Hydro Tek H-4000C-LR Manual

ISO 9001 Cered
OPERATION & MAINTENANCE MANUAL
4000C Series Faucet
5055 Forsyth Commerce Rd, Ste 124, Orlando, FL 32807
Phone [phone] | Fax [phone]
www.hydrotekintl.com

ISO 9001 Cered
4000C Series
U.S. Patent 6192530B1, 4741363
AC or Baery Powered Sensor Operated Faucet
The 4000C Series faucet is a single-hole deck mounted,
piston operated sensory faucet that provides a vandal
resistant, no touch lavatory soluon with hot/cold mixing
and manual on/o that promotes beer hygiene and
energy savings.
• ADA Compliant. Meets all barrier free codes
• Conserves water and energy
• Easily installed in new or retrot applicaons
• Compevely priced for today’s commercial market
• Promotes cleanliness & hygiene
• Proven Hydrotek crasmanship and reliability
Available in:
AC Powered Models
DLow Lead, AC Powered (H-4000C-LR)
DLow Lead, AC Powered Scrub Sink (H-4000C-SD-LR)
DLow Lead, AC Powered with DC Backup (H-4000C-LRDC)
DLow Lead, AC Powered with DC Backup Scrub Sink (H-4000C-LRDC)
Baery Powered Models
DLow Lead, Baery Powered (HB-4000C-LR)
DLow Lead, Baery Powered Scrub Sink Version (HB-4000C-SD-LR)
• ACCU-SENSE adjustable sensor eyes.
• Chrome plated, solid brass construcon.
• Wall mountable, waterproof control box with
armored, vandal resistant control and power
cables.
• Preset/adjustable sensor range of 6” - 30” for
various installaon requirements.
• Standard automac me-out feature. Preset
at 30 seconds, but adjustable to 10, 30, or 60
seconds. Prevents accidental sink overow.
• Shut-o delay is adjustable from 1 (preset) to 8
seconds.
• Solid brass body with single hole deck mounng.
Oponal 4” or 8” cover plate for 3 point
anchoring.
• Includes in-line lter with clean-out trap to
reduce maintenance costs.
• All parts are eld-replaceable to ensure quick
and easy repair.
• Same faucet-eld switchable to AC or baery
powered.
• AC with DC backup models automacally switch
to baeries during a power outage.
• Manual override provides connuous water ow
for special applicaons or in case of failure.
• Manual controlled temperature adjustment.
• Slow closing, piston-operated solenoid valve
provides reliable and smooth operaon without
water hammer.
• Superior VSI silicone elastomer piston seals
are unaected by chlorine, chloromines, or
ammonia.
• Standard 2.0 GPM Laminar ow control.
• Control module allows a unique self-check of all
electrical components.
Features:

Hydrotek Automac Faucets
4000C Series
Deck Mounted / Mixing / Manual On & O with Temperature Adjust
Meets ANSI/ASME A112.18.1 M-1989
Operaon:
1. A connuous, invisible beam is emied from the sensor.
2. The faucet is acvated by placing hands under the spout within the eecve
range of the beam. Water starts to ow immediately for as long as the user’s
hands remain in the sensor range.
3. When hands are removed, the water ow stops. The sensor will automacally
reset and be ready for the next user.
4. In the baery powered version, a ashing red light will indicate a low baery
condion.
5. Use the faucet handle for temperature adjustment and manual on/o.
Specicaons:
Faucet Construcon: - Solid brass, chrome plated
Control Circuit: - Solid state, AC or baery, switchable
Auto. Time-out: - Preset at 20 seconds and adjustable
to 10, 30, or 60 seconds
Line Purge (request only): - 2 minute run every 12 hours or 24 hours
Scrub Mode Delay (request only): - 60, 120, 180 seconds
Sensor Range: - Preset and adjustable
Shut-o Delay: - Presets and adjustable from 1-8 seconds
Control Cable: - Armored, vandal resistant
Solenoid Valve: - 6V DC, normally closed
- Waage: 0.4W (idle), 5W (in use)
- Operang Pressure: 5 psi to 125 psi
Flow Control: - 2.0 GPM, Laminar Flow Control
- 2.5 GPM Rose Spray for scrub sink
ACMode
Power Adapter
Standard Plug-in: - Input AC 120V 60 Hz or 220V
(UL/CSA) - Output DC 12V, 0.8A/Class 2
Power Cable: - Armored, vandal resistant
Oponal Mul-Unit Adapter: - Serves up to 8 faucets
(UL/CSA) - Input AC 120V, Output DC 12V, 3A
BaeryMode
Baery Powered Models: - (4) AA Alkaline Baeries
Baery Service Life: - 400,000 on/o cycles, up to 4 years
Package Includes:
(1) Faucet with electronic sensor
(1) Control box
(1) 12V DC plug-in power adaptor (H-4000C, -DC, -LR and -LRDC only)
(1) In-line lter with clean-out trap
(1) Flex, S.S. supply tube, 3/8”
(1) 6” Gooseneck Spout
(1) Mounng hardware
(1) 2.0 GPM Flow Control
(4) AA Alkaline baeries (HB-4000C, -DC, -LR, -LRDC only)
(1) Baery holder (HB-4000C, -DC, -LR, -LRDC only)
Dimensions:
Base Width (Outside Measurement) 2-1/2”
Base Depth 2”
Faucet Height (Aerator to Base) 5-1/4”
Faucet Height Overall 6-3/8”
Depth (Center of Aerator to Center of Faucet Base) 5-1/8”
Mounng Bolt Length 2-1/2”
Mounng Bolt Paern Single-hole mount
Oponal Variaons and Accessories
• 1.5 GPM So-Flow Aerator; 0.35, 0.5, 2.2 GPM Laminar Flow
• 4” or 8” Centerset Cover Plate
• HC-010 Mul-Unit Voltage Adapter (AC Powered Only) - 8 units
• HC-0104 Mul-Unit Voltage Adapter (AC Powered Only) - 4 units
• HBL-04 Thermostac Mixing Valve with Checks
• Wrist Blade Handle
H-4000C (AC Powered)
HB-4000C (Baery Powered)
HYDROTEK INTERNATIONAL, INC.
5055 Forsyth Commerce Rd., Ste 124
Orlando, FL 32807
800.922.9883 (Phone)
866.670.5580 (Fax)
www.hydrotekintl.com

4000C Series
DC Powered Sensor Operated Mixing Faucet
Installaon Instrucons
ISO 9001 Cer  ed
4000C Series
Sensor Operated Faucet
Installa on Instruc ons
HYDROTEK INTERNATIONAL, INC.
5055 Forsyth Commerce Rd., Ste 124
Orlando, FL 32807
800.922.9883 (Phone)
866.670.5580 (Fax)
www.hydrotekintl.com
1. Faucet Body
2. Gooseneck Spout
3. Spout Lock Nut
4. 
5. 
6. 
7. Supply Tube (2)
8. Filter/Check Valve (2)
9. 
10. Control Cable
11. Control Box
12. Control Module
Parts:
1.         
replace stop washers, if required.
2.         
Control Cable (10) 
on the PC board inside of the Control Box (11).
a. AC Powered: Connect the power adapter to the Control
Module (12) inside of the Control Box (11)
Power Adapter into a 120 V AC wall outlet. Place your


b. Ba ery Powered:     
        
connected to the PC board. Place your hand in front of


3. Control Cable (10)

4. Supply Tubes (7)

NO TEFLON TAPE, NO PIPE DOPE
5. [OPTIONAL]

the cover plate.
6.       Supply Tubes (7)
and Control Cable (10)      
Moun ng Washer (5) and
Moun ng Nut (6).
7.      Control Cable (10), drill two
         
         Control
Cable (10)Control
Box (11)

8. Filters/Check Valves (8)
the Nylon Washers (9) 
Supply Tubes (7)

NO TEFLON TAPE, NO PIPE DOPE
9. Mount Gooseneck Spout (2)Lock
Nut (3). Open stop valves and check for leaks. Test the

the faucet. This handle can also be used to set the water
temperature.
10. Connect the electrical cables as described in step 2. Control
and power cables must be seated in the control box properly
to maintain waterproof seal. Reinstall the control box cover.
11.         
         
  

12. 

1
2
4
6
5
7
9
3
8
10
11
12
AC Adapter
(for AC models only)

 

4000C Series
Sensor Operated Mixing Faucet
Troubleshoong Guide




Turn the manual handle clockwise to increase temperature and counter-clockwise to decrease.
Problem Possible Cause To Diagnose Remedy

 Check water supply Turn water on
Power supply failure

• 
• Check power adapter

Replace power adapter
  



• 
• 
Replace electronic PCB
 
 Clean solenoid
 Open clean-out trap and check
 




Replace solenoid coil
 
check 





IMPORTANT: 
For service and inquiry about available repair kits, please call Hydrotek Technical Support at [phone].
Care and Cleaning Instrucons:
• WARNING!will
• 
• If chemical cleaners are used for other parts of the lavatory, ensure that the faucet is protected from


4000C Series
Sensor Operated Mixing Faucet
Solenoid Valve Repair Kit Installaon
Blue Side Mark
Solenoid Cover
Solenoid Coil
HCB-017B Solenoid Valve Repair Kit
Control Disc
Piston Spring
Piston
O-Ring
Control Valve
Control Spring
1. Disconnect power by unplugging the power
adapter (for AC powered models) or unplugging
the battery pack inside the control box.
2. Turn o the water at the angle stop valve or the
main supply.
3. Turn the adjustment handle (right side of the
faucet) into manual override mode to purge the
rest of the water from the faucet.
4. Pry the Blue Side Mark o of the Solenoid Cover.
5. Remove the Solenoid Cover by removing the
phillips head screw holding it in place.
6. Remove the screws holding the Solenoid Coil
and carefully separate the coil from the faucet
body.
7. Gently pry the Control Valve from faucet and
remove the Control Spring and Control Disc. The
Control Disc can be easily removed by opening
the water supply solwly until the Control Disc is
pushed out of the faucet.
8. Inspect the Valve Seat for debris and clean if
necessary with ne grain steel wool.
9. Replace the Piston and Piston Spring within the
Solenoid Coil.
10. Replace the O-Ring, Control Spring, and Control
Disc and reassemble according to the diagram
above.
11. Install the Solenoid Coil, Solenoid Cover and Blue
Side Mark according to the diagram above.
12. Turn on the water supply and check for leaks.
Test the manual override function by turning the
adjustment handle to manual override mode.
13. Reconnect the power and push the reset button
on the Control Module (circuit board). Make sure
the adjustment handle is in AUTO mode and test
the sensor function of the faucet.
*Solenoid Valve maintenance recommended every 4
years.
Visit our website for a video of this procedure!
www.hydrotekintl.com

4000C Series
Sensor Operated Mixing Faucet
Control Module Sengs
IMPORTANT: Always push the Reset Buon aer any adjustments
1 2 3 4 5 6 7 8
Factory Preset
= Switch Position
Shut O Time Delay (Aer hands are removed)
Sw1 Sw2 Sw3 Delay
On On On 1 Sec
On On O 2 Sec
On O On 3 Sec
On O O 4 Sec
O On On 5 Sec
O On O 6 Sec
O O On 7 Sec
O O O 8 Sec
Automac Time O (maximum run me aer acvaon)
Sw4 Sw5 Time O
On On OFF
On O 15 Sec
O On 30 Sec
O O 60 Sec
Sensor Distance
Sw6 Mode Distance
On Std 4” - 12”
O Enhanced 10” - 12”
To increase distance, turn adjuster CLOCKWISE
To decrease distance, turn adjuster COUNTER-CLOCKWISE
Faucet Switch - DO NOT TOUCH
Sw7 Sw8 Mode
On O Auto Faucet

4000C Series
Sensor Operated Mixing Faucet
Assembly Parts
No Descripon Part Number
1 Solenoid Valve Repair Kit 
2Temperature Adjuster Rod
Assembly 
3 
4 Supply Tube (2 needed) 
5 2.0 GPM Laminar Flow Control 
6 Solenoid Coil 
7 Filter Screen (2 needed) 
8 PCB Module 
Please visit our website, www.hydrotekintl.com, for
our most current Products Pricing Sheet.
1
5
4
2
3
6
7
8
