HYCON HY17M26 Series User manual

©2022 HYCON Technology Corp.
www.hycontek.com
APD-HY17MIDE010-V02_EN
HY17M26 Series
IDE Hardware User’s Manual
.

HY17M26 Series
IDE Hardware User’s Manual
©2022 HYCON Technology Corp
www.hycontek.com
APD-HY17MIDE010-V02_EN
page2
Table of Contents
1. PACKAGE CONTENTS...............................................................................................................................................4
2. SAFETY PRECAUTIONS............................................................................................................................................5
3. SOFTWARE INSTALLATION REQUIREMENTS....................................................................................................6
3.1. IDE Software Installation Requirements................................................................................................................ 6
4. DESCRIPTION OF THE HARDWARE......................................................................................................................7
4.1. Architecture description.............................................................................................................................................7
4.2. Control Box Introduction........................................................................................................................................... 7
4.3. Introduction to Target Board..................................................................................................................................... 8
4.4. Target Board Circuit Diagram.................................................................................................................................11
4.5. Control Box and Target Board Hardware Connection Steps............................................................................ 12
5. REVISIONS..................................................................................................................................................................13
.

HY17M26 Series
IDE Hardware User’s Manual
©2022 HYCON Technology Corp
www.hycontek.com
APD-HY17MIDE010-V02_EN
page3
Attention:
1、HYCON Technology Corp. reserves the right to change the content of this datasheet
without further notice. For most up-to-date information, please constantly visit our
website: http://www.hycontek.com .
2、HYCON Technology Corp. is not responsible for problems caused by figures or
application circuits narrated herein whose related industrial properties belong to third
parties.
3、Specifications of any HYCON Technology Corp. products detailed or contained herein
stipulate the performance, characteristics, and functions of the specified products in the
independent state. We does not guarantee of the performance, characteristics, and
functions of the specified products as placed in the customer’s products or equipment.
Constant and sufficient verification and evaluation is highly advised.
4、Please note the operating conditions of input voltage, output voltage and load current
and ensure the IC internal power consumption does not exceed that of package
tolerance. HYCON Technology Corp. assumes no responsibility for equipment failures
that resulted from using products at values that exceed, even momentarily, rated values
listed in products specifications of HYCON products specified herein.
5、Notwithstanding this product has built-in ESD protection circuit, please do not exert
excessive static electricity to protection circuit.
6、Products specified or contained herein cannot be employed in applications which
require extremely high levels of reliability, such as device or equipment affecting the
human body, health/medical equipments, security systems, or any apparatus installed in
aircrafts and other vehicles.
7、Despite the fact that HYCON Technology Corp. endeavors to enhance product quality
as well as reliability in every possible way, failure or malfunction of semiconductor
products may happen. Hence, users are strongly recommended to comply with safety
design including redundancy and fire-precaution equipments to prevent any accidents
and fires that may follow.
8、Use of the information described herein for other purposes and/or reproduction or
copying without the permission of HYCON Technology Corp. is strictly prohibited.
.

HY17M26 Series
IDE Hardware User’s Manual
©2022 HYCON Technology Corp
www.hycontek.com
APD-HY17MIDE010-V02_EN
page4
1. Package Contents
HY17M26 IDE Hardware development kit includes HY17M00 Control Box and
HY17M26-NS32 Target Board(refer to table 1-1), In addition, the HY17M00 control box can
be used as an IDE hardware development tool, and can also be used as a programmer of
the HY17M series, this user’s manual mainly introduces the control box applied to the IDE
hardware development tool, the related hardware is equipped as shown below:
Model No.
Part Name
Description
Quantity
HY17M26-DK01
1. HY17M26-AM01
HY17M26-NS32 Target Board
1
2. HY17M00-CM01
HY17M00 Control Box
1
3. Cable line
USB Type A to Mini B Cable
1
4. Interface line
5pin/2.54 (2.54mm pitch)
1
Table1-1
.

HY17M26 Series
IDE Hardware User’s Manual
©2022 HYCON Technology Corp
www.hycontek.com
APD-HY17MIDE010-V02_EN
page5
2. Safety Precautions
Do not place heavy objects on the display panel, in order to avoid damage caused by
stress.
Place the application display boards at steady place, so as to avoid falling damage.
Do not use this product with the input voltage which is not meeting the electrical
specifications,, in order to avoid working abnormally or damage.
Avoid application display boards being touched by liquid, dirt and avoid being exposed
to moisture during operation. This application should be kept in a dry environment, so
as not to affect the function and performance.
Remove the power supply when not using it.
When following status occurred, please remove the power supply immediately, and
contact our engineer.
Power Supply line is worn or damaged.
Power source (battery) connected but no any light on while operating.
Component off.
.

HY17M26 Series
IDE Hardware User’s Manual
©2022 HYCON Technology Corp
www.hycontek.com
APD-HY17MIDE010-V02_EN
page6
3. Software Installation Requirements
3.1. IDE Software Installation Requirements
Minimum System Requirements of operating HY17M IDE hardware development kit:
(1) PC/NB hardware requirement:
IBM PC compatible X86 system CPU
512MB Memory (1GB recommended)
1GB Hard disk
(2) Supported Products:
HY17M26 Series chip
(3) Supported Hardware Model No.:
HY17M26-DK01: HY17M26 IDE hardware development kit
(FW version applicable to HY17M00-CM01 is W17M01.9.2 or above)
(4) Supported software version:
HY17M IDE V2.02 above: HY17M Series Assembly Language IDE software
H08 CIDE V1.30 above: HYCON 8-bit MCU C Language IDE software
(5) Supported Operating system:
Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
(6) Apply the following interface modes:
USB Port with HID-compliant device
The HY17M26-DK01's USB Port driver uses the Windows standard HID driver
(Figure 3-1), so no It can be used with an additional USB driver
Figure 3-1
.

HY17M26 Series
IDE Hardware User’s Manual
©2022 HYCON Technology Corp
www.hycontek.com
APD-HY17MIDE010-V02_EN
page7
4. Description of the hardware
4.1. Architecture description
The HY17M00-CM01 Control Box is a control device between the HY17M26-AM01
Target Board and the HY17M IDE software. It can be used as a development tool through
the connection between the JTAG line and the USB cable, the assembly diagram is as
follows:
Figure 4-1
4.2. Control Box Introduction
Control Box (Model No.: HY17M00-CM01) is commonly used in HY17M series products
(appearance shown in Figure 4-2), the following describes the related functions of the
Control Box:
Figure 4-2
(1) Information LED
Feature: status Indicator LED
Description: the definition of L1~L3 is as follows
Item
Name
Description
L1
Ok
Green LED, When the USB Port is connected to a computer
or an external 5V power supply, the L1 light indicates that the
Control Box is powered.
L2
Error
Red LED (reserved, no use).
L3
Busy
Yellow LED (reserved, no use).
.

HY17M26 Series
IDE Hardware User’s Manual
©2022 HYCON Technology Corp
www.hycontek.com
APD-HY17MIDE010-V02_EN
page8
(2) Debug Port
Feature: The Debug interface port is connected to the Debug port of Target Board to
control the chip.
Description: Pins are defined as follows
Item
Name
Description
1
PCAL
HAO calibration pin
2
VDD
Power source output, fixed output 3.3V with 100mA power
supply
3
SCL
I2C Clock Pin (with pull-up 10KΩ)
4
SDA
I2C Data Pin (with pull-up 10KΩ)
5
VSS
Ground Pin
(3) USB Port
Feature: USB Port.
Description: Connect to your computer via USB Type A to Mini B Cable.
(4) Programming Switch
Feature: the switch for programming.
Description: when the control box is used as an IDE development tool, please do not
press "Program" button at will to avoid the HY17M26 chip’s code on the
Target Board being changed and affecting normal development.
4.3. Introduction to Target Board
The Target Board (Model No.: HY17M26-AM01) is commonly used in the HY17M26
series (Appearance shown in Figure 4-3), this Target Board can be used in addition to IDE
hardware tools, It can also be used as a demo board, the following describes the related
functions of the Target Board:
.

HY17M26 Series
IDE Hardware User’s Manual
©2022 HYCON Technology Corp
www.hycontek.com
APD-HY17MIDE010-V02_EN
page9
Figure 4-3
(1) U1
Feature: Target Board Chip, called HY17M26 (Part No: HY17M26-NS32).
(2) J10
Feature: External Power source VDD_EXT pin.
Description: Pins are defined as follows
Pin
Name
Description
1-1
VSS
Power ground pin
2-2
VDD_EXT
External Power supply pin
(3) J5
Feature: Target Board Chip’s UART/I2C interface port and also can be used as
secondary Debug port and HAO calibration pin.
Description: Pins are defined as follows
Pin
Name
Description
1-1
PCAL
HAO calibration pin
2-2
VDD_ICE
External Power supply pin
3-3
SCL/RC/ECK2
UART RX pin, I2C and Debug Port2’s clock pin
(with pull-up 4.7KΩ on board)
4-4
SDA/TX/EDIO2
UART TX pin, I2C and Debug Port2’s data pin
(with pull-up 4.7KΩ on board)
5-5
VSS
Power ground pin
(4) J6
Feature: Target Board Chip’s primary Debug port and HAO calibration pin.
Description: Pins are defined as follows
Pin
Name
Description
1-1
PCAL
HAO calibration pin
2-2
VDD_ICE
External Power supply pin
3-3
ECK
Debug port’s clock pin
4-4
EDIO
Debug port’s data pin
5-5
VSS
Power ground pin
(5) J1
Feature: Target Board Chip’s VDD power source selection.
Description: Pins are defined as follows
Pin
Name
Description
1
VDD_ICE
Target Board Chip’s VDD power is coming from Control Box
2
VDD_IN
Target Board Chip’s VDD power
3
VDD_EXT
Target Board Chip’s VDD power is coming from external
power
.

HY17M26 Series
IDE Hardware User’s Manual
©2022 HYCON Technology Corp
www.hycontek.com
APD-HY17MIDE010-V02_EN
page10
(6) J9
Feature: Target Board Chip’s SPI interface (implemented with firmware) port, The main
purpose is to be able to connect to the ENOB tool's control board SPI for use as an
ENOB demo board.
Description: Pins are defined as follows
Pin
Name
Description
1
VDD
Target Board chip’s Power Pin
2
SDI
Target Board chip’s SDI Pin
3
SCK
Target Board chip’s SCK Pin
4
SDO
Target Board chip’s SDO Pin
5
CS
Target Board chip’s CS Pin
6
VSS
Power Ground pin
(7) J8
Feature: Target Board Chip’s I2C interface port.
Description: Pins are defined as follows
Pin
Name
Description
1
VSS
Power ground pin
2
VDD
Target Board Chip’s VDD power
3
SCL
I2C’s clock pin
4
SDA
I2C’s data pin
(8) J7
Feature: Target Board Chip’s UART interface port.
Description: Pins are defined as follows
Pin
Name
Description
1
VDD
Power ground pin
2
VSS
Target Board Chip’s VDD power
3
RC
UART’s receive pin
4
TX
UART’s transform pin
Note：The above only describes the basic functions that the Target Board will use, for other
unlisted parts, please refer to the circuit diagram or contact FAE technical support.
.

HY17M26 Series
IDE Hardware User’s Manual
©2022 HYCON Technology Corp
www.hycontek.com
APD-HY17MIDE010-V02_EN
page11
4.4. Target Board Circuit Diagram
Figure 4-4
Note：This Target Board circuit diagram " A20035 V01_HY17M26-AM01_HY17M26 Target
Board.pdf " is placed in the IDE software directory and can be referenced by yourself.
* If using Assembly IDE, it’s placed in “HYCON\HY17M IDE\Schematic" directory.
* If using H08 C IDE, it’s placed in “HYCON\H08 CIDE\ICESchematic\HY17M" directory.
.

HY17M26 Series
IDE Hardware User’s Manual
©2022 HYCON Technology Corp
www.hycontek.com
APD-HY17MIDE010-V02_EN
page12
4.5. Control Box and Target Board Hardware Connection Steps
Step1: Make sure that Target Board’s J1 pin are shorted together.
Step2: Connect the Control Box Debug Port and Target Board’s Debug Port with the 5-wire
Debug interface line.
Step3: Use the USB Cable to connect to the Control Box’s USB Port and the computer's
USB port (the L1 LED will light up).
Step4: After Step 1~3 (as shown in Figure 4-5), the hardware connection is completed.
Figure 4-5
.

HY17M26 Series
IDE Hardware User’s Manual
©2022 HYCON Technology Corp
www.hycontek.com
APD-HY17MIDE010-V02_EN
page13
5. Revisions
The following describes the major changes made to the document, excluding the font and
punctuation changes.
Version
Page
Date
Revision Summary
V02
All
2022/03/29
First edition
.
