User’s Manual
GSM 102 Gate
GSM Wireless Terminal
Appearance ___________________________________________ Error! Bookmark not defined.
LED indicators____________________________________________________________________2
Connectors _______________________________________________________________________2
Install The Terminal___________________________________________________________ 2
Installing the SIM Card ___________________________________________________________________2
The installation for connecting to ordinary telephone direct _______________________________________ 3
The installation for connecting to register cost equipment_________________________________________3
Operating the terminal _________________________________________________________ 3
The Information of Signal Quality and Software Version _________________________________________3
Inquire Signal Quality and Software Version___________________________________________________4
Signal Quality___________________________________________________________________________4
Making Calls ___________________________________________________________________________4
Answering Incoming Calls_________________________________________________________________4
Adjusting the Volume of Voice _____________________________________________________________ 4
Technical Specification ___________________________________________________________________4
The Instructions for Terminal’s Running Status_________________________________________________5
Familiar Trouble and Troubleshooting____________________________________________ 5

Hybrid Systems JSC Users Manual
Page 2 of 6 GSM 102 Gate
LED indicators (From left to right)
LED1 -Network indicator (Flashing once in one second indicates that the terminal is
on GSM network. Being dead or being lit for a long time indicates that the terminal has
failed to login onto GSM network)
LED2 -Power indicator (it’s lit while power source is connected correctly) LED3 -
Warning indicator (Staying lit more than 10 seconds indicates that the terminal can’t work
in gear. Staying lit less than 10 seconds or flashing indicate that the terminal is dealing
with short message)
LED4 -Working indicator (staying lit when handset has being lift or hand-free key
had been pressed)
LED5 -Signal indicator (The flashing speed indicates signal strength. The details
refer to “Inquire Signal
Connectors
Map 2 the rear connection map to mains
1. Phone port: Connecting to telephone (Two telephone can be connected at the same
time). Line port – connecting to the PSTN
2 Power port: Make the flat side of power adapter plug be upturned and push it in
3 Antenna port
Install The Terminal
Installing the SIM Card
Proceed as follows:
1. Slide back the SIM door and lift it up
2. Slide the SIM card into the SIM door making sure that the clipped corner of the SIM
card lines up with the clipped corner of the SIM holder
3. Close the SIM door
4. Slide the SIM door to lock the SIM card in place

Hybrid Systems JSC Users Manual
Page 3 of 6 GSM 102 Gate
Installation Condition
Require 220v AC power. GSM signal can cover the area where the terminal is placed.
Signal quality affects voice quality direct.
The installation for connecting to ordinary telephone direct
1. Install the SIM card proceeding as “Installing the SIM Card”
2. Connect one end of the telephone line to “Telephone port” and the other end connect
to a telephone.
3. Install the antenna and power supply well. The distance between telephone and
terminal is 1.5m at least.
4. Connect one end of the power adapter to “Power port” and another end connect to
220v AC power. About 10-45 seconds later, the terminal works in gear (The login
time is different according to local network).
Draw your attentions: Because there are many types of ordinary telephone and their
electric parameters are different.In order to avoid mutual disturbance between telephone
and terminal and affects voice quality.The distance between telephone and terminal must be
beyond 2m.
The installation for connecting to register cost equipment
If users demand register cost during calls, register cost equipment can be connected
between terminal and ordinary telephone. Register cost equipment registers cost according
to anti-polarity signal that is provided by terminal
Operating the terminal
The Information of Signal Quality and Software Version
If the connected telephone has the function of displaying incoming calls, the
telephone rings after it is in login onto GSM network successfully and a code of 8 digits will
be displayed. The code indicates the information of signal quality, malfunctions and software
version as follows:
- The first two digits indicate the signal quality, it ranges from “00” to “31”. Stronger the
signal is, bigger the digits is. If it is less than 10, the quality of voice will be poor.
- The third and the forth digit is the code of malfunction:“00”: good “11”: failed in login
onto GSM network “22” or “33”: PIN error (PIN code isn’t 1234 or PIN code isn’t disabled)
“44”: lock card error “55”: lock terminal error,“77”: lock network error, “99”: read SIM
card error)
- The later four digits is software version code: for example 4060 indicates the software
version code is 4.06.
If the telephone displays “11”, “22”, “33”, “44”, “77”, “99” and it can’t work in gear,
please contact the service provider.

Hybrid Systems JSC Users Manual
Page 4 of 6 GSM 102 Gate
Inquire Signal Quality and Software Version
1. Lift the handset and then dial “***9#”. Hang up as soon as you hear busy tone. The
telephone rings and displays a code of 8 digits. The code indicates the information of
signal quality and software version as follows:
The first two digits indicate signal quality. It ranges from “00” to “31”. Stronger the
signal is, bigger the digits is. If it is less than 10, the quality of voice will be poor.
The third and the forth digit is standby.
The later four digits are software version code: for example 4060 indicates the software
version code is 4.06.
Signal Quality
User can judge the signal quality according to the flashing speech of network
indicator (LED1). Flash once in four seconds: signal is good Flash once in two seconds:
signal is weakerFlash once in one second: signal is very weak, the quality of the voice is
poor, please check the terminal.
Making Calls
Lift the handset or press “hand-free” key, you will hear dialing tone, then you can
dial the telephone numbers you want to call.
Dialing: dial the telephone numbers you want to call
On completion of dialed digits, you can press “#” to transmit telephone numbers. If
you don't dial any key for continual 6 seconds during the dialing, the terminal transmits the
dialed telephone numbers automatically.
When it is necessary to register cost, the terminal sends out anti-polarity signal (the
signal is used to register cost by register cost equipment). During a call, dial digital key or
“*” or “#” to output DTMF.
If the calling party or called party hang up, the terminal stops sending out anti-
polarity signal.
If users dial barred numbers, telephone will give out the sound of three-time toot to
ask the user to hang up.
Answering Incoming Calls
When some calls are coming in, if the connected telephone has the function of
displaying incoming calls, the telephone rings and displays the incoming telephone
numbers. Now users can lift the handset or press “hand-free” to answer the call.
Adjusting the Volume of Voice
Lift the handset. Dial “*33XY#”, and then hang up when hear the sound of toot. X
and Y both belong to the digits that range from 1 to 5. X indicates microphone volume. Y
indicates speaker volume. Level 1 is the lowest volume and level 5 is the highest.
Technical Specification
•Working condition Environment temperature: 0~+50
•Relative humidity: 10%~95%
•Air pressure: 86~106kpa

Hybrid Systems JSC Users Manual
Page 5 of 6 GSM 102 Gate
•Environment yawp: ≤60dB (A)
•Working frequency: GSM900MHz/GSM1800MHz
•Stability of frequency: better than 2.5PPM
•Signal sensitivity: -103dBM
•Transmit power: <2w
•Power: 220v±15% AC
•The max distance between terminal and telephone: 100M
The Instructions for Terminal’s Running Status
The instruction for initializing terminal When LED2 is lit, the terminal begins to
initialize. If LED1 and LED4 are flashing simultaneously, the terminal is searching for GSM
network. About 1545 seconds later, the telephone rings which indicates that the process of
initializing terminal finishes. If LED3 stays lit, initialization is unsuccessful. On this condition
user can set parameters for the terminal but the terminal can’t be used to make any calls. If
users dial telephone numbers, LED3 will flash and the telephone will give out the sound of
three-time “toot” to ask the user to hang up.
While users dialed barred numbers or other error numbers, the telephone gives out
the sound of three-time “toot” to indicate that user should hang up and redial.
While you are lifting the handset and don’t dial any key for continuous 15 seconds or
the nobody answer the dialed telephone for 90 seconds after the called telephone has
ringed, the telephone will give out the sound of three-time “toot” to indicate the user to
hang up. If the user doesn’t hang up for a long time, all indicating sound will be ended after
1 minute.
While calls coming in, work indicator flashes. If user answers the call, the work
indicator stays lit.
When the handset is lift, working indicator (LED5) stays flashing until user hangs up.
When SMS is coming, warning indicator (LED3) and working indicator (LED5) both
stay lit that indicates that the terminal are dealing with SMS.
If LED3 stays flashing and the telephone gives out the sound of three-time “toot”, it
indicates that the terminal is on the warning status. Please hang up.
Familiar Trouble and Troubleshooting
Phenomena Trouble Trouble Shooting
Warning
indicator stay
lit for a long
time
Failed in login
onto GSM
network
1. The signal is too weak Please move the
terminal to the place where signal is stronger.
2. Check whether antenna is connected well.
3. SIM card is locked. Please contact the
service provider.
Signal indicator
flashes fast
Signal is too
weak
1. Check whether antenna is connected well.
2. The signal is too weak Move the terminal or
antenna to the place where signal is strong.
Power indicator
isn’t lit
Having not
connect to
power supply or
there is some
trouble with
power adapter
1. Check whether the adapter is connected
well. 2. There is some trouble with the power
adapter Please contact the provider of the
terminal.

Hybrid Systems JSC Users Manual
Page 6 of 6 GSM 102 Gate
Only free
numbers can
be called out
The residual
money on SIM
card is too less Add money to the SIM card subscriber
Can’t hear
sound during
calls
The malfunction
on the
telephone
Change the connected telephone with a good
one
Poor voice
quality during
calls or there is
echo during
calls
The voice
volume is too
high or the
signal of
network is too
weak.
1. Adjust voice volume to be lower. 2. The
local signal is too weak. Move the terminal to
the place where signal is stronger. 3. Make
the antenna is longer from the telephone 4.
The voice quality of the connected telephone
isn’t good. Change the connected telephone
5. Trouble on the GSM network.
No ringing
sound
The malfunction
on the
telephone
1. Malfunction on the connected telephone 2.
Malfunction on terminal. Please contact the
provider of the terminal.
Incoming calls
can’t be
answered
The connected
telephone does
not match the
terminal or
forbidding
answering
incoming calls is
set
1. Change the connected telephone with a
suitable one. 2. Forbidding answer incoming
calls is set up, please contact the service
provider.
