OWNER’S GUIDE
NSFR
AQUAFIER®
ADVANCED ACTIVATED CARBON
WATER TREATMENT SYSTEM
Model Series
10401, 10402, 10403
Hydrotech, Inc.
25555 West Avenue Stanford, Valencia, CA 91355
[phone] FAX [phone]

INTRODUCTION
NSFR
THIS GUIDE IS APPLICABLE TO ALL AQUAFIER®MODELS
TABLE A
SYSTEM CONFIGURATION FAUCET TYPE
Filtration Unit Flow Monitor Chrome Stainless or Polymer None
Faucet Smartap®10403002 10403102* 10402102*
Pushbutton Smartap® 10403001 10403101* 10402101*
Aquafier®
4 Vessel
Unitary Manifold
None 10401000 10401100* 10402100*
* System Tested and Certified By NSF International Against ANSI/NSF 53 and ANSI/NSF 42.
CERTIFIED CONTAMINANT REDUCTION PERFORMANCE
SYSTEM TESTED AND CERTIFIED BY NSF INTERNATIONAL AGAINST ANSI/NSF 53 AND ANSI/NSF 42 FOR REDUCTION OF
ASBESTOS LEAD PARTICULATES CYSTS* TURBIDITY
AESTHETICS: TASTE, AND ODOR CHLORINE REDUCTION CLASS I VOLATILE ORGANIC CHEMICALS (VOC's)
* Certification for reduction of Cysts including Cryptosporidium parvum ococysts and cysts of Giardia and Entamoeba.
SYSTEM STATISTICS
SYSTEM CAPACITY
without Smartap®Flow Monitor
SYSTEM CAPACITY
with Smartap®Flow Monitor
SERVICE FLOW RATE
at the Manifold Unit Outlet
3969 Litres (1050 gallons) 6615 Litres (1750 gallons) 1.9 Liters/minute (0.5 Gallons/minute)
PERFORMANCE INDICATOR
SMARTAP®WATER FLOW MONITOR
The optional Smartap®Monitor indicates filter cartridge status by measuring the volume of water passing through the
Aquafier® Water Treatment System. When water is dispensed, it flows through the system actuating the monitor and
recording the elapsed time for each dispense. Monitor indication is based on the cumulative number of gallons passed
through the system (elapsed time multiplied by flow rate). A green light indicates filters are functioning normally.
A yellow light indicates filters are nearing useful capacity and should be replaced.
Disconnecting the battery from the clip resets the Monitor. Installing a new battery each time filter cartridges are replaced
ensures an accurate indication of system performance and a continuing supply of high quality drinking water.
FAUCET ACTUATED SMARTAP®FLOW MONITOR PUSHBUTTON ACTUATED SMARTAP®FLOW MONITOR
A light illuminates in a Light Bar each time a faucet
or additional point-of-use device is activated.
Light Bar Assembly is located at faucet base (Chrome or
Stainless Steel) or front of faucet body (Polymer).
Power is provided by nine volt alkaline battery.
A light illuminates when the test button is pressed.
Pushbutton Actuator and Indicator Lights
are located on the Manifold Cover.
Power is provided by nine-volt alkaline battery.
I

INTRODUCTION
CONDITIONS FOR USE TECHNICAL DATA UPDATES
Source Water Supply Profile This Manual Incorporates The Following Technical Changes
Community/Private Chlorinated/Non-Chlorinated
Feed Water Pressure1 173-690 kPa (25-100 psig)
Temperature 4°-38° C (40°-100° F)
Technical Bulletin 98-002:
Optional Components - Polymer Product Water Faucet
Installation Instructions - Polymer Faucet - Page 8
Parts Breakdown, Polymer Faucet - Page 9, Figure 9
1. Pressure Regulator is recommended for feed water pressures exceeding 552 kPa (80 psig).
ITEM #1 - FAUCET SMARTAP®MONITOR WITH CONNECTIONS AND STANDARD FAUCET
ITEM #1A - PUSHBUTTON SMARTAP®MONITOR ITEM #1B - WITHOUT SMARTAP®MONITOR TUBING CONNECTIONS AT MODULE
Item Description Part No. Item Description Part No.
1
1A
1B
2
Module, Aquafier®Carbon Filtration System
Faucet Actuated Smartap®Water Quality
Monitor
Pushbutton Smartap®Water Quality Monitor
Module Only, No Monitor
Product Water Faucet
Chrome or Stainless Steel
Polymer, Plain Front or with Light Bar
Page I,
Table A
Page 7, Fig 7
Page 9, Fig 9
3
n/s*
n/s*
n/s*
n/s*
n/s*
Installation Kit, All Faucets
Supply Valve Assembly, Saddle Tapping
Tubing, 1/4" x 54" White
Tubing, 3/8" x 60" Blue
Screw, Mounting Bracket (2 each)
Owner's Guide, Aquafier®104 Series
Performance Data Sheet (104 Series NSF Listed)
42902003
34900001
20300014
20300013
32701002
36101004
36101194
* not shown
Figure 1 Component and Interconnection Locators, 104 Series
OPTIONS AND ACCESSORIES
METAL OR POLYMER FAUCET
The product water faucets are available in Chrome-Plated Brass (EPA and California Proposition 65 Compliant), Polished
Stainless Steel, or a decorator color molded Polymer (five colors). Units are available with or without Light Bar. NSF
Listed Systems require either a Stainless Steel or Polymer faucet.
Contact your Hydrotech® Dealer to purchase these items or to obtain more information.
II

INSTALLATION REQUIREMENTS
READ THIS ENTIRE INSTALLATION AND SERVICE GUIDE BEFORE BEGINNING INSTALLATION
This Aquafier®Drinking Water Treatment System is designed for ease of installation and serviceability.
It is constructed with the finest materials available.
Using these instructions and paying close attention to parameters outlined within "CONDITIONS FOR USE" detailed
on Page ii will ensure a successful installation.
This system must be installed in accordance with applicable city, state, and local plumbing codes.
To insure the system continues to operate at its optimum level,
it is necessary to have a routine maintenance and replacement schedule (Page 11).
The frequency at which filters need changing will depend on quality of feed water supply and level of system usage.
PREPARATION
1. Check that all appropriate components are packed
with your system (Page II, Figure 1). Refer to
applicable Component Parts Breakdown (Figure 7, 9,
or 10) for a complete list of its constituent parts.
2. Determine locations for component installation. Two
requirements for consideration are: access to cold
water supply line and to household sink. Specific
requirements are detailed in Table 1.
PRODUCT WATER FAUCET FILTRATION MODULE
Faucet may be installed in any convenient location.
Make sure underside of location is free of obstructions.
Module may be installed under a sink or in any convenient
location. within 15 feet of source water supply and faucet
* DO NOT PLACE MODULE WHERE IT WILL BE EXPOSED TO FREEZING AND/OR DIRECT SUNLIGHT.
Mount Module on side of cabinet using bracket (attached to Module) and two screws provided in the Installation Kit.
HOLD THE MODULE BY THE FILTER HOUSINGS WHEN PICKING UP OR CARRYING THE UNIT
Table 1 Component Location Requirements
NOTE
THIS DRINKING WATER SYSTEM IS FOR USE ON POTABLE WATER SUPPLIES ONLY.
COMMONWEALTH OF MASSACHUSETTS PLUMBING CODES 248 CMR SHALL BE ADHERED TO.
CONSULT WITH YOUR LICENSED PLUMBER FOR INSTALLATION OF THIS SYSTEM.
CAUTION
DO NOT USE WITH WATER THAT IS MICROBIOLOGICALLY UNSAFE OR OF UNKNOWN
QUALITY WITHOUT ADEQUATE DISINFECTION BEFORE OR AFTER THE SYSTEM.
SYSTEMS CLAIMING CYST REDUCTION
SYSTEMS CERTIFIED FOR CYST REDUCTION
MAY BE USED ON DISINFECTED WATERS THATMAY CONTAIN FILTERABLE CYSTS.
IF SIGNIFICANT INLET WATER PRESSURE DIFFERENTIALS OCCUR, PRESSURE REGULATOR MUST BE USED.
III

1
INTER-COMPONENT CONNECTIONS
Connections between the cold water supply line, filtration unit, product water faucet, and optional accessories are
accomplished using plastic tubing and push-together quick-connect type fittings.
PLASTIC TUBING
1. Cut tube ends square and straight. Do not deform
the tube (i.e., cause tube to compress its diameter so
it is no longer round).
2. Make sure the outer surface of the tube is clear of
marks or scratches for a length equal to twice the
tube diameter. This allows the "O" ring to seat
properly against the tube.
3. Avoid sharp changes in direction when routing the
tubing. Sharp turns cause the tubing to flex and
deform which reduces its flow capacity and may
increase lateral stress on the fittings, causing leaks.
QUICK-CONNECT FITTINGS
Fittings consist of two parts: a Body and a colored Collet.
The Collet color corresponds to the tubing color to be
used at that connection (See Figure 2A.).
1. To install a tube, push it through Collet until it seats
firmly at bottom of fitting (Figures 2.A. and 2.B.).
2. To remove a tube, push and hold the Collet against
the Body while pulling the tube out (Figure 2.C.).
NOTE: Systems are shipped with a plug in each fitting
(prevents leakage of sanitizing fluid). Remove a
plug in the same manner as a tube.
A. Push tube through Collet into Body B. Tube must seat firmly at bottom of fitting C. Push Collet against Body to release tube
Figure 2 How to Use Quick-Connect Fittings

- 2 -
SADDLE TAPPING VALVE INSTALLATION ON COPPER TUBE
NOTE: State and local plumbing codes may prohibit use of saddle tapping valves. An Inlet Adapter Valve
Assembly (P/N 42500004) is available as an alternate installation (See Page 4).
1. Locate shut off valves on water lines under sink. To
identify hot supply pipe and cold supply pipe, turn
both faucets on and let water run. As water flows,
hot water pipe becomes noticeably warmer.
CAUTION: DO NOT INSTALL FEED WATER
ASSEMBLY ON HOT WATER LINE.
2. Turn off cold water supply by closing shut off valve.
Drain line by opening sink faucet. Some mixing type
faucets may require hot water supply be shut off as
well.
NOTE: If no shut-off valve is installed under sink, close
main water valve during this installation.
All instructions refer to components shown in
Figure 3A unless otherwise noted.
CAUTION: Do not turn valve handle before or while
installing saddle tapping valve. Make sure
piercing lance does not protrude beyond
rubber gasket before installing valve.
3. Assemble saddle tapping valve assembly on tube.
a. Hold Back Plate against tube.
• 3/8" O.D. and smaller tubing, use
bracket with side projections.
• 1/2" or larger tubing, use "V" side of
bracket (See Figure 3B).
b. Hold Valve Saddle against tubing in a position
directly opposite Back Plate.
c. Install screws far enough so Saddle and Back
Plate are held securely against tube.
d. Rotate assembly so tubing connection is aligned
toward Filtration Module input port.
e. Tighten screws evenly (brackets must be
parallel). Tighten each screw firmly. Do not crush
tube.
4. Connect source water tubing to valve housing using
compression fitting.
a. Slide nut and sleeve onto tubing (in that order).
b. Install insert into plastic tubing.
c. Install tube with insert and sleeve into valve
housing.
d. Thread compression nut onto housing, tighten.
5. Connect tubing from saddle tapping valve to Filtration
Module inlet elbow (Item 8 on Page 10, Figure 10).
6. Turn saddle tapping valve handle clockwise until it is
firmly seated and piercing lance is fully extended.
NOTE: Supply line is pierced and valve is closed.
Do not open valve until system is activated
(Page 11).
7. Turn on cold water supply. Check saddle tapping
valve installation for leaks. Allow water to run from
faucet for a few minutes to clear any debris in the line
caused by installation.
NOTE: If flow from sink faucet is reduced, clean faucet
aerator.
Figure 3A Saddle Tapping Valve Assembly
P/N 34900001 installed on 3/8” O.D. Tubing

- 3 -
SADDLE TAPPING VALVE INSTALLATION ON THICK WALL PIPE
NOTE: State and local plumbing codes may prohibit use of saddle tapping valves. An Inlet Adapter Valve
Assembly (P/N 42500004) is available as an alternate installation (See Page 4).
1. Locate and shut off source water supply line (See
Page 2, Steps 1 & 2 with associated Notes).
CAUTION: DO NOT INSTALL FEED WATER
ASSEMBLY ON HOT WATER LINE.
CAUTION: Use a battery powered hand drill to avoid
shock hazard.
NOTE: If no shut-off valve is installed under sink, close
main water valve during this installation.
All instructions refer to components shown in
Figure 3B unless otherwise noted.
Place a container or towel below shut-off valve to
catch any remnant water.
Use a clean drill bit for this procedure.
2. Drill a 3/16" hole in pipe. Hole must be located so
that tubing connection will be oriented toward
Filtration Module input port.
3. Assemble saddle tapping valve assembly on pipe.
a. Turn Valve handle to expose lance beyond
rubber gasket no more than 3/16”.
b. Place Valve Saddle against pipe. Make sure
lance fits into hole.
c. Hold Back Plate in a position directly opposite
Valve Saddle.
d. Install screws far enough so Valve Saddle and
Back Plate are held firmly against pipe.
e. Tighten screws evenly (brackets must be
parallel). Tighten each screw firmly. Do not crush
pipe.
4. Connect source water tubing to valve housing using
compression fitting (See Page 2, Step 4).
5. Connect tubing from saddle tapping valve to Filtration
Module inlet elbow (Item 8 on Page 10, Figure 10).
6. Turn saddle tapping valve handle clockwise until it is
firmly seated and piercing lance is fully extended.
NOTE: Supply line is pierced and valve is closed.
Do not open valve until system is activated
(Page 11).
7. Turn on cold water supply. Check saddle tapping
valve installation for leaks. Allow water to run from
faucet for a few minutes to clear any debris in the line
caused by installation.
NOTE: If flow from sink faucet is reduced, clean faucet
aerator.
Figure 3B Saddle Tapping Valve Assembly
P/N 34900001 installed on
7/16” – 1/2” O.D. Tubing
ADDITIONAL POINT OF USE CONNECTION
NOTE: Icemakers typically use 1/4" tubing as feed line. Use a reducing union (P/N 33501043) for this connection.
1. To connect an additional point of use (icemaker,
extra faucet in wet bar and/or another use for treated
water), place a "tee" connector (P/N 33501040) in
3/8" blue line between faucet and back of RO
Module.
2. Connect "tee" to point-of-use with 3/8" blue tubing
(P/N 60602001). Connect tubing to point-of-use.
Connector requirements are based on type of
delivery device i.e., a typical icemaker uses 3/8" x
1/4" reducing device (P/N 33501043)

- 4 -
INLET ADAPTER VALVE INSTALLATION
NOTE: This assembly is offered as an optional installation method. Make sure it is approved for use under State
and local plumbing codes before ordering kit (P/N 42500004).
NOTE: Use this assembly on U.S.N.P.T.* pipe thread fittings only.
CAUTION:DO NOT INSTALL FEED WATER ASSEMBLY ON HOT WATER LINE.
1. Locate shut off valves on water lines under sink. To
identify hot supply pipe and cold supply pipe, turn
both faucets on and let water run. As water flows,
hot water pipe becomes noticeably warmer.
2. Turn off cold water supply by closing shut off valve.
Drain line by opening sink faucet. Some mixing type
faucets may also require turning off hot water supply.
NOTE: If no shut off valve is installed under sink, close
main water valve during this installation.
Place a container or towel below shut-off valve to
catch any water remaining in pipe.
All item callouts refer to Figure 4 unless noted
otherwise.
3. Disconnect cold water supply line to sink at inlet
valve end of line.
NOTE: Use Teflon tape (P/N 35700002) on male
threaded connections in Steps 4, 6, 7, and 8.
EXISTING COLD WATER
SUPPLY VALVE
COLD WATER LINE
TO SINK
4. Insert rubber washer (Item 1) into inlet adapter (Item
2) and install adapter onto supply valve. Align outlet
hole (in side of adapter) toward Filtration Module.
5. Replace existing rubber grommet on cold water
supply line with grommet supplied in kit (Item 3).
6. Attach cold water supply line to inlet adapter.
7. Install ball valve (Item 4) into inlet adapter.
8. Install male connector (Item 5) into inlet ball valve.
9. Install ¼” white tubing (Item 6) from male connector
to Filtration Module inlet elbow (Item 8 on Page 10,
Figure 10).
10. Close inlet valve by turning handle so it is at a right
angle (90º) to valve body.
11. Turn on cold water supply. Check installation for
leaks. Allow water to run from faucet for a few
minutes to clear any debris in the supply line caused
by this installation.
NOTE: If flow from faucet is reduced, clean faucet
aerator.
Item Description Part No.
Inlet Assembly
1 Rubber Washer 33400002
2 Inlet Adapter 1/2" x 1/2" x 1/8" 33201001
3 Rubber Grommet 33400003
4 Inlet Ball Valve 1/8" 34900002
5 Male Connector 1/4" x 1/8" NPT* 33503301
Component of Installation Kit
6 Tubing, 1/4" White 20300014
* United States National Pipe Thread
Figure 4 Inlet Adapter Assembly P/N 42500004 Installation and Parts Breakdown

- 5 -
PRODUCT WATER FAUCET SITE PREPARATION
Refer to Faucet Installation Instructions (Pages 6 and 8) for site location and mounting hole
specifications.
Primary considerations for site selection are convenience of use and an open area under sink.
Always check underside of selected location for obstructions.
PORCELAIN/ENAMEL OVER STEEL
OR CAST IRON SINKS
NOTE: A heavy duty, variable speed drill motor is
recommended for this procedure.
Use of a spring-loaded porcelain drill set is
strongly recommended (Figure 5).
Plastic sleeve supplied on pilot drill (Figure 5.A.)
is to be positioned on drill bit against drill chuck.
This prevents chuck from contacting porcelain
after pilot hole has been completed.
Suggestion: Practice on discarded sinks to familiarize
yourself with operation of porcelain cutter kit.
CAUTION: Avoid high motor R.P.M. during initial
penetration of porcelain, as high drill speed
will cause excessive chipping.
1. Using carbide tipped bit with plastic sleeve (Figure
5.A.), drill pilot hole completely through porcelain and
metal underneath.
2. Place spring-loaded porcelain saw (Figure 5.B.) into
drill chuck. Make sure pilot guide is inserted tightly.
Insert pilot guide into pilot hole. Push down gently on
drill motor to apply light pressure to porcelain surface.
Start drill motor turning as slowly as possible.
After initial cut has started, motor speed may be
gradually increased. The cut may require three to
four minutes to complete. Going faster could result in
excessive chipping. Be sure a complete ring has
been cut through porcelain to material underneath.
3. Place finish hole saw (Figure 5.C.) into drill chuck.
Make sure pilot guide is inserted tightly. Insert pilot
guide into pilot hole. Begin cut using a slow speed
and light pressure until porcelain (inside ring cut in
Step 2) has been penetrated to material underneath.
4. Remove saw from hole and clean all debris from
porcelain surface. Reinsert saw into hole and cut
through remaining material.
TILE COUNTER TOP
1. Follow procedures detailed in section labeled
"Porcelain/Enamel Over Steel" (substitute "tile" for
"Porcelain" in instructions).
STAINLESS STEEL SINK
1. Use a center punch to make a small indentation to
mark center of desired location.
2. Drill a pilot hole with a 1/8" metal drill bit, then enlarge
hole with a 3/8" metal drill bit.
3. Complete hole size by using a 1 1/4" chassis punch
available from your dealer (P/N 36201006).
NOTE: Installation hole is ready, install faucet.
A. PILOT DRILL
B. SPRING LOADED PORCELAIN SAW
C. FINISH HOLE SAW

- 6 -
Figure 5 Porcelain Cutter Kit P/N 36201003
PRODUCT WATER FAUCET INSTALLATION - STAINLESS STEEL OR CHROME FAUCET
Install faucet on flat surface at least 2" in diameter. Unused 1 1/4" hole is ideal.
Steps unique to a specific configuration are so noted. All other steps are common to either configuration.
New Faucet Installation
Refer to Faucet Site Preparation, Page 5.
Replacement Faucet Installation
Verify size of existing hole is 1 1/4" ± 1/4".
NOTE: Item callouts refer to Page 7, Figure 7 unless
otherwise noted.
Part numbers for each callout are determined by
faucet material:
Chrome-Plated Faucets (brass faucet nipple):
Tables A and B.
Stainless Steel Faucet (copper faucet nipple)
Tables C and D).
1. Pushbutton Smartap®: Verify faucet body, metal
faucet base washer, and rubber base washer are in
place above sink (Items 2, 3, and 4).
Optional Faucet Smartap®:Verify faucet body,
metal faucet base washer, light bar base washer, light
bar assembly, and washboard gasket are in place
above sink (Items 2, 3, 14, 12, and 13).
2. Install 3/8" blue tube into faucet connector (Item 8).
3. Pushbutton Smartap®:Insert tube into mounting
hole and place faucet over hole.
Optional Faucet Smartap®:Insert tube and monitor
cord into mounting hole and place faucet over hole.
NOTE: Do not pinch, kink, or otherwise deform
monitor cord.
4. Install slotted washer, washer, and nut on faucet
nipple below sink and snug them up. Align faucet
before tightening. Do not over tighten.
5. Connect 3/8" blue tubing to swivel elbow located on
rear of module.
6. Optional Faucet Smartap®: Connect monitor cord to
telephone-style connector located on manifold cover
(See Figure 6).
NOTE: The basic installation is complete and system is
ready for activation (See Page 11).
Figure 6 Connecting Monitor cord to Manifold.

- 7 -
A + B Chrome Faucet with Light Bar 11702001 C + D Stainless Steel Faucet with Light Bar 11702002
Item Description Part No. Item Description Part No.
A Chrome Faucet 40301002 C Stainless Steel Faucet 40301007
1
2
3
4
5
6
7
8
9
10
11
Handle, Faucet
Body, Faucet - Chrome
Washer, Faucet Base - Chrome
Washer, Rubber - Faucet Base
Washer, Slotted
Washer, Faucet
Nut, Faucet
Connector, Faucet - 3/8" x 7/16"
Kit, Rebuild Faucet - Chrome
Long Reach Spout - Chrome
Sani tip, Black
35902032
35902003
35902078
35902080
35902105
35902104
31901108
33503302
35903001
35902055
35902042
1
2
3
4
5
6
7
8
9
10
11
Handle, Faucet
Body, Faucet - Stainless Steel
Washer, Faucet Base - Stainless Steel
Washer, Rubber - Faucet Base
Washer, Slotted
Washer, Faucet
Nut, Faucet
Connector, Faucet - 3/8" x 7/16"
Kit, Rebuild Faucet - Stainless Steel
Long Reach Spout - Stainless Steel
Sani tip, Black
35902032
35902016
35902079
35902080
35902105
35902104
31901108
33503302
35903002
35902061
35902042
B Components - Optional Light Bar D Components - Optional Light Bar
12
13
14
Light Bar - 2 Indicator Lights
Gasket, Washboard F/M
Washer, Faucet Base Lt Bar (replaces Item 4)
41200002
20400018
21000002
12
13
14
Light Bar - 2 Indicator Lights
Gasket, Washboard F/M
Washer, Faucet Base Lt Bar (replaces Item 4)
41200002
20400018
21000002
Figure 7 Parts Breakdown, Non-Air Gap Product Water Faucet Assemblies, Chrome, or Stainless Steel

8
PRODUCT WATER FAUCET INSTALLATION - POLYMER FAUCET
Install on flat surface at least 2 7/16" in diameter. Unused 1 1/4"- 1 7/16" opening is ideal.
New Faucet Installation
Refer to Faucet Site Preparation, Page 5.
Replacement Faucet Installation
Verify size of existing hole. If hole measures 1 7/16",
faucet may be installed without changes. If hole
measures 1 1/4", remove two locator tabs (See Figure 8)
prior to installation by breaking them off at faucet base.
Figure 8 Faucet Locator Tabs.
NOTE: Item callouts refer to Page 9, Figure 9 unless
otherwise noted.
1. Remove mounting nut (Item 23) and bracket (Item 22)
from faucet.
2. Install 3/8" blue tube into blue collet in faucet base.
3. Plain Front: Insert tube into mounting hole and place
faucet over hole. Align faucet body with narrow face
forward.
Light Bar: Insert tube and monitor cord into
mounting hole and place faucet over hole. Align
faucet body with light bar forward.
NOTE: Do not pinch, kink, pull, or otherwise deform
monitor cord.
4. Install mounting bracket and nut below sink. Tighten
mounting nut by hand so that faucet does not move.
Do not over tighten.
NOTE: Faucet is packaged for right-hand operation. For
left-hand operation, realign knob by completing
Step 5.
NOTE: Item callouts in Step 5 refer to Page 9, Figure 9.
5. Align faucet knob for left-hand operation.
a. Rotate knob to rear of faucet (closed position).
b. Remove knob cover (Item 1) using a thin, flat tool
to pry cover from knob.
c. Remove knob attachment screw (Item 2) using a
Phillips-head screwdriver.
d. Remove knob (Item 3) by pulling it (by hand)
straight up. Rotate knob counterclockwise 90º,
and re-install.
e. Install knob attachment screw. Tighten screw
until free movement (i.e., rocking) is eliminated.
f. Snap knob cover into place.
6. Install spout into faucet body. Lubricate “O” ring with
FDA approved Silicone Lubricant. Align spout with
faucet outlet, gently push spout to bottom of outlet.
7. Connect 3/8" blue tubing to swivel elbow located on
rear of module.
8. Light Bar: Connect monitor cord to module. Insert
cord into a telephone-style connector located on
Filtration Module cover (See Page 6, Figure 6).
NOTE: The basic installation is complete and system is
ready for activation (See Page 11).
CLEAN FAUCET SURFACE USING DISHWASHING DETERGENT ONLY. DO NOT USE ABRASIVES OR SOLVENTS.

9
Item Description Part No. Item Description Part No.
1
2
3
4
5
6
7
Cover, Knob - Color
Cover, Knob - Plated
Screw, Knob
Knob, Faucet
Cover, Body - Color
Cover, Body - Plated
Spout, Faucet
Tip, Spout
“O” ring, Spout
2080050*
3580050*
32701021
2080090*
2081700*
3581700*
3580130*
2080150*
34201004
8
9
10
11
12
13
14
15
Screw, Bearing
Bearing
Body Assembly
Gasket, Sink
“O” ring, Tube Spacer/Stop
Collet 3/8" Blue
Bracket, Mounting
Nut, Mounting
32701022
20800101
403039‡*
20819001
34201019
33502005
20800301
20821001
‡ SEVENTH DIGIT OF PART NUMBER IS CODE SPECIFYING FAUCET BODY CONFIGURATION
Code 0 designates faucet body with plain front. Code 1 designates faucet body with 1 LED.
Code 2 designates faucet body with 2 LED. Code 3 designates faucet body with 3 LED.
Example: 40303935 is a Faucet Body Assembly (3 LED)
* EIGHTH DIGIT OF PART NUMBER IS CODE SPECIFYING PART COLOR.
Codes 1 (White), 3 (Almond), 4 (Black) designate plain color parts and assemblies.
Codes 0 (Chrome/Black), 2 (Chrome/White), 6 (Satin/Black), and 8 (Satin/White) designate electro-plated parts and assemblies.
Codes 5 (Chrome/Black) and 7 (Chrome/White) designate vacuum-metalized parts and assemblies.
Example: 20800903 is a Faucet Knob in Almond or 40303935 is a Faucet Body Assembly (3 LED) in Chrome/Black.
Figure 9 Parts Breakdown, Non-Air Gap Product Water Faucet, Polymer Plain Front P/N 114001†, Light Bar P/N 114003†

10
Item Description Part No.
Faucet Smartap®Monitor
Module Cover and Flow Switch
Pushbutton Smartap®Monitor
Module Cover and Flow Switch
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Cover, 4-vessel Manifold - No Monitor
Bracket, Mounting
Screw, Mounting Bracket
Screw, Retaining Plate
Plate, Retaining - Inlet Valve Cover
Cover, Inlet Valve
“O” Ring, Inlet Valve Cover
Elbow, 1/4" Stem w/white collet
Elbow, 3/8" Stem w/blue collet
Control Assembly, Flow 0.5 GPM
Manifold Sub-Assembly, Aquafier®
Housing, Filter
“O” Ring, Filter Housing
Cartridge, Carbon VOC Reduction
Cartridge, Carbon Lead Reduction
Tube, Parallel Cross-over
“O” Ring, Port Retainer
Plug, Port Retainer
Plug, Switch Housing
"O" Ring, Switch Housing Plug
"O" Ring, Cartridge
Activator, Smartap® Flow Monitor
Sending Unit, Flow Switch
Spring, Flow Switch
Magnet, Flow Switch
Optional Faucet Smartap® Flow Monitor
Cover, 4-vessel Manifold - Faucet Monitor
Monitor, Flow - Faucet Smartap®
Battery, Alkaline 9 volt
Optional Pushbutton Smartap® Monitor
Cover, 4-vessel Manifold - Pushbutton
Monitor, Flow, Pushbutton Smartap®
Pushbutton, Monitor
Guard, Pushbutton
42100005
21100001
32701002
32701001
31900041
42200002
34201024
33503502
33503503
40600009
41300006
20500023
34201026
41400011
41400010
42200001
34201033
20500107
20500026
34201021
34201010
40200013
31900025
40600013
42100008
40200018
31300001
42100007
40200030
20500080
20500050
Figure 10 Parts Breakdown, 104 Series Four Vessel Manifold Module

11
ACTIVATING THE SYSTEM
Turn on the Source Water
NOTE: Make sure all water lines and fittings are secure
and free from leakage.
1. Open source water supply valve. Check for leakage.
2. Open product water faucet and let water flow to drain
for at least 10 minutes. This will expel the air from the
system.
3. Close product water faucet. In 5 minutes, check the
connections for leaks and correct if necessary.
Connect The Smartap®Monitor Battery
NOTE: Battery is mounted inside the module cover.
Battery may be connected prior to installation.
1. Loosen three mounting bracket screws. Gently pull
module cover up and away from the module body.
2. Connect the battery by pressing the clip onto the
battery terminals (See Page 13, Figure 11).
3. Replace module cover and tighten bracket screws.
4. To test connection, activate monitor by pressing test
button or opening product water faucet. If an indicator
light illuminates, connection is good.
SERVICING THE SYSTEM
MAINTENANCE - WARRANTY INFORMATION
Recommended Service Intervals Hydrotech® Warranty
Replace filters as required based on Smartap®Water Flow Monitor indications
or every 6 to 12 months depending on feed water quality.
System: 2 years limited
Smartap®: 5 years
FAUCETS
Non-Air Gap Faucet Part Number Non-Air Gap Faucet Part Number Non-Air Gap Faucet Part Number
Stainless Steel, Faucet Only
Stainless Steel, with Light Bar
40301007
11702002
Chrome, Faucet Only
Chrome, with Light Bar
40301002
11702001
Polymer, Plain Front
Polymer, Light Bar
1140010*
1140032*
* Color Suffix Codes: 0 (Chrome/Black), 1 (White), 2 (Chrome/White), 3 (Almond), 4 (Black), 5 (Chrome/Black), 6 (Satin/Black), 7 (Chrome/White), and
8 (Satin/White). Codes 0, 2, 6, and 8 designate electro-plated faucets. Codes 5 and 7 designate vacuum-metalized faucets
PARTS AND SERVICE ARE AVAILABLE THROUGH YOUR HYDROTECH®DEALER.
ROUTINE MAINTENANCE
RECOMMENDATIONS
HAVE ALL COMPONENTS ON HAND AND READY BEFORE BEGINNING PROCEDURE.
A CLEAN WORK AREA AND EQUIPMENT ARE ESSENTIAL TO PROPERLY CLEAN AND/OR SANITIZE THE SYSTEM.
(I.e., CLEAN HANDS, TOOLS, WORK SURFACE, AND CONTAINERS)
SERVICE REQUIREMENTS
To insure the system operates at its optimum level,
certain routine maintenance must be performed.
Frequency of maintenance performance will depend on
feed water quality and level of system usage.
CLEAN: Each time filters are replaced
SANITIZE: At least once every 12
months.
EQUIPMENT NEEDED
Safety glasses
Rubber gloves, sanitary
Wash Cloth, Clean and Lint-free
Household bleach - Unscented Only
(5 1/4% sodium hypochlorite)
Liquid dish soap
Plastic bucket, Plastic bowl
“O” Ring Lube FDA Approved
(P/N 30300026)
REPLACEMENT FILTER SETS “O” RINGS
P/N 41400011 Carbon Filter, VOC Reduction (White Caps)
P/N 41400010 Carbon Filter, Lead Reduction (Black Caps)
P/N 34201010 Carbon Cartridge
P/N 34201026 Filter Housing

12
CLEANING, SANITIZING, AND CARTRIDGE REPLACEMENT PROCEDURE
1. Mix a mild cleaning solution of dish soap and clean
potable water in the plastic bowl.
2. Shut feed water supply valve and open product water
faucet to relieve system pressure.
NOTE: Do not attempt to remove filter housings until water
flow stops. This reduces pressure inside the
system so housings may be safely removed.
3. Remove each filter housing by turning it counter-
clockwise. Remove each filter cartridge as its housing
is removed. Discard filters.
Icemaker:Transfer ice cubes from bin/tray to clean
freezer container for storage until procedure is done.
NOTE: Use sanitary rubber gloves for this procedure to
avoid contaminating sanitizing solution or filters.
Wear gloves whenever cleaning/ sanitizing system
components or handling new filter cartridges.
4. Remove filter housing "O" rings and wash them with
cleaning solution. Rinse them well with clean potable
water. Inspect the "O" rings for damage (i.e., nicks or
scratches). Replace damaged "O" rings.
NOTE: Use caution when cleaning module. Do not get the
Smartap®Flow Monitor electronics, wiring, or
connectors wet.
5. Clean filter housings and manifold ports, inside and
outside with washcloth and cleaning solution. Do not
use abrasive materials.
6. Rinse housings/manifold with clean potable water.
7. Inspect manifold and filter housing "O" ring groove
area for damage (i.e., nicks or scratches). Replace
damaged components.
8. Place a small amount of "O" ring lubricant over the
surface of the filter housing "O" ring. Install the "O" ring
into the filter housing groove.
TO SANITIZE SYSTEM: Complete Steps 9-29.
TO INSTALL FILTERS: Complete Steps 17-29.
CAUTION: WEAR SAFETY GLASSES WHILE
PERFORMING THIS PROCEDURE.
CAUTION: EXCESSIVE CONCENTRATIONS OF
BLEACH WILL DAMAGE PLASTIC AND
RUBBER COMPONENTS. Rinse all parts
that contact bleach thoroughly with clean
potable water.
CAUTION: Read the "WARNINGS" on the bleach
container before using.
CAUTION: Handle sanitizing solution carefully. Avoid
contact with unprotected areas.
9. Mix sanitizing solution of 1.5 ml (1/3 teaspoon) of
household bleach and 3.8 L (1 gallon) of clean, potable
water in the bucket. Mix the solution well.
10. Add 236 ml (one cup or 8 oz.) of sanitizing solution to
each of the filter housings and install them onto the
manifold (do not install filters at this time). Tighten
each filter housing by hand only.
NOTE: TIGHTEN FILTER HOUSINGS BY HAND
ONLY. Do not use tools as they will over-
tighten and damage housings.
11. Slowly open the feed water supply valve.
12. Open product water faucet. Keep open for 5 seconds
after water starts coming out.
13. Close the product water faucet.
14. Wait 30 minutes, open product water faucet and let
water flow 5 minutes.
15. After 5 minutes, close feed water supply valve and
allow water to flow until system pressure is relieved.
NOTE: Do not attempt to remove filter housings until water
flow stops. This reduces pressure inside the
system so housings may be safely removed.
16. Remove the filter housings and dispose of the water.
Rinse housings and manifold ports thoroughly with
clean potable water.
NOTE: Do not remove protective plastic bag from filters.
Open the top of the bag only enough to expose the
top cap and "O" rings. Place a small amount of
“O” ring lubricant on surface of each “O” ring.
17. Install the filter cartridges. Hold cartridge by its
protective plastic bag and insert the cartridge into the
manifold turning it 1/2 turn as it enters the port (See
Page II, Figure 1 for location of each cartridge).
Slide bag from cartridge and discard. Replace each
filter housing as each cartridge is installed.
NOTE: TIGHTEN FILTER HOUSINGS BY HAND
ONLY. Do not use tools as they will over-
tighten and damage housings.

13
CLEANING, SANITIZING, AND CARTRIDGE REPLACEMENT
NO WATER FLOW MONITOR:
Complete Steps 26 - 29
OPTIONAL SMARTAP®WATER FLOW MONITOR:
Complete Steps 18 – 29
NOTE: The water flow monitor and battery are mounted
inside the manifold cover.
Monitor must be reset to zero each time system is
serviced and cartridges replaced.
If monitor is not reset, there is no way to determine
when filters were changed or if the system is still
operating within specifications.
Monitor is reset when the battery is disconnected
from the clip.
Installing a new battery when filter cartridges are
replaced ensures an accurate indication of system
performance and a continuing supply of high
quality drinking water.
Failure to replace battery may result in yellow light
when system is reconnected.
Use caution when working with module. The
wiring therein connects the control board to the
sending unit. If these wires are damaged, the
monitor will not function.
Do not get the monitor components wet (includes
circuit board, phone jack, and battery connections).
18. Loosen three mounting bracket screws. Gently pull
module cover up and away from module body.
19. Disconnect the battery. The connection to the battery
is a snap type connector (See Figure 11).
20. Remove the battery by sliding it out of its holder.
21. Replace the battery with a new alkaline 9-volt transistor
battery (P/N 31300001).
22. Carefully slide the battery into its holder.
NOTE: Use caution when reconnecting the battery (See
Figure 11).
23. Reconnect the battery by pressing the clip onto the
battery terminals.
24. Replace the module cover and tighten bracket screws.
25. Turn feed water valve slowly to the open position.
26. To test the connections, activate the Smartap®monitor
by pressing the test button or opening the product
water faucet. If an indicator light illuminates,
connections are good.
27. Open product water (and extra point-of-use) faucet.
Let water flow until all air has been expelled from
system.
28. Close product water (and extra point-of-use) faucet. In
5 minutes, check the connections for leaks and correct
if necessary.
Icemaker: Let the tray/bin fill with ice cubes. Discard
all ice cubes to the drain. This flushes sanitizing
solution from the lines to the icemaker.
29. Open product water (and extra point-of-use) faucet.
Let the water flow for 10 minutes. This will expel any
remaining air from the system.
NOTE: The system is ready to use. Should there be any
aftertaste or odor to the water or ice cubes, repeat
Step 29.
Figure 11 Smartap®Battery Connection

14
TROUBLE SHOOTING GUIDE
AQUAFIER®FILTRATION SYSTEM
Symptom Probable Cause Solution
No water. Water supply is turned OFF. Turn water ON.
Not enough water. Water supply is blocked.
Clogged filter cartridges are restricting water
flow.
Clear restriction, rotate valve handle on tap
water feed valve.
Replace filter cartridges.
Water has an offensive taste and/or odor. Filters depleted. Replace filters, clean and sanitize system.
Leak at fitting. Tubing not pushed completely into fitting.
Defective tube.
Worn or damaged "O" Ring.
Push tube into fitting past "O" Ring seal.
Cut damaged area off of tube or replace tube.
(refer to Page 1, Figure 2)
Replace "O" Ring*.
Leak at filter housing. "O" Ring has not seated.
"O" Ring has nick or scratches.
Lube and Reseat "O" Ring*.
Replace "O" Ring *.
Leak at saddle tapping valve. Loose clamp.
Tubing deformed.
Tighten clamp screws, do not crush source
water tubing.
Cut damaged area off of tube or replace tube
and sleeve.
* Always check there is adequate lubricant (P/N 30300026) on "O" Rings before installation.
OPTIONAL SMARTAP®WATER FLOW MONITOR
Symptom Probable Cause Solution
Yellow Service Light. Filters depleted.
Battery not replaced when filters changed.
Replace filters.
Replace battery.
No Lights. Light assembly is not connected. Plug connector into phone jack.
CAUTION: Change the battery only when changing the filters as removal and replacement of the battery resets the Aquafier®monitor.
CAUTION: Change the battery each time the filters are changed. If battery is not replaced, user/technician cannot determine system status within
cycle.
Table 2 System Troubleshooting Indicators, Common Solutions, and Correction Procedures

15
INSTALLATION AND SERVICE RECORD
DATE INSTALLED SYSTEM: SERVICE FLOW 0.5 GPM
DATE SERVICED SERVICED BY COMPANY
SERVICE PERFORMED ڤCLEANING ONLY ڤCLEANING & SANITIZING ڤREPAIR
FILTERS REPLACED ڤCARBON Pb1 LEAD ڤCARBON 5s VOC's
COMMENTS
DATE SERVICED SERVICED BY COMPANY
SERVICE PERFORMED ڤCLEANING ONLY ڤCLEANING & SANITIZING ڤREPAIR
FILTERS REPLACED ڤCARBON Pb1 LEAD ڤCARBON 5s VOC's
COMMENTS
DATE SERVICED SERVICED BY COMPANY
SERVICE PERFORMED ڤCLEANING ONLY ڤCLEANING & SANITIZING ڤREPAIR
FILTERS REPLACED ڤCARBON Pb1 LEAD ڤCARBON 5s VOC's
COMMENTS
DATE SERVICED SERVICED BY COMPANY
SERVICE PERFORMED ڤCLEANING ONLY ڤCLEANING & SANITIZING ڤREPAIR
FILTERS REPLACED ڤCARBON Pb1 LEAD ڤCARBON 5s VOC's
COMMENTS

8Copyright 2001 Hydrotech, Inc. Form IGAQ-02 09/01
Part No. 36101004
LIMITED WARRANTY
Subject to the conditions and limitations described below, Hydrotech® warrants its Aquafier® Model 104 Series
Reverse Osmosis Drinking Water Treatment Systems (excluding cartridge filters and battery), when installed in
accordance with Hydrotech® specifications, to be free from defects in materials and workmanship under normal
use within the operating specifications for a periods of two (2) years from the date of purchase. Hydrotech® also
warrants the Smartap® Water Quality Monitor to be free from defects in materials and workmanship under normal
use within the operating specifications for a periods of five (5) years from the date of purchase. This warranty
shall apply only to the original end-user of the drinking water system.
Other than the cartridge filters and battery, any part found defective within the terms of this warranty will be
repaired or replaced by Hydrotech®. If any part is found defective, Hydrotech® also reserves the right to replace
the drinking water appliance with a comparable Hydrotech®drinking water system of equal or greater quality. You
pay only freight for repaired or replaced parts from our factory and local dealer charges, including but not limited
to labor charges, travel and transportation expenses and handling fees.
This warranty shall not apply to any part damaged by accident, fire, flood, freezing, Act of God, bacterial attack,
sediment, misuse, misapplication, neglect, alteration, installation, or operation contrary to our printed instructions,
or by the use of accessories or components which do not meet Hydrotech® specifications. If the drinking water
system is altered by anyone other than Hydrotech®, the warranty shall be void.
ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THE PERIOD
SPECIFIED ABOVE FOR THE PARTS DESCRIBED IN THIS LIMITED WARRANTY.
As a manufacturer, we do not know the characteristics of your water supply. The quality of water supplies may
vary seasonably or over a period of time. Your water usage may vary as well. Water characteristics can also
change if the drinking water appliance is moved to a new location. For these reasons, we assume no liability for
the determination of the proper equipment necessary to meet your requirements, and we do not authorize others
to assume such obligation for us. Further, we assume no liability and extend no warranties, express or implied,
for the use of this product with a non-potable water source or a water source which does not meet the conditions
for use as described in this Owner’s Guide.
HYDROTECH’S OBLIGATIONS UNDER THIS WARRANTY ARE LIMITED TO THE REPAIR OR
REPLACEMENT OF THE FAILED PARTS OF THE DRINKING WATER SYSTEM, AND WE ASSUME NO
LIABILITY WHATSOEVER FOR DIRECT, INDIRECT, INCIDENTAL, CONSEQUENTIAL, SPECIAL, GENERAL
OR OTHER DAMAGES, WHETHER FROM CORROSION OR OTHER CAUSES.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply
to you. Similarly, some states do not allow the exclusion of incidental or consequential damage, so the above
limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may have other
rights that vary from state to state.
Hydrotech, Inc.
25555 West Avenue Stanford, Valencia, CA 91355
Phone [phone] Fax [phone]
