hyfire HFW-MA-05 User manual

OVERVIEW
This detector model samples the air and the environmental temperature in the protected area. An alarm condition is raised when the detected
environmental smoke quantity, the temperature level or the thermal variation rate exceeds the alarm threshold.
COMPATIBILITY
This detector is compatible only with wireless systems based on the Sagittarius protocol.
For more specific information concerning compatibility refer to your fire security system supplier.
INSTALLATION - IMPORTANT NOTES
For detector spacing, placement and special applications refer to your specific national standards.
Mount the detector as far as possible from metal objects, metal doors, metal window openings, etc. as well as cable conductors, cables
(especially from computers), otherwise the operating distance may greatly drop. The detector must NOT be installed near elect ronic devices
and computer equipment that can interfere with its wireless link quality.
This detector must be installed according precisely to the procedures described in this manual.
Test this detector after installation.
BEFORE INSTALLING THE DETECTOR
1) Extract the batteries cover from the back of the detector.
2) Power-up the detector removing the isolating tab in the battery
housing. LED indicators signal “Power up”.
3) Link the detector to the Sagittarius wireless system (LINKING).
4) Check the WIRELESS LINK QUALITY.
5) SELECT A GOOD LOCATION FOR THE DETECTOR.
6) Tag device’s loop and address data (IDENTIFICATION).
7) Fix the detector supporting base to the wall (BASE INSTALLATION).
LED INDICATORS
Picture 1: provide visual indication for functional conditions and battery levels as indicated in
table 1.
Hyfire Wireless Fire Solutions Limited - Unit B12a, Holly Farm Business Park, Honiley,
Warwickshire, CV8 1NP - United Kingdom
www.hyfirewireless.com
HFW-MA-05
BI-DIRECTIONAL WIRELESS ADDRESSABLE MULTICRITERIA
DETECTOR WITH VARIABLE SENSITIVITY
LED INDICATORS
Picture 1
928m/02
Table 1
Detector’s status LEDs indication
Power up 1 second GREEN, then 4 X 0.5 second RED blink
Linking to the system Blinking GREEN until linking is completed
Link failure RED on (continuous)
Normal condition LEDs off
Alarm Blinking RED: 0.5 second on and 0.5 second off
Battery 1 fault 0.1 second ORANGE blink, then 5 seconds off
Battery 2 fault 0.1 second GREEN blink, then 5 seconds off
Both batteries fault
0.1 second ORANGE, then 5 seconds off
0.1 second GREEN, then 5 seconds off
Other fault sequential ORANGE / GREEN 0.5 second blinking
Tamper LEDs off
Lost link with wire to
wireless translator /
wireless expander
LEDs off
Type 1 Test Mode Blinking GREEN every 1 second for 1 minute
Type 2 Test Mode GREEN on (continuous) for 30 minutes

LINKING
The system is waiting to achieve a wireless child device (for further information
refer to the translator’s or the Wirelex configuration software’s literature):
1) Move the link switch’s cursor from ON to the opposite side of its run (we will
call it BLANK, since it carries no indication). LED indicators signal “Linking to the
system” (picture 2).
Linking is successful when:
a) the translator indicates so (check translator’s literature)
OR
b) the Wirelex software indicates so (check the Wirelex’s literature).
If linking is unsuccessful:
2) Check if evident mistakes were made.
3) Perform the LINKING RECOVERY.
LINKING RECOVERY
1) Take out both batteries from their holders
2) Move alternatively the link switch to ON / BLANK five times (picture 2)
3) Move the link switch to ON
4) Reinsert both batteries into their holders, oriented as per polarity marks
5) Perform the LINKING procedure.
DETECTOR SENSITIVITY SETTINGS
During installation using the Wirelex software it’s possible to set the smoke sensitivity and the heat class of the detector (see tables 4 and 5).
Otherwise if the installation is performed manually through the translator keyboard, default setting will be applied.
WIRELESS LINK QUALITY
It is possible to check wireless link quality between the detector and its linked-to translator or expander in this way:
1) Move the link switch to the ON position.
2) LED indicators will start blinking according to the following table:
3)
NOTE: Ensure the link switch is returned to the "BLANK" (operational) position on completion of testing.
SELECT A GOOD LOCATION FOR THE DETECTOR
Choose for the detector a placement position that:
- compliances with your specific standards
- is reached by a strong wireless signal from its linked-to
translator or expander module
- is not interfered by environmental factors.
IDENTIFICATION
For identification purposes, analogue loop number and device’s
address can be recorded on the plastic tag supplied with the
base (picture 3).
Extract the plastic tag from the bottom of the base, write or label
identification data on it and, finally, insert it in the side slot of the
base.
[email protected] L20-LMCXX-1400 (vA.4)
Table 2
Picture 3
Communication quality Assessment Device’s indication
No communication Fail Two red blinks
Communication quality: 0 dB - 10 dB (Mark 2) Poor, not acceptable One red blink
Communication quality: 10 dB - 20 dB (Mark 3) Medium-low, not recommended One green blink
Communication quality: 20 dB - 30 dB (Mark 4) Good Two green blinks
Communication quality: > 30 dB (Mark 5) Excellent Two green blinks
During the linking phase, the
detector must be positioned
close to the aerial (within a
few centimeters) of the translator or
expander to which it is being linked.
Picture 2
Link switch

BASE INSTALLATION
Fix the base to the wall with the provided screws (picture 4).
DETECTOR PLACEMENT
1) Install the batteries cover.
2) Position the detector centrally on the base
ensuring it is level.
3) Rotate clockwise applying gentle pressure.
The detector will drop into its keyed location.
4) Continue to rotate clockwise a few degrees
until the detector has fully engaged in the
base.
5) When the detector is firmly engaged, check
the alignment of the raised reference marks
on the detector and on the base (picture 5).
DETECTOR LOCKING
To lock the detector to the base, screw in the provided security screw; screw entry is locat-
ed on the side of the detector’s base (picture 6).
TAMPER DETECTION
When the detector is detached from the base a tamper message event is sent to the control panel.
TESTING
Test this detector after installation.
After each test reset the fire security system from the control panel, as per your control panel in-
structions.
TEST MODES
Test modes make the HFW-MA-05 more reactive to aerosol stimulus; two test mode types are
provided:
Type 1 Test Mode - triggered by a test magnet; persists for 1 minute. This mode makes the detector
almost instantaneously alarm agent reactive.
Type 2 Test Mode - remotely triggered by the Wirelex program; persist for 30 minutes. This mode
makes the detector as reactive to smoke as an optical smoke detector, simulating it.
TEST 1 - MAGNET TEST
1) Hold a suitable magnet in correspondence of the indicated area (picture 7)
2) LED indicator will signal “Type 1 Test Mode”
3) Apply again the magnet in correspondence of the indicated area (picture 7)
4) LED indicator will signal “Alarm”
TEST 2 - AEROSOL TEST
Use only suitable aerosol testers supplied by approved manufacturers.
1) Hold a suitable magnet in correspondence of the indicated area (picture 7)
2) LED indicator will signal “Type 1 Test Mode”
3) By following its specific instructions, apply the aerosol test device to the detector
4) Wait a few seconds
5) LED indicator will signal “Alarm”
TEST 3 - AEROSOL TEST
Use only suitable aerosol testers supplied by approved manufacturers.
1) Remotely activate the detector’s green LED from the Wirelex program
2) LED indicator will signal “Type 2 Test Mode”
3) By following its specific instructions, apply the aerosol test device to the detector
4) Wait a few seconds
5) LED indicator will signal “Alarm”
TEST 4 - HEAT TEST
Use only suitable heat test devices from approved manufacturers.
1) By following its specific instructions, apply the heat test device to the detector.
2) Wait a few seconds.
3) LED indicator will signal “Alarm”.
Picture 5
Dust covers DO NOT provide
complete protection against
contamination: detectors
should be removed before construc-
tion, major re-decoration or other dust
producing work is started.
Dust covers MUST be removed before
the system can be made operational.
Hyfire Wireless Fire Solutions Limited - Unit B12a, Holly Farm Business Park, Honiley,
Warwickshire, CV8 1NP - United Kingdom
www.hyfirewireless.com
Picture 4
Picture 6
Picture 7

MAINTENANCE - CLEANING
1) Remove the detector from its base.
2) Smoke entry areas and thermistor area: use a small,
soft bristle brush to dislodge any obvious contaminants
such as insects, spider webs, hairs, etc.
3) Smoke entry areas and thermistor area: use a small
vacuum tube or dry, clean, compressed air to suck up or
blow any remaining small particles away.
4) Wipe the exterior housing of the detector with a clean,
damp, lint-free cloth to remove any surface film that can
later attract airborne contaminants.
5) Install the detector onto its base again.
6) Test the detector.
MAINTENANCE - BATTERY REPLACEMENT
When a low battery condition is indicated,
both batteries must be changed altogether.
During this procedure the linking switch must NOT
be touched at all !
1) Detach the detector from its base.
2) Extract the batteries cover.
3) Extract the batteries.
4) Insert the new batteries into their holders,
oriented as per polarity marks.
5) Reinstall the batteries cover.
6) Reinstall the detector onto its base.
7) Test the detector.
[email protected] L20-LMCXX-1400 (vA.4)
Table 3
TECHNICAL SPECIFICATIONS **
Communication range with the
translator or expander 200 m Open space
Operating frequency 868 MHz
Operating frequency channels 7
Radiated power ≤ 14 dBm (25 mW)
Batteries type* Type CR123A (3 Vdc) 8.2 years life
Parent expander’s check-up period 60 seconds (default setting)
Alarm threshold temperature.
Class A1R ROR 58 °C
Alarm threshold temperature.
Class B - high temperature 78 °C
Dimensions 110 mm x 65 mm
Weight 190 g Base and batteries
included
IP rating 40
Max tolerated humidity
(no condensing) 95% RH
Operating temperature range From –10 °C to +55 °C
WARNINGS AND LIMITATIONS
Our devices use high quality electronic components and plastic materials that are highly resistant to
environmental deterioration. However, after 10 years of continuous operation, it is advisable to
replace the devices in order to minimize the risk of reduced performance caused by external factors.
Ensure that this device is only used with compatible control panels. Detection systems must be
checked, serviced and maintained on a regular basis to confirm correct operation. Smoke detectors
may respond differently to various kinds of smoke particles, thus application advice should be sought
for special risks. Detectors cannot respond correctly if barriers exist between them and the fire
location and may be affected by special environmental conditions. Refer to and follow national codes
of practice and other internationally recognized fire engineering standards. Appropriate risk assess-
ment should be carried out initially to determine correct design criteria and updated periodically.
WARRANTY
All devices are supplied with the benefit of a limited 3 years warranty relating to faulty materials or
manufacturing defects, effective from the production date indicated on each product. This warranty is
invalidated by mechanical or electrical damage caused in the field by incorrect handling or usage.
Product must be returned via your authorized supplier for repair or replacement together with full
information on any problem identified. Full details on our warranty and product’s returns policy can
be obtained upon request.
Hyfire Wireless Fire Solutions Limited - Unit
B12a, Holly Farm Business Park, Honiley,
Warwickshire, CV8 1NP - United Kingdom
EN 54-25:2008
EN 54-5:2000
Class A1R
EN 54-7:2000+A1:2002+A2:2006
CEA 4021:2003
HFW-MA-05
For use in compatible fire detection and alarm
system
SMOKE SENSITIVITY (EN 54)
Threshold level Wirelex setting Notes
Level 1 High
Level 2 Normal default
Level 3 Low
THERMAL SENSITIVITY (EN 54)
Detector Class Wirelex setting Notes
A1R A1R default
BS High temperature Non-approved
NOTE OF THE DOCUMENT:
Hyfire Wireless Fire Solutions hereby declares that this detector is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC. A copy of the original Declara-
tion of Conformity
(Document: DoC LI01) is made available to the user on website: www.argussecurity.it
Table 4
Table 5
* When a low battery condition is indicated, both batteries must be changed for new cells.
Lifespan of batteries indicated is subject to standard environmental conditions, default
monitor settings and excellent link quality.
** Check latest version of document TDS-LMCXX for further data, obtainable from your
supplier.
2831/0051/0681 0832
17
HF-20-004CPR
21
HF-20-004UK
