HYDAC International FMM-P-L User manual

FMM-P-L
FluidMonitoring Module
Installation and Maintenance Instructions
English (translation of original instructions)
Document No.: 3493215

FluidMonitoring Module Trademarks
Trademarks
The trademarks of other companies are exclusively used for the products of those
companies.
Copyright © 2010 by
HYDAC FILTER SYSTMES GMBH
all rights reserved
All rights reserved. This manual may not be reproduced in part or whole without the
explicit written agreement from HYDAC Filter Systems. Contraventions are liable to
compensation.
Exclusion of liability
We made every endeavor to ensure the accuracy of the contents of this document.
Consequently, we accept no liability for such errors as may exist nor for any damage
or loss whatsoever which may arise as a result of such errors. The content of the
manual is checked regularly. Any corrections required will be incorporated in future
editions. We welcome any suggestions for improvements.
All details are subject to technical modifications.
Technical specifications are subject to change without notice.
HYDAC FILTER SYSTEMS GMBH
Postfach 12 51
66273 Sulzbach / Saar
Germany
Documentation Representative
Mr. Günter Harge
c/o HYDAC International GmbH, Industriegebiet, 66280 Sulzbach / Saar
Telephone: ++49 (0)6897 509 1511
Telefax: ++49 (0)6897 509 1394
E-mail: [email protected]
HYDAC FILTER SYSTEMS GMBH en Page 2 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09

FluidMonitoring Module Contents
HYDAC FILTER SYSTEMS GMBH en Page 3 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09
Contents
Trademarks ...............................................................................................................2
Documentation Representative...............................................................................2
Contents....................................................................................................................3
Preface ...................................................................................................................... 5
Customer Service ...................................................................................................6
Modifications to the Product ...................................................................................6
Warranty .................................................................................................................6
Using the Documentation .......................................................................................7
Safety Information and Instructions.......................................................................8
Obligations and Liability..........................................................................................8
Explanation of Symbols and Warnings, etc. ...........................................................9
Proper/Designated Use .......................................................................................... 9
Improper Use .......................................................................................................... 9
Informal Safety Precautions.................................................................................. 10
Training and Instruction of Personnel ...................................................................11
Safety Measures to Be Followed during Normal Operation.................................. 11
Maintenance, Servicing and Troubleshooting....................................................... 12
Modifications to the FMM...................................................................................... 12
Storing the FMM ..................................................................................................... 12
Checking the Scope of Delivery............................................................................ 13
FMM Features ......................................................................................................... 14
Restrictions Pertaining – FMM-P-L-0-CS1xx0......................................................15
Restrictions Pertaining – FMM-P-x-1-CS1xx1 ......................................................15
Continuously rotatable display..............................................................................15
Hydraulic schematic .............................................................................................. 16
Dimensions .............................................................................................................16
FMM components...................................................................................................17
Attaching the FMMP mechanically ....................................................................... 18
FMM hydraulic installation .................................................................................... 19
Connecting FMM with the hydraulic system........................................................ 21
Error messages / Troubleshooting.......................................................................22
Performing Maintenance .......................................................................................22
Maintenance interval............................................................................................. 22
Changing the Filter Element .................................................................................23
Decommissioning the FMM...................................................................................24

FluidMonitoring Module Contents
HYDAC FILTER SYSTEMS GMBH en Page 4 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09
Disposing of the FMM ............................................................................................ 24
Spare Parts and Accessories................................................................................25
Technical data ........................................................................................................ 26
Customer Service...................................................................................................26
Model Code .......................................................................................................... 27

FluidMonitoring Module Preface
Preface
We have compiled the most important instructions for the operation and
maintenance of our product for you, its user, in this documentation.
It will acquaint you with the product and assist you in using it as intended in an
optimal manner.
Keep it in the vicinity of the product so it is always available.
Note that the information on the unit's engineering contained in the documentation
was that available at the time of publication.There may be deviations in technical
details, figures, and dimensions as a result.
If you discover errors while reading the documentation or have additional comments
or suggestions, contact us at:
HYDAC FILTER SYSTEMS GMBH
Technische Dokumentation
Postfach 12 51
66273 Sulzbach / Saar
Germany
We look forward to receiving your input.
“Putting experience into practice”
HYDAC FILTER SYSTEMS GMBH en Page 5 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09

FluidMonitoring Module Preface
HYDAC FILTER SYSTEMS GMBH en Page 6 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09
Customer Service
Contact our technical sales department if you have any questions on our product.
When contacting us, please always include the model/type designation, serial no.
and part-no. of the product:
Telefax: ++49 (0)681 509 - 846
E-mail: [email protected]
Modifications to the Product
We would like to point out that changes to the product (e.g. purchasing additional
options, etc.) may mean that the information in the operating instructions is no
longer applicable or adequate.
After modification or repair work that affects the safety of the product has been
carried out on components, the product may not be returned to operation until it has
been checked and released by a HYDAC technician.
Please notify us immediately of any modifications made to the product whether by
you or a third party.
Warranty
For the warranty provided by us, please refer to the General Terms of Sale and
Delivery of HYDAC Filter Systems GmbH.
Refer to these at www.hydac.com General terms and conditions.

FluidMonitoring Module Preface
Using the Documentation
Note that the method described for locating specific information does
not release you from your responsibility of carefully reading these
instructions prior to starting the unit up for the first time and at regular
intervals in the future.
What do I want to know?
I determine which topic I am looking for.
Where can I find the information I’m looking for?
The documentation has a table of contents at the beginning. There, I select
the chapter I'm looking for and the corresponding page number.
Chapter description
Page number
Edition date
Document language
Documentation no.
with index/
file name
The documentation number with its index enables you to order another copy of the
operating and maintenance instructions. The index number is incremented upward
by one number every time the manual is revised or changed.
HYDAC FILTER SYSTEMS GMBH en Page 7 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09

FluidMonitoring Module Safety Information and Instructions
HYDAC FILTER SYSTEMS GMBH en Page 8 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09
Safety Information and Instructions
These operating instructions contain the key instructions for properly and safely
operating the FMM.
Obligations and Liability
The basic prerequisite for the safe and proper handling and operation of the FMM is
knowledge of the safety instructions and warnings.
These operating instructions in general, and the safety precautions in particular, are
to be adhered to by all those who work with the FMM.
Adherence is to be maintained to pertinent accident prevention regulations
applicable at the site where the product is used.
The safety precautions listed herein are limited solely to using the FMM.
The FMM has been designed and constructed in accordance with the current state
of the art and recognized safety regulations. Nevertheless, hazards may be posed to
the life and limb of the individual using the product or to third parties. Risk of
damage may be posed to the product or other equipment and property.
The FMM is only to be used as follows:
solely for its designated use
only when in a safe, perfect condition
Any faults or malfunctions which might impair safety are to be properly repaired or
remedied immediately.
Our General Terms and Conditions apply. They are provided to the owner upon
conclusion of purchase of the unit at the latest. Any and all warranty and liability
claims for personal injuries and damage to property shall be excluded in the event
they are attributable to one or more of the following causes:
improper use of the FMM or use deviating from its designated use
improper assembly, installation, commissioning, operation and maintenance of
the FMM
modifications to the FMM made by the user or purchaser
Improper monitoring of unit components that are subject to wear and tear
Improperly performed repair work

FluidMonitoring Module Safety Information and Instructions
Explanation of Symbols and Warnings, etc.
The following designations and symbols are used in this manual to designate
hazards, etc.:
DANGER
DANGER denotes situations
which can lead to death if
safety precautions are not
observed.
WARNING
WARNING denotes situations
which can lead to mortal injury
if safety precautions are not
observed.
CAUTION
CAUTION denotes situations
which can lead to severe
injuries if safety precautions
are not observed.
NOTICE
NOTICE denotes situations
which can lead to property
damage if safety precautions
are not observed.
Proper/Designated Use
The FluidMonitoring Module FMM was developed for the continuous monitoring of
particulate contamination and water content in hydraulic systems.
Analyzing the size and quantity of contamination enables quality standards to be
verified and documented and the requisite optimization measures to be
implemented.
Any other use shall be deemed to be improper and not in keeping with the product's
designated use.
Proper or designated use of the product extends to the following:
Maintaining adherence to all the instructions contained herein.
Performing requisite inspection and maintenance work.
Improper Use
Any use deviating from the proper/designated use described above is prohibited.
Improper use may result in hazard to life and limb.
Example of improper use:
Improper connection of the pressure and return lines of the FMM.
HYDAC FILTER SYSTEMS GMBH en Page 9 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09

FluidMonitoring Module Safety Information and Instructions
Informal Safety Precautions
Always keep the operating instructions in the vicinity of the measurement unit.
Apart from the operating instructions, any and all general and local regulations
pertaining to accident prevention and environmental protection are to be made
available and observance is to be maintained to them.
Make sure to keep the safety and hazard symbols and warnings on the FMM in a
legible condition.
Check the hoses and connection fittings for leakage daily (visual check). The
electrical components of the FMM are to also be regularly checked (visual check
once a month). Replace any loose connections or damaged cables immediately.
WARNING
Hydraulic systems are under pressure
Bodily injury
►The hydraulic system must be depressurized
before performing any work on the hydraulic
system.
HYDAC FILTER SYSTEMS GMBH en Page 10 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09

FluidMonitoring Module Safety Information and Instructions
HYDAC FILTER SYSTEMS GMBH en Page 11 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09
Training and Instruction of Personnel
The FMM may only be operated by properly trained and instructed personnel.
The areas of responsibility of your staff must be established in a clear-cut manner.
Staff undergoing training may not use the FMM unless supervised by an
experienced staff member.
Individuals Personnel undergoing training
P
ersonne
l
w
ith
technical training/ engineering background Electrician Supervisor with the appropriate authority
Activity
Packing
Transportation X X X
Commissioning X X X
Operation X X X X
Troubleshooting/
locating the source of malfunction X X X
Remedying of mechanical faults X X
Remedying of electrical faults X X
Maintenance X X X X
Repair work X
Decommissioning/storage X X X X
Safety Measures to Be Followed during Normal Operation
Do not operate the FMM unless all the safety devices function properly.
The product is to be checked once a day for external damage and the proper
functioning of the safety devices.

FluidMonitoring Module Storing the FMM
HYDAC FILTER SYSTEMS GMBH en Page 12 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09
Maintenance, Servicing and Troubleshooting
The prescribed adjustment, maintenance/servicing and inspection work is to be
conducted in a timely fashion.
Disconnect the FMM from the power supply and protect the entire system from
being inadvertently switched on when performing maintenance, inspection or repair
work.
Check any screwed fittings which have been removed to see that they have been
properly secured.
Always check the product to see that it functions properly when performing
maintenance and servicing work.
Modifications to the FMM
Do not make any modifications (design modifications, extensions) to the FMM
without the prior consent of the manufacturer.
Any modifications require written permission from HYDAC Filter Systems GmbH
Immediately replace any machine components which are not in perfect condition.
Use only original spare parts.
Storing the FMM
Store the FMM in a clean, dry place, in the original packing if possible. Do not
remove the packing until you are ready to install the unit.
Drain the FMM completely before putting it into storage. If necessary, rinse the FMM
with n-heptane to prevent it from gumming up during storage.
The cleaning agents and flushing oils used are to be handled and disposed of
properly.

FluidMonitoring Module Checking the Scope of Delivery
Checking the Scope of Delivery
The Fluid Monitoring Module FMM Unit comes packed and factory-assembled.
Before starting up the FMM, check that the content of the package is complete.
The following items are supplied:
Item Qty. Description
1 1 FluidMonitoring Module
2 1 Connector (female) with 8-pole, M12x1, shielded
3 1 Connector (female), 5-pole, M12x1
- 1 Operating and Maintenance Instructions FMM (this document)
- 1 Operating and maintenance instructions AS1000
- 1 CD-ROM with:
- Software CoCoS 1000
- Operation and maintenance instructions CS 1000
- 1 CD-ROM with FluMoS Light software
- 1 Calibration certificate CS1000
HYDAC FILTER SYSTEMS GMBH en Page 13 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09

FluidMonitoring Module FMM Features
HYDAC FILTER SYSTEMS GMBH en Page 14 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09
FMM Features
The FluidMonitoring Module FMM-P-L Series combines HYDAC's Condition
Monitoring Products ContaminationSensor CS 1000 and AquaSensor AS 1000 in
one system.
The FMM is used as a robust and stationary system for online measurement of solid
particle contamination and water content in hydraulic and lubricant fluids (e.g. for the
detection of leakages).
The FMM features all of the requisite connectors / adapters, enabling it to be easily
connected to existing hydraulic circuits.
The FMM is suitable for the following operating pressures:
FMM with pressure accumulator 15 … 250 bar
FMM without pressure accumulator 15 … 300 bar
Advantages offered by the FMM:
Cost-effective solution
Early warning of critical machine states
Continuous fluid monitoring
Condition-based maintenance planning

FluidMonitoring Module FMM Features
Restrictions Pertaining – FMM-P-L-0-CS1xx0
NOTICE
Impermissible operating fluid
The module will be destroyed
►The FMM may only be used with mineral oils or mineral oil-based raffinates.
Restrictions Pertaining – FMM-P-x-1-CS1xx1
CAUTION
Impermissible operating fluid
The module will be destroyed
►The FMM may only be used with HDFR fluids (phosphoric acid esters, e.g.
Skydrol, Fryquel, Hyjet).
Continuously rotatable display
The CS 1000 display can be continuously rotated by
a total of 270°. 180° counterclockwise and 90°
clockwise.
To rotate the display, grasp the cover plate with your
hand and turn in the desired direction.
No tools are required for rotating the display.
HYDAC FILTER SYSTEMS GMBH en Page 15 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09

FluidMonitoring Module Hydraulic schematic
Hydraulic schematic
Dimensions
HYDAC FILTER SYSTEMS GMBH en Page 16 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09

FluidMonitoring Module FMM components
FMM components
Item Description
1 FMM Installation block
2 ContaminationSensor CS 1000 series
3 Connector (female), 8-pole, M12x1
4 AquaSensor AS 1000 series
5 Connector (female), 5-pole, M12x1
6 Inlet (IN), with test connector type 1604 or G ¼ according to ISO 228r
7 Outlet (OUT), with test connector type 1604 or G ¼ according to ISO
228.
8 Test connection (TP1), test connector Type 1604
9 Test connection (TP2), test connector Type 1604
10 Pressure accumulator
11 Filter element (installed)
HYDAC FILTER SYSTEMS GMBH en Page 17 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09

FluidMonitoring Module Attaching the FMMP mechanically
Attaching the FMMP mechanically
We recommend installing the unit vertically, so that the flow direction is from bottom
to top. When selecting the installation site, check the ambient conditions such as
temperature, dust, water, etc. The CS features a protection rating of IP 67 according
to DIN 40050 / EN60529 / IEC 529 / VDE 0470.
Fastening can be carried out by means of the four holes in the connection stock with
four M6 screws in accordance with ISO 4762 (minimum length 80 mm).
HYDAC FILTER SYSTEMS GMBH en Page 18 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09

FluidMonitoring Module FMM hydraulic installation
FMM hydraulic installation
WARNING
Non-permitted operating pressure
Bodily injury
►Note the maximum operating pressure of 300
bar.
NOTICE
The minimum differential pressure is < 15 bar
If the minimum differential pressure is not given, measuring errors will occur.
►Always observe the minimum differential pressure of 15 bar
To minimize measurement errors resulting from trapped air in the system, we
recommend that the flow direction through the FMM is from bottom (IN) to top
(OUT).
The FMM comes delivered with four test connectors (Type 1604), one at the inlet
(IN) and one at the outlet (OUT) port, as well as at the two testing points (TP1 /
TP2).
If the hydraulic connection is done via the connector thread G 1/4 according to ISO
228, the test connectors must be removed.
HYDAC FILTER SYSTEMS GMBH en Page 19 / 28
MoWa FMM-P-L 3493215 en 2010-03-09.doc 2010-03-09

FluidMonitoring Module FMM hydraulic installation
HYDAC FILTER SYSTEMS GMBH en Page 20 / 28
