PRODUCT GUIDE
HydraMax®
Product Installation Guide
HD-LIT-014 05/23
2 Bucket System
PRODUCT GUIDE
2
System at a Glance
Inspection Port Cover 5.5” Net Pot
Circulator
Qwik-Lok Tee
Circulator Tubing
Inspection Port
Tee
Pump
Qwik-Lok
Adapter
Tubing
Adapter
8-Gallon Bucket
Bucket Legs
Qwik-Lok Hose
Drain Fitting
PRODUCT GUIDE
3
Pump Assembly
Apply 2-3 wraps of Teon
tape to the threads as shown.
Tigten the adapter to the pump until
they are snug. Do not over-tighten.
Circulator
Spring Clamp
Circulator Tubing
Tubing Adapter
Pump
Qwik-Lok Adapter
Start by applying Teon tape to the pump
adapters, then assemble the parts as illustrated.
Before pushing the tubing over the barbs of the
pump, tee and circulator, place spring clamps on
both ends of the tubing. Finally, slide the spring
clamps over the barbs to secure the tubing in
place.
PRODUCT GUIDE
4
Bucket Assembly
Insert the drain tting with
gasket from inside the bucket
and tighten the nut below.
Insert each leg into the bucket and
then press or tap the bucket onto a
level surface to ensure that each leg
is fully seated.
PRODUCT GUIDE
5
Final Assembly
Attach Qwik-Lok hoses to the drain
ttings, then to the Tee. Attach the
last hose from the tee to the pump.
Slide all the locking rings into the
locked position.
Lower the circulator into the the
bucket, mating the bracket to the
recessed lip in the corner.
Remember to slide spring clamps
onto the hoses before pushing the
hose over the barb. Then, slide the
spring clamp over the barb.
PRODUCT GUIDE
6
Latched Position
Locked Position
Open Position
To connect a Qwik-Lok hose, with the blue
ring in the “latched” position, simply push the
hose onto the tting.
Once connected, slide the blue ring to the
“locked” position.
To disconnect, hold the blue ring with two
ngers and pull the hose off of the tting in
one motion.
Qwik-Lok Operation
