PRODUCT GUIDE
HydraMax®
Product Installation Guide
HD-LIT-013 05/23
1 Bucket System

PRODUCT GUIDE
2
HydraMax 1-Bucket
System at a Glance
Inspection Port Cover
5.5” Net Pot
Circulator
Spring Clamp
Circulator Tubing
Pump
Tubing Adapter
Inspection Port
8-Gallon Bucket
Bucket Legs
Qwik-Lok Hose
Qwik-Lok Adapter
Drain Fitting

PRODUCT GUIDE
3
HydraMax 1-Bucket
Pump Assembly
Apply 2-3 wraps of Teon
tape to the threads as shown.
Tigten the adapter to the pump until
they are snug. Do not over-tighten.
Circulator
Spring Clamp
Spring Clamp
Circulator Tubing
Tubing Adapter
Pump
Qwik-Lok Adapter
Start by applying Teon tape to the pump
adapters, then assemble the parts as illustrated.
Before pushing the tubing over the barbs of the
pump and circulator, place spring clamps on
both ends of the tubing. Finally, slide the spring
clamps over the barbs to secure the tubing in
place.

PRODUCT GUIDE
4
HydraMax 1-Bucket
Bucket Assembly
Insert the drain tting with
gasket from inside the bucket
and tighten the nut below.
Insert each leg into the bucket and
then press or tap the bucket onto a
level surface to ensure that each leg
is fully seated.

PRODUCT GUIDE
5
HydraMax 1-Bucket
Final Assembly
Attach the Qwik-Lok hose to the
drain tting and slide the locking
ring into the locked position. Attach
the other end of the hose to the
pump as shown.
Lower the circulator into the the
bucket, mating the bracket to the
recessed lip in the corner.
Remember to slide a spring clamp
onto the hose before pushing the
hose over the barb. Then, slide the
spring clamp over the barb.

PRODUCT GUIDE
6
Latched Position
Locked Position
Open Position
To connect a Qwik-Lok hose, with the blue
ring in the “latched” position, simply push the
hose onto the tting.
Once connected, slide the blue ring to the
“locked” position.
To disconnect, hold the blue ring with two
ngers and pull the hose off of the tting in
one motion.
HydraMax 1-Bucket
Qwik-Lok Operation
