Hypro 4001 Series Use and care manual

4-ROLLER PUMP
SERIES 1200
6-ROLLER PUMP
SERIES 1500
Max. Flow Rate: ................62 gpm
Max. Pressure: ..................150 psi
Max. RPM: ....................1000 rpm
Ports: ....1-1/2" NPT Inlet & Outlet
Shaft:................15/16" Dia. (Solid)
Continuous Operation........100 psi
Intermittent Operation........150 psi
Max. Flow Rate: ................74 gpm
Max. Pressure: ..................150 psi
Max. RPM: ......................800 rpm
Ports: ....1-1/2" NPT Inlet & Outlet
Shaft: ......................1" Dia. (Solid)
Continuous Operation........100 psi
Intermittent Operation........150 psi
5-ROLLER PUMP
Max. Flow Rate: ................45 gpm
Max. Pressure:.................. 200 psi
Max. RPM: ....................1000 rpm
Ports:............1" NPT Inlet & Outlet
............1-1/4" Hose Barb Included
Shaft:................15/16" Dia. (Solid)
Continuous Operation........100 psi
Intermittent Operation........200 psi
SERIES 1700
Max. Flow Rate: ............22.4 gpm
Max.Pressure: ..................200 psi
Max. RPM: ......................800 rpm
Ports: ........3/4" NPT Inlet & Outlet
..................1" Hose Barb Included
Shaft:................15/16" Dia. (Solid)
Continuous Operation........100 psi
Intermittent Operation........200 psi
7-ROLLER PUMP
SERIES 7700SERIES 7560
8-ROLLER PUMP
Max. Flow Rate: ................22 gpm
Max. Pressure: ..................300 psi
Max. RPM: ....................1000 rpm
Ports: ........3/4" NPT Inlet & Outlet
..................1" Hose Barb Included
Shaft:................15/16" Dia. (Solid)
Continuous Operation........100 psi
Intermittent Operation........300 psi
Max. Flow Rate: ................22 gpm
Max. Pressure: ..................300 psi
Max. RPM: ....................1200 rpm
Ports: ........3/4" NPT Inlet & Outlet
..................1" Hose Barb Included
Shaft:....................5/8" Dia. (Solid)
Continuous Op. ..........100-150 psi
Intermittent Operation........300 psi
Max. Flow Rate: ......9 gpm (4001)
7 gpm (4101)
Max. Pressure: ..................150 psi
Max. RPM:..........1800 rpm (4001)
2600 rpm (4101)
Ports: ........3/4" NPT Inlet & Outlet
Shaft:....................5/8" Dia. (Solid)
1/2" Dia. (Hollow)
Continuous Operation........100 psi
Intermittent Operation........150 psi
6-ROLLER PUMP
SERIES 6500SERIES 4001 & 4101
4-ROLLER PUMP
iron, Ni-Resist or the new SilverCast™ body and rotor, 416
stainless steel shaft, sealed factory-lubricated ball
bearings, cartridge-type lip seals of Viton, Buna-N or
leather, and versatile Super Rollers. (Super Rollers feature
the life of polypropylene and the chemical resistance of
nylon.) Rotation for all models is counterclockwise for easy
tractor PTO drive, except models 4001 and 4101 which are
clockwise. Pumps are available in reverse rotation.
Hypro roller pumps are designed for agricultural and
industrial spraying and transfer of a variety fluids. These
include insecticides, herbicides, emulsives, aromatic
solvents, liquid fertilizers and many other liquids. The
economical rotary-action roller principle requires no check
valves while providing positive displacement
characteristics with less friction and lower starting torque
than other pumps. Construction features include a cast-
ROLLER PUMPS
®®
¤¤
®®
OUT
IN
®
®
O
U
T
I
N
®
®
Installation, Operation, Repair and Parts Manual 10-04
Description
Form L-0100R

It is permissible to mount the torque arm with the chain in
the down position. To do this, mount the arm to the pump in
the reverse position. Do not use the tension spring or chain.
WARNING: Do not attach torque arm to movable
linkages.
Figure 1
7. Make certain that the power source conforms to the
requirements of your equipment.
8. Provide adequate protection in guarding around the
moving parts such as the shaft and pulleys.
9. Disconnect power before servicing.
10. Release all pressure within the system before servicing
any component.
11. Drain all liquids from the system before servicing any
component.
12. Check all hoses for weak or worn condition before each
use. Make certain that all connections are tight and
secure.
13. Periodically inspect the pump and the system
components. Perform routine maintenance as required
(see Maintenance section).
14. Never operate a gasoline engine in an enclosed area.
Be sure the area is well ventilated.
15. Use only pipe, hose and fittings rated for the maximum
psi rating of the pump.
16. Never use these pumps for pumping water or other
liquids for human or animal consumption.
1. Use a Pressure Relief Device on the discharge side
of the Pump to prevent damage from pressure
buildup when the pump discharge is blocked or
otherwise closed and the power source is still
running.
2. WARNING: Never pump flammable or explosive
fluids such as gasoline, fuel oil, kerosene, etc. Never
use in explosive atmospheres. The Pump should be
used only with liquids compatible with the Pump
component materials. Failure to follow this warning
can result in personal injury and/or property
damage and will void the product warranty.
3. Never pump acids (i.e. acid fertilizer) with Super
Rollers! When pumping acidic fertilizer, Hypro
recommends only the Silver Series castings and Teflon
rollers, or use one of Hypro's poly centrifugal pumps.
4. Never run the pump faster than maximum
recommended speed.
5. Never pump at pressures higher than the maximum
recommended pressure.
6. Never pump liquids at temperatures higher than the
recommended maximum temperatures (140˚ F / 60˚ C).
engine for additional information. Read all safety information
before attempting to install or operate the pump.
This manual will cover the installation of the basic drive
configurations available for Hypro roller pumps. Consult the
recommendations of the manufacturer of your motor or
The preferred method for mounting the torque arm and
pump to a tractor is with the chains going up to provide
support for the pump (see Figure 1). Attach the torque arm
to the pump with the long side of the arm on the inlet side of
the pump for this type of mounting. Many tractors do not
have easy attachment points for securing the tension and
torque chains. It may be necessary to drill holes in the
tractor's master shield to attach the chains.
It is also acceptable to mount an angle iron on the master
shield to attach the chains.The chains should be attached to
the tractor as close to vertical as possible to avoid a bending
force on the pump.
1. Mount the pump and torque arm to the PTO shaft using
a Hypro series 1320, 1321 or 1323 coupler.
2. Attach the torque chain to the tractor frame with arm in
horizontal position.
3. Attach the tensioning chain to the tractor frame while
applying tension to the spring.
2
General Safety Information
Drive Source Installation
Tractor PTO Installation

Figure 6
Figure 7
Figure 5
Push the belt midway between the pulleys,
check the deflection (d) and adjust:
d = 0.016 x L
=
=
Belt and pulley drive systems are typically used to reduce
pump speed. For determining proper pulley sizes, use the
formula below as a guideline and use “A” or “B” section
belts.
MOTOR RPM FLOW (@ RATED SPEED) PUMP PULLEY DIA.
PUMP RPM FLOW (DESIRED) MOTOR PULLEY DIA.
EXAMPLE: Use a 1725 RPM electric motor to drive a
pump at 950 RPM.
Typically, a pulley diameter on the motor is 3.4 inches. The
pump pulley diameter can be determined from the formula
above:
1725 PUMP PULLEY DIAMETER
950 3.4 INCHES
1725 X 3.4 INCHES = 6.2 INCHES
950
1. Install pulley or bushing/sheave combination (See
Figure 5) onto pump and motor shaft. Mount pump next
to the motor making sure pulleys are lined up properly
(See Figure 6 for proper pump and motor orientation).
Use a straight edge as shown. Rotate to check for run-
out and bent shafts.
2. Make sure belts have proper tension—belts too tight will
cause bearing wear and belts too loose will cause
slipping. (See Figure 7).
3. The rotation on the 4000 series roller pump is gas-
engine-rotation, opposite from the standard roller pump.
3
d
L
Belt/Pulley Drive Installation

6. A strainer should be installed in the suction line. Clean
the strainer as soon as it becomes clogged.
7. Never attach an agitator or any restriction to a
bypass line of a pressure relief device because
system damage may occur.
Figure 8
NOTE: Use only pipe, fittings, accessories, hose, etc.
rated for the maximum pressure rating of the pump.
1. Select adequate size drive unit to avoid overloading.
Avoid unnecessary restrictions in the line such as
elbows, check valves, and all extraneous curves and
bends.
2. Avoid using looped sections of tubing or pipe which
might permit air to become trapped.
3. Use pipe joint sealant on pipe threads to assure
watertight connections.
4. Selection of the right type and size of hose is vital to
good performance. Be sure to hook up the lines to the
proper ports on the pump.
5. Always use a good quality suction hose (one or two
braid reinforced hose to prevent collapse) of at least
the same diameter as the inlet port of the pump. If
the suction (inlet) hose is more than four feet long,
then use the next larger size.
air. Make sure line strainer is free of debris. If pump does not
self-prime disconnect suction hose, fill with water and
reconnect to liquid source.Often a squirt of oil into the ports
of the pump will seal clearances and help priming.
Care of the Pump
Hypro roller pumps are all carefully machined to close
tolerance—high pressure operation depends on close-fitting
parts.Proper care and maintenance will keep your pump
wear at a minimum and will keep it running smoothly and
trouble-free for a long time.
WARNING: Never pump corrosive or abrasive liquids as
these will cause rapid wear or deterioration of body, rotor,
shaft and seals in the pump.The pump should be used only
with liquids compatible with pump component materials.
Never exceed maximum specified rpm and pressure. Never
run pump dry.Failure to follow this warning will void the
product warranty.
Priming the Pump
To help prime the pump keep the inlet or suction line as
short as possible with a minimum of bends, elbows and
kinks.Make sure all connections are tight and do not leak
When direct driving Hypro roller pumps with flexible
couplings make sure that the speed (rpm) of the gas engine
or electric motor is within the maximum rated rpm of your
pump. Also make sure that shaft rotation is correct between
the pump and the motor or gas engine (See Figure 8).
1. Mount motor or engine into position on base.
2. Lineup pump shaft with straight edge as shown in
Figure 4 to assure they are aligned. Shim pump if
necessary to match shaft height of engine or motor.
Shaft ends should not touch.
3. Mark exact position of pump on base — remove and
install coupling halves on both shafts. Place coupling
center disc into one of the coupling halves.
4. Reposition pump, sliding coupling halves together.
NOTE: No end thrust should be applied to pump when
coupling is connected.
5. Tighten pump mounting; then, tighten the set screws on
each coupling.
4
Direct Drive — Flexible Coupling
System Installation
Operation and Maintenance
Figure 9
Typical System
Installation
Bypass line

Figure 12
Figure 11
Figure 10
Standard CCW rotation to CW rotation
Standard CCW rotation to CW rotation
Standard CCW rotation to CW rotation
7700). Note that slots
should slant back from
rotation direction.
Diagram of 7-roller rotor
with special slanted,
wide roller slots (Series
SLANTED SLOT Rotor
SCOOPED Rotor
Standard NON-SCOOP Rotor
1. Determine the Rotor Type of your Pump by referring to
exploded drawing on the parts list. The three types of
Rotors are NON-SCOOP, SCOOPED, and SLANTED
SLOT.
2. Follow the steps listed in Repair Instructions for
disassembly of the Pump.
3. If your Pump has a NON-SCOOP Rotor (4001, 4101,
6500, 7560) it can be reversed merely by turning the
Rotor/Shaft Assembly around intact (without changing
the position of the Rotor on the Shaft). Reassemble the
Pump with the driving end of Shaft out the Endplate
Side of the Pump. (Standard Pump Rotors are driven
from the Body Side.)
4. If your Pump has a SCOOPED Rotor (1200, 1500,
1700) or a SLANTED SLOT (7700) Rotor follow the
following steps for reversing the Shaft in the Rotor.
a. Loosen and remove the Rotor Set Screw.
b. Press the Shaft out of the Rotor.
c. Reassemble the Shaft and Rotor with the driving
end of Shaft on the opposite side of the Rotor from
standard assembly.
d. Before installing the Rotor on the Shaft, be sure it is
positioned in the correct location on the Shaft
(diameter of Shaft is slightly larger at Rotor
position). Center punch the Shaft through Rotor Set
Screw hole. Then with a drill smaller than Set Screw
— spot drill Shaft so that Set Screw will hold
securely. (Don't drill too deep — just enough so Set
Screw will bite into Shaft).
e. Reassemble the Pump with driving end of Shaft
extending out of endplate side of Pump. (The
standard Pump Rotor is driven from the body side.)
Remember, the Rotor position remains the same —
the Shaft only is reversed — “end for end”.
Note: Configuration is opposite from above for 4001 and
4101 series.
Flush the Pump After Each Use
One of the common causes of faulty pump performance
is “gumming” or corrosion inside the pump. This
prevents the rollers from moving freely in their rotor
slots. Flush the pump with a solution that will neutralize
liquid pumped, mixed according to manufacturer's
directions.
To Prevent Corrosion
After cleaning pump as above, flush it with a 50-50 solution
of permanent type automobile antifreeze (containing a rust
inhibitor) and water. A rust inhibitor such as Fluid Film
(Hypro Part No. 2160-0010 ) can also be squirted into the
ports of the pump. Turn shaft several times to draw
protective liquid through pump and coat entire inner surface.
Drain pump and plug ports to keep out air during storage.
For short periods of idleness noncorrosive liquids may be
left in the pump, but air must be kept out. Plug ports or
seal port connections.
Rotation
Pump rotation must be the same as shown by the arrows on
the pump. Facing the shaft end of the pump, the suction port
is on your left and the shaft must turn counterclockwise. If
reverse rotation is desired, rotor and shaft assembly must be
reversed so that the shaft extends through the endplate. See
Reversing Rotation Section below for proper procedure.
Note: Configuration is opposite for 4001 and 4101 series.
5
Reversing Rotation

Figure 17
Figure 16
Figure 15
Figure 14
Figure 13
6. With the Rollers exposed, remove them – examining
each one carefully for excessive wear. When replacing
damaged Rollers always replace the full set.
7. To remove the Rotor with Shaft from the End Plate –
support the End Plate in an Endplate Support Fixture
with the Rotor down. Center the Bearing Disassembly
Tool or 3/8" bolt, on Pump Shaft. Apply pressure to
press Shaft out of Ball Bearing (See Figure 14).
8. To remove the Ball Bearing – place the End Plate in a
Endplate Support Fixture with the front of the End Plate
down (See Figure 15). Center Bearing Support Tool and
slowly press Bearing out of Casting. Repeat procedure
to remove Bearing from Pump Body (See Figure 16)
using Body Support Fixture.
9. After removing the Ball Bearing, check the Seals in both
End Plate and Pump Body. If wear is evident or leakage
has been noticed, punch the Seals out with a
screwdriver and hammer. Seals cannot be removed
without damaging them.
10. To press the Shaft out of the Rotor, first carefully wash the
Rotor and Shaft with kerosene – removing all traces of rust
and other foreign matter. Use steel wool or emery cloth,
rinsing parts afterward to wash off all emery dust. Remove
the Allen Set Screw. Support the Rotor in the press
through the slot in the Base and press Shaft through.
To Take the Pump Apart
1. Remove the Adapter from the Pump Shaft.
2. File off any burrs on the Pump Shaft.
3. Using a screwdriver, pry off the Bearing Cover on the
End Plate and Pump Body
4. Remove the End Plate Bolts.
5. Support the Pump at its Ports in an Endplate Support
Fixture with the End Plate down. Use wood blocks for
Series 1500, 1700 and 4001/4101. Place on press bed.
Center press on Pump Shaft and apply pressure to
press the Pump apart. (See Figure 13).
While the Pump is Apart
Carefully inspect all parts for wear, such as:
• Undersize or swollen Rollers in both length and diameter.
• Worn Seals.
• Worn Shaft at drive end, and pitted or grooved at the seal area.
•Rough Bearings and loss of grease from the Bearings.
•Undersize Rotor and/or worn Roller Slots.
• Excessive wear in Body – both on inside diameter and at back
face.
• Body cracks at the bolt holes and at the O-ring sealing area.
•End wear (Body, Endplate, and Rotor).
•Proper size O-ring in the End Plate.
After the above parts have been checked and the various
points have been considered, you can decide if the Pump is
repairable. When worn parts have been replaced, always
take up the end clearance by lightly sanding the End Plate
and matching body surface (See Figure 17). NOTE: End
clearance should not be more than .004 inches.
Inspect Inside of End Plate
If a groove is noticeable, the End Plate should be resurfaced
by rubbing it on a sheet of 80 grit emery paper (placed on flat
surface) until all trace of wear has been removed. Rotate the
End Plate frequently to remove evenly the same amount of
metal over the entire surface. NOTE:This surface of the End
Plate must be perfectly flat. If attempt has been made to
pry Pump apart with a screwdriver file off all nicks, burrs
and other damage marks around the bolt holes.
6
Repair Instructions

Figure 24
Figure 23Figure 22
Figure 21
Figure 20
Figure 19
Figure 18
NOTE: If the End Plate has been resurfaced the Body face
must also be resurfaced to allow for material taken off the
End Plate.Follow same procedure as above with emery
cloth. Before new parts are installed all burrs should be
removed – particularly in the Rotor Slots and Body.
Do not machine clean the Body Casting. A more
satisfactory job can be done by hand cleaning with an
emery cloth. Wettable talc powder mixture (5 lbs.
powder to 5 gallons water) can be used for breaking in a
repaired Pump if Pump appears to be binding. Run
Pump for about 5 minutes. This will also serve to clean
and remove corrosion from the Pump. Follow with a
clear rinse and protect from rust. (See Maintenance.)
2. Remove the assembled portion from the arbor press and
invert it on the press table with the Bearing Support Tool
under the Bearing. Then place Rollers in the Roller Slots as
close to center of Rotor as possible. Place the Pump Body
over Rotor and Shaft and carefully ease the end of the Shaft
past the lips of the Seal in Pump Body (Figure 21). Center
Bearing Support Tool with counter bored end down on inner
race of Ball Bearing, and slowly press the Pump Body down
to fit the End Plate (Figure 22).
3. Turn Pump over; line up bolt holes and replace Assembly
Bolts. Alternately and evenly tighten the Bolts as shown
(Figure 23). NOTE: After Bolts have been tightened, check to
see if Rotor is centered in Pump Case. Try to turn the Pump
shaft, using a crescent wrench on the Shaft as a lever.
2. If this fails to center the Rotor to where it can be turned
freely — tap other end of Shaft, protecting it as above.
When the Shaft can be turned by hand — using wrench
as above — it is not binding.
3. If the Pump binds within and tapping does not free it, it
may be necessary to “run the Pump in” to wear off high
spots. Use talc solution mentioned earlier. Check Pump
frequently during run in.
Assemble Rotor & Shaft To Endplate
1. Install the Shaft Rotor Assembly by carefully pushing the
short end of the Shaft Rotor Assembly through the Shaft
Seal into the End Plate.Place in the arbor press with the
drive end of the Shaft pointed down. Use the Bearing
Support Tool on top of the Bearing and press the assembly
together. (Figure 20). Leave just enough clearance between
the Rotor and End Plate so that Rotor can be turned by
hand. If it turns too freely, sand a little more off the Body end
that faces the End Plate.You should notice a slight drag, but
be able to turn Shaft with an adapter on it, by hand. The
“slight drag” will wear off after the Pump has been used a
short time. Installing new Rollers, Seals, Bearings, and
Shafts will not prove entirely satisfactory for volume and
pressure unless end clearance is taken up.
Re-Assembly
Replace Seals and Bearings
Carefully place the Seal in the Pump Body with crimped side
down. Press the Seal to the bottom of the cavity, using the
stepped end of the Bearing & Seal Assembly Tool (Figure
18). Then put the Bearing in position in the Pump Body and
press into place with counter bored end of Bearing & Seal
Assembly Tool (Figure 19). Repeat the above procedure with
the End Plate. Seat the O-ring in the groove. If necessary,
make sure the O-ring stays in place by stretching it.
Center Rotor in Pump Case
If pump turns hard:
1. Place short brass rod (or hardwood dowel) against end of
Shaft (Figure 24). Center rod on Shaft (not on Bearing).
Tap lightly with hammer.Try turning Shaft again.
7

Tool Kit No. 3011-0021 for Series 4001/4101
Consists of: (A = 3010-0003) Bearing & Seal Assembly Tool;
(B = 3010-0004) Bearing Disassembly Tool; (C = 3010-
0010) Bearing Support Tool; (D = 3010-0014) Bearing Race
Support Tool; (E = 3010-0066) Wire Brush; (F = 3010-0067)
Brush Holder; (G = 3020-0009) 1/16" Allen Wrench; Tool
Box.
Tool Kit No. 3011-0006 for Series 6500
Consists of: (A = 3010-0001) Endplate Support Fixture;
(B = 3010-0002) Body Support Fixture; (C = 3010-0003)
Bearing & Seal Assembly Tool; (D = 3010-0004) Bearing
Disassembly Tool; (E = 3010-0010) Bearing Support Tool; (F
= 3010-0014 )Bearing Race Support Tool; (G = 3010-0066)
Wire Brush; (H = 3010-0067) Brush Holder; (I = 3020-0009)
1/16" Allen Wrench; Tool Box.
Symptom Probable Cause(s) Corrective Action
Pump does not prime. Leak in suction line. Check hose and fittings for leaks and correct.
Obstruction in suction line.Inspect hose for obstruction such as debris or
loose inner liner.
Suction hose sucked to bottom Cut a notch or “V” in end of suction hose.
or side of tank.
Rollers stuck in Pump. Disassemble Pump and inspect Rollers.
Pump seals leaking air. Replace seals.
Pump turning in wrong direction. Correct rotation of Pump (See Reversing Pump).
Loss of pressure Clogged suction strainer. Check strainer and clean it regularly.
Kinked or blocked suction hose. Inspect suction hose and repair as necessary.
Air leak in inlet side plumbing. Check hose and connections for leaks.
Use pipe joint sealant and retighten connections.
Relief valve setting too low or Check relief valve and correct setting or replace
weakened spring. weakened spring.
Faulty gauge. Replace gauge.
Pump seals leak air. Replace seals.
Nozzle orifices worn. Replace nozzles.
Pump worn. Repair pump (See Repair Instructions).
Pump will not turn Corrosion (rust), scale or residue Loosen Endplate Bolts. Squirt oil into ports to
help free rotor.Retighten Bolts.
Solid object lodged in Pump. Disassemble Pump and remove objects.
8
Repair Tool Kits
Troubleshooting

HYPRO
2222C
5555 55555
11A
3A
7
13
12
15
16
9
8
1
17
98
26
3
45
3B
21
22
23
20
453C
18 19
Repair Parts Kit No. 3430-0390 Consists of: (4) Ref.5 Super Rollers, (1)
Ref.6 O-Ring Gasket, (2) Ref.8 Viton Seals.
IMPORTANT:
When ordering parts, give PART
NUMBER and PART DESCRIPTION.
Reference Numbers are used ONLY to
point out parts in the drawing and are
NOT to be used as ordering numbers.
Repair Parts Kit No. 3430-0158 Consists of: (4) Ref.5 Polypropylene
Rollers, (1) Ref. 6 O-Ring Gasket, (2) Ref. 8 Viton Seals.
Ref.Qty.Part
No. Req'd. Number Description
Ref. Qty. Part
No. Req'd. Number Description
6 1 1720-0104 O-Ring Gasket for Endplate
7 4 2220-0018 Endplate Screw
8 2 2107-0002 Viton Seal (Std.)
8 2 2102-0001 Buna-N Seal (Optional)
82 2103-0001 Leather Seal (Optional)
92 2000-0010 Ball Bearing (High temp. grease)
11A 1 Name Plate (Specify pump model #)
12 1 3420-0024 Base Kit — Includes:
1 Base, 2 Bolts, and 2 Lock washers for
mounting pump to electric motors with
3-1/2" shaft centerline
13 1 3420-0025 Base Kit — Includes:
1 Base, 2 Bolts, and 2 Lock Washers for
mounting pump to electric motors/gas
engines with 4-3/16" shaft centerlines
15 1 kit 1320-0016 Adapter with 4 setscrews for
gas engine mount. (5/8" x 5/8")
15 1 kit 1320-0015 Adapter (5/8" x 3/4")
16 1 2300-0023 Shaft Bearing Cover
17 1 2300-0021 Bearing Cover
18 11420-0001 Locking Collar
19 12230-0001 Set Screw
20 1 1510-0054 Base
21 2 1450-0003 Bumper
22 2 2210-0003 Bolt
23 2 2260-0002 Lock Washer
1 1 0100-4001C Body (Cast Iron) with Std. Seal (4001)
1 1 0100-4101C Body (Cast Iron) with Std. Seal (4101)
1 1 0100-4001N Body (Ni-Resist) with Std. Seal (4001)
1 1 0100-4101N Body (Ni-Resist) with Std. Seal (4101)
1 1 0100-4001X Body(SilverCast) with Std. Seal (4001)
110100-4101X Body(SilverCast) with Std. Seal (4101)
210200-4001C Endplate (Cast Iron) with Std. Seal (4001)
210200-4101C Endplate (Cast Iron) with Std. Seal (4101)
2 1 0200-4001N Endplate (Ni-Resist) with Std. Seal (4001)
2 1 0200-4101N Endplate (Ni-Resist) with Std. Seal (4101)
2 1 0200-4001X Endplate (SilverCast) with Std. Seal (4001)
2 1 0200-4101X Endplate (SilverCast) with Std. Seal (4101)
3 1 0300-4001C Rotor (Cast Iron) & Shaft Assembly (4001)
31 0300-4101C Rotor (Cast Iron) & Shaft Assembly (4101)
3 1 0300-4001N Rotor (Ni-Resist) & Shaft Assembly (4001)
3 1 0300-4101N Rotor (Ni-Resist) & Shaft Assembly (4101)
310300-4001X Rotor (SilverCast) & Shaft Assembly (4001)
310300-4101X Rotor (SilverCast) & Shaft Assembly (4101)
3A 10500-6600 Shaft Only
3B 1 0301-4001N Rotor (Ni-Resist) & Shaft Assembly (4001)
3B 1 0301-4101N Rotor (Ni-Resist) & Shaft Assembly (4101)
3B 1 0301-4101X Rotor (SilverCast) & Shaft Assembly (4101)
3B 1 0301-4001X Rotor (SilverCast) & Shaft Assembly (4001)
3C 1 0550-4001 Shaft Only (Hollow Shaft)
4 1 2230-0002 Rotor Set Screw
4 1 2230-0016 Rotor Set Screw (SilverCast Only)
5 4 1005-0002 Super Rollers (Std.)
5 4 1002-0002 Polypropylene Rollers (Optional)
541001-0002 Buna-N Rollers (Optional)
5 4 1055-0002 Teflon Rollers (Optional)
Hypro Models 4001C, 4101C, 4001N, 4101N and
4001XL, 4101XL, 4001XL-H, 4101XL-H
9

10
Series 6500
Note: When ordering parts, give
quantity, part number, description
and complete model number.
Reference numbers are used
ONLY to identify parts in the
drawing and NOT to be used as
order numbers.
1234
567
8
9
10
11
12
13
3214
15
See Page 17 for the proper coupler or adapter.
Repair Parts Kits:
# 3430-0380 Consists of: (6) Ref. 7
Super Rollers, (1) Ref. 6 O-ring and
(2) Ref. 3 Viton Seals
# 3430-00175 Consists of: (6) Ref 7
Polypropylene Rollers, (1) Ref. 6
Oring, and (2) Ref. 3 Viton Seals
# 3430-0621 Consists of: (1) Ref 8
Phenolic rotor, (1) Ref 9 Metal insert
and (1) Ref 10 Shaft
Ref. Qnty. Part Ref. Qnty. Part
No. Req'd. No. Description No. Req'd. No. Description
1 1 2300-0021 Bearing Cover 9 1 1201-0018 Metal insert
2 2 2000-0010 Sealed Ball Bearing 10 1 0500-6500 Shaft
3 2 2107-0002 Viton Seal (Standard) 11 1kit 3420-0023 Base Kit - Includes:
3 2 2102-0001 Buna-N Seal (Optional) (1) Base, (2) Bolts and (2) Washers
4 4 2210-0004 Bolts 12 1 0100-6600C Body (Cast Iron) with seal
5 1 0200-6600C Endplate (Cast-Iron) with seal 12 1 0100-6600N Body (Ni-Resist) with seal
5 1 0200-6600N Endplate (NI-Resist) with seal 12 1 0100-6600X Body (SilverCast) with seal
5 1 0200-6600X Endplate (SilverCast) with seal 13 1 2404-0052 1" Hose Barb
6 1 1720-0008 Oring Gasket for Endplate 14 1 2300-0023 Shaft Bearing Cover
7 6 1005-0004 SuperRoller (Standard)
7 6 1002-0004 Polypropylene Roller (Optional) 15 N/A Metal rotor assy:
7 6 1052-0004 Buna-N Roller (Optional) Replaced by kit 3430-0621
(Phenolic rotor assy)
7 6 1055-0004 Teflon Roller (Optional)
8 1 0401-6500P Phenolic Rotor (Standard)
1

11
SERIES 7560
1
2
34
56
7
8
9
10
11 12
3
2
13
14
15
16
See Page 17 for the proper coupler or adapter.
Note: When ordering parts, give
quantity, part number, description
and complete model number.
Reference numbers are used
ONLY to identify parts in the
drawing and NOT to be used as
order numbers.
Repair Parts Kits:
# 3430-0381 Consists of: (8) Ref. 7
Super Rollers, (1) Ref. 6 O-ring and
(2) Ref. 3 Viton Seals
# 3430-0167 Consists of: (8) Ref 7
Polypropylene Rollers, (1) Ref. 6
Oring, and (2) Ref. 3 Viton Seals
# 3430-0622 Consists of: (1) Ref. 8
Phenolic rotor, (1) Ref. 9 Shaft, and
(1) Ref. 15 Key
Ref. Qnty. Part Ref. Qnty. Part
No. Req'd. No. Description No. Req'd. No. Description
1 1 2300-0020 Bearing Cover 8 1 0403-7500P Phenolic (Standard)
2 2 2008-0001 Sealed Ball Bearing 9 1 0510-7500 Shaft (416 Stainless)
3 2 2112-0003 Viton Seal (Standard) 10 1 kit 3420-0003 Base Kit - Includes:
3 2 2112-0001 Buna-N Seal (Optional) (1) Base, (3) Boltsand (3) Washers
4 6 2210-0004 Bolts 11 1 0104-7500C Body (Cast Iron) with seal
5 1 0204-7500C Endplate (Cast-Iron) with seal 11 1 0104-7500N Body (Ni-Resist) with seal
5 1 0204-7500N Endplate (NI-Resist) with seal 11 1 0104-7500X Body (SilverCast) with seal
5 1 0204-7500X Endplate (SilverCast) with seal 12 1 2404-0052 1" Hose Barb
6 1 1720-0014 Oring Gasket for Endplate 13 1 2300-0022 Shaft Bearing Cover
7 8 1005-0004 SuperRoller (Standard) 14 1 1610-0005 Key
7 8 1002-0004 Polypropylene Roller (Optional) 15 1 1610-0059 Key (Stainless Steel)
7 8 1052-0004 Buna-N Roller (Optional) 16 1 N/A Metal rotor assembly. Use kit
7 8 1055-0004 Teflon Roller (Optional) 3430-0622 (Phenolic rotor)

12
Series 7700
Note: When ordering parts, give
quantity, part number, description
and complete model number.
Reference numbers are used
ONLY to identify parts in the
drawing and NOT to be used as
order numbers.
See Page 17 for the proper coupler or adapter.
1234
5
67
8
9
10
11
3
2
12
13
14
15
16
Repair Parts Kits:
# 3430-0381 Consists of: (8) Ref. 7
Super Rollers, (1) Ref. 6 O-ring and
(2) Ref. 3 Viton Seals
# 3430-0167 Consists of: (8) Ref 7
Polypropylene Rollers, (1) Ref. 6
Oring, and (2) Ref. 3 Viton Seals
# 3430-0623 Consists of: (1) Ref.8
Phenolic rotor, (1) Ref. 9 Shaft
and (1) Ref. 15 Key
Ref. Qnty. Part Ref. Qnty. Part
No. Req'd. No. Description No. Req'd. No. Description
1 1 2300-0020 Bearing Cover 8 1 0401-7700P Phenolic (Standard)
2 2 2008-0001 Sealed Ball Bearing 9 1 0510-7500 Shaft (416 Stainless)
3 2 2112-0003 Viton Seal (Standard) 10 1 kit 3420-0010 Base Kit - Includes:
3 2 2112-0001 Buna-N Seal (Optional) (1) Base and (4) Bolts
4 6 2210-0004 Bolts 11 1 0100-7700C Body (Cast Iron) with seal
5 1 0200-7700C Endplate (Cast-Iron) with seal 11 1 0100-7700N Body (Ni-Resist) with seal
5 1 0200-7700N Endplate (NI-Resist) with seal 11 1 0100-7700X Body (SilverCast) with seal
5 1 0200-7700X Endplate (SilverCast) with seal 12 1 2404-0052 1" Hose Barb
6 1 1720-0014 Oring Gasket for Endplate 13 1 2300-0022 Shaft Bearing Cover
7 7 1005-0004 SuperRoller (Standard) 14 1 1610-0005 Key
7 7 1002-0004 Polypropylene Roller (Optional) 15 1 1610-0059 Key (Stainless Steel)
7 7 1052-0004 Buna-N Roller (Optional) 16 1 N/A Metal rotor assembly. Replaced by kit
7 7 1055-0004 Teflon Roller (Optional) 3430-0623 (Phenolic rotor)

See Page 17 for the proper coupler or adapter.
Repair Parts Kit No. 3430-0437 Consists of: (5) Ref. 12 Super Rollers, (1)
Ref. 7 O-Ring Gasket, and (2) Ref. 4 Viton Seals.
Repair Parts Kit No. 3430-0383 (Universal) Consists of: (6) Ref. 12 Super
Rollers, (2) Ref.7 O-Ring Gaskets, and (2) Ref. 4 Viton Seals.
Repair Parts Kit No. 3430-0160 Consists of: (5) Ref. 12 Polypropylene
Rollers and (1) Ref. 7 O-Ring Gasket, and two Ref. 4 Buna-N Seals.
10 1 1610-0005 Key
11 1 2230-0018 Set Screw
11 1 2230-0034 Set Screw (SilverCast Only)
12 5 1005-0005 Super Roller (Standard)
12 5 1002-0005 Polypropylene Roller (Optional)
12 51055-0005 Teflon Roller (Optional)
13 1 0100-1700C Body (Cast Iron) with seal
13 1 0100-1700N Body (Ni-Resist) with seal
13 1 0100-1700X Body (SilverCast) with seal
14 1 kit 3420-0010 Base Kit — Includes: (1) Base and (4) Bolts
16 1 2404-0191 1-1/4" Hose Barb
24 1 2300-0020 Bearing Cover
25 1 2300-0022 Shaft Bearing Cover
2A 16031-0258 Name Plate (Specify Pump Model #)
32 2008-0001 Sealed Ball Bearing
42 2112-0003 Viton Seal (Standard)
4 2 2112-0001 Buna-N Seal (Optional)
562210-0005 Bolt
6 1 0200-1700C Endplate (Cast-Iron) with seal
6 1 0200-1700N Endplate (Ni-Resist) with seal
6 1 0200-1700X Endplate (SilverCast) with seal
7 1 1720-0099 O-ring Gasket for Endplate
810300-1700C Rotor (Cast Iron) with shaft (Std. Rotation)
8 1 0300-1700N Rotor (Ni-Resist) with shaft (Std. Rotation)
81 0300-1700X Rotor (SilverCast) with shaft (Std. Rotation)
8A 1 0301-1700C Rotor (Cast Iron) w/shaft (Reverse Rotation)
8A 1 0301-1700N Rotor (Ni-Resist) w/shaft (Reverse Rotation)
8A 10301-1700X Rotor (SilverCast) w/shaft (Reverse Rot.)
910500-1502 Shaft Only
Ref. Qnty. Part
No. Req'd. Number Description
Ref. Qnty. Part
No. Req'd. Number Description
IMPORTANT:
When ordering parts, give PART
NUMBER and PART DESCRIPTION.
Reference Numbers are used ONLY
to point out parts in the drawing and
are NOT to be used as ordering
numbers.
Repair Parts Kit No. 3430-0159 Consists of: (5) Ref. 12 Polypropylene
Rollers and (1) Ref. 7 O-Ring Gasket.
Repair Parts Kit No. 3430-0161 Consists of: (5) Ref. 12 Polypropylene
Rollers and (1) Ref.7 O-Ring Gasket, and (2) Ref.4 Viton Seals.
Repair Parts Kit No. 3430-0407 Consists of: (5) Ref. 12 Super Rollers, (1)
Ref. 7 O-Ring Gasket, (2) Ref. 4 Viton Seals and (2) Ref. 3 Sealed Ball
Bearings.
Models 1700C, 1700N, and 1700XL
13

IMPORTANT:
When ordering parts, give PART
NUMBER and PART DESCRIPTION.
Reference Numbers are used ONLY
to point out parts in the drawing and
are NOT to be used as ordering
numbers.
See Page 17 for the proper coupler or adapter.
25
3
4
13
14
10
9
8
12
11
9
10
11 8A
7
6
5
4
3
24
2A
Repair Parts Kit No. 3430-0204 Consists of: (6) Ref. 12 Teflon Rollers, (1)
Ref. 7 O-Ring Gasket, and (2) Ref. 4 Buna-N Seals.
Repair Parts Kit No. 3430-0164 Consists of: (6) Ref. 8 Polypropylene
Rollers, (1) Ref.7 O-Ring Gasket, and (2) Ref. 4 Viton Seals.
Repair Parts Kit No. 3430-0163 Consists of: (6) Ref. 8 Polypropylene
Rollers, (1) Ref. 7 O-Ring Gasket, and (2) Ref. 4 Buna-N Seals.
Repair Parts Kit No. 3430-0406 Consists of: (6) Ref. 12 Super Rollers, (1)
Ref. 7 O-Ring Gasket, (2) Ref. 4 Viton Seals and (2) Ref. 3 Sealed Ball
Bearings.
10 1 1610-0005 Key
11 12230-0018 Set Screw
11 12230-0034 Set Screw (SilverCast Only)
12 6 1005-0005 Super Roller (Standard)
12 6 1002-0005 Polypropylene Roller (Optional)
12 6 1055-0005 Teflon Roller (Optional)
13 1 0100-1500C Body (Cast Iron) with seal
13 10100-1500N Body (Ni-Resist) with seal
13 1 0100-1500X Body (SilverCast) with seal
14 1 kit 3420-0004 Base Kit — Includes:
(1) Base ,(4) Bolts (4) Lockwashers
24 1 2300-0020 Bearing Cover
25 12300-0022 Shaft Bearing Cover
Ref. Qnty. Part
No. Req'd. Number Description
2A 1 6031-0258 Name Plate (Specify Pump Model #)
3 2 2008-0001 Sealed Ball Bearing
4 2 2112-0001 Buna-N Seal (Standard)
4 2 2112-0003 Viton Seal (Optional) (Std. for SilverCast)
5 6 2210-0026 Bolt
6 1 0200-1500C Endplate (Cast-Iron) with seal
6 1 0200-1500N Endplate (Ni-Resist) with seal
6 1 0200-1500X Endplate (SilverCast) with seal
7 1 1720-0003 O-ring Gasket for Endplate
8 1 0300-1502C Rotor (Cast Iron) with shaft (Std. Rotation)
8 1 0300-1502N Rotor (Ni-Resist) with shaft (Std. Rotation)
8 1 0300-1502X Rotor (SilverCast) with shaft (Std. Rotation)
8A 1 0301-1502C Rotor (Cast Iron) w/shaft (Reverse Rotation)
8A 1 0301-1502N Rotor (Ni-Resist) w/shaft (Reverse Rotation)
8A 10301-1502X Rotor (SilverCast) w/shaft (Reverse Rotat.)
910500-1502 Shaft Only
Ref. Qnty. Part
No. Req'd. Number Description
Repair Parts Kit No. 3430-0383 (Universal) Consists of: (6) Ref. 12
Super Rollers, (2) Ref. 7 O-Ring Gaskets, and (2) Ref. 4 Viton Seals.
Repair Parts Kit No. 3430-0388 Consists of: (6) Ref. 12 Super Rollers
and (1) Ref.7 O-Ring Gasket.
Repair Parts Kit No. 3430-0386 Consists of: (6) Ref. 12 Super Rollers, (1)
Ref. 7 O-Ring Gasket, and (2) Ref. 4 Viton Seals.
Repair Parts Kit No. 3430-0387 Consists of: (6) Ref. 12 Super Rollers, (1)
Ref. 7 O-Ring Gasket, and (2) Ref. 4 Buna-N Seals.
Repair Parts Kit No. 3430-0162 Consists of: (6) Ref.12 Polypropylene
Rollers and (1) Ref.7 O-Ring Gasket.
Models 1500C, 1500N, and 1500XL
14

Locking Collar Kit No. 3430-0207
For Series 1200 Roller Pumps
This locking collar kit holds the pump driver shaft securely
on the tractor PTO shaft. It is designed to increase pump life
by reducing pump and PTO shaft wear due to vibration. To
install locking collar:
1. Slide collar onto pump driver shaft.
2. Thread the longer set screw through the locking collar
and partially through the threaded hole in the pump
driver shaft. IMPORTANT: It is necessary to allow a
minimum of 1/8" clearance between the locking collar
and the pump driver shaft at set screw.
3. Thread the shorter set screw into the other threaded
hole in the locking collar.
4. Slide pump driver hub over PTO shaft. Be sure PTO
groove is under set screw.
5. Tighten the longer screw very securely with a 3/16"
allen wrench.
6. Tighten the shorter set screw very securely with the
same wrench. This binds set screw which prevents it
from coming loose.
7. NOTE: Locking collar is off-center on the pump driver
shaft when properly installed.
10 10500-1200 Shaft
11 12230-0018 Set Screw
12 1 0100-1200C Body (Cast Iron) with seal
13 1 1610-0005 Key
14 1 kit 3410-0031 Set Screw Kit
15 1 1320-0081 1-3/8" 6-spline 540 rpm PTO Adapter
(Forged Steel) Includes Kit No. 3410-0031
16 1 kit 3430-0207 Locking Collar Kit — Includes:
(1) Collar and (2) Setscrews
ORDER PARTS FROMYOUR SUPPLIER
Parts Kit No. 3430-0374 Consists of (4) Ref. 8 Super Rollers, (1) Ref 7O-
Ring, (2) Ref 4 Buna-N Seals
Ref. Qnty. Part
No. Req'd. Number Description
Ref.Qnty.Part
No. Req'd. Number Description
11 1800-0013 Retainer Ring
2 1 2840-0049 Bearing Cover
2A 1 6031-0258 Name Plate (Specify Pump Model #)
3 2 2001-0006 Ball Bearing
4 2 2112-0008 Buna-N Seal (Standard)
4 2 2112-0009 Viton Seal (Optional)
5 4 2210-0019 Hex Head Bolt
6 1 0200-1200C Endplate (Cast-Iron) with seal
71 1720-0127 O-ring Gasket for Endplate
8 4 1005-0006 Super Roller (Standard)
9 1 0300-1200C Rotor (Cast Iron) with shaft (Std. Rotation)
9A 1 0301-1200C Rotor (Cast Iron) w/shaft (Reverse Rotation)
Model 1200
15

Note: "HP" is electrical horsepower. Consult your gas engine supplier for engine horsepower required.
PSI 0 25 50 100 150
RPM GPM HP GPM HP GPM HP GPM HP GPM HP
540 33.1 .51 29.7 1.02 27.8 1.45 24.3 2.46 21.0 3.54
600 36.8 .66 33.6 1.15 31.7 1.68 28.3 2.78 25.0 3.95
1000 62.1 2.02 58.5 3.04 56.9 3.69 53.9 5.31 50.9 7.12
BAR 0 3.4 6.9 10.3 13.8 17.2 20.7
RPM LPM HP LPM HP LPM HP LPM HP LPM HP LPM HP LPM HP
540 36.7 0.08 30.3 0.38 27.3 0.68 25 0.97 21.2 1.29 18.5 1.65 16.3 1.91
1000 68.9 0.2 62.4 0.71 58.3 1.26 55.6 1.8 53 2.34 50.7 2.91 48.1 3.47
1200 82.5 0.3 76.1 0.9 72.3 1.51 68.9 2.14 65.5 2.84 62.4 3.48 59.4 4.17
BAR 0 3.4 6.9 10.3 13.8
RPM LPM HP LPM HP LPM HP LPM HP LPM HP
540 53.7 0.23 48.8 0.56 45 1.1 42.4 1.64 39 2.22
600 57.9 0.28 53 0.62 49.2 1.2 46.6 1.8 43.9 2.44
800 83.6 0.37 78.3 0.86 73.8 1.66 70.4 2.4 67.4 3.26
PSI 0 25 50 75 100 125 150
RPM GPM HP GPM HP GPM HP GPM HP GPM HP GPM HP GPM HP
1100 5.5 .06 4.9 .14 4.4 .24 4.1 .34 3.8 .41 3.5 .51 3.3 .62
1400 7.1 .10 6.4 .20 5.9 .32 5.6 .44 5.3 .56 5.0 .68 4.8 .78
1800 9.1 .14 8.5 .30 8.0 .46 7.6 .62 7.3 .78 7.0 .95 6.7 1.1
4101 Models
PSI 0 25 50 75 100 125 150
RPM GPM HP GPM HP GPM HP GPM HP GPM HP GPM HP GPM HP
1800 5.0 .11 4.8 .21 4.5 .34 4.2 .45 3.9 .56 3.7 .68 3.4 .78
2200 6.2 .14 5.8 .27 5.6 .40 5.4 .55 5.0 .68 4.7 .82 4.4 .96
2600 7.2 .16 6.9 .30 6.6 .46 6.4 .62 6.0 .76 5.7 .92 5.4 1.08
Series
6500
Series
7700
Series
7560
Series
1700
Series
1500
Series
1200
PSI 0 50 100 150 200
RPM GPM HP GPM HP GPM HP GPM HP GPM HP
540 25.0 .27 21.0 1.18 19.0 2.13 17.0 2.89 15.0 3.85
600 28.0 .34 24.5 1.39 22.0 2.36 20.0 3.34 18.0 4.39
1000 45.0 1.42 43.0 3.0 41.0 4.67 39.0 6.07 - -
PSI 0 50 100 150 200
RPM GPM HP GPM HP GPM HP GPM HP GPM HP
540 14.2 .23 12.9 .56 11.9 1.10 11.2 1.64 10.3 2.22
600 15.3 .28 14.0 .62 13.0 1.20 12.3 1.80 11.6 2.44
800 22.1 .37 20.7 .86 19.5 1.66 18.6 2.40 17.8 3.26
BAR 0 1.7 3.4 5.2 6.9 8.6 10.3
RPM LPM HP LPM HP LPM HP LPM HP LPM HP LPM HP LPM HP
1800 18.9 0.11 18.1 0.21 17.0 0.34 15.9 0.45 14.8 0.56 14.0 0.68 12.9 0.78
2200 23.5 0.14 21.9 0.27 21.2 0.4 20.4 0.55 18.9 0.68 17.8 0.82 16.6 0.96
2600 27.3 0.16 26.1 0.3 25.0 0.46 24.2 0.62 22.7 0.76 21.6 0.92 20.4 1.08
BAR 0 1.7 3.4 5.2 6.9 8.6 10.3
RPM LPM HP LPM HP LPM HP LPM HP LPM HP LPM HP LPM HP
1100 20.8 0.06 18.5 0.14 16.6 .24 15.5 0.34 14.4 0.41 13.2 0.51 12.5 0.62
1400 26.9 0.1 24.2 0.2 22.3 0.32 21.2 0.44 20.1 0.56 18.9 0.66 18.2 0.78
1800 34.4 0.14 32.2 0.3 30.3 0.46 28.7 0.62 27.6 0.78 26.5 0.95 25.4 1.1
BAR 0 3.4 6.9 10.3 13.8 17.2 20.7
RPM LPM HP LPM HP LPM HP LPM HP LPM HP LPM HP LPM HP
540 45.4 0.33 42 0.74 39 1.25 36 1.77 32.5 2.26 29.5 2.78 26.9 3.3
800 69.3 0.89 66.2 1.26 64 1.95 60.9 2.65 58.7 3.4 54.9 4.2 51.9 4.9
1000 85.2 1.56 83.3 1.78 80.6 2.53 78 3.5 75.7 4.2 71.5 5.3 68.1 6.1
BAR 03.4 6.9 10.3 13.8
RPM LPM HP LPM HP LPM HP LPM HP LPM HP
540 94.6 0.27 79.5 1.18 71.9 2.13 64.3 2.89 56.8 3.85
600 106 0.34 92.7 1.39 83.3 2.36 75.7 3.34 68.1 4.39
1000 170 1.42 163 3.00 155 4.67 148 6.07 - -
BAR 0 1.7 3.4 6.9 10.3
RPM LPM HP LPM HP LPM HP LPM HP LPM HP
540 125 0.51 112 1.02 105 1.45 92 2.48 79.5 3.54
600 139 0.66 127 1.15 120 1.68 107 2.78 94.6 3.95
1000 235 2.02 221 3.04 215 3.69 204 5.31 193 7.12
PSI 30 50 100 150
RPM GPM HP GPM HP GPM HP GPM HP
540 - - 48.8 2.70 44.2 4.47 41.0 6.17
600 - - 54.3 3.12 50.5 5.05 47.0 6.94
800 74.0 4.0 72.5 5.08 69.5 7.31 67.0 9.60
Metric
American Standard
4001 Models
PSI 0 50 100 150 200 250 300
RPM GPM HP GPM HP GPM HP GPM HP GPM HP GPM HP GPM HP
540 9.7 .08 8.0 .38 7.2 .68 6.6 .97 5.6 1.29 4.9 1.65 4.3 1.91
1000 18.2 .20 16.5 .71 15.4 1.26 14.7 1.80 14.0 2.34 13.4 2.91 12.7 3.47
1200 21.8 .30 20.1 .90 19.1 1.51 18.2 2.14 17.3 2.84 16.5 3.48 15.7 4.17
PSI 0 50 100 150 200 250 300
RPM GPM HP GPM HP GPM HP GPM HP GPM HP GPM HP GPM HP
540 12 .33 11.1 .74 10.3 1.25 9.5 1.77 8.6 2.26 7.8 2.78 7.1 3.3
800 18.3 .89 17.5 1.26 16.9 1.95 16.1 2.65 15.5 3.4 14.5 4.2 13.7 4.9
1000 22.5 1.56 22 1.78 21.3 2.53 20.6 3.5 20 4.2 18.9 5.3 18.0 6.1
BAR .3 .5 1 1.5
RPM LPM HP LPM HP LPM HP LPM HP
540 - - 184.7 2.01 167.3 3.33 155.2 4.60
600 - - 205.5 2.33 191.2 3.76 177.9 5.18
800 280.1 2.98 274.4 3.79 263.1 5.45 253.6 7.16
Series
4000
16
Roller Pump Performance Chart

Quick Couplers
(Female to Female)
Part Number PTO (I.D.) Pump End (I.D.) Material RPM Pump Model
1320-0015 3/4" 5/8" steel * 4000, 6500
1320-0016 5/8" 5/8" steel * 4000, 6500
1320-0022 13⁄8" (6 spline) 5/8" die cast 540 6500
1320-0033 13⁄8" (6 spline) 15/16" die cast 540 1500, 1700, 7560, 7700
1320-0038 13⁄8" (21 spline) 15/16" die cast 1000 1500, 1700, 7560
1320-0053 13⁄8" (21 spline) 5/8" die cast 1000 4000, 6500
1320-0054 3/4" 15/16" die cast *1500, 1700, 7560,7700
1320-0059 13⁄8" (6 spline) 1" die cast 540 1200/5200
1320-0076 13⁄8" (6 spline) 15/16" forged steel 540 1500, 1700, 7560, 7700
1320-0077 13⁄8" (6 spline) 5/8" forged steel 540 6500
1320-0078 13⁄8" (21 spline) 15/16" forged steel 1000 1500, 1700, 7560
1320-0079 13⁄8" (21 spline) 5/8" forged steel 1000 4000, 6500
1320-0080 13⁄4" (20 spline) 15/16" forged steel 1000 1500, 1700, 7560
1320-0081 13⁄8" (6 spline) 1" forged steel 540 1200/5200
Part Number PTO (I.D.) Pump End (I.D.) Material RPM Pump Model
1321-0006 13⁄8" (6 spline) 5/8" die cast 540 6500
1321-0007 13⁄8" (6 spline) 15/16" die cast 540 1500, 1700, 7560, 7700
1321-0008 13⁄8" (21 spline) 5/8" die cast 1000 4000, 6500
1321-0009 13⁄8" (21 spline) 15/16" die cast 1000 1500, 1700, 7560
1321-0012 13⁄8" (multi-speed) 5/8" die cast 540/1000 4000, 6500
1321-0013 13⁄8" (multi-speed) 15/16" die cast 540/1000 1500, 7560, 7700
1323-0072 13⁄8" (6 spline) 15/16" forged steel 540 1500,1700, 7560, 7700
1323-0073 13⁄8" (21 spline) 15/16" forged steel 1000 1500, 1700, 7560
1323-0074 13⁄8" (6 spline) 5/8" forged steel 540 6500
1323-0075 13⁄8" (21 spline) 5/8" forged steel 1000 4000, 6500
1323-0076 13⁄8" (multi-speed) 15/16" forged steel 540/1000 1500, 1700, 7560
1323-0077 13⁄8" (multi-speed) 5/8" forged steel 540/1000 4000, 6500
List of Dimensions — Hypro Adapters
PTO Adapters
(Female to Female)
17
* Refer to the recommended pump rpm.

Use a SilverCast™, Ni-Resist, or cast iron
pump, Super Rollers and Viton.seals
NOTE: For weed control chemicals containing
glyphosate (such as Roundup®) or other
acidics, use only a SilverCast pump with Super
or polypropylene rollers and Viton seals. Teflon
rollers may be used up to 100 psi.
Use a SilverCast, Ni-Resist or cast iron pump with Super
Rollers. Use Viton or leather seals.
Use a SilverCast or Ni-Resist pump with
polypropylene rollers and Buna-N seals.
Use a SilverCast, Ni-Resist or cast iron pump, Super,
rubber or polypropylene rollers and
Buna-N or Viton seals.
NOTE: Limit pressure to 100 psi
when using rubber rollers
or wettable powders.
Use SilverCast pump, Viton seals, polypropylene or
Teflon rollers.
NOTE: Limit pressure to 100 psi
when using Teflon rollers.
WEED CONTROL
CHEMICALS
INSECT CONTROL
BRUSH CONTROL
PEST CONTROL
CHEMICALS,
FUMIGANTS, ETC.
LIQUID FERTILIZERS
POWDERED
FERTILIZERS
PUMPING
SPRAYING
MATERIAL HANDLING
ACIDS
Emulsions, soluble powders,
sodium arsenate.
Emulsions not containing
aromatic solvents.
Heavy-duty sprays using
diesel oil for carrier.
This category or use includes mosquito
sprays, termite control liquids,
nematocides, soil and grain fumigants
where any of the following chemicals
with aromatic solvents are present:
Pentachlorophenol, xylene, xylol, ben-
zene, high sulphur fuel or diesel oil.
Fumigants containing: ethylene
dichloride, ethylene dibromide, carbon
tetrachloride, perchlorethylene,
trighlorethylene, methyl bromide, and
other aromatic solvents.
Up to 32% nitrogen content, or others
if the liquid is at atmospheric pressure
and the temperature is handled.
Fertilizers dissolved in water
(greenhouse plant food).
Large quantities of plain water.
Wettable powder sprays.
Heavy abrasive powders in suspension.
Mild sulfuric acid for spraying. Mild muri-
atic acid, inhibited muriatic, etc.
Application Specific Chemicals Suggested Pump, Rollers and Seals
Material options for rollers and seals are
listed in the order of recommendations for
usage. These recommendations are only a
general guide. For suggestions on specific
chemicals or applications, call Hypro’s
Technical/Applications Department at
[phone].
WHAT
Roller Pump, Rollers and Seals
SHOULD YOU USE?
18

• NOTES •
19

Hypro (“Hypro”) warrants to the original purchaser of its products (the “Purchaser”) that such products will be free from defects in mate-
rial and workmanship under normal use for the period of one (1) year for all products except: oil crankcase plunger pumps will be free
from defects in material and workmanship under normal use for the period of five (5) years, and accessories will be free from defects in
material and workmanship under normal use for the period of ninety (90) days. In addition, Hypro warrants to the purchaser all forged
brass pump manifolds will be free from defects in material and workmanship under normal use and from damage resulting from environ-
mental conditions for the life of the pump.
“Normal use” does not include use in excess of recommended maximum speeds, pressures, vacuums and temperatures, or use requir-
ing handling of fluids not compatible with component materials, as noted in Hypro product catalogs, technical literature, and instructions.
This warranty does not cover freight damage, freezing damage, normal wear and tear, or damage caused by misapplication, fault, negli-
gence, alterations, or repair that affects the performance or reliability of the product.
THIS WARRANTY IS EXCLUSIVE. HYPRO MAKES NO OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIM-
ITED TO ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Hypro’s obligation under this warranty is, at Hypro’s option, to either repair or replace the product upon return of the entire product to the
Hypro factory in accordance with the return procedures set forth below. THIS IS THE EXCLUSIVE REMEDY FOR ANY BREACH OF
WARRANTY.
IN NO EVENT SHALL HYPRO BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, WHETHER
FOR BREACH OF ANY WARRANTY, FOR NEGLIGENCE, ON THE BASIS OF STRICT LIABILITY, OR OTHERWISE.
Return Procedures
All pumps or products must be flushed of any chemical (ref. OSHA Section 0910.1200 (d)(e)(f)(g)(h) and hazardous chemicals
must be labeled before being shipped* to Hypro for service or warranty consideration. Hypro reserves the right to request a
Material Safety Data sheet from the Purchaser for any pump or product Hypro deems necessary. Hypro reserves the right to “disposition
as scrap” pumps or products returned which contain unknown substances, or to charge for any and all costs incurred for chemical test-
ing and proper disposal of components containing unknown substances. Hypro requests this in order to protect the environment and
personnel from the hazards of handling unknown substances.
For technical or application assistance, call the Hypro Technical/Application number: 1-800-445-8360.
To obtain service or warranty assistance, call the Hypro Service and Warranty number: 1-800-468-3428;
or call the Hypro Service and Warranty FAX: [phone].
Be prepared to give Hypro full details of the problem, including the following information:
1. Model number and the date and from whom you purchased your pump.
2. A brief description of the pump problem, including the following:
•Liquid pumped. State the pH and any non-soluble • Drive type (gas engine/electric motor; direct/belt drive;
materials, and give the generic or trade name. tractor PTO) and rpm of pump.
• Temperature of the liquid and ambient environment. • Viscosity (of oil, or other than water weight liquid).
• Suction lift or vacuum (measured at the pump). • Elevation from the pump to the discharge point.
• Discharge pressure. • Size and material of suction and discharge line.
• Size, type, and mesh of the suction strainer. • Type of spray gun, orifice size, unloader/relief valve.
Hypro may request additional information, and may require a sketch to illustrate the problem.
Contact the factory to receive a return material authorization before sending the product. All pumps returned for warranty work should
be sent shipping charges prepaid to:
HYPRO
Attention: Service Department
375 Fifth Avenue NW
New Brighton, Minnesota 55112-3288
*Carriers, including U.S.P.S., airlines, UPS, ground freight, etc., require specific identification of any hazardous materials being
shipped.
Failure to do so may result in a substantial fine and/or prison term. Check with your shipping company for specific instructions.
Printed in the USA
2004 Hypro
Limited Warranty on Hypro Roller Pumps
