EDGE Pro CNC Field Service Bulletin 808110 Revision 1 3
Wireless networking for EDGE Pro CNCs
Introduction
The Hypertherm EDGE Pro CNC supports the addition of wireless networking for part downloads, Remote Help, and
other network tasks. This Field Service Bulletin applies to kit number 228835 and provides instructions for:
Installing the 141482 wireless network card into the motherboard of the EDGE Pro CNC.
Mounting the antennas and routing the antenna wiring to the wireless card.
Verifying that the Windows®operating system has connected to the network card and wireless network.
Mapping a network drive in Windows and in Phoenix.
This FSB describes only how to install the wireless network card. Refer to your EDGE Pro Instruction Manual for more
detailed information about how to set up a network or workgroup.
Materials and tools
#2 Phillips screwdriver
Drill with 6.5 mm (0.25 inch) bit (for installing antennas on the CNC enclosure)
8 mm (5/16 inch) wrench
The following procedures require operating knowledge of Hypertherm’s computer numerical controls (CNCs). If
necessary, refer to the instruction manual for detailed information on your CNC.
Kit 228835 Contents
(1) 141482 wireless network card with antennas.
(1) 229919 USB flash drive with Netis driver.
(2) 223250 0.3 m (12 inches) coaxial cable extensions with bulkhead-mount connectors.
The CD enclosed with the wireless network card is not needed for this installation. The hardware drivers are on
the USB flash drive stick provided with the kit.
DANGER!
ELECTRIC SHOCK CAN KILL
Disconnect electrical power before performing any maintenance.
See the Safety section of the system’s manual for more safety precautions.

4EDGE Pro CNC Field Service Bulletin 808110 Revision 1
Wireless networking for EDGE Pro CNCs
Installing the wireless network card
1. Turn OFF AC power to the CNC.
2. Open the EDGE Pro CNC enclosure by removing the 6 screws, then open the front door.
3. Remove the screw holding the metal plate on PCI slot 2. Keep the screw and discard the metal plate.
4. Install the wireless network adapter into PCI slot 2 on the motherboard. DO NOT install the network card into PCI
slot 1.
5. Secure the network card to the EDGE Pro CNC using the screw from the metal plate that you removed earlier.
6. Remove the left side panel of the enclosure so you can access the connectors for the coaxial antenna cables.
CAUTION!
Static electricity can damage circuit boards. Use proper precautions when handling printed circuit
boards.
Store PC boards in anti-static containers.
Wear a grounded wrist strap when handling PC boards.
PCI 2

EDGE Pro CNC Field Service Bulletin 808110 Revision 1 5
Wireless networking for EDGE Pro CNCs
Preparing to install the antenna
Follow these guidelines before mounting the antennas on a CNC enclosure:
The antennas must exit to room air, preferably without metallic obstructions blocking signal transmission (such as
equipment cabinets, circuit breaker panels, transformers, etc).
Antennas should not be located near the floor.
Use a plastic protective barrier if necessary to prevent accidental bumping of antenna orientation.
You must drill two holes to accommodate the threaded, bulkhead-mount antenna connectors, as described in the
next section. Verify that the connectors make contact with the metal on the enclosure, or use a lock washer to
penetrate any coating on the enclosure. Metal-to-metal contact ensures that the antennas are grounded to the
chassis.
The antenna connections are not waterproof.
Installing the antenna
When you install the antenna:
Make sure not to twist or kink the extension cables.
The extension cables should reside entirely inside the enclosure. Only the antenna itself should be on the outside of
the enclosure.
1. Drill two 6.35 mm (0.25 inch) holes in the CNC enclosure as shown in the following illustration.
Prevent metal fragments from entering the enclosure.
Remove any metal burrs on the inner and outer surface of the enclosure.
6.30 mm
(0.25 inch)
diameter
28.32 mm
(1.12 inch)
35.56 mm
(1.40 inch)
34.80 mm
(1.37 inch)

6EDGE Pro CNC Field Service Bulletin 808110 Revision 1
Wireless networking for EDGE Pro CNCs
2. Remove the lock washer and nut from the bulkhead-mount of each cable end.
3. Thread each bulkhead-mount cable end through a hole and secure it with the lock washer and nut tightened to
10 inch-pounds.
Use an 8 mm (5/16 inch) wrench to tighten the nut to the enclosure.
Verify that the antenna base makes contact with unpainted metal on the enclosure to verify proper grounding.
4. Connect the antennas to the cable bases on the outside of the enclosure and orient them vertically.
5. Connect the other end of the cables to the coaxial connectors on the wireless network board.
Finger-tip tighten the nut on each cable to the coaxial connector.
Avoid twisting or kinking the cables.
The entire extension cable should be within the CNC enclosure. Only the antennas are mounted on the outside
of the enclosure.
6. Replace the side panel and re-fasten the screws.
7. Close the front door and re-fasten the screws.
Installing the driver
Load the driver from the USB flash drive if prompted.
1. Plug in the USB memory stick from the kit.
2. Plug in a USB keyboard.
3. Restore AC power to the CNC.
4. If the “Found New Hardware Wizard” pops up, click Cancel. Do NOT interact with the pop-up.

EDGE Pro CNC Field Service Bulletin 808110 Revision 1 7
Wireless networking for EDGE Pro CNCs
5. Load the driver as follows:
a. Press ALT+F4 to exit Phoenix.
b. Click the Windows Start icon (or the Windows key on the keyboard).
c. Choose Windows Explorer > My Computer.
d. Choose USB disk (E:).
Note: Your drive letter may vary. Be sure to choose the USB disk.
e. Locate and double-click on the 081333.exe file.
f. Follow the prompts to install the driver.
g. Wait for the pop-up message that states “Install shield wizard complete” and then click finish.
h. Restart the CNC for the driver to take effect.

8EDGE Pro CNC Field Service Bulletin 808110 Revision 1
Wireless networking for EDGE Pro CNCs
Verifying the wireless network in Windows
If the EDGE Pro CNC is shipped from the factory with the wireless network card drivers installed, verify the wireless
network in Windows:
1. Turn ON the EDGE Pro CNC.
2. In Phoenix, choose Setups > Password and enter the Special Setups password.
3. Choose System > Network Tools. The Network Connections dialog opens showing all network connections.
4. If a wireless network connection does not display and Windows does not load the required drivers automatically,
contact Technical Support.

EDGE Pro CNC Field Service Bulletin 808110 Revision 1 9
Wireless networking for EDGE Pro CNCs
Disabling unused network connections
If you have a wired network that is set up for automatic configuration but is not connected, you must disable the adapter
for this network to prevent connection delays for the CNC.
NOTE: If you have a Hypernet connection, DO NOT disable it. Hypernet is used to communicate with a plasma
system or the ArcGlide THC, but not with other computers on a network.
1. Press Alt+F4 to exit Phoenix.
2. Choose Start > Settings > Network Connections.
3. Right-click a network adapter that is not being used and choose Status. The status window for the adapter opens.
4. Choose Disable, then Close to disable the network adapter.

10 EDGE Pro CNC Field Service Bulletin 808110 Revision 1
Wireless networking for EDGE Pro CNCs
Mapping a network drive
Phoenix requires a networked folder to be defined in Windows. After you define the network folder, you can add it as a
folder in Phoenix.
Before you begin, connect a USB keyboard to the EDGE Pro CNC.
1. Press Alt+F4 to exit the Phoenix software.
2. Choose Start Menu > Windows Explorer > Tools > Map Network Drive.
3. Choose a drive letter, then the folder. Make note of the folder path. When you connect to the folder in Phoenix, you
will need to enter the folder path, also known as the UNC address.
4. Choose Reconnect at logon.
5. Choose Finish to save the mapped network drive.

EDGE Pro CNC Field Service Bulletin 808110 Revision 1 11
Wireless networking for EDGE Pro CNCs
Adding a folder in Phoenix
The Add Folders feature must be enabled in the Special Setups screen before you can perform these steps.
1. Restart the Phoenix software.
2. From the Main Screen, choose the Files soft key.
3. Double-click the blue message to add a folder.
4. Choose Mapped Drive.
5. Enter a Drive Name. This is the name that appears in the Load Files list.
6. Enter the path to the folder that contains the files. The path is formatted \\servername\foldername.
7. Choose OK.

12 EDGE Pro CNC Field Service Bulletin 808110 Revision 1
Wireless networking for EDGE Pro CNCs
Wireless troubleshooting
Follow these guidelines if you are experiencing problems using the wireless network on your CNC.
The wireless network card requires a bus mastering slot on the motherboard. On the EDGE Pro motherboard
(141110), PCI slot 1 is not a bus mastering slot. Make sure the wireless card is installed in PCI slot 2.
The wireless network card conforms to 802.11N and 802.11G standards and connects to either a wireless G or N
local area network (LAN). It provides wireless G or better performance for part program downloads, remote Help, or
other network tasks.
An 802.11G wireless network can operate at reasonable speeds up to 38 m (125 feet) from the wireless router
or access point, even if the path between the CNC and the access point is obstructed with a wall or door.
An 802.11N wireless network can operate at reasonable speeds up to 70 m (230 feet) from the wireless router
or access point. However, 802.11N requires a clear line of sight between antennas.
When in doubt, use the 802.11G wireless network connection.
The network must be set to broadcast its SSID for it to be visible as a connection.
Make sure the wireless network card appears in the Windows Device Manager under the “Network Adapters”
heading, and does not have a yellow ! or ? next to it.
Use the Windows Network Connections Manager to locate your router or wireless network access point. Choose
Start > Settings > Network Connections.
If the network connection wizard does not list any company wireless networks, check the network availability using a
Windows XP laptop or other wi-fi device to verify the router or access point connection is available at that physical
location.
Signal strength diminishes with distance. A wireless network connection does not require 100% signal strength to be
effective (shown as four solid bars on the screen). If the Network Connections Manager shows two or three signal
strength bars, the network connection is reasonable.
If the connection speed frequently dips below 24 Mbs or signal strength dips below two bars, move the wireless
router or access point closer to the CNC, or add another access point closer to the CNC.
For best network performance, minimize the number of clients on the wireless network.
Avoid connecting slower wireless devices to the network (for example, 802.11B devices) because the performance
of the entire network may decrease to that level.
Contact your network administrator for additional support.
