}
Light Blue
2
2, 4 & 6 Fans
120V NEUTRAL
BROWN BAND
120V POWER
Fans 1
BROWN BAND
4 ft
6 ft
8 ft
10 ft
12 ft
5
5
4
4
4
5
5
5
5
5
5
5
Optional
Two Row
Canopy
Optional
Three Row
Canopy
Connector
5
BL
W
BL
W
G
R
BL
W
B
R
RR
BL BL
R
BL
R
RR
BL
BL
R
BL
R
RR
B
B
Orange or Tan Band
Standard Lighting 1 Row Canopy
Optional Lighting 2 Row Canopy
3 Row Canopy
5
455
Connector
W
B
BL
BL
R
BL
R
RR
Optional Lighting 1 Row Rail
B
4 ft 6 ft or 8 ft 12 ft
4 ft 6 ft or 8 ft 12 ft
R = Red Y = Yellow G = Green BL = Blue B = Black W = White
= 120V POWER = 120V NEUTRAL = FIELD GROUND
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS
= CASE GROUND
Fan Wiring
Offtime Defrost
Light Circuits
C5X-LE Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
6 of 8

7 of 8P/N 0473382_E HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
5
4
5
5
5
5
B
W
BL
BL
R
BL
R
BL
R
BL
W
R
W
R
B
R
BL
BL
R
4
B
BL
BL
BL
BL
BL
R
R
R
R
R
R = Red Y = Yellow G = Green BL = Blue B = Black W = White
= 120V POWER = 120V NEUTRAL = FIELD GROUND
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS
= CASE GROUND
Optional Shelf Harness and Light Circuits for
Five Rows of Shelves
4 ft case
Connector
5
4
5
5
5
5
B
W
Connector
6 ft or 8 ft case
12 ft case
BL
BL
R
BL
R
BL
R
BL
W
R
W
R
B
R
BL
BL
R
4
B
BL
BL
BL
BL
BL
R
R
R
R
R
5
4
5
5
5
5
B
W
BL
BL
R
BL
R
BL
R
BL
W
R
W
R
B
R
BL
BL
R
4
B
BL
BL
BL
BL
BL
R
R
R
R
R
Optional Shelf Lighting
Fluorescent Fixtures

C5X-LE Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
8 of 8
R
BL
R
BL
R
BL
R
BL
R
BL
R
BL
R
BL 7
7
7
7
7
7
7
RBL
6
B
B
W
W
BL
R
G
4 ft case
6 ft or 8 ft case
12 ft case
(TYP)
Shelf Light
Plug & Receptacle
B
Connector
R
BL
R
BL
R
BL
R
BL
R
BL
R
BL
R
BL 7
7
7
7
7
7
7
RBL
6
B
B
W
W
BL
R
R
BL
R
BL
R
BL
R
BL
R
BL
R
BL
R
BL 7
7
7
7
7
7
7
RBL
6
B
B
W
W
BL
R
R = Red G = Green BL = Blue B = Black W = White
= 120V POWER = 120V NEUTRAL = FIELD GROUND
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS
= CASE GROUND
W
Connector
Optional Shelf Harness and LED Light Circuits for
3, 4, 5, 6 & 7 Rows of Shelves
Optional Shelf Lighting
LED Fixtures
