ESBD
Technical Data Sheet
P/N 0453552_B
NSF®Certified
January 2007
Item Part # Description Wiring Item #
FAN ASSEMBLIES AND THERMOSTATS
A. 0392457 Fan Motor, Evaporator (120V) (1)
(MO.4410101)
0409511 Fan Blade (120V) (FB.0409511)
embossing toward motor
0436517 Fan Motor, Evaporator (230V)
(MO.4410105)
0409512 Fan Blade (230V) (FB.0409512)
embossing toward motor
B. 0404551 Fan Motor, Ambient (120V) (2)
(MO.0404551)
0404552 Fan Motor, Ambient (230V)
(MO.4410590)
C. 0382028 Standard Non-adjustable (3)
Defrost Thermostat
(CT.0382028)
D. 0353949 Optional Adjustable (4)
Refrigeration Thermostat
(CT.4481087)
Item Part # Description Wiring Item #
HEATERS
E. 0460453 Heater, Ambient (120V) (5)
(HE.4850579)
E. 0461866 Heater, Ambient (230V) (6)
(HE.4850646)
LAMPS AND BALLASTS
F. 0355716 Ballast, Electronic, 2 lamps
(120V) (BA.0355716) (7)
F. 0355398 Ballast, Electronic, 3 lamps
(120V) (BA.4480118) (8)
F. 0440215 Ballast, Electronic, 2 lamps
(230V 50-60 Hz) (BA.4481267) (7)
F. 0428652 Ballast, Electronic, 3 lamps
(230V 50-60 Hz) (BA.4480897) (8)
0385104 Ballast Transformer
(230V 50-60 Hz, per ballast)
(TR.4481191)
G. Fluorescent Lamp (9)
Replace with like fixtures
We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
©2007 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM

HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A. ESBD Technical Data Sheet2 of 6
26 1/4
(667)
A
D
C
45 1/4
(1149)
29 3/8
(746)
35/8 (92)
E
33 1/4
(845)
Legs
Water Seal
C
L
Front
Refrigeration
Outlet
Electrical
B
Waste Outlet
Dimensions shown as in. and (mm).
Meat & Delicatessen
Engineering
Plan Views
4 ft 6 ft 8 ft 12 ft
General
(A) Case Length (without ends or partitions) 48 1/4(1226) 72 3/8(1838) 96 3/8 (2448) 144 1/2(3670)
Maximum O/S dimension back to front (with bumper) 45 1/4(1149) 45 1/4(1149) 45 1/4(1149) 45 1/4(1149)
Back of case to front of front panel 33 1/4 (845) 33 1/4 (845) 33 1/4 (845) 33 1/4 (845)
RH end of case to outside edge of external support 1 5/8(41) 1 5/8(41) 1 5/8(41) 1 5/8(41)
Distance between edges of
external support and center support NA 28 1/2(724) 40 5/8 (1032) 40 5/8 (1032)
Distance between edges of center supports NA NA NA 44 (1118)
Distance between edges of external supports 37 (940) NA NA NA
Electrical Service (Electrical Field Wiring connection point)
(C) Length of electrical raceway 38 (965) 29 5/8 (752) 41 3/4 (1060) 41 3/4 (1060)
RH End of case to center of farthest knockout 10 3/8 (264) 10 (254) 10 1/4 (260) 10 1/4 (260)
Back of case to center of end knockout 3 5/8 (92) 3 5/8 (92) 3 5/8 (92) 3 5/8 (92)
(B) RH End of case to RH end of raceway 5 (127) 5 (127) 5 (127) 5 (127)
Waste Outlet
(D) RH End of case to the center of waste outlet 24 1/8 (613) 24 1/8 (613) 24 1/8 (613) 72 1/4 (1835)
LH End of case to the center of waste outlet 24 1/8 (613) 48 1/4 (1226) 72 1/4 (1835) 72 1/4 (1835)
Back O/S of case to center of waste outlet 26 1/4 (667) 26 1/4 (667) 26 1/4 (667) 26 1/4 (667)
Water Seal
Edge of water seal to center of waste outlet 4 (102) 4 (102) 4 (102) 4 (102)
Outside diameter of the drip pipe 1 1/2 (38) 1 1/2 (38) 1 1/2 (38) 1 1/2 (38)
(Field installed water seal outlets, tees, and connectors
are shipped with the merchandiser.)
Refrigeration Outlet
Back of case to center of refrigeration outlet 29 3/8 (746) 29 3/8 (746) 29 3/8 (746) 29 3/8 (746)
(E) RH end of case to center of refrigeration outlet 8 1/4 (210) 8 1/4 (210) 8 1/4 (210) 8 1/4 (210)

REFRIGERATION DATA
Note: This data is based on store temperature
and humidity that does not exceed 75°F and
55% R.H.
ESBD
Discharge Air (°F) 25
Evaporator (°F) 20
Unit Sizing (°F) 18
Btu/hr/ft ESBD
Parallel 355
Conventional 380
DEFROST DATA
ESBD
Frequency (hr) 12
Defrost Water (lb/ft/day) 0.5
(± 15% based on case configuration and
product loading).
OFFTIME ESBD
Temp Term (°F) 43
Failsafe (minutes) 90
ELECTRIC OR GAS Not Recommended
Standard Defrost Thermostat
Close on rise: close 43°F — open 33°F
CONVENTIONAL CONTROLS
Low Pressure Backup Control
ESBD
CI/CO (Temp °F)*13
Indoor Unit Only, Pressure Defrost
Termination (Temp °F)*
Not Recommended
*Use a Temperature Pressure Chart to
determine PSIG conversions.
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1 1/2
Merchandiser Liquid Line (in.) 3/8
Merchandiser Suction Line (in.) 5/8
Estimated Charge (lb)**
4 ft 0.8
6 ft 1.2
8 ft 1.5
12 ft 2.0
**This is an average for all refrigerant types.
Actual refrigerant charge may vary by
approximately half a pound.
Length Added to Lineup by Each End
and Partition 1in.
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM 3 of 6P/N 0453552_B
24 3/4
(629)
8 1/4
(210)
22
(559)
52 1/8
(1324)
31
(787)
22 3/4
(578)
26 1/4
(667)
16 5/8
(422)
27 1/4
(692)
ESBD
12 1/2
(318)
4(102)
29 3/8
(746) 33 1/4
(845)
45 1/4
(1149)
12
(305)
20
(508)
Electrical
Refrigeration
Outlet
FAN COIL
Dimensions shown as in. and (mm).
Impact Elite ESBD
Meat & Delicatessen
Elite Curved Hinged Glass, Blower, 3 Display Levels
NSF Certification
These merchandisers are manufactured to meet ANSI /National Sanitation
Foundation (NSF ®) Standard #7 requirements.

HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A. ESBD Technical Data Sheet4 of 6
Impact Elite ESBD
Meat & Delicatessen
Electrical Data
Number of Fans 4 ft 6 ft 8 ft 12 ft
Refrigeration (120V 60hz) – 4W 1 2 2 3
Ambient Air Wipe – 15W 2 4 4 6
Export Refrigeration (230V 50 hz ) – 4W 1 2 2 3
Export Ambient Air Wipe – 15W 2 4 4 6
Amperes Watts
Merchandiser 4 ft 6 ft 8 ft 12 ft 4 ft 6 ft 8 ft 12 ft
Refrigeration Fans
Standard (120V 60hz) 0.31 0.62 0.62 0.93 24 48 48 72
Energy Efficient (120V 60hz) 0.14 0.28 0.28 .42 10 20 20 30
Export (230V 50 hz) 0.18 0.36 0.36 0.56 27 54 54 81
Ambient Air Wipe Fans
Standard (120V 60hz) 0.52 1.04 1.04 1.56 45 90 90 135
Export (230V 50 hz) 0.30 0.60 0.60 0.90 50 100 100 150
Constant-on Anti-Sweat Heaters (On/Off Switch Optional)
Standard (120V 60hz) 3.34 6.68 6.68 10.02 400 800 800 1200
Export (230V 50 hz) 1.74 3.48 3.48 5.22 400 800 800 1200
Minimum Circuit Ampacity
With Standard Fans (120V 60hz) 3.95 7.69 7.69 11.44
With Energy Efficient Fans (120V 60hz) 3.78 7.35 7.35 10.93
With Export Fans (230V 50 hz ) 2.20 4.20 4.20 6.21
Maximum Over Circuit Protection 120V 20
Maximum Over Circuit Protection 230V 15
Standard Lighting* (120V 60hz) 4 ft 6 ft 8 ft 12 ft 4 ft 6 ft 8 ft 12 ft
2 Row Canopy 0.49 0.98 0.98 1.42 59 118 118 171
Optional Lighting
1 Row Rail 0.49 0.49 0.49 0.71 59 59 59 86
1 Row Ledge 0.49 0.49 0.49 0.71 59 59 59 86
1 Row Shelves 0.49 0.49 0.49 0.71 59 59 59 86
2 Row Shelves 0.49 0.98 0.98 1.42 59 118 118 171
115V Lighting Circuit Total = Standard Lighting + Total Optional Lighting + Optional Shelf Lighting
230V Lighting Circuit Total = Multiply 115V Lighting Circuit Total by 0.52do

HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM 5 of 6P/N 0453552_B
Defrost
Termination
Thermostat
Refrigeration Thermostat
To
Condensing
Unit
}
(Field Installed)
34
DB
DB
LB
LB
R = Red G = Green BL = Blue LB = Light Blue DB = Dark Blue B = Black W = White
= 120V POWER = 120V NEUTRAL = Field GROUND = Case GROUND
Fan Wiring
Offtime Defrost
Fans
Electric Service Receptacle Receptacles
120V N EUTRAL
MAROON
BAND
120V P OWER
W
B
G
N.E.C.
TAGS
MAROON
BAND
BROWN BAND
Fans
BROWN BAND
120V POWER
120V NEUTRAL
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
Circled Numbers = Parts List Item Numbers
Grayed components in 12 foot models only.
1
BROWN BAND
Fans
BROWN BAND
120V POWER
120V NEUTRAL
2
Ambient Fan
Wiring
Glass Air Wipe
Fans
Purple BAND
Heaters
Purple BAND
120V POWER
120V NEUTRAL
5
Ambient Heater
Wiring
Heaters
4 ft case has 2 Heaters
6 ft case has 4 Heaters
8 ft case has 4 Heaters
12 ft case has 6 Heaters
4 ft case has 2 Fans
6 ft case has 4 Fans
8 ft case has 4 Fans
12 ft case has 6 Fans
4 ft case has 1 Fan
6 ft case has 2 Fans
8 ft case has 2 Fans
12 ft case has 3 Fans
Heater
Switch

ESBD Technical Data Sheet6 of 6 HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
