Hydro Tek HB8RFKC Series Manual

Sensor Faucets and Flush Valves
OPERATION & MAINTENANCE MANUAL
HB-8000SLE Series Flush Valve
(includes HB8RSLE)
5055 Forsyth Commerce Rd, Ste 124, Orlando, FL 32807
Phone [phone] | Fax [phone]
www.hydrotekintl.com

8000 Series
U.S. Patent 6192530B1, 5699994
AC, Baery, or Solar Powered Sensor Operated Flush Valves
Sensor Faucets and Flush Valves
The Hydrotek 8000 Series Automac Flush Valves are the most advanced,
electronic ushing system in the industry today. By incorporang our eld-
tested electronic circuitry and slow-closing solenoid valves, Hydrotek has
developed an innovave non-diaphragm, piston ushing mechanism that
will provide years of dependable and trouble-free service. The Hydrotek
AUTOFLUSH system is completely automac: there is no need to contact
any surface, no handle to push, and it ushes only when it is used. It
provides the ulmate sanitary protecon, the convenience of cleaner
restroom facilies, and the most ecient system in water conservaon.
• ADA Compliant. Meets all
barrier free codes
• Conserves water and energy
• Easily installed in new or retrot
applicaons
• Compevely priced for today’s
commercial market
• Promotes cleanliness & hygiene
• Proven Hydrotek crasmanship
and reliability
• ACCU-SENSE adjustable sensor eyes
• Standard manual mechanical override buon for
both urinals & water closets
• Standard brass/chrome-plated, all metal
construcon with other nishes available
• AC/DC powered - eld switchable
• Preset/adjustable ow rate and sensor distance
• Self-diagnosc electronics
• Standard vandal resistant stop valve (complete
units only)
• Superior piston ushing mechanism
• Field adjustable for le and right rough-in
• Baery replacement without water shut-o
• Operang pressures: 10-125 PSI
• Standard self-cleaning ltering system
• Switchable from/to urinal or closet
• 36 hour sennel ush
• Superior VSI silicone elastomer seals, unaected
by chlorine, chloromines or ammonia
• AC with DC backup models automacally switch to
baeries during a power outage
• Uses inexpensive AA baeries
• Baery service life: 400,000 on/o cycles (650,000
for the HB-8000SLE Series)
• Low baery indicator light (baery powered only)
• No outside power source required (baery
powered only)
• Can be installed by one tradesperson (baery
powered only)
Features:
H-8000C Series (AC)
Complete Units
HB-8000C Series (Baery)
Complete Units
HB8RFKC Series (Baery)
Complete Units
HB-8000SLE Series (Solar)
Complete Units

Hydrotek Autoush Valves
8000 Series
Meets A.S.S.E. Standard 1037-89
H-8000C (AC Powered) HB-8000C (Baery Powered)
HYDROTEK INTERNATIONAL, INC.
5055 Forsyth Commerce Rd., Ste 124
Orlando, FL 32807
800.922.9883 (Phone)
866.670.5580 (Fax)
www.hydrotekintl.com
The 8000 Series Flush Valves are available in:
H-8000C Series (AC Powered):
9H-8000C-A (Closet)
9H-8000C-B1 (Urinal)
9H-8000C-B2 (Urinal)
*Water conservaon, concealed and AC with DC
backup models available*
HB-8000C Series (Baery Powered):
9HB-8000C-A (Closet)
9HB-8000C-B1 (Urinal)
9HB-8000C-B2 (Urinal)
*Water conservaon and concealed models available*
HB-8000SLE Series (Solar Powered):
9HB-8000SLE-A (Closet)
9HB-8000SLE-B1 (Urinal)
9HB-8000SLE-B2 (Urinal)
*Water conservaon and retrot models available*
HB8RFKC Series Retrot Models (Baery Powered):
Sloan & Zurn Retrot
9HB8RFKC-C (Closet)
9HB8RFKC-U (Urinal)
Delany Retrot
9HB8RFKC-CD (Closet)
9HB8RFKC-UD (Urinal)
*Water conservaon models available*
PLUMBING SPECIFICATIONS:
Model Fixture Supply Line Top Spud Flow Rate
H/HB-8000C-A Closet 1” 1-1/2” 1.6 GPF
H/HB-8-128 Closet 1” 1-1/2” 1.28 GPF
H/HB-8000C-B1 Urinal 3/4” 3/4” 1.0 GPF
H/HB-8000C-B2 Urinal 1” 1-1/4” 1.0 GPF
HB8RFKC-C/U Cl. & Ur. N/A N/A 0.5-3.5 GPF
ELECTRICAL REQUIREMENTS:
• AC Powered Units:
– Solenoid valve and sensor: 6V DC
– Transformer: Input 120V AC, 60 Hz
Output 12V DC
• Baery Powered Units
– Solenoid valve and sensor: 6V DC
– Baery: (4) AA Alkaline Baeries
– Baery Service Life:
◦ 400,000 ushes, up to 6 years (Baery)
◦ 650,000 ushes, up to 10 years (Solar)
BASIC PACKAGE INCLUDES:
H-8000C
(-A, -B1, -B2)
HB-8000C
(-A, -B1, -B 2)
HB8RFKC
(-C, -U)
HB-8000SLE
(-A, -B1, -B2)
(1) Flush Valve 9 9 9 9
(1) Stop Valve 9 9 9
(1) Sweat Kit 9 9 9
(1) Flush Tube 9 9 9
(1) Spud Coupling 9 9 9
(1) Vacuum Breaker 9 9 9
(1) AC Adapter 9
(1) AC Input Tube 9
(4) AA Baers 9 9 9
OPTIONAL ACCESSORIES:
• HC-010 Mul-Unit Power Adapter (AC only) - 8 units
• HC-0104 Mul-Unit Power Adapter (AC only) - 4 units

HB-8000SLE
Solar Powered Flush Valve with Baery Backup
Installaon Instrucons
ISO 9001 Cer fi ed
HB-8000SLE
Solar Powered Flush Valve with Ba ery Backup
Installa on Instruc ons
Installa on Instruc ons:
1. Prior to installa on, “DRY TEST” the unit for proper opera ons.
Loosen the Set Screws (1) using the allen wrench provided and
remove the Top Cap (2) from the valve body by pulling it straight
up.
2. Properly insert 4 AA ba eries into the Ba ery Holders (3). Push
the RESET bu on and watch the indicator lights on the Control
Module (4) for the following pa ern: Red, (click), Green, Red,
Red. This indicates that the electronics are func oning properly.
If the indicator lights do not blink, contact the factory or your
local Hydrotek representa ve.
3. Connect the Solar Input connector in the Top Cap (2) to the
proper receptacle on the Control Module (4).
4. Reinstall the Top Cap (2) onto the valve body and  ghten the Set
Screws (1). Install the Stop Valve (5) to the supply line using a
Hydrotek Sweat Kit (op onal).
5. Connect the valve body to the Stop Valve (5) using the Slip Joint
Nut (6).
6. A ach the Vacuum Breaker (7) and Tailpiece (9) to the valve
body using the Lock Nut (8). Secure the Tailpiece (9) to the
plumbing fi xture using the provided Spud Coupling (10).
7. Turn the water on through the Stop Valve (5) and check for
leaks. Push and hold the Override Bu on (11) for 30 seconds
and check the fi xture for over ow. Adjust the water  ow from
the Stop Valve (5) for a smoother  ush.
8. TEST: Stand in front of the  ush valve for 4 seconds, then step
away. The valve should  ush automa cally. If not, refer to the
Troubleshoo ng Guide.
9. Flow rates are preadjusted from the factory. If minor adjustments
are needed, contact Hydrotek for further details.
Parts:
1. Set Screws 7. Vacuum Breaker
2. Top Cap 8. Lock Nut
3. Ba ery Holder (2) 9. Tailpiece
4. Control Module 10. Spud Coupling
5. Angle Stop 11. Override Bu on
6. Slip Joint Nut
HYDROTEK INTERNATIONAL, INC.
5055 Forsyth Commerce Rd., Ste 124
Orlando, FL 32807
800.922.9883 (Phone)
866.670.5580 (Fax)
www.hydrotekintl.com
1
2
3
4
5
6
7
9
10
8
11

HB-8000SLE Series
Sensor Operated Flush Valve
Troubleshoong Guide
Normal Operaon: When power is connected, the ush valve will immediately perform diagnosc funcon.
You will hear a clicking sound and see lights ash. When the sensor is acvated, the light will ash once and
the valve will ush. The red indicator light will ash when the baeries are low.
Problem Possible Cause To Diagnose Remedy
Valve will not turn on:
Water not turned on Check water supply Turn water on
Power supply failure
No light, no clicking:
• Check baeries
• Check power adapter
Reinstall or replace baeries/
Replace power adapter
Low baery Light connues to ash Replace baeries
Electronic PCB / Sensor is
defecve
No light, no clicking:
• Reinsert baeries
• Reaach power adapter
Replace electronic PCB
Solenoid valve is clogged Solenoid is clicking but no water
is coming out Clean solenoid
Solenoid coil is defecve
Insert new baeries or reaach
power adapter. Light blinks but
no solenoid is clicking
Replace solenoid coil
Valve will not shut o:
The solenoid valve is normally closed. Turn o water and acvate the valve. If there is a clicking
sound, the solenoid valve is dirty. If there is no clicking sound, then check the solenoid valve. If
water is leaking through, the solenoid valve is dirty and needs to be serviced.
Other factors include:
• Sensor distance is too long
• Control module is defecve
• Manual override buon is scking
IMPORTANT: Periodic maintenance is required for smooth and trouble-free operaon of this ush valve.
For service and inquiry about available repair kits, please call Hydrotek Technical Support at [phone].

HB-8000SLE Series
Sensor Operated Flush Valve
Assembly Parts
No Descripon Part Number
1Baery Holders (2 required) HCC-104A
2Control Module HCC-080SLE
3 Solenoid Coil HCC-098
4Sensor Eye and Cable HCC-080E
5Sweat Kit Assembly HC-084 (3/4”)
HC-084B (1”)
6Angle Stop - Complete Assembly HC-082A (3/4”)
HC-082B (1”)
7Angle Stop Repair Kit HC-082C
8Control Disc Assembly HCC-102
9Manual Override Buon Assembly HC-089
10 Vacuum Breaker Repair Kit HC-086
11 Flush Tube
HC-086A (1-1/2”)
HC-086B (3/4”)
HC-086C (1-1/4”)
12 Top Spud Assembly
HC-093A (3/4”)
HC-093B (1-1/4”)
HC-093C (1-1/2”)
RSolenoid Valve Repair Kit HCC-106
Please visit our website, www.hydrotekintl.com, for
our most current Products Pricing Sheet.
1
2
4
3
5
6
7
8
9
10
11
12
R

HB-8000SLE Series
Sensor Operated Flush Valve
Control Module
1 2 3
4
56789
LEGEND
1. DC Input Pin Receptor
2. Dip Switches
3. Reset Buon
4. Indicator Lights
5. Solenoid Pin Receptor
6. Control Cable (Sensor Eye) Pin Receptor
7. Sensor Distance Adjustment Dial
8. Solar Input Pin Receptor
9. DC Input Pin Receptor

HB-8000SLE Series
Sensor Operated Flush Valve
Control Module Sengs
Flow rate and sensor arming me can be adjusted via the dip switches located on the Control Module.
Gallons
Per
Flush Sw 1 Sw 2 Sw 3 Sw 4
Urinal
0.125* ON ON OFF ON
0.5 ON ON ON ON
1.0 ON ON ON OFF
Closet 1.28 ON ON OFF OFF
1.6 ON OFF ON ON
Flushing Volume
Flush Valves are preset to 1.0 GPF for urinal and 1.6 GPF for closet
Sw 5 Sw 6 Sw 7 Sw 8 Arming Time
Urinal Standard OFF OFF OFF ON 3 seconds
Oponal ON OFF OFF ON 1.5 seconds
Sensor Arming Time
Sensing Time Required to Flush
Sw 5 Sw 6 Sw 7 Sw 8 Arming Time
Closet Standard ON OFF OFF OFF 4 seconds
Oponal OFF OFF OFF OFF 8 seconds
NOTE: PUSH THE RESET BUTTON ON THE CONTROL MODULE AFTER
ANY ADJUSTMENTS TO THE DIP SWITCHES.
Sensor Distance Adjustment
Clockwise Increase sensing distance
Counter-Clockwise Decrease sensing distance
*0.125 ow rate seng only available if ordered that way from the factory
For alternate ow rates not listed, please contact Hydrotek direct
