OWNER’S GUIDE
HYDROTECH®
ADVANCED REVERSE OSMOSIS
WATER TREATMENT SYSTEMS
101 SERIES
THIN FILM COMPOSITE MEMBRANE
102 SERIES
THIN FILM COMPOSITE MEMBRANE
103 SERIES
CELLULOSE TRIACETATE MEMBRANE
Hydrotech, Inc.
25555 West Avenue Stanford, Valencia, CA 91355
Phone [phone] Fax [phone]

INTRODUCTION
SYSTEM CONFIGURATIONS
SYSTEM UNITARY MANIFOLD AND FILTER CARTRIDGES
Model Vessels Sediment Filter Pre-Filter Membrane Post-Filter Output†
101 Series 4 String Wound Polypropylene CTO Carbon Thin Film Composite CTO Carbon 9, 15, 25, 35, 45
102 Series◊3 String Wound Polypropylene None Thin Film Composite CTO Carbon 9, 15, 25, 35, 45
103 Series 3 String Wound Polypropylene None Cellulose Triacetate CTO Carbon 9, 15
† Manufacturer’s Reference Designation Only. Refer to Production and Recovery Rates table for certified output production rates.
◊Production and Contaminant Reduction Performance Certification by NSF International is not applicable. This system is not available in California.
MODEL NUMBERS TABLE A
GUIDE IS APPLICABLE TO HYDROTECH®REVERSE OSMOSIS DRINKING WATER TREATMENT SYSTEMS AS SPECIFIED IN THIS TABLE
Select Claims, System, Output, Monitor, and Faucet. Assemble Respective Codes in Sequence.
Claims Chemical / Mechanical Chemical / Mechanical / Nitrate**
System Code 101/102◊/103Series 101/102◊/103Series 101 Series 101 Series
Output Designation 9 15 25‡ 35‡45‡9 15 25‡35‡45‡9 15 25 35 45 9 15 25 35 45
Output Code 03 04 05‡06‡07‡03 04 05‡06‡07‡03 04 05 06 07 03 04 05 06 07
Monitor Pushbutton Smartap®Faucet Smartap®Pushbutton Smartap®Faucet Smartap®
Faucet Chrome S/S or Polymer Chrome S/S or Polymer Chrome S/S or Polymer Chrome S/S or Polymer
Faucet Code 001 101* 002 102* 003 103** 004 104**
Example: 4 vessel, Chemical/Mechanical Reduction, 25 GPD, Faucet Smartap®, Polymer Faucet, NSF Listed is Model Number 10105102 ‡ 101 SERIES
ONLY
PRODUCTION AND RECOVERY RATES – 101 AND 103 SERIES
* System Tested and Certified by NSF International against ANSI/NSF 58 as detailed on Performance Data Sheet
Model 10103 10104 10105 10106 10107 10303 10304
System
Output
19 Liters/day
(5 gal/day)
28 Liters/day
(7.3 gal/day)
29 Liters/day
(7.5 gal/day)
34 Liters/day
(9 gal/day)
45 Liters/day
(12 gal/day)
15.1 Liters/day
(4 gal/day)
29.5 Liters/day
(7.6 gal/day)
Recovery Rating*** 34% 25% 21% 24% 24% 26% 34%
*** System has been tested and operates at the specified recovery rating under standard test conditions as specified in the Performance Data Sheet.
The recovery rating is a percentage measure of the amount of influent water which is delivered as permeate under open permeate discharge conditions.
CONDITIONS FOR USE THIN FILM COMPOSITE MEMBRANE
Source Water Supply Profile Chemical Parameters Max mg/L
Community/Private Chlorinated/Non-Chlorinated Hardness (CaCO3) <350
Feed Water Pressure2 242-690 kPa (35-100 psig) Iron (Fe ) <0.1
Temperature 4°-38° C (40°-100° F) Manganese (Mn) <0.05
pH Range 3.0 - 11.0 Hydrogen Sulfide (H2S ) 0.00
Maximum TDS Level 2000 mg/L Residual Chlorine (Cl2) <2.0
Turbidity <1.0 NTU
Maximum SDI1 <4.0
1. Silt Density Index: Value stated in SDI units.
NOTE: 2. PRESSURE REGULATOR IS RECOMMENDED FOR FEED WATER PRESSURES EXCEEDING 552 kPa (80 psig).
I

INTRODUCTION
CERTIFIED CONTAMINANT REDUCTION PERFORMANCE – 101 AND 103 SERIES
System Tested and Certified by NSF International against ANSI/NSF 58 for the reduction of
ARSENIC* ASBESTOS BARIUM CADMIUM COPPER
TRIV ALENT CHROMIUM HEXAVALENT CHROMIUM CYSTS** FLUORIDE
LEAD NITRATES†RADIUM 226/228 SELENIUM TURBIDITY
NSFR
CHLORINE - TASTE AND ODOR#TOTAL DISSOLVED SOLIDS (TDS)
NOTE: Contaminant Reduction Performance is not applicable to 102 Series (Systems are not available in California).
* Applicable to 101 Series only. This system shall be used for arsenic reduction on chlorinated water supplies containing detectable residual free chlorine
at the system inlet. Water systems using an in-line chlorinator should provide a one minute chlorine contact time before th RO system.
** Certified for reduction of Cysts including Cryptosporidium parvum oocysts and cysts of Giardia and Entamoeba
† 101 Series Only: This system is acceptable for treatment of influent concentrations of no more than 27 mg/L nitrate (NO3) and 3-mg/L nitrite (NO2) in
combination measured as 7.8 mg/L nitrogen (N) and is certified for nitrate/nitrite reduction in water supplies with a pressure of 280 kPa (40 psig) or
greater. This system is not available in California.
# System Tested and Certified by NSF International against ANSI/NSF 42 to a product water capacity of 3000 gallons.
OPTIONS AND ACCESSORIES
METAL OR POLYMER FAUCETS PRESSURIZED PRODUCT WATER STORAGE TANKS
The product water faucets are available in Chrome-Plated Brass
(EPA and Proposition 65 Compliant), Polished Stainless Steel, or a molded
Polymer (five colors). Units are available with or without Light Bar.
NSF Listed Systems require either a Stainless Steel or Polymer faucet
as shown on Pages 10 and 11 of this Guide
Product Water Storage Tanks are available in Steel, Polypropylene, or Fiber-
Reinforced Resin with nominal capacities of 7.8L /2 gal to 38.9L /10.3 gal.
Tank Assemblies include shut-off valve and quick connect fittings.
NSF Listed Systems require Approved Storage Tank Assemblies
as shown on Page 14 of this Guide.
FAUCET ACTUATED SMARTAP®MONITOR BOOSTER PUMP
Indicator lights appearing in a Light Bar report system status.
Light Bar is located at faucet base (Chrome or Stainless Steel) or integrated
into faucet body front cover (Polymer). It connects to electronics inside RO
Module by a length of phone cord routed to terminal on manifold cover.
A booster pump may be used if system pressure is below 242 kPa (35 psi).
Pump should be placed near RO Module
and installed in feed water line just before it enters Module.
Power supplies are available in a variety of voltages.
Contact your Hydrotech® Dealer to purchase these items or to obtain more information.
CONDITIONS FOR USE CELLULOSE TRIACETATE MEMBRANE
Source Water Supply Profile Chemical Parameters Max mg/L
Community/Private Chlorinated Hardness ( CaCO3) <350
Feed Water Pressure2 242-690 kPa (35-100 psig) Iron ( Fe ) <0.1
Temperature 4°-38° C (40°-100° F) Manganese ( Mn ) <0.05
pH Range 4.0 - 8.0 Hydrogen Sulfide ( H2S ) 0.00
Maximum TDS Level 1500 mg/L Residual Chlorine ( Cl2) 0.01-1.0
Turbidity <1.0 NTU
Maximum SDI1 <4.0
1. Silt Density Index: Value stated in SDI units.
NOTE: 2. PRESSURE REGULATOR IS RECOMMENDED FOR FEED WATER PRESSURES EXCEEDING 552 kPa (80 psig).
II

INTRODUCTION
ITEM #1 - PUSHBUTTON SMARTAP®MONITOR WITH LOCATORS
ITEM #1A - FAUCET ACTUATED SMARTAP®MONITOR
STANDARD STORAGE TANK ASSEMBLY
REVERSE OSMOSIS SYSTEM PRODUCT WATER STORAGE
Item Description Part No. Item Description Part No.
1
1A
2
Pushbutton Smartap®Water Quality Monitor
Faucet Actuated Smartap®Water Quality Monitor
Product Water Faucet, Chrome or Stainless
Steel
Product Water Faucet, Polymer (Decorator
Color)
Pg. I, Table A
Pg. I, Table A
Pg. 9, Fig. 9
Pg. 11, Fig. 11
3
4
5
Product Water Storage Tank Assembly
Tank, Product Water Storage
Valve, Shut-Off
Elbow, Stem
Pg. 14, Fig. 14
INSTALLATION KIT POLYMER FAUCET INSTALLATION KIT METAL FAUCET
Item Description Part No.
Item Description Part No.
6
7
8
9
10
11
12
n/s**
Complete Kit
Supply Valve Assembly, Saddle Tapping
Drain Clamp Assembly, Saddle Clamp
Tubing, 1/4" x 54" White
Tubing, 3/8" x 60" White
Tubing, 3/8" x 60" Blue
Tubing, 3/8" x 60" Red (attached to faucet)
Tubing, 1/4" x 48" Red (attached to faucet)
Screw, Mounting Bracket (2 each)
42902026
34900001
42000001
20300014
20300012
20300013
20300018
20300015
32701002
6
7
8
9
10
11
12
n/s**
Complete Kit
Supply Valve Assembly, Saddle Tapping
Drain Clamp Assembly, Saddle Clamp
Tubing, 3/8" x 60" White
Tubing, 1/4" x 54" White
Tubing, 3/8" x 60" Blue
Tubing, 3/8" x 60" Red
Tubing, 1/4" x 48" Red
Screw, Mounting Bracket (2 each)
42902004
34900001
42000001
20300012
20300014
20300013
20300018
20300015
32701002
n/s** Owner’s Guide, 101, 102, and 103 Series 36101005 n/s** Performance Data Sheet (101 Series NSF
Listed) 36101105
** not shown n/s** Performance Data Sheet (103 Series NSF
Listed) 36101183
Figure 1 Component and Interconnection Locators, 101, 102, and 103 Series
III

INSTALLATION REQUIREMENTS
READ THIS ENTIRE INSTALLATION AND SERVICE GUIDE BEFORE BEGINNING INSTALLATION
Hydrotech®101 and 103 Series Reverse Osmosis (RO) Drinking Water Treatment Systems have been designed for ease
of installation and serviceability. They are constructed with the finest materials available.
Using these instructions and paying close attention to parameters outlined within
"CONDITIONS FOR USE" detailed on Page I will ensure a successful installation.
All systems must be installed in accordance with applicable city, state, and local plumbing codes. To insure a system
continues to operate at its optimum level, it is necessary to have a routine maintenance and replacement schedule (Page
16). The frequency at which filters must be changed will depend on quality of feed water supply and level of system usage.
Hydrotech®RO systems contain a replaceable treatment component critical to effective reduction of
Total Dissolved Solids (TDS). Product water shall be tested periodically to verify the system is performing properly.
Operator performs test using the Smartap®Water Quality Monitor.
PREPARATION
1. Check that all appropriate components are packed
with your system (Figure 1). Refer to applicable
Component Parts Breakdown (Figures 9, 11, 12, 13,
or 14) for a complete list of parts.
2. Determine locations for RO component installation.
Two requirements for consideration are: access to
cold water supply line and household sink drain pipe.
Specific requirements are detailed in Table 1.
PRODUCT WATER FAUCET
Faucet may be installed in any convenient location.
Make sure underside of location is free of obstructions
REVERSE OSMOSIS MODULE*
Module may be installed under sink or in any convenient
location within 15 feet of source water supply and faucet.
STORAGE TANK
Tank may be placed in any space within 15 feet of faucet, generally under kitchen sink or in an adjacent unused cabinet.
Tubing length between components should be kept to a minimum, avoiding sharp bends or kinks.
* DO NOT PLACE MODULE WHERE IT WILL BE EXPOSED TO FREEZING AND/OR DIRECT SUNLIGHT.
Mount Module on side of cabinet using bracket (attached to Module) and two screws provided in the Installation Kit.
HOLD THE MODULE BY THE FILTER HOUSINGS WHEN PICKING UP OR CARRYING UNIT.
Table 1 Component Location Requirements
NOTE
THIS DRINKING WATER SYSTEM IS FOR USE ON POTABLE WATER SUPPLIES ONLY.
SOURCE WATER EXCEEDING CHEMICAL PARAMETERS REQUIRES PRE-TREATMENT.
COMMONWEALTH OF MASSACHUSETTS PLUMBING CODES 248 CMR SHALL BE ADHERED TO.
CONSULT WITH YOUR LICENSED PLUMBER FOR INSTALLATION OF THIS SYSTEM.
CAUTION
DO NOT USE WITH WATER THAT IS MICROBIOLOGICALLY UNSAFE OR OF UNKNOWN QUALITY
WITHOUT ADEQUATE DISINFECTION BEFORE OR AFTER THE SYSTEM.
SYSTEMS CLAIMING CYST REDUCTION
SYSTEM MAY BE USED ON DISINFECTED WATER THAT MAY CONTAIN FILTERABLE CYSTS.
IF SIGNIFICANT INLET WATER PRESSURE DIFFERENTIALS OCCUR, PRESSURE REGULATOR MUST BE USED.
- 1 -

SMARTAP®WATER QUALITY MONITOR
Hydrotech®101, 102, and 103 Series Reverse Osmosis Systems incorporate a proven performance indicator. Our patented
Smartap®Water Quality Monitor uses dual probe LOGIC PULSE MEMORY technology to accurately indicate membrane
performance. A split-second power pulse compares feed water Total Dissolved Solids (TDS) level with that of the product water.
Then, by reversing the polarity of the electronic pulse, the probes are cleaned and kept free of chemical plating. A nine-volt
alkaline battery provides power to the Monitor. To prolong battery life, indicator lights self-extinguish after a few seconds even if
the button is being pressed or water is being dispensed. For optimum monitor performance, the battery should be replaced each
time system is sanitized.
NOTE: Monitor Troubleshooting Indicators and Common Solutions are shown in Table 2 on Page 19.
THE SMARTAP® WATER QUALITY MONITOR IS AVAILABLE IN TWO MODELS
Pushbutton Actuated Smartap®
Pressing a test button located on the manifold cover activates monitor. When button is pressed, and momentarily held down,
monitor reports membrane status by illuminating a light located next to test button. A green light means system is operating
normally. A yellow light indicates system needs servicing (membrane may be depleted or fouled). While the button may be
pressed at any time, the most accurate readings are obtained when the system is making water.
Faucet Actuated Smartap®
Monitor is activated by opening product water faucet or extra point-of-use device. When monitor is activated, it reports system
status by illuminating a light appearing in a light bar located at faucet base (Chrome or Stainless Steel faucet) or integrated
into faucet body front cover (Polymer faucet). A green light means system is operating normally. A yellow light means
membrane may be depleted or fouled. An orange light means a trained technician should service the system.
INTER-COMPONENT CONNECTIONS
Connections between cold water supply line, RO Module, storage tank, product water faucet, and drain line are accomplished
using plastic tubing and push-together quick-connect type fittings.
PLASTIC TUBING
1. Cut tube ends square and straight. Do not deform
tube (i.e., cause tube to compress its diameter so it
is no longer round).
2. Make sure outer surface of tube is clear of marks or
scratches for a length equal to twice tube diameter.
This allows "O" ring to seat properly against tube.
3. Avoid sharp changes in direction when routing
tubing. Sharp turns cause tubing to flex and deform,
which reduces its flow capacity and may increase
lateral stress on the fittings, causing leakage.
QUICK-CONNECT FITTINGS
Fittings consist of two parts: a Body and a colored Collet.
Collet color corresponds to tubing color to be used at
that connection (Figure 2.A.).
1. To install a tube, push it through Collet until it seats
firmly at bottom of fitting (Figure 2.A and 2.B.).
2. To remove a tube, push and hold Collet against
Body while pulling tube out (Figure 2.C.).
NOTE: Systems are shipped with a plug in each fitting
(prevents leakage of sanitizing fluid). Remove a
plug in same manner as a tube.
A. Push tube through Collet into Body B. Tube must seat firmly at bottom of fitting C. Push Collet against Body to release tube
Figure 2 How to Use Quick-Connect Fittings
- 2 -

SADDLE TAPPING VALVE INSTALLATION ON COPPER TUBE
NOTE: State and local plumbing codes may prohibit use of saddle tapping valves. An Inlet Adapter Valve
Assembly (P/N 42500004) is available as an alternate installation (See Page 5).
1. Locate shut off valves on water lines under sink. To
identify hot supply pipe and cold supply pipe, turn
both faucets on and let water run. As water flows,
hot water pipe becomes noticeably warmer.
CAUTION: DO NOT INSTALL FEED WATER
ASSEMBLY ON HOT WATER LINE.
- 3 -
2. Turn off cold water supply by closing shut off valve.
Drain line by opening sink faucet. Some mixing type
faucets may require hot water supply be shut off as
well.
NOTE: If no shut off valve is installed under sink, close
main water valve during this installation.
All instructions refer to components shown in
Figure 3.A. unless otherwise noted.
CAUTION: Do not turn valve handle before or while
installing saddle tapping valve. Make sure
piercing lance does not protrude beyond
rubber gasket before installing valve.
3. Assemble saddle tapping valve assembly on tube.
a. Hold Back Plate against tube.
• 3/8" O.D. and smaller tubing, use
bracket with side projections.
• 1/2" or larger tubing, use "V" side of
bracket (See Figure 3.B.).
b. Hold Valve Saddle against tubing in a position
directly opposite Back Plate.
c. Install screws far enough so Saddle and Back
Plate are held securely against tube.
d. Rotate assembly so tubing connection is aligned
toward RO Module input port.
e. Tighten screws evenly (brackets must be
parallel). Tighten each screw firmly. Do not crush
tube.
4. Connect source water tubing to valve housing using
compression fitting.
a. Slide nut and sleeve onto tubing (in that order).
b. Install insert into plastic tubing.
c. Install tube with insert and sleeve into valve
housing.
d. Thread compression nut onto housing, tighten.
5. Connect tubing from saddle tapping valve to RO
Module inlet elbow (Item 13 on Page 12, Figure 12 or
Page 13, Figure 13).
6. Turn saddle tapping valve handle clockwise until it is
firmly seated and piercing lance is fully extended.
NOTE: Supply line is pierced and valve is closed.
Do not open valve until system is
activated (Page 15).
7. Turn on cold water supply. Check saddle tapping
valve installation for leaks. Allow water to run from
faucet for a few minutes to clear any debris in the line
caused by installation.
NOTE: If flow from sink faucet is reduced, clean faucet
aerator.
Figure 3A Saddle Tapping Valve Assembly
P/N 34900001 installed on 3/8” O.D. Tubing

SADDLE TAPPING VALVE INSTALLATION ON THICK WALL PIPE
NOTE: State and local plumbing codes may prohibit use of saddle tapping valves. An Inlet Adapter Valve
Assembly (P/N 42500004) is available as an alternate installation (See Page 5).
1. Locate and shut off source water supply line (see
Page 3, Steps 1 and 2 with associated NOTES).
CAUTION: DO NOT INSTALL FEED WATER
ASSEMBLY ON HOT WATER LINE.
CAUTION: Use a battery powered hand drill to avoid
shock hazard.
NOTE: If no shut off valve is installed under sink, close
main water valve during this installation.
- 4 -
All instructions refer to components shown in
Figure 3.B. unless otherwise noted.
Place a container or towel below shut-off valve to
catch any remnant water.
Use a clean drill bit for this procedure.
2. Drill a 3/8” hole in pipe. Hole must be located so that
tubing connection will be oriented toward the RO
Module input port.
3. Assemble saddle tapping valve assembly on tube.
a. Turn valve handle to expose lance beyond rubber
gasket no more than 3/16”.
b. Place Valve Saddle against pipe. Make sure
lance fits into hole.
c. Hold Back Plate against tubing in a position
directly opposite Valve Saddle.
d. Install screws far enough so Saddle and Back
Plate are held securely against tube.
e. Tighten screws evenly (brackets must be
parallel). Tighten each screw firmly. Do not
crush tube.
4. Connect source water tubing to valve housing (see
Page 3, Step 4).
5. Connect tubing from saddle tapping valve to RO
Module inlet elbow (Item 13 on Page 12, Figure 12 or
Page 13, Figure 13).
6. Turn saddle tapping valve handle clockwise until it is
firmly seated and piercing lance is fully extended.
NOTE: Supply line is pierced and valve is closed.
Do not open valve until system is
activated (Page 15).
7. Turn on cold water supply. Check saddle tapping
valve installation for leaks. Allow water to run from
faucet for a few minutes to clear any debris in the line
caused by installation.
NOTE: If flow from sink faucet is reduced, clean faucet
aerator.
Figure 3B Saddle Tapping Valve Assembly
P/N 34900001 installed on
7/16” – ½” O.D Tubing
ADDITIONAL POINT OF USE CONNECTION
NOTE: Icemakers typically use 1/4" tubing as feed line. Use a reducing union (P/N 33501043) for this connection.
1. To connect an additional point of use (icemaker, extra
faucet in wet bar and/or another use for treated water),
place a "tee" connector (P/N 33501040) in 3/8" blue
line between faucet and back of RO Module.
2. Connect "tee" to point-of-use with 3/8" blue tubing
(P/N 60602001). Connect tubing to point-of-use.
Connector requirements are based on type of
delivery device i.e., a typical icemaker uses 3/8" x
1/4" reducing device (P/N 33501043).

INLET ADAPTER VALVE INSTALLATION
NOTE: This assembly is offered as an optional installation method. Make sure it is approved for use under State
and local plumbing codes before ordering kit (P/N 42500004).
NOTE: Use this assembly on U.S.N.P.T.* pipe thread fittings only.
CAUTION:DO NOT INSTALL FEED WATER ASSEMBLY ON HOT WATER LINE.
1. Locate shut off valves on water lines under sink. To
identify hot supply pipe and cold supply pipe, turn
both faucets on and let water run. As water flows,
hot water pipe becomes noticeably warmer.
2. Turn off cold water supply by closing shut off valve.
Drain line by opening sink faucet. Some mixing type
faucets may also require turning off hot water supply.
NOTE: If no shut off valve is installed under sink, close
main water valve during this installation.
Place a container or towel below shut-off valve to
catch any water remaining in pipe.
All item callouts refer to Figure 4 unless noted
otherwise.
3. Disconnect cold water supply line to sink at inlet
valve end of line.
4. Insert rubber washer (Item 1) into inlet adapter (Item
2) and install adapter onto supply valve. Align outlet
hole (in side of adapter) toward location of RO
Module.
- 5 -
5. Replace existing rubber grommet on cold water
supply line with grommet supplied in kit (Item 3).
6. Attach cold water supply line to inlet adapter.
NOTE: Use Teflon tape (P/N 35700002) on male
threaded connections in Steps 4, 6, 7, and 8.
7. Install ball valve (Item 4) into inlet adapter.
8. Install male connector (Item 5) into inlet ball valve.
9. Install ¼” white tubing (Item 6) from male connector
to RO Module inlet elbow (Item 13 on Page 12,
Figure 12 or Page 13, Figure 13).
10. Close inlet valve by turning handle so it is at a right
angle (90º) to valve body.
11. Turn on cold water supply. Check installation for
leaks. Allow water to run from faucet for a few
minutes to clear any debris in the supply line caused
by this installation.
NOTE: If flow from faucet is reduced, clean faucet
aerator.
Item Description Part No.
Inlet Assembly
1 Rubber Washer 33400002
2 Inlet Adapter 1/2" x 1/2" x 1/8" 33201001
3 Rubber Grommet 33400003
4 Inlet Ball Valve 1/8" 34900002
5 Male Connector 1/4" x 1/8" NPT* 33503301
Component of Installation Kit
6 Tubing, 1/4" White 20300014
* United States National Pipe Thread
Figure 4 Inlet Adapter Assembly P/N 42500004 Installation and Parts Breakdown

DRAIN OUTLET ASSEMBLY INSTALLATION
- 6 -
NOTE: State and local plumbing codes may prohibit use of saddle tapping drain connections.
NOTE: Location and orientation of drain outlet assembly is vital to system performance.
Horizontal Drain Line:
Locate drain hole as close as possible to top of pipe
(between 45º and top) and as far as practical from
garbage disposal.
Vertical Drain Line:
Locate drain hole on a straight length of drainpipe next to
"P"/"S" trap between trap and sink.
Figure 5 Drain Hole Location and Installation
1. Select a location for drain hole based on type of sink
and orientation of drain line (Figure 5).
NOTE: Item callouts refer to Figure 6 unless noted
otherwise.
2. Position drain outlet saddle (Item 1) on drainpipe.
Allow adequate space for drilling operation.
3. Tighten saddle bolts evenly on both sides. Avoid over-
tightening.
4. Using opening in drain outlet saddle as a guide, drill a
3/8" to 7/16" diameter hole in drainpipe. Clean any
debris out of drain saddle connection.
5. Install drain saddle stem adaptor (Item 2) fitting into
drain saddle. Use Teflon tape (P/N 35700002) to seal
threads between stem adapter and saddle.
6. Install union elbow (Item 3), onto stem adapter by
pushing either end of elbow firmly onto stem.
Item Description Part No.
1
2
3
Drain Saddle
Stem Adapter
3/8” Union Elbow
42000002
33503101
33503401
Figure 6 Drain Outlet Assembly

PRODUCT WATER FAUCET SITE PREPARATION
Refer to Faucet Installation Instructions (Pages 8 & 10) for site location and mounting hole specifications.
Primary considerations for site selection are convenience of use and an open area under sink.
Always check underside of selected location for obstructions.
PORCELAIN/ENAMEL OVER STEEL
OR CAST IRON SINKS
NOTE: A heavy duty, variable speed drill motor is
recommended for this procedure.
Use of a spring-loaded porcelain drill set is
strongly recommended (Figure 7).
- 7 -
The plastic sleeve supplied on pilot drill (Figure
7.A) is to be positioned on drill bit against drill
chuck. This prevents chuck from contacting
porcelain after pilot hole has been completed.
Suggestion: Practice on discarded sinks to familiarize
yourself with operation of porcelain cutter kit.
CAUTION: Avoid high motor R.P.M. during initial
penetration of porcelain, as high drill speed
will cause excessive chipping.
1. Using carbide tipped bit with plastic sleeve (Figure
7.A.), drill pilot hole completely through porcelain and
metal underneath.
2. Place spring-loaded porcelain saw (Figure 7.B.) into
drill chuck. Make sure pilot guide is inserted tightly.
Insert pilot guide into pilot hole. Push down gently on
drill motor to apply light pressure to porcelain surface.
Start drill motor turning as slowly as possible.
After initial cut has started, motor speed may be
gradually increased. The cut may require three to
four minutes to complete. Going faster could result in
excessive chipping. Be sure a complete ring has
been cut through porcelain to material underneath.
3. Place finish hole saw (Figure 7.C.) into drill chuck.
Make sure pilot guide is inserted tightly. Insert pilot
guide into pilot hole. Begin cut using a slow speed
and light pressure until porcelain (inside ring cut in
Step 2) has been penetrated to material underneath.
4. Remove saw from hole and clean all debris from
porcelain surface. Re-insert saw into hole and cut
through remaining material.
TILE COUNTER TOP
1. Follow procedures detailed in section labeled
"Porcelain/Enamel Over Steel" (substitute "tile" for
"Porcelain" in instructions).
STAINLESS STEEL SINK
1. Use a center punch to make a small indentation to
mark center of desired location.
2. Drill a pilot hole with a 1/8" metal drill bit, then enlarge
hole with a 3/8" metal drill bit.
3. Complete hole size by using a 1 1/4" chassis punch
available from your dealer (P/N 36201006).
NOTE: Installation hole is ready, install faucet.
A. PILOT DRILL
B. SPRING LOADED PORCELAIN SAW
C. FINISH HOLE SAW
Figure 7 Porcelain Cutter Kit P/N 36201003

PRODUCT WATER FAUCET INSTALLATION - STAINLESS STEEL OR CHROME FAUCET
Install faucet on flat surface at least 2" in diameter. Unused 1 1/4" hole is ideal.
Steps unique to a specific configuration are so noted. All other steps are common to either configuration.
New Faucet Installation
Refer to Faucet Site Preparation, Page 7.
Replacement Faucet Installation
Verify size of existing hole is 1 1/2" ± 1/4".
NOTE: Item callouts refer to Page 9, Figure 9 unless
noted otherwise. Part numbers for each callout
are specified according to faucet type:
Chrome-Plated Faucets (brass faucet nipple):
Tables A and B.
Stainless Steel Faucets (copper faucet nipple):
Tables C and D.
1. Pushbutton Smartap®: Verify faucet body, metal
base washer, and rubber base washer are in place
above sink (Items 2, 3, and 4).
Optional Faucet Smartap®:Verify faucet body,
metal base washer, light bar base washer, light bar
assembly, and washboard gasket are in place above
sink (Items 2, 3, 15, 13, and 14).
2. Install 3/8" red tube on larger faucet barb. Install 1/4"
red tube on smaller faucet barb. Install 3/8" blue tube
into faucet connector (Item 9).
- 8 -
3. Pushbutton Smartap®:Insert all three tubes into
mounting hole and place faucet over hole.
Optional Faucet Smartap®:Insert all three tubes
and monitor cord into mounting hole and place faucet
over hole.
NOTE: Do not pinch, kink, or otherwise deform
monitor cord. Align cord with cutout in plastic
spacer.
4. Install slotted washer, spacer, washer, and nut on
faucet nipple below sink and snug them up. Be sure
to align faucet properly before tightening. Do not over
tighten.
5. Connect loose ends of tubing as follows:
a. 3/8" blue tubing to 3/8" swivel elbow located on
rear of module.
b. 1/4" red tubing to 1/4" swivel elbow located on
rear of module.
c. 3/8" red tubing to 3/8" swivel elbow on drain
saddle.
NOTE: Red 3/8" tube connecting product water faucet to
drain saddle must run vertically (or as closely as
possible) with no sharp bends or loops (See Page
6, Figure 5).
6. Connect 3/8" white tubing between RO Module outlet
and storage tank.
7. Optional Faucet Smartap®: Connect monitor cord to
telephone-style connector located on manifold cover
(Figure 8).
NOTE: The basic installation is complete and system is
ready for activation (see Page 15).
Figure 8 Connecting Monitor cord to Manifold.

A + B Chrome Faucet with Light Bar 11701001 C + D Stainless Steel Faucet with Light Bar 11701002
Item Description Part No. Item Description Part No.
A Chrome Faucet 40301001 C Stainless Steel Faucet 40301004
1
2
3
4
5
6
7
8
9
10
11
12
Handle, Faucet
Body, Faucet - Chrome
Washer, Faucet Base - Chrome
Washer, Rubber - Faucet Base
Washer, Slotted
Spacer, Plastic
Washer, Faucet
Nut, Faucet
Connector, Faucet - 3/8" x 7/16"
Kit, Rebuild Faucet - Chrome
Spout, Long Reach - Chrome
Sani tip, Black
35902032
35902003
35902078
35902080
35902105
21000001
35902104
31901108
33503302
35903001
35902055
35902042
1
2
3
4
5
6
7
8
9
10
11
12
Handle, Faucet
Body, Faucet - Stainless Steel
Washer, Faucet Base - Stainless Steel
Washer, Rubber - Faucet Base
Washer, Slotted
Spacer, Plastic
Washer, Faucet
Nut, Faucet
Connector, Faucet - 3/8" x 7/16"
Kit, Rebuild Faucet - Stainless Steel
Spout, Long Reach - Stainless Steel
Sani tip, Black
35902032
35902008
35902079
35902080
35902105
21000001
35902104
31901108
33503302
35903002
35902061
35902042
B Components - Optional Light Bar Part No. D Components - Optional Light Bar Part No.
13
14
15
Light Bar - 3 Indicator Lights
Gasket, Washboard F/M
Washer, Faucet Base Lt. Bar (replaces Item 4)
41200001
20400018
21000002
13
14
15
Light Bar - 3 Indicator Lights
Gasket, Washboard F/M
Washer, Faucet Base Lt. Bar (replaces Item 4)
41200001
20400018
21000002
Figure 9 Parts Breakdown, Air Gap Product Water Faucet Assemblies, Chrome, or Stainless Steel
- 9 -

PRODUCT WATER FAUCET INSTALLATION - POLYMER FAUCET
Install on flat surface at least 2 7/16" in diameter. Unused 1 1/4"- 1 7/16" opening is ideal.
New Faucet Installation
Refer to Faucet Site Preparation, Page 7.
Replacement Faucet Installation
Verify size of existing hole. If hole measures 1 7/16",
Faucet may be installed without changes. If hole
measures 1 1/4", remove two locator tabs (Figure 10)
prior to installation by breaking them off at faucet base.
- 10 -
Figure 10 Faucet Locator Tabs and Air Gap.
1. Remove mounting nut and "U" bracket from faucet.
2. Install 3/8" blue tube into blue collet in faucet base.
3. Plain Front: Insert three tubes into mounting hole
and place faucet over hole. Align faucet body with
narrow face forward.
Light Bar: Insert three tubes and monitor cord into
mounting hole and place faucet over hole. Align
faucet body with light bar forward.
NOTE: Do not pinch, kink, pull, or otherwise deform
monitor cord.
4. Install "U" bracket and mounting nut below sink.
Tighten mounting nut by hand so that faucet does not
move. Do not over tighten.
NOTE: Faucet is packaged for right-hand operation. For
left-hand operation, realign handle by completing
Step 5.
NOTE: Item callouts in Step 5 refer to Page 11, Figure
11.
5. Align faucet knob for left-hand operation.
a. Rotate knob to rear of faucet (closed position).
b. Remove knob cover (Item 1) using a thin, flat tool
to pry cover from knob.
c. Remove knob attachment screw (Item 2) using a
Phillips-head screwdriver.
d. Remove knob (Item 3) by pulling it (by hand)
straight up. Rotate handle counterclockwise 90º,
and re-install knob.
e. Install knob attachment screw. Tighten screw
until free movement (i.e., rocking) is eliminated.
f. Snap knob cover into place.
6. Install spout into faucet body. Lubricate “O” ring with
FDA approved Silicone Lubricant. Align spout with
faucet outlet, gently push spout to bottom of outlet.
7. Connect loose ends of tubing as follows:
a. 3/8" blue tubing to 3/8" swivel elbow located on
rear of module.
b. 1/4" red tubing to 1/4" swivel elbow located on
rear of module.
c. 3/8" red tubing to drain connection.
NOTE: Red 3/8" tube connecting faucet to drain
connection must run vertically (or as closely
as possible) with no sharp bends or loops
(See Page 6, Figure 5).
8. Light Bar: Connect monitor cord to module. Insert
cord into a telephone-style connector located on
module cover (See Page 8, Figure 8).
NOTE: The basic installation is complete and system is
ready for activation (see Page 15).
CLEAN FAUCET SURFACE USING DISHWASHING DETERGENT ONLY. DO NOT USE ABRASIVES OR SOLVENTS.

Item Description Part No. Item Description Part No.
1
2
3
4
5
6
7
Cover, Knob - Color
Cover, Knob - Plated
Screw, Knob
Knob, Faucet
Cover, Body - Color
Cover, Body - Plated
Spout, Faucet
Tip, Spout
“O” ring, Spout
2080050*
3580050*
32701021
2080090*
2081700*
3581700*
3580130*
2080150*
34201004
8
9
10
11
12
13
14
15
16
Screw, Bearing
Bearing
Air Gap Assembly
Body Assembly
Gasket, Sink
“O” ring, Tube Spacer/Stop
Collet 3/8" Blue
Bracket, Mounting
Nut, Mounting
32701022
20800101
40303800
403039‡*
20819001
34201019
33502005
20800301
20821001
‡ SEVENTH DIGIT OF PART NUMBER IS CODE SPECIFYING FAUCET BODY CONFIGURATION
Code 0 designates faucet body with plain front. Code 1 designates faucet body with 1 LED.
Code 2 designates faucet body with 2 LED. Code 3 designates faucet body with 3 LED.
Example: 40303935 is a Faucet Body Assembly (3 LED)
* EIGHTH DIGIT OF PART NUMBER IS CODE SPECIFYING PART COLOR.
Codes 1 (White), 3 (Almond), 4 (Black) designate plain color parts and assemblies.
Codes 0 (Chrome/Black), 2 (Chrome/White), 6 (Satin/Black), and 8 (Satin/White) designate electro-plated parts and assemblies.
Codes 5 (Chrome/Black) and 7 (Chrome/White) designate vacuum-metalized parts and assemblies.
Example: 20800903 is a Faucet Knob in Almond or 40303930 is a Faucet Body Assembly in EP/Chrome with Black Light Bar (3 LED).
Figure 11 Parts Breakdown, Air Gap Product Water Faucet, Polymer Plain Front P/N 114002‡* and Light Bar P/N 114004‡*
- 11 -

Faucet Smartap®Monitor
Inlet Valve and Magnet Assemblies
Faucet Smartap®Monitor
Module Cover and Sending Unit Assemblies
Figure 12 Exploded Schematic , 101 Series Four Vessel Manifold Module
- 12 -

Item Description Part No.
Faucet Smartap®Monitor
Inlet Valve and Magnet Assemblies
1
1A
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18A
19
20
21
22
23
24
25
26
27
28
29
30
30A
31
32
33
33A
34
35
36
37
38
39
40
Cover, 4-vessel Manifold – Pushbutton
Cover, 3-vessel Manifold – Pushbutton
Battery, 9-volt alkaline
Monitor, Water Quality - Smartap®
Guard, Pushbutton
Pushbutton, Monitor
Bracket, Mounting
Screw, Mounting Bracket
Screw, Retaining Plate
Plate, Retaining - Inlet Valve Cover
Cover, Inlet Valve
"O" Ring, Inlet Valve Cover
Shut Off Assembly
Elbow, 1/4" Stem w/white collet
Flow Control (by Model)
Model 10103/10203/10303, Red Tape
Model 10104/10204/10304, Yellow Tape
Model 10105/10205, Black Tape
Model 10106/10206, Purple Tape
Model 10107/10207, Orange Tape
Cap, Flow Control
Elbow, 1/4" Stem w/red collet
Elbow, 3/8" Stem w/blue collet
Manifold Sub-Assembly, 4 vessel
Manifold Sub-Assembly, 3 vessel
Check valve, Duckbill
Stop, Tube
“O” Ring, Collet Retainer
Retainer Assembly, Outlet
Elbow, 3/8" Stem w/white collet
Plug, Switch Housing
"O" Ring, Switch Housing Plug
Housing, Filter
"O" Ring, Filter Housing
Cartridge, String-Wound Pre-Filter
Cartridge, Carbon CTO
Filter, Membrane Thin Film Composite
Model 10103/10203, Green Casing Red Tape
Model 10104/10204, Green Casing Yellow Tape
Model 10105/10205, Green Casing Black Tape
Model 10106/10206, Green Casing Purple Tape
Model 10107/10207, Green Casing Orange
Tape
Filter, Membrane Cellulose Triacetate
Model 10303, Blue Casing, Red Tape
Model 10304, Blue Casing, Yellow Tape
"O" Ring, Cartridge
"O" Ring, Membrane Flow Tower
Optional Faucet Smartap® Monitor
Cover, 4-vessel Manifold - Faucet Monitor
Cover, 3-vessel Manifold - Faucet Monitor
Monitor, Faucet Smartap®Monitor
Sending Unit, Flow Switch
Spring, Flow Switch
Magnet, Flow Switch
Cover Assembly, Inlet Valve
Spring, Inlet Valve
Magnet, Inlet Valve
42100002
42100001
31300001
40200002
20500050
20500080
21100001
32701002
32701001
31900041
20500066
34201024
40600010
33503502
40600003
40600004
40600005
40600006
40600007
40600001
33503505
33503503
41300040
41300022
42500014
20500094
34201033
40600033
33503504
20500026
34201021
20500023
34201026
41400008
41400009
41400003
41400004
41400005
41400006
41400007
41400001
41400002
34201010
34201006
42100004
42100003
40200012
40200013
31900025
40600013
40600012
31900026
40600011
Faucet Smartap®Monitor
Module Cover and Sending Unit Assemblies
Figure 13 Parts Breakdown, 101/102/103 Series, Exploded Schematic 102 and 103 Series Three Vessel Manifold Module
- 13 -

12.1L (3.2 GAL) CAPACITY STEEL - BLUE
[8.8 L (2.4 gal) usable capacity]
Dimensions with fittings: 17” H x 11” D
12.1L (3.2 GAL) CAPACITY STEEL - WHITE
[8.8 L (2.4 gal) usable capacity]
Dimensions with fittings: 17” H x 11” D
Item Description Part No. Item Description Part No.
1
2
3
Storage Tank Assembly
Tank, Product Water Storage - Blue
Valve, Shut-off
Elbow, 3/8" Stem w/white collet
42600001
34500001
33503601
33503504
1
2
3
Storage Tank Assembly
Tank, Product Water Storage - White
Valve, Shut-off
Elbow, 3/8" Stem w/white collet
42600017
34500003
33503601
33503504
38.9L (10.3 GAL) CAPACITY STEEL - BLUE
[28.3 L (7.49 gal) usable capacity]
Dimensions with fittings: 24” H x 15” D
7.6L (2 GAL) CAPACITY POLYMER - WHITE
[5.6 L (1.5 gal) usable capacity]
Dimensions with fittings: 21” H x 9” D
Item Description Part No. Item Description Part No.
1
2
3
4
Storage Tank Assembly
Tank, Product Water Storage - Blue
Valve, Shut-off 1/4" MNPT X 1/4” FNPT
Connector, 3/8” x 1/4” MNPT
Elbow Assembly, 3/4" FNPT x 1/4" FNPT
42600003
34500002
34900007
33501020
40900035
1
2
3
Storage Tank Assembly
Tank, Product Water Storage - White
Valve, Shut-off
Elbow, 3/8" Stem w/white collet
426000021
34500004
33503601
33503504
Figure 14 Parts Breakdown, Product Water Storage Tank Assemblies
- 14 -

ACTIVATING THE SYSTEM
NOTE: Make sure all water supply lines, drain lines, and fittings are secure and free from leakage.
1. Open source water supply valve. Close product
water faucet. Check for leakage.
2. Turn tank valve one-quarter turn counter- clockwise to
open valve (handle should be in line with tubing as it
enters connection).
3. Confirm system is producing water. Module will be
sending rinse water to drain.
NOTE: Battery is located inside manifold cover.
Use caution when working with manifold cover.
Wiring therein connects monitor components. If
wires, circuit board, or connections are damaged
and/or wetted, monitor will not function.
Connect battery to monitor after system has been
in production mode for at least 5 minutes. This
ensures sensing switch is in proper position to
record data.
Item Callouts refer to Page 12, Figure 12 (101
Series) or Page 13, Figure 13 (103 Series) unless
noted otherwise.
4. Loosen mounting bracket screws (Item 7). Gently pull
module cover (Item 1) up and away from the manifold
body.
5. Connect battery (Item 2) by pressing clip onto battery
terminals (Page 18, Figure 15).
6. Replace module cover and tighten screws.
7. Test battery connection by activating monitor. Open
product water faucet or press pushbutton, whichever
is applicable. If an indicator light illuminates,
connection is good.
NOTE: Close faucet immediately after light illuminates.
Test is to confirm battery connection, not water
quality.
8. Open product water faucet and let water flow until all
air has been expelled from system. Lock faucet
open by rotating handle 90º or by lifting handle,
whichever is applicable.
9. Close product water faucet. In 30 minutes, check
connections for leaks and correct if necessary.
Icemaker/Extra point of use: Check connections on
these supply lines for leaks.
10 Allow storage tank to fill overnight.
DO NOT USE
THE FIRST FULL STORAGE TANK OF WATER
11 Discard (to drain) first full tank of water by opening
product water (and extra point-of-use) faucet until
water flow stops, then close faucet. This will flush
sanitizing solution from system.
Icemaker: Let tray/bin fill with ice cubes. Discard all
ice cubes. This flushes sanitizing solution from lines
to icemaker.
NOTE: System is ready to use. Should there be any
aftertaste or odor to water or ice cubes, repeat
Steps 10 and 11.
DO NOT USE THE FIRST STORAGE TANK OF WATER
Allow storage tank to fill overnight. Dispense this water to drain.
This process removes factory-installed sanitizing solution from the entire system and sends it to drain.
This process also sanitizes fittings and tubing used during installation.
- 15 -

KEY COMPONENTS
MEMBRANES AND FILTERS
Membrane - Cellulose Triacetate Part No. Membrane - Thin Film Composite Part No. Filter Part No.
Blue Casing
Model 10303 - Red Tape
Model 10304 - Yellow Tape
41400001
41400002
Sediment Filter - Black Cap
Carbon Filter CTO - Blue Cap
41400008
41400009
Green Casing
Models 10103/10203 - Red Tape
Models 10104/10204 - Yellow Tape
Models 10105/10205 - Black Tape
Models 10106/10206 - Purple Tape
Models 10107/10207 - Orange Tape
41400003
41400004
41400005
41400006
41400007
PRODUCT WATER FAUCETS AND STORAGE TANKS
Air Gap Faucet Part No. Air Gap Faucet Part No. Storage Tanks Part No. Storage Tanks Part No.
Stainless Steel
Chrome Plated Brass
40301004
40301001
Polymer, Plain Front
Polymer, Light Bar
1140020*
1140043*
12.1L (3.2 gal) Steel Blue
12.1L (3.2 gal) Steel White
42600001
42600017
38.9L (10.3 gal) Steel Blue
7.6L (2.0 gal) Polymer White
42600003
42600021
*Color Suffix Codes
EPChrome/Black = 0, White = 1, EPChrome/White = 2, Almond = 3, Black = 4, Chrome/Black = 5, Satin/Black = 6, Chrome/White = 7, Satin/White = 8
PARTS AND SERVICE AVAILABLE THROUGH YOUR HYDROTECH®DEALER
ROUTINE MAINTENANCE
RECOMMENDATIONS
HAVE ALL COMPONENTS ON HAND AND READY BEFORE BEGINNING PROCEDURE.
A CLEAN WORK AREA AND EQUIPMENT ARE ESSENTIAL TO PROPERLY CLEAN AND/OR SANITIZE THE SYSTEM.
(i.e., CLEAN HANDS, TOOLS, WORK SURFACE, AND CONTAINERS)
Service Requirements Recommended Service Intervals
To insure the system operates at its optimum level,
certain routine maintenance must be performed.
Frequency of maintenance performance will depend on
feed water quality and level of system usage.
CLEAN: Each time filters are replaced
SANITIZE: At least once a year and each time membrane is replaced
Replace filters as required or every 6 to 12 months
depending on feed water quality.
Replace membrane as required based on Smartap®
Water Quality Monitor indication or periodic TDS rejection tests.
Maximum recommended service life for membrane is 60 months.
EQUIPMENT NEEDED
Safety glasses
Rubber gloves, sanitary
Wash Cloth, Clean and Lint-free
Liquid dish soap
Household bleach - Unscented Only
(5 1/4% sodium hypo chlorite)
Plastic storage bag
Manual Air Pump
Plastic bucket
Plastic bowl
“O” ring Lube FDA Approved
(P/N 30300026)
REPLACEMENT FILTER SETS
101 SERIES
P/N 41400008 Sediment Filter (1 each)
P/N 41400009 CTO Carbon Filter (2 each)
102 AND 103 SERIES
P/N 41400008 Sediment Filter (1 each)
P/N 41400009 CTO Carbon Filter (1 each)
REPLACEMENT MEMBRANES
101 AND 102 SERIES
P/N 41400003, Model 10103 or 10203, Red Tape
P/N 41400004, Model 10104 or 10204, Yellow Tape
P/N 41400005, Model 10105 or 10205, Black Tape
P/N 41400006, Model 10106 or 10206, Purple Tape
P/N 41400007, Model 10107 or 10207, Orange Tape
103 SERIES
P/N 41400001, Model 10303, Red Tape
P/N 41400002 Model 10304, Yellow Tape
NOTE
Verify membrane type by casing color (TFC is green, CTA is blue)
Verify GPD rating (match tape color on membrane to tape on Flow Control)
“O” RINGS
P/N 34201010 Sediment or Carbon Cartridge to Port
P/N 34201026 Filter Housing
P/N 34201010 Membrane to Flow Tower, Lower
P/N 34201006 Membrane Flow Tower, Upper
- 16 -
