HydraMaster Truckmount to Go TMTG 4000 User manual

Owner’s Manual
HydraMaster
11015 47th Avenue West
Mukilteo, Washington 98275
MAN-47717 Rev. A, June 2019
No part of this manual may be reproduced or used in any form or by any means (i.e. graphic, electronic, photocopying or electronic
retrieval systems) without the express written permission of HydraMaster. Specications and information in this document are
subject to change without prior notice. All rights reserved. © 2019 HydraMaster

i - TMTG 4000 Owner’s Manual
Table of Contents
GENERAL INFORMATION ........................................................................ SECTION 1
How to use these resources.................................................................... 1-1
Contact Information................................................................................. 1-3
Warnings, Cautions and Notices............................................................. 1-4
Responsibilities ....................................................................................... 1-8
Machine Specications ........................................................................... 1-13
High Altitude Operation ........................................................................... 1-15
Local Water Precautions ......................................................................... 1-15
TRANSPORTATION INFORMATION........................................................ SECTION 2
CLEANING AND CHEMICALS .................................................................. SECTION 3
Precautions ............................................................................................. 3-1
Preparing the Carpet for Extraction......................................................... 3-2
Rinse and Recover.................................................................................. 3-2
Overwetting............................................................................................. 3-3
Streaking................................................................................................. 3-3
Cleaning Tool Tips................................................................................... 3-4
OPERATING INSTRUCTIONS.................................................................. SECTION 4
Start Up Procedure ................................................................................. 4-3
Shut Down Procedure............................................................................. 4-5
MACHINE MAINTENANCE ....................................................................... SECTION 5
Operational Maintenance........................................................................ 5-2
Overall Machine Maintenance................................................................. 5-4
Engine Maintenance ............................................................................... 5-5
High Pressure Pump Maintenance ......................................................... 5-7
Vacuum System Maintenance ................................................................ 5-11
Descaling Procedure (Required)............................................................. 5-12
Freeze Guarding ..................................................................................... 5-13
WATER AND CHEMICAL SYSTEM .......................................................... SECTION 6
ELECTRICAL SYSTEM.............................................................................. SECTION 7
Electrical System Information.................................................................. 7-1
SYSTEMS TROUBLESHOOTING ............................................................ SECTION 8
Heating System....................................................................................... 8-2
Chemical System .................................................................................... 8-3

TMTG 4000 Owner’s Manual - ii
Engine..................................................................................................... 8-4
High Pressure System ............................................................................ 8-8
Vacuum System ...................................................................................... 8-10
ASSEMBLIES AND PARTS LISTS............................................................ SECTION 9
Truckmount to Go 4000 Parts List .......................................................... 9-9
Truckmount to Go 4000 Console Parts List ............................................ 9-14
Frame Assembly Parts List ..................................................................... 9-16
Blower Assembly Parts List..................................................................... 9-19
Pump Assembly Parts List ...................................................................... 9-20
Dash Assembly Parts List ....................................................................... 9-24
Di󰀨erential Check Valve Assembly Parts List.......................................... 9-25
By-Pass Valve Assembly Parts List......................................................... 9-26
Orice Assembly Parts List ..................................................................... 9-27
Engine Assembly Parts List..................................................................... 9-29
Blower Heat Exchanger Assembly Parts List.......................................... 9-31
Idler Pulley Assembly Parts List.............................................................. 9-32
Silencer Assembly Parts List................................................................... 9-33
Water Box Assembly Parts List ............................................................... 9-35
Exhaust Assembly Parts List................................................................... 9-36
70 Gallon Universal Recovery Tank (URT) Assembly Parts List............. 9-38
70 Gallon Universal Recovery Tank (URT) Cover Assembly Parts List .. 9-40
14” Hose Reel - Garden Assembly Parts List.......................................... 9-41
Vacuum Relief Valve Assembly Parts List............................................... 9-42
Dump / Vacuum Bracket - TMTG Assembly Parts List............................ 9-43
HOW TO ORDER PARTS .......................................................................... SECTION 10
Warranty Parts Orders ............................................................................ 10-1
Parts Orders............................................................................................ 10-1
Emergencies ........................................................................................... 10-1
WARRANTY INFORMATION..................................................................... SECTION 11
Blower .................................................................................................... 11-1
High Pressure Water Pump ................................................................... 11-1
Recovery Tank ....................................................................................... 11-1
Chemical System .................................................................................... 11-1
Control Panel ......................................................................................... 11-1
Vacuum and Solution Hoses .................................................................. 11-2
Cleaning Wand and Tool ......................................................................... 11-2
Water Heating System ............................................................................ 11-2
Hard Water Deposits............................................................................... 11-2
Warranty Procedure ................................................................................ 11-2
ACCESSORIES AND CHEMICAL SOLUTIONS...................................... SECTION 12

iii - TMTG 4000 Owner’s Manual

1-1: General Information
1 - Introduction
This Owner’s Manual provides you with important Contact Information, Warnings and
Precautions, a System Operation Overview and Maintenance Logs.
Read the entire Operations Instruction Booklet and Owner’s Manual before using
this product. Failure to do so can result in serious injury or death.
HOW TO USE THESE RESOURCES
The Operations Instruction Booklet is to be used for quick reference only and is not
intended to be a comprehensive source of information. Refer to the Owner’s Manual when
more detailed information is needed.
The Machine Maintenance Log is located within the Owner’s Guide. It is wise to keep
the operations instruction booklet in a visible location near the truckmount so that the log
stays up to date. Please note that records of maintenance must be kept and copies
may be required to be furnished to HydraMaster before any warranty is honored.
The Owner’s Manual contains information on everything from cleaning and chemicals to
truckmount operation and maintenance. It also contains detailed machine assemblies and
parts lists as well as a troubleshooting guide. You should become familiar with the material
in the Owner’s Manual as it contains information that is essential for safe operation and
increased truckmount reliability.
It is the purpose of this manual to help you properly understand, maintain and service
your TMTG 4000. Follow the directions carefully and you will be rewarded with years of
protable, trouble-free operation.
It is imperative that no section of this manual be overlooked when preparing for operation
of the TMTG 4000. Please read the manual to familiarize yourself with the operation of
your TMTG 4000, paying special attention to all Warnings and Cautions.

General Information: 1-2
This Owner’s Manual contains the following sections:
• Contact Information
• Warnings, Cautions and Notices
• Responsibilities
• System Concept
• Machine Specications
• High Altitude Operation
• Local Water Precautions
• Filling the fuel tank
• Securing the Load
• Operating Instructions
• Machine Maintenance
• Water and Chemical System
• Electrical System
• Systems Troubleshooting
• Assemblies and Parts List
• How to Order Parts
• Warranty Information
• Accessories and Chemical Solution.

1-3: General Information
CONTACT INFORMATION
If you have any questions regarding the operation, maintenance or repair of this machine,
please contact your local distributor.
To nd a local distributor, please visit our website at
http://hydramaster.com/HowToBuy/DealerLocator.aspx
If your question cannot be resolved by your distributor or by the information within this
manual, you may contact HydraMaster direct using the following phone numbers.
HOURS TELEPHONE NUMBERS E-MAIL ADDRESSES
Monday-Friday
7:00 a.m. to 5:00 p.m.
Pacic Time
Technical Support
[phone]
FAX : [phone]
Technical Support
[e-mail]
Customer Service/Parts
[phone]
FAX : [phone]
Customer Service/Parts
[e-mail]
When calling your distributor, be sure to reference the serial number and date of purchase.
FOR YOUR REFERENCE:
Serial No. ____________________________________________________
Date of Purchase: _____________________________________________
Purchased From (Distributor): ____________________________________

General Information: 1-4
WARNINGS, CAUTIONS AND NOTICES
HydraMaster uses this WARNING symbol throughout the manual to warn of
possible injury or death.
This CAUTION symbol is used to warn of possible equipment damage.
This NOTICE symbol indicates that federal or state regulatory laws may apply,
and also emphasizes supplemental information.

1-5: General Information
Warnings and Cautions specic to the TMTG 4000 include the following:
During the operation of the truckmount many components are in motion. Never
touch any part of the truckmount that is in motion. Serious injury may result.
During the operation of the truckmount many surfaces will become extremely hot.
Never touch hot surfaces. Serious injury may result.
The operation of this truckmount can produce noise levels exceeding 85 decibels
to a distance of 10 ft. The Occupational Safety and Health Administration (OSHA)
recommends the use of hearing protective equipment if a person is exposed to an
average of 85 decibels over an 8-hour period. Check with local and state agencies
concerning hearing conservation rules.
During the operation of the truckmount carbon monoxide and other toxic fumes
are produced. Position the vehicle so that any fumes produced will be directed
away from inhabited areas and any points of building entry (doors, windows, air
conditioning units, fans, etc.). Do not occupy the vehicle while the truckmount is in
operation. Serious injury may result.
During the operation of the truckmount, chemicals known to the State of California
to cause cancer, birth defects and other reproductive harm are produced by the
engine exhaust.
Never operate the truckmount with a portable gas container other than the gas
tank included as part of the TMTG 4000. Serious injury or death may result.
Transporting a vented fuel container that presently contains, or has ever contained
in the past, a ammable liquid is strictly forbidden by HydraMaster and by federal
and state regulations. Doing so will increase the risk of re and explosion. Serious
injury or death may result.

General Information: 1-6
Never smoke in or around the truckmount. Doing so will increase the risk of re
and explosion. Serious injury or death may result.
During the operation of the truckmount the exhaust system will become extremely
hot. Keep all ammable materials away from the truckmount exhaust system.
Failure to do so will increase the risk of re and explosion. Serious property
damage may result.
Never operate the truckmount when the vehicle is tilted more than 10 degrees in
any direction. Doing so will result in improper lubrication of the internal components,
and will increase the risk of serious component or engine damage.
Never perform cleaning operations when the truckmount engine is running at the
IDLE throttle position. Failure to do so will increase the risk of serious component
or engine damage.
Never operate the truckmount with the vehicle doors closed. Doing so results in
extremely high temperatures inside the vehicle and will lead to serious component
or engine damage.
Never use concentrated acids or solvents (including d-limonene) in the truckmount
water system or chemical system. Use of these products will cause serious
component damage.
Never operate the truckmount with a water hardness reading measuring 3.0 grains
per gallon or higher. Using reading than 3.0 grains per gallon will cause scale
to build up inside the truckmount water system. Scale build up causes serious
component damage. Test all water prior to use and use water softening equipment
if necessary.

1-7: General Information
Never allow water to freeze inside the truckmount. Serious component damage
will occur. Perform all freeze guarding procedures outlined in this digital Owner’s
Manual.
Many vehicles have critical components mounted directly below the oor that can
easily be damaged. Before drilling holes in the oor of the vehicle inspect the
underside of the vehicle for critical components. Failure to do so may result in
damage to the vehicle.
Use of the vacuum recovery system when stripping or otherwise removing wax
from oors is specically excluded as an approved use of the truckmount. Failure
to follow this exclusion may lead to component failure and will invalidate your
warranty.
Use of the vacuum recovery system for “dry cleaning”, without corresponding
solution application (i.e. duct cleaning), is specically excluded as an approved
use of the truckmount. Failure to follow this exclusion may lead to component
failure and will invalidate your warranty.
If concentrated acids or solvents are used to pre-treat surfaces before power
washing, do not recover them through the vacuum system. Failure to follow this
exclusion may lead to component failure and will invalidate your warranty.

General Information: 1-8
RESPONSIBILITIES
The Equipment Owners Responsibilities
Ensure that the vehicle payload is suitable for all of the equipment that will be installed
and transported. This includes and is not limited to: the truckmount, recovery tanks,
fresh water tanks and on-board water, hose reels, hoses, cleaning tools, chemicals,
drying equipment, etc. Payload capacity information is available through the auto dealer,
the manufacturer’s web site, and is also located on the door pillar of the driver’s side
door.
Ensure the equipment is properly secured to the vehicle. Rated attachment points must
be used on both the vehicle and machine. Customer is responsible for recommendation
and supplying of the tie downs or the allowance of renter used tie downs. Owner is
responsible for accommodating open trailer or vehicle transportation. All local laws and
regulations must be followed for properly securing payloads.
Prior to operating the truckmount read this manual in its entirety and familiarize yourself
with the information contained here. Special attention should be paid to all cautions and
warnings.
The distributor should provide a thorough review of the operation manual with the
purchaser along with instruction and familiarization in:
• How all the Truckmounts systems function.
• All safety precautions and their importance.
• How to correctly start and shut down the truckmount.
• How to correctly clean with the truckmount.
• Where and how often to check and change component oil levels.
• Freezing damage and how to avoid it. This includes explaining proper freeze
guarding procedures.
• How to do basic troubleshooting of the truckmount.
• Hard water damage and how to avoid it. This includes how to determine if hard water
exists in your area and the installation and use of water softening systems.
• The Truckmounts warranty and warranty procedures.
Any modication of the truckmount may void the warranty.

1-9: General Information
Distributor’s Responsibility
Acceptance of Shipment
Before accepting the truckmount, check the following:
1. The truckmount should be free from any damage during shipping. Do not sign the
delivery receipt until you have closely inspected the truckmount and noted any
damage on the delivery receipt. Hidden damage may be present even if the box looks
okay. It is recommended that the box be opened before you sign for the shipment.
2. Check the packing list and verify that all items are accounted for.
Installation Responsibilities
• Ensure proper payload capacity. It is the distributor’s responsibility to verify that the
equipment package does not exceed the vehicle capacity.
• Ensure proper placement of the truckmount, fresh water tank, and accessories in the
vehicle, and check that they are secured properly.
• Check the pump, vacuum blower and engine oil levels prior to starting the truckmount.
• Start and run the truckmount and check that all systems function properly.
• Test all hoses, wands and other accessories for correct operation.
• Ensure timely return of the document package.

General Information: 1-10
Training
The distributor should provide a thorough review of the operation instruction booklet with
the purchaser along with instruction and familiarization in:
1. How all the truckmount’s systems function.
2. All safety precautions and their importance.
3. How to correctly start and shut down the truckmount.
4. How to correctly clean with the truckmount.
5. Where and how often to check and change component oil levels.
6. Freezing damage and how to avoid it. This includes explaining proper freeze guarding
procedures.
7. How to do basic troubleshooting of the truckmount.
8. Hard water damage and how to avoid it. This includes how to determine if hard water
exists in your area and the installation and use of water softening systems.
9. The truckmount’s warranty and warranty procedures.

1-11: General Information
SYSTEM CONCEPT
The system utilizes an internal combustion engine to provide the power necessary to
turn both a vacuum pump and a high pressure water pump.
The heat of the engine and blower exhausts is transferred to the high pressure water in
the nned tube heat exchanger of the system.
Finally, the chemical is injected into the pressurized water stream and the heated solu-
tionis delivered to the cleaning tool. The solution is recovered by the vacuum generated
by the vacuum pump This solution is collected in the recovery tank for proper disposal.
Features
• TMTG is not limited to water extraction like other mobile systems. It provides deep
cleaning and water extraction capabilities. Most restoration job sites require compre-
hensive deep cleaning needs after the ood waters have been extracted
• Proven power, vacuum, and cleaning solution delivery platform used on HydraMas-
ters most popular slide-in mounted truckmount systems
• Sturdy platform with forklift guides for exible application
• Store and ship in container or pod for quick delivery. Lightweight enough the unit can
be permanently mounted on an industrial cart for easy transport through college and
industrial campuses, amusement parks, golf courses and resorts.
The HydraMaster Truckmount to Go is a mobile, high performance cleaning and extrac-
tion system designed for restoration and cleaning contractors, facility managers, and
disaster emergency response teams who need an easy to operate and easy to transport
unit. It can be directly delivered to the job site for immediate and on-going deep cleaning
and extraction of carpets, upholstery, hard surface oors, sidewalk, porch and entry way
cleaning; water and ood extraction, and pressure washing where immediate collection
of cleaning solutions and soiling are benecial.
The complete self-contained, turn-key system can be transported via atbed or pick-up
truck, van, trailer, or even an industrial cart that is rated for a ¾ to 1 ton capacity. As the
unit provides its own power, no electricity is needed. The complete system includes: a
wastewater recovery tank; high capacity automatic wastewater disposal system (for
pumping wastewater to an on-location sanitary sewage access point); fuel tank; vacuum
hoses on hangers and garden and solution hoses mounted on a high capacity hose
reel; and a cleaning and extraction wand. In addition, the TMTG uses a state-of-the-art
heat exchange system to heat the cleaning solution, eliminating the need for a second
fuel source required for hot water pressure washers.

General Information: 1-12
The TMTG does not require the contractor or facility to permanently tie up a vehicle.
The unit is simply forklifted into the transport vehicle for delivery to the job site, or
shipped by container or crate to the work site.
HydraMaster is one of the largest manufacturers of truck mounted and high perfor-
mance portable cleaning and extraction machines. For over 48 years, HydraMaster has
innovated uncompromising deep cleaning, extraction and drying solutions.

1-13: General Information
MACHINE SPECIFICATIONS
Frame Dimensions 44”W x 45”H x 57”D
Weight 1009 lbs (Empty Recovery Tank) 1529 lbs (Full Recovery Tank)
Engine - 23HP Briggs
and Stratton air-cooled
Oil Type: 5W-30 Synthetic
Capacity Approx. 1 1/2 quarts, or 48
oz. (when changing oil and
lter)
Engine RPM 3,150 RPM (no load)
Fuel Consumption 1.1 G PH
Ignition Electric Key Start 12 Volt
Vacuum Blower -
Tuthill 4005 Competitor
Plus SL (Dual Splash
Lubrication)
Max Vac 14” Hg
Oil Type PneuLube or other ISO 100
rating
Gear End Capacity Approx. 5.8 oz.
Drive End Capacity Approx. 4.7 oz.
Water Pump Oil Type 30w Non-Detergent
Electric Clutch Capacity Approx. 8 oz.
Pump Flow Rate 3.5 GPM
Pump RPM 1750
Operating Pressure 1,000 psi
Chemical System Stainless Steel Last-Step
Chemical Injection, Meter
Controlled
Heating System Finned Tube Heat Exchanger

General Information: 1-14
Standard Equipment Full Frame Enclosure Rain Guard, Full Steel Cage,
Primer/Powder coated, vacuum
hose hangers, tie down points
Recovery Tank 70 Gallon Maxx-Air Universal
Recovery Tank
Cleaning Wand Evo 1-1/2 Wand
Chemical Jug 2.5 Gallon
Recovery Tank Pump Out Automatic Waste tank Dump
System (AWDS)
Remote Hose Connection
Panel
Vacuum, AWDS, and recovery
tank drain
Garden Hose Reel (Non-Live) Includes 50’ Garden hose w/
Reel Capacity up to 100’
Solution Hose Reel (Non-Live) Includes 100’ Solution hose w/
Reel Capacity up to 250’
Fuel Tank 7 Gallon Painted Steel EPA/
CARB/SORE Approved
12vdc Battery YTX
Van Decal
Owners Manual (CD)
Operation Instruction Book
Spare Parts - Engine HM Part Number
Oil Filter 000-049-014
Fuel Filter 000-049-258
Foam Pre-Air Filter 000-049-053
Air Filter 000-049-012
Exhaust Gasket 000-057-082
Spark Plugs 000-106-016

1-15: General Information
HIGH ALTITUDE OPERATION
Elevation plays a key role in how the truckmount will operate. Operation at high altitude
(above 5,000 ft. [1,524 m]) may require a high-altitude carburetor jet. Use of this jet at high
altitude will improve power, reduce fuel consumption and help reduce excessive carbon
build-up in the exhaust and heat exchanger systems.
Contact the local Briggs and Stratton dealer or HydraMaster to obtain the proper jet size.
Find your local Briggs and Stratton dealer at:
http://www.vanguardengines.com/where-to-buy/dealer-locator/
LOCAL WATER PRECAUTIONS
The quality of water varies greatly. Many areas have an excess of minerals in the water
which results in what is commonly called “hard water.” These minerals tend to adhere to
the insides of heater coils and other parts of the machines causing damage and a loss of
cleaning e󰀨ectiveness. This inuences the reliability and e󰀩ciency of equipment in direct
proportion to the level of hardness.
Hard Water Advisory
HydraMaster recognizes that any hard water deposits which might occur within the water
system of our truckmounts is a serious problem. The precision technology of truckmount
heat exchanger systems is intolerant of any foreign material. Hard water deposits will
ultimately decrease the performance of the system and are expected to seriously lower
the reliability of the machine.
To validate a machine’s warranty, HydraMaster requires that all machines operating in
designated “Hard Water Areas” (3.0 grains or more per gallon [3.79 liters]) be tted with
a water softening system, or a properly installed magnetic-type descaler must be used
and maintained. Periodic descaling or acid-rinsing alone is not adequate in these areas.
HydraMaster does not recommend any particular type or brand; however, the relative
e󰀨ectiveness of some types of magnetic descalers or softeners may require additional
periodic use of descaling agents.
HydraMaster also recommends, in the strongest possible terms, that machines in all areas
be tted with a water softening system for improved operation and reliability.
Failure to take appropriate measures to prevent scale build up can result in system
failure and loss of warranty on a󰀨ected parts.
