Introduction
1Introduction
Thank you for choosing our product. We hope you will enjoy using the device.
HyQuest Solutions manufactures, sells, installs and operates quality instrumentation, data loggers and communication
technology. Products are designed with passion for environmental monitoring and with a deep understanding of the
quality, accuracy and robustness needed to fulfil the requirements of measurement practitioners in the field.
The present User Manual will help you understand, install and deploy the device. If, however, you feel that a particular
information is missing, incomplete or confusing, please do not hesitate to contact us for further support!
The OSS-B1 universal current meter is a field-proven instrument for measuring the velocity of water in open and closed
channels. It is used for point measurements of flow velocities on the water surface or in vertical profiles down to the
riverbed at flow speeds of 0.025 m/s to 10 m/s.
One of the great features of the OSS-B1 is it can be used with 20 mm diameter wading rod and relocating device,
streamlined suspension tube, portable winches and permanent cableway installations, with streamlined or ground feeling
weights. A tail fin assembly is provided to control directional stability during suspended measurements.
The OSS-B1 comes with lots of accessories which enable the user to endure water flow measurement easily and
accurately.
All current meters manufactured by Hyquest Solutions are calibrated in our purpose built high velocity rating tank prior
to shipment. This rating tank is considered as best in the world since it can run at a velocity of 0.005 m/s minimum and 8
m/s maximum with a velocity resolution of +/- 0.001 mm
As part of our service we are able to recondition and recalibrate current meters of any make, including electromagnetic
and other solid state meters. Calibration is directly traceable to International Standards.
All current meters are calibrated in accordance with AS 3778.6.3-1992. This standard is identical with and has been
reproduced from ISO 3455:1976.
The purpose of this manual is to make the user familiar with the OSS-B1 current meter. It is a sensitive and reliable
precision instrument. It is advisable to read this manual carefully and fully understand its use. After reading this manual if
you are not sure about any details, please do not hesitate to contact our office (contact details are on the cover of this
manual).

© 2022 HyQuest Solutions 7
Installation
2Installation
This chapter contains the following subsections:
§ Unpacking your OSS-B1 Current Meter
2.1 Unpacking your OSS-B1 Current Meter
This package should contain:
§ OSS-B1 Body
§ OSS-B1 Lead
§ Body Key
§ Fan type A (Fan type 1,2 and 4 are accessories)
§ 3 wading rods 1.8m (3 sections) or 3.00m (3 sections)
§ CMC20A, PVD100 or CMC3 counter
§ 2 spare bearings
§ 1 reed switch
§ Screwdriver (Short)
§ Screwdriver (Small)
§ O-Rings for (fan carrier-1, reed switch cover -2, lead-1, terminal post-1)
§ Post ground
§ 1 oil bottle
§ Rating Tables
Note: Tail Fin Stem Assembly and other accessories are supplied on request.
7

© 2022 HyQuest Solutions 8
Operation
3Operation
One impulse signal is produced per Fan revolution. As shown in figure1 below, this signal is generated by an encapsulated
reed switch (1) which resides inside the meter body (2) and a permanent magnet (3) set into the rotating Fan assembly. A
cover sealed with two O-rings provides a water-tight housing for the reed switch, while gold plated contact pins ensure
low-resistance signal passage.
The voltage must not exceed 9V DC. Provided the impulse counters have spark-suppression circuits, the meter can be
loaded with up to 1.6 watts. All our counters meet these requirements (refer to specification).
Four type of stainless steel Fans (4) can be used with this meter, all these Fans are supported on bearings which run within
the oil filled hub of the Fan assembly. The capillary oil passage between the stainless steel axle (5) and Fan carrier (6),
prevents entry of water to the bearings. A locknut on the shaft locates the bearings and sets the end float of the assembly.
Figure 1

© 2022 HyQuest Solutions 9
Operation
Figure 2
Figure 3
Figure 4

© 2022 HyQuest Solutions 10
Maintenance
4Maintenance
The maintenance of the OSS-B1 current meter can be divided in three sections as stated below.
Section 1: Prior to discharge measurements
Initial set up
§ Open the case and pick up the Fan assembly.
§ Undo the fan carrier.
§ Remove fan carrier and shaft assembly (do not put it down anywhere it may attract dirt particles).
§ Hold the fan upright and ¾ fill with oil.
§ Replace the oil bottle cap.
§ Replace axle and fan carrier, excess oil will be forced up through the capillary gap around the axle, ensure fan carrier
is tightened.
§ Wipe the excess oil of the meter using lint free paper towel.
§ Do not forget to close the oil bottle straight after usage to avoid contamination of the oil.
§ Slide the fan assembly into the body and use the stubby screwdriver to tighten the retaining screw to lock the fan
assembly in place.
§ Prior to spin test hold the current meter in the horizontal position and spin by hand for approx. one minute to get
rid of the hydraulic pressure.
§ Spin test the meter against time. This is required to test the performance of the shaft and bearings.
§ Spin test results are dependent on the fan type and temperature (see table below).
OSS-B1 Spin Test
Fan No.
Time (sec)
A
Minimum 110 sec
1
Minimum 85 sec
2
Minimum 70 sec
4
Minimum 90 sec
§ After the spin test is performed connect your current meter to the counter using the lead, this important to test the
lead, reed switch and counter.
Section 2: During and after Discharge Measurements
After every discharge measurement, or one hour of use the current meter should be cleaned and refilled with oil, if
continuing a discharge measurement.
§ Spin test meter.
§ Undo the cleaning jar cap and ¾ filling with white spirit.
§ Remove fan assembly from meter body by undoing the retraining screw and separating the body from the fan.
§ Remove fan carrier and shaft assembly (do not put it down anywhere it may attract dirt particles).
§ Empty the old oil in a recycling container (do not tip oil on the ground this will pollute the environment).
§ Put the shaft and bearing assembly into the cleaning jar.
§ Agitate them.
§ Fill up the fan with white spirit put your thumb in place of carrier and shake it really hard for a few seconds.
§ Blow dry the shaft assembly, fan carrier and fan.
§ Re-assemble the fan, if discharge measurement is finished.
§ Wipe box clean and return the fan assembly to the case.
§ If continuing a discharge measurement, Refill the fan with oil as per section 1.
§ Spin test the current meter at per section 1.
§ Repeat all the above steps for every discharge measurement.
§ Tip the white spirit in a spare bottle.
Note: Both oil and white spirit can be recycled using filter papers.

© 2022 HyQuest Solutions 11
Maintenance
Section 3: Tips for Easy Maintenance
It is advisable that the user maintain the OSS-B1 current meter at all time.
§ Keep the OSS-B1 case clean.
§ Clean all the tools after usage.
§ Use lint free paper towels and white spirit (do not use methylated).
§ Office service is required for the OSS-B1 current meter about once a month if it is used on a daily basis (i.e. Fully
dismantle shaft assembly, fan carrier and fan; Clean each item using hot soapy water and then rinse with white spirit).
§ Check the lead and new the ends connections.
§ If the current meter fails the spin test refer to the mechanical fault finding section for details.
§ Test lead, counter and reed switch (see electrical fault finding section for details).
For more information, see the following subsection:
§ Service and Recalibration
4.1 Service and Recalibration
§ Recalibrate the current meter every 300 hours of use or once a year whichever comes first (see Hyquest Solutions
calibration certificate for details).
§ For recalibration only, send the body and the fans that require calibration (to save weight). However, if other items
needs repair they can be sent with the body and fans.
Note: Hyquest Solutions provides a recalibration and repair service for most types of current meters.
12
12
11

© 2022 HyQuest Solutions 12
Troubleshooting
5Troubleshooting
Mechanical Fault Finding
Symptom
Possible Causes
Action
Remark
Failed spin test
§ Dirty or faulty
bearings.
§ Clean Bearings and try to spin
test again. If Problem persists
replace bearings.
§ Dirty bearings can be
identified towards the end of
the spin test when the fan
stops suddenly.
§ Bent shaft.
§ If the shaft is slightly bent
return to HS for repair.
§ If the shaft is very bent return
to HS for replacement.
§ Bent shaft can be identified by
looking at the pointed centre
of the fan during spin test. If
this point is turning off-centre
this indicates that the shaft is
bent.
Electrical Fault Finding
If an electrical fault has been traced to the current meter, the following conditions should be checked using a multi-meters
or impulse counter.
Faults will be either CLOSED CIRCUIT or OPEN CIRCUIT, and if the CMC-20A counter is used, set the control switches to
“ON” and “INT” (ie. no time limit). Spin the Fan and if the audible signal sounds continuously, the fault is a “CLOSED
CIRCUIT”. If no audible signal is heard, the fault then is an “OPEN CIRCUIT”.
Closed Circuit Fault
Symptom
Possible Cause
Action
Fault occurs only when meter in
water.
§ Water entering contact plug
receptacle and earth between plug
and body
§ Replace damaged plug or missing
seal (see figure 7)
Circuit closed in any magnet position,
but open with magnet removed.
§ Reed switch failed
§ Replace reed switch assembly
(Figure 3 )
Circuit closed without magnet in
position.
§ Reed switch damaged
§ Water damaged during handling
allowing contacts to earth onto
meter body
§ Replace reed switch assembly
§ Remove reed switch (Figure 3
No.1) and insulated contact
assembly (Figure 3 No 8). Drain
or wipe away water. Flush with
alcohol or methyl. Spirits, then air
dry. Apply silicone grease to
contact surfaces and thread on
insulating sleeve before replacing.
Check damaged O-rings (Figure
3No 9 and10) replace. Apply
silicon grease before fitting.
§ Check for damage to spigot
through reed switch assembly.
Return to factory for repairs.
9
9
9
9

© 2022 HyQuest Solutions 13
Troubleshooting
Open Circuit Fault
Symptom
Possible Cause
Action
Open circuit between plug (11) and
insulated reed switch contact (8)
(Figure 3 ).
§ Faulty plug contact.
§ Faulty insulated contact assembly
(8) (Figure 3 ).
§ Check fit of plug in hole.
§ Remove, wipe surface clean and
check spring compression. Re-
assemble with silicone grease on all
surfaces.
No closure of reed switch contact
when magnet in position.
§ Damaged Reed Switch Assy.
§ Replace.
Reed switch operating but signal not
passing to body.
§ Faulty earth contact (12) (Figure
3).
§ Check spring compression. Remove
assembly and wipe clean contact
surfaces with silicon grease and re-
assemble.
99
9

© 2022 HyQuest Solutions 14
Repair
6Repair
HyQuest Solutions precision instruments and data loggers are produced in quality-controlled processes. All HyQuest
Solutions production and assembly sites in Australia, New Zealand and Europe are ISO 90001 certified. All equipment is
factory tested and/or factory calibrated before it is shipped to the client. This ensures that HyQuest Solutions products
perform to their fullest capacity when delivered.
Despite HyQuest Solutions most rigorous quality assurance (QA), malfunction may occur within or outside of the warranty
period. In rare cases, a product may not be delivered in accordance with your order.
In such cases HyQuest Solutions’ return and repair policy applies. For you as a customer, this means the following:
1. Contact HyQuest Solutions using the Repair Request Form made available online:
https://www.hyquestsolutions.eu/fileadmin/Form/Telemetry_Solution_app.jpg.pdf
In response you will receive a reference number that must be referenced on all further correspondence and on the
freight documents accompanying your return shipment.
2. Please provide as much information and/or clear instructions within the return paperwork. This will assist our test
engineers with their diagnosis.
3. Please do not ship the goods prior to obtaining the reference number. HyQuest Solutions will not reject any
equipment that arrives without reference number; however, it may take us longer to process.
Custom requirements for items sent to HyQuest Solutions for warranty or non-warranty repairs: Check with your
national customs/tax authorities for details, processes and paperwork regarding tax exempt return of products. Typically,
special custom tariff codes are available (such as HS Code = 9802.00) that verify the item is being returned for repair and
has no commercial value. Please note that the customs invoice / dispatch documents should also clearly state: “Goods
being returned to manufacturer for repair – No Commercial value”. It is mandatory to have any returned goods
accompanied by a commercial invoice on headed paper. HyQuest Solutions reserves the right to charge the customer for
time spent rectifying incorrect customs documents.
Note: Please ensure that your goods are packed carefully and securely. Damage that occurs during transit is not covered
by our warranty and may be chargeable.
For more information, see the following subsections:
§ Replacement of Cable Ends
§ Part List
6.1 Replacement of Cable Ends
Impulse Counter End and Complete Repair
14
17

© 2022 HyQuest Solutions 15
Repair
a. Strip back 140 mm of main cable insulation (1) after
shortening to new length.
b. Expose 5 mm of conductor (2) and twist strands
tightly, then solder.
c. Slide on heat shrink sleeve (3), red and black
identifying sleeves (4) and plug covers (5).
d. Push soldered conductors into plugs (6) and lock
with grubscrew (7).
e. Bring cover forward over plugs.
f. Position heat shrink sleeve centrally over grey cable
insulation and fix in place
Note: Repair to either plug end individually can be made
also, by only cutting away the damaged end and
following steps b, d & e.
Figure 5

© 2022 HyQuest Solutions 16
Repair
Current Meter Ends and Complete Repair
a. Shorten cable (1) to new length and strip outer
insulation (2) to 140mm (red plug end) and 120mm
(black plug end).
b. Expose 5mm of conductors (3) and twist strands
tightly, then solder.
c. Slide on heat shrink sleeve (4) red (5), and black (6)
identifying sleeves.
d. On the positive (+) end, push plug cap (7), washer (8),
rubber bush (9) and plug holder (10) over cable.
e. Lock conductor into plug pin (11), then slide back
into plug holder and screw plug cap into place.
f. Fit rubber seal (12) to plug pin.
g. For the negative (-) end, slide on black heat shrink
tube (13). Push conductor into the earth pin (14) and
solder in place. Bring heat shrink sleeve forward
onto earth pin and fix down with heat.
h. Fix down heat shrink sleeve (4) over main cable
termination.
i. Repairs can be made individually to the positive (+)
end with steps 2, 4, 5, and 6 and to the negative (-)
end, by following steps 2 and 7. However, the
shortened ends of the cable might be difficult to
assemble conveniently onto the current meter, and
it is usually preferable to reconstruct the cable as
detailed in figure 6.
Figure 6

© 2022 HyQuest Solutions 17
Repair
6.2 Part List

© 2022 HyQuest Solutions 18
Repair

© 2022 HyQuest Solutions 19
Repair

© 2022 HyQuest Solutions 20
Repair
