hyfire ALTAIR LITE Series User manual

HFI-TAE-05
ANALOGUE CLASS P THERMAL DETECTOR
ALTAIR LITE SERIES
LOOP IN (+)
LOOP IN (-)
LOOP OUT (+)
LOOP OUT (-)
SHIELD
Figure 2
Hyfire Wireless Fire Solutions Limited - Unit B12a, Holly Farm Business Park, Honiley,
Warwickshire, CV8 1NP - United Kingdom
www.hyfirewireless.com
928d/03
[email protected] L20-A350L-1400 (vA.5)
GENERAL DESCRIPTION
This type of detector (figure 1) continuously samples the temperature variation in the protected
area to provide the earliest warning of fire, offering, at the same time, a high level of false alarm
rejection.
These detectors are designed for an open area protection and must only be connected to control
panels that use the Altair analogue-intelligent addressable communication protocol for monitoring
and control, providing high rates of information exchange and fast and secure responses.
Note: Before installing this device please thoroughly read this leaflet and refer to the applicable
European Standards and National Codes of Practice (e.g. BS5839-1:2002 for UK) for guidance on
location, spacing and acceptable use. Also seek guidance from the compatible control panel
instructions to ensure appropriate design criteria and configuration specifications are followed.
INSTALLATION
For the installation to the ceiling, the detector must be mounted only on the compatible adaptor bases listed in the “TECHNICAL
SPECIFICATIONS” table. Refer to the specific base’s literature for further details.
WIRING
After having installed the base to the ceiling, wiring has to be carried out in order to connect the base to the analogue loop and, so, to
the installation.
Analogue loop wires must be correctly connected to the base’s terminals: check the performed wiring by referring to the figure 2
diagram.
Figure 1
REMOTE OUTPUT CAPABILITY
Remote output capability is available as a standard feature, so a
remote indication lamp or a compatible slave platform sounder
(check power requirements and loop drive limits) may be wired to
the base terminals (Figure 3).
If other equipment is connected to the remote output, its
supply current must be eventually limited by using an ade-
quate resistor. Consult the TECHNICAL SPECIFICATIONS
table and assess the external device current absorption’s
value.
DEVICE PROGRAMMING - ADDRESS SETTING
Detectors can be addressed using a special hand-held program-
ming unit. Addresses may be selected from a range from 1 to 240,
although, of course, each device on the loop must have a unique
address.
Automatic addressing by the control panel cannot be performed
with this type of device.
DEVICE PROGRAMMING - THERMAL SENSITIVITY SETTING
A choice of two thermal sensitivity levels is available; these two
levels correspond to a Rate Of Rise (ROR) A1R class (most
sensitive) and to a class BS (least sensitive), according to the EN
54 part 5 European normative.
Sensitivity level can be selected through a hand-held program-
ming unit or, if such feature is provided, directly through the
control panel.
DETECTOR PLACEMENT
1) Position the detector centrally on its adaptor base ensuring it is
level.
2) Rotate clockwise applying gentle pressure. The detector will drop into its keyed
location.
3) Continue to rotate clockwise a few degrees until the detector has fully engaged in
the adaptor base (figure 4).
4) When the detector is firmly engaged, check the alignment of the raised reference
marks on the detector and on the base (figure 5).
IMPORTANT NOTES ON DETECTORS PLACEMENT
Disconnect loop power before installing the detector.
Dust covers help to protect the devices during shipping and when first installed.
They are not intended to provide complete protection against contamination, there-
fore, detectors should be removed before construction, major re-decoration or other
dust producing work is started. Dust covers must be removed before the system can
be made operational.
Figure 5
Figure 4
REMOTE
ALARM (+)
REMOTE
ALARM (-)
Figure 3

MAINTENANCE
Before starting any maintenance work, isolate and disable the system in order to avoid accidental and unwanted alarm or fault condi-
tions.
Remove the detector from its mounting base to allow inspection in good light at ground level.
Inspect the thermistor area and use a small, soft bristle brush to dislodge any evident contaminants such as insects, spider webs,
hairs, etc. Use a small vacuum tube or clean, dry and compressed air to suck up or blow away any remaining small particles from the
thermistor area. Wipe the exterior housing of the detector with a clean, damp, lint free cloth to remove any surface film tha t can later
attract airborne contaminants.
After all detectors have been inspected, repositioned on their mounting bases and power has been re-applied, check correct opera-
tion by testing the device.
TECHNICAL SPECIFICATIONS **
* Product operates
down to 15 V, but without LED indication.
** Further technical data: see document TDS-A350L held by the manufacturer.
WARNINGS AND LIMITATIONS
Our devices use high quality electronic components and plastic materials that are highly
resistant to environmental deterioration. However, after 10 years of continuous operation,
it is advisable to replace the devices in order to minimize the risk of reduced performance
caused by external factors. Ensure that this device is only used with compatible control
panels. Detection systems must be checked, serviced and maintained on a regular basis
to confirm correct operation.
Smoke detectors may respond differently to various kinds of smoke particles, thus
application advice should be sought for special risks. Detectors cannot respond correctly
if barriers exist between them and the fire location and may be affected by special envi-
ronmental conditions. Refer to and follow national codes of practice and other interna-
tionally recognized fire engineering standards. Appropriate risk assessment should be
carried out initially to determine correct design criteria and updated periodically.
WARRANTY
All devices are supplied with the benefit of a limited 5 years warranty relating to faulty
materials or manufacturing defects, effective from the production date indicated on each
product.
This warranty is invalidated by mechanical or electrical damage caused in the field by
incorrect handling or usage. Product must be returned via your authorized supplier for
repair or replacement together with full information on any problem identified.
Full details on our warranty and product’s returns policy can be obtained upon request.
Hyfire Wireless Fire Solutions Limited - Unit
B12a, Holly Farm Business Park, Honiley,
Warwickshire, CV8 1NP - United Kingdom
EN 54-5:2000 + A1:2002
HFI-TAE-05
For use in compatible fire detection and alarm
system.
Class A1R and BS (class P)
Power supply *from 18 V (min) to 40 V (max)
Average standby current consumption 45 uA @ 24 V
Remote output max current consumption (externally limited) 20 mA
Compatible adaptor bases HFI-DMBS-05 - “Low Profile Adaptor Base”
Thermal alarm threshold (ROR A1R class) 58 °C
Thermal alarm threshold (BS class) 78 °C
Operating temperature range -30 °C / +70 °C (no icing)
Humidity 95% RH (no condensation)
ANTI -TAMPER DETECTOR LOCK
The detector can be locked to its base as a deterrent to intentional removal performed by non authorized personnel.
Using a cutter, remove the anti-tamper plastic detail, as illustrated in figure 6.
To unlock the detector, insert the tip of a screwdriver into the side slot of the base by exerting only a light pressure (figure 7), and
release the detector by turning it anticlockwise.
LED INDICATORS
This detector is equipped with two red LEDs; their flash pattern indicate the present condition of
the detector itself:
Blinking: indicates the normal operative status of the detector; the performance of this pattern
depends upon the control panel’s model and its settings.
Continuous: indicates an alarmed condition of the detector.
Fault conditions are not indicated by LEDs, but only on the control panel.
Positioning of these LEDs is illustrated in figure 8.
IDENTIFICATION TAB
The adaptor base is equipped with a plastic tab where identification data can be visibly displayed.
Detach the tab from the base; write or label it with the required information, then insert it into its adaptor base’s slot.
TESTING THE DETECTORS - PRELIMINARY NOTE
Detectors should be tested after installation and during periodic maintenance visits; it is recommended each device should be tested
at least once per year.
After each test reset the system and allow at least one minute for power stabilisation.
HEAT TEST
Use a hair dryer of 1000-1500 W or an heat tool from an approved manufacturer. Direct the heat towards the detector from its side.
Hold the heat source at about 15 cm away from the detector in order to prevent damage to its cover during testing.
The detector should trigger an alarm message to the control panel, and, successively, the detector’s red LED should be activated by
the control panel itself.
Figure 8
Hyfire Wireless Fire Solutions Limited - Unit B12a, Holly Farm Business Park, Honiley,
Warwickshire, CV8 1NP - United Kingdom
www.hyfirewireless.com [email protected] L20-A350L-1400 (vA.5)
Figure 6Figure 6
Figure 7
2831 0832
14
HF-20-008CPR
21
HF-20-008UK
Figure 9
