Hypertherm HyPerformance Plasma HPR800XD Reference manual

HPR800XD
Snubber Board Replacement
Field Service Bulletin
807340 – Revision 0 – June, 2011

HPR800XD SNUBBER BOARD REPLACEMENT
Field Service Bulletin 1
Introduction
Purpose
This field service bulletin provides the instructions necessary to replace the snubber board in an HPR800XD
power supply.
Kit 228841 contents
Part number Description Quantity
229340 Snubber sub-assembly: HPR800XD 1
WARNING
ELECTRIC SHOCK CAN KILL
Disconnect electrical power before performing any maintenance.
All work requiring removal of the power supply cover must be performed
by a qualified technician.
See the Safety Section of the system’s Manual for more safety
precautions.

HPR800XD SNUBBER BOARD REPLACEMENT
2 Field Service Bulletin
Remove the old snubber board
1. Remove the left side panel on the HPR800XD power supply.
Left side panel removed and installation location shown
2. Remove the two nuts and washers that secure wires A1 and A2 to the bus bars, and then remove the four screws
that secure the old snubber board to the back panel of the power supply. Keep the nuts, washers, and screws for
use when installing the new snubber board. Discard the old snubber board.
Snubber board assembly installation
Machine
screws Snubber board
assembly
Wire A1 and A2
connections
Location of the
snubber board

HPR800XD SNUBBER BOARD REPLACEMENT
Field Service Bulletin 3
2. Use the nut and washer that were removed earlier to secure wire A1 to terminal A1 on the bus bar.
Terminal A1
Wire A1
Wire A1 installation
Install the new snubber board
1. Orient the snubber board assembly as shown below and install it using the 4 machine screws that were removed
earlier.
Machine
screws
Snubber board
assembly
Location of the mounting screws

HPR800XD SNUBBER BOARD REPLACEMENT
4 Field Service Bulletin
Terminal A2
Wire A2
Wire A2 installation
3. Use the nut and washer that were removed earlier to secure wire A2 to terminal A2 on the bus bar.
3. Put the left side cover back on the power supply.
