HYT TC3600 User manual

1
THANK YOU!
We are grateful for your purchase of HYT product. We believe this easy–to-use
radio will provide you with dependable and reliable communications. This HYT
portable two-way radio is a precision device. Treat it with care, and you will enjoy
years of reliable operation.
MODELS COVERED IN THIS MANUAL
TC3600 VHF Radio
TC3600 UHF Radio

2
Contents
User Safety, Training, and General Information
Compliance with RF Energy Exposure Standards
Important Note: FCC Information
FCC Compliance
Precautions
Product Inspection
Battery Information
Accessory Installation
Battery
Antenna
Belt Clip
Earplug Cover
External Earphone/Microphone (optional)
Getting Started
Features and Operation
Turn on/off the radio
Adjust the Volume
Power-on Password (only for keypad mode)
Keypad Lock/Unlock (only for keypad mode)
Select Channel
Transmit
Receive
Monitor
Repeater/Talk Around
Repeater/ Reverse Frequency
Power Level
Scan
Call
Emergency ANI/Emergency Alert
Record
VOX Feature
Low Battery Alert
2-Tone/HDC1200 Selective Signalling
Troubleshooting Guide
Care and Cleaning
Optional Accessories
Frequency Chart

3
User Safety, Training, and General Information
READ THIS IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION
BEFORE USING YOUR HYT PORTABLE TWO-WAY RADIO.
Compliance with RF Energy Exposure Standards
Your HYT two-way radio is designed and tested to comply with a number of national and
international standards and guidelines (listed below) regarding human exposure to radio
frequency electromagnetic energy. This radio complies with the IEEE (FCC) and ICNIRP
exposure limits for occupational/controlled RF exposure environment at duty cycles of
up to 50% talk-50% listen and should be used for occupational use only. In terms of
measuring RF energy for compliance with the FCC exposure guidelines, your radio
radiates measurable RF energy only while it is transmitting (during talking), not when it
is receiving (listening) or in standby mode.
Note: The approved batteries supplied with this radio are rated for a 5-5-90 duty cycle
(5% talk-5% listen-90% standby), even though this radio complies with the FCC
occupational RF exposure limits at duty cycles of up to 50% talk.
Your HYT two-way radio complies with the following of RF energy exposure
standards and guidelines:
zUnited States Federal Communications Commission, Code of Federal Regulations;
47CFR part 2 sub-part J
zAmerican National Standards Institute (ANSI)/Institute of Electrical and Electronic
Engineers (IEEE) C95. 1-1992
zInstitute of Electrical and Electronic Engineers (IEEE) C95. 1-1999 Edition
zInternational Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998
zMinistry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radio
Frequency Electromagnetic Fields in the Frequency Range from 3KHz to 300GHz, 1999
zAustralian Communications Authority Radio communications (Electromagnetic
Radiation-Human Exposure) Standard 1999 (applicable to wireless phones only)
Operational Instructions and Training Guidelines
To ensure optimal performance and compliance with the occupational/controlled

4
environment RF energy exposure limits in the above standards and guidelines, users
should transmit no more than 50% of the time and always adhere to the following
procedures:
Transmit and Receive
To transmit (talk), push the Push-To-Talk (PTT) button; to receive, release the PTT
button.
Hand-held radio operation
Hold the radio in a vertical position with the microphone one to two inches (2.5 to 5 cm)
away from the lips.
Body-worn operation
zAlways place the radio in a HYT approved clip, holder, holster, case, or body
harness for this product. Use of non- HYT -approved accessories may exceed FCC
RF exposure guidelines.
zIf you do not use a HYT approved body-worn accessory and are not using the radio
in the intended use position in front of the face, then ensure the antenna and the
radio are kept one inch (2.5 cm) from the body when transmitting.
Antennas & Batteries
zUse only HYT approved, supplied antenna or HYT approved replacement antenna.
Unauthorized antennas, modifications, or attachments could damage the radio and
may violate FCC regulations.
zUse only HYT approved, supplied batteries or HYT approved replacement batteries.
Use of non- HYT -approved batteries may exceed FCC RF exposure guidelines.
Approved Accessories
For a list of HYT approved accessories, see the accessories page of this user manual or
visit the following website which lists approved accessories: http://www.hyt.com.cn.

5
Important note: FCC Information
FCC Compliance
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the

6
user is encouraged to try to correct the interference by one or more of the following
measures:
zReorient or relocate the receiving antenna.
zIncrease the separation between the equipment and receiver.
zConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
zConsult the dealer or an experienced radio/TV technician for help.
FCC Requirements
Your radio must be properly licensed by the Federal Communications Commission prior
to use. Your HYT Wireless dealer can assist you in meeting these requirements. Your
dealer will program each radio with your authorized frequencies, signaling codes, etc.,
and will be there to meet your communications needs as your system expands.
Precautions
zOnly qualified technicians are allowed to maintain this product.
zDo not use the radio or charge a battery in explosive areas such as coal gas, dust,
steam, etc.
zSwitch OFF the radio while refueling or parking at gas station.
zDo not modify or adjust this radio for any reason.
zDo not expose the radio to direct sunlight over a long time nor place it close to
heating source.
zDo not place the radio in excessively dusty, humid areas, or on unstable surfaces.
zStubby antenna especially suits communication in close quarters；While long and
fine antenna provides better communication quality and avoids any
uncomfortableness when wearing the radio on waist.
zThe communication range will be impacted in rainy or cloudy days or when you are
in forest.
Safety: It is important that the operator is aware of and understands hazards common
to the operation of any radio.

7
Supplied Accessories
Please carefully take the transceiver out of the box. We recommend that you confirm the
items listed in the following table are enclosed before discarding the box. If any items
are missing or have been damaged during shipment, file a claim with the carrier
immediately.
Available Accessories
Item Qty. (pcs)
Antenna* 1
Belt Clip 1
Strap 1
Battery 1
Desktop Charger 1
AC Adapter 1
Owner’s Manual 1
Declaration of Conformity* 1
*Notes:
① Frequency is marked on the color circle of the antenna. Red circle indicates UHF
and green indicates VHF. If frequency is not marked on the color circle, please
refer to the label on the main unit for details.
② Only for European market.
Battery Information (Take a keypad type model for example)
Initial use of the battery
The battery is not fully charged at the factory. Please charge the new battery before
initial use. In general, the battery should be charged for 12 hours before initial use,
which is suitable for Ni-Cd, Ni-MH or Li-ion battery charged with slow or rapid charger. It
is recommended to take this step during the first three times of use. When the battery
power is low, it needs to be charged.
Applicable Battery Packs
Charge only the HYT approved battery packs. Other batteries may burst and cause
personal injury.

8
Safety attention
1. Conductive metals including jewelry, key, etc, may result in short circuit, discharge,
generation of a large quantity of heat, or leakage when coming into contact with
battery contacts or electrodes. To avoid damage to articles or human injury, treat any
battery with care.
2. Do not short out the battery terminals or dispose of the battery in fire. Never attempt
to disassemble the battery. If discarded, the battery should be thrown into dedicated
battery recycle box.
Normal operation
★Please charge the battery indoor to ensure the optimal charging effect.
★In general, the battery can be removed if the charger indicator turns from red to
green.
★Turn off the radio when charging the battery inside the radio.
★Do not charge the battery if its power hasn’t been used up (if the power used up, the
radio will give alert tone), otherwise, the battery life will be shortened.
★Do not return fully charged batteries to the charger for an “extra boost”. This action
will significantly reduce cycle life.
To prolong battery life
★Battery performance will be greatly decreased under -20℃temperature. Please use
back-up battery in cold weather. The cold battery unable to work in this situation may
work under room temperature, so keep it for later use.
★The dust on the battery contact may affect the life cycle of the battery. Please use
clean dry cloth to wipe it before the insertion of the battery into the radio.
Battery storage notice
1. Due to the self-discharge, the battery which will not be used for a long time should
be stored after full charge to avoid the damage to the battery because of
over-discharge.
2. Take out the battery stored for about 6 months to charge it, to avoid the influence of
electrolyte over-discharge on battery capacity.
3. Notice the ambient humidity and temperature for the battery storage. Please store it
in cool dry area with room temperature, to decrease self-discharge.
Battery charging
When radio LED flashes red and three Beeps sound every 30 seconds after the battery
is installed, that means battery power is low. Please charge the battery.

9
You are recommended to use HYT-approved, supplied charger; Charger LED will
indicate the charging status.
1. Plug the power cable into the adapter.
2. Plug the DC socket of adapter into the DC jack on the rear of the charger.
3. Insert the battery or the radio with battery into the charger cup.
4. Plug the AC socket of adapter into an AC outlet.
5. Make sure that the battery connectors are in contact with the charging terminals; the
charger LED glows red and charging begins.
6. The charger LED glows green when the battery is fully charged in about 3 hours,
please remove the battery or the radio with battery from the charger.
*Notes: Charger LED may flash red if you put the battery into the charger, which is a
normal pre-charge process for the charger to protect the battery when the battery power
is low. It will turn to normal charge status (glow red) after 30 seconds.
LED Indication
Flashing red Low battery voltage
Red Charging
Green Fully charged

10
Accessory Installation (Take a keypad type model for example)
Battery
Attaching the battery:
Insert the two tabs on bottom of the battery into the slots at the bottom of the radio. Push
the top of the battery towards the radio until a click is heard. (See figure 1)
Fig. 1
Removing the battery:
Turn off the radio. Push the battery latch on the middle of the radio to remove the upper
side of the battery away from the radio and then remove the battery. (See figure 2)
Fig. 2
Antenna
Insert the threaded end of the antenna into the connector on top of the radio. Rotate the
antenna clockwise to fasten it.
Rotate the antenna counterclockwise to remove it. (See figure 3)
Battery Latch

11
Fig. 3
Belt Clip
Attaching Belt Clip:
Align the slot of the belt clip with the T-slot at the battery cover and press the belt clip
downwards until it is locked. (See figure 4)
Fig. 4
Removing the belt clip:
Press the disassembly release upwards with a key until it releases and then push the
belt clip upwards with your thumb to remove it. (See figure 5)
Fig.5
Earphone/Microphone Jack Cover
To remove the Earphone/Microphone jack cover, rotate the screw at the bottom of the
cover counterclockwise with a screwdriver until it is free. (See figure 6)
Disassembly Release
Attach Remove

12
Fig. 6
External Earphone/Microphone (Optional)
Insert the tab at the bottom of the earphone/microphone into the slot on the radio. (See
figure 7). Align the thumbscrew at top of the earphone/microphone with the hole on the
radio and turn it clockwise to fasten.
Fig. 7

13
Getting Started
(Keypad type model) (Non-keypad type model)
(1) Antenna
Used to transmit/receive signals.
(2) LED
The following table indicates LED mode and corresponding radio status:
LED Status
Not lit Standby
Green Receive
Red Transmit
Flashing green Scan
Flashing red Low battery voltage
Flashing orange Call waiting
(3) Channel Selector
Used to select wanted channel.
(4) Programmable key [A]
(5) Power/Volume Control Knob
Rotate the Power/Volume Knob clockwise until a “click” is heard to turn the radio on;
rotate fully counter-clockwise to turn the radio off. When the radio is on, turn the knob
to adjust volume.
(6)Battery Latch
Used to fasten the battery.
(7) Speaker
Used to output receiver audio and alert tones
(8) Microphone

14
Used to input voice audio
(9) External Jack
Used to connect with external earphone or programming cable.
(10) Belt Clip
Used to clip the radio on your belt
(11) Battery Pack
(12) PTT Button
Press and hold the PTT Button to transmit. Release the PTT Button to receive.
(13) Programmable Key [B]
(14) Programmable Key [C]
The following table shows the key function when:
•Short pressed
•Long pressed
Key Function Short Press Long Press
Emergency Alert Enable emergency Alert Disable emergency Alert
Monitor Disable monitor Monitor
Scan Enable/Disable scan Enable/Disable scan
Nuisance Delete Delete nuisance channel in
scan Delete nuisance channel in scan
Select High/Low
Power Select High/Low Power Select High/Low Power
Repeater/Talk
Around Select Repeater or Talk Around Mode
Select Repeater or Talk Around
Mode
Repeater/Reverse
Frequency Select Repeater or Reverse Frequency Mode
Select Repeater or Reverse
Frequency Mode
Call Transmit a Call Transmit a Call
Selective Call Transmit selective call or group call signalling (2-Tone)
or HDC shortcut key
Transmit selective call or group
call signalling (2-Tone) or HDC
shortcut key
Vibration Toggle Vibration On/off Toggle Vibration On/off
Record Enable/Disable Record
Function Enable/Disable Record Function
Play Toggle Record Playing On/off Toggle Record Playing On/off
Delete Delete the Current Message Delete the Current Message
Please contact your dealer for more details about the programmable keys.

15
(15) Function Keypad (See figure 8)
Exit: Used to return to the upper menu
Up key
Down key
Menu/Select Key: Used to enter menu mode. In menu mode, this key is used to select
options.
Fig. 8
(16) LCD Display
Used to indicate operation status of the radio.
(17) Numeric Keypad (See figure 9)
Used to input information to the program menu of the radio. (Only for a keypad type
model)
Fig. 9
Exit Up Down Menu/Select Key

16
Features and Operation
Turn On/Off the Radio
To turn the radio on, rotate the “Power/Volume” knob clockwise. An alert tone indicates
that the self-test of the radio completed successfully. The LED glows green during
power-up. If self-test fails and/or the selected channel is not set, you will also hear an
alert tone.
To turn the radio off, rotate the “Power/Volume” knob counterclockwise until a click is
heard.
Adjust the Volume
Rotate the “Power/Volume” knob to adjust the volume.
Power-on Password (Only for a keypad type model)
This radio offers password protection feature. “Password” will appear on LCD after
power on if password is set in the radio. The radio enters conventional mode after
entering 1-8 digit password.
Keypad Lock/Unlock (Only for a keypad type model)
Hold down key and then press “*” key in 2 seconds to lock the keypad. When the
keypad is locked, holding down key and then pressing “*” key in 2 seconds can
unlock the keypad. LCD displays “ ” icon when keypad is locked.
Select Channel
The radio provides 256 conventional channels (16 zones, 16 channels in each zone).
Some of the channels may be not programmed and can’t be used. Please contact your
dealer for more details.
Rotate the “Channel Selector” knob to select the wanted channel.
1. Select an appropriate zone. (Refer to “select zone” in Menu Mode).
2. Rotate “Channel Selector” knob until your wanted channel is selected.
Transmit
1. Turn on the radio.
2. Rotate the “Channel Selector” knob to select the wanted channel.

17
3. Make sure there is no activity on the channel.
4. Press the PTT button and speak into the microphone with your mouth 1- 2 inches
away from the radio. The LED glows red during transmission.
5. Release the PTT button to finish transmission.
Receive
1. Turn on the radio.
2. Rotate the “Channel Selector” knob to select the wanted channel.
3. Adjust the volume.
4. If vibration mode is set and a call is received, the radio will alert you with vibration
and no audio will be heard. The LED glows green during receiving.
5. When CTCSS/CDCSS or squelch tail elimination feature is set by your dealer:
•No squelch tail will be heard at the end of a received transmission when the
courtesy tone is disabled.
•A beep tone sounds at the end of a received transmission when the courtesy tone
is enabled.
Please contact your dealer for more details.
Monitor
1. Press MONI key to monitor the current channel.
2. Press MONI key again to exit.
3. Your dealer can set three monitor modes: Selective call monitor, CTCSS monitor
and Carrier monitor.
Selective call monitor: To prohibit selective call squelch;
CTCSS monitor: To prohibit all signaling squelch and open the speaker when carrier is
detected.
Carrier monitor: To prohibit all squelch and open the speaker.
Repeater/Talk Around
When you are out of the communication range of the repeater and within the
communication range of your group member, you can bypass the repeater and talk
directly to your group member.
Press the programmed “Repeater/Talk Around” key to select between “repeater” and

18
“talk around” mode. An alert tone indicates that radio is in talk around mode (simplex). A
different alert tone indicates that the radio is out of the talk around mode (duplex).
Repeater/Reverse Frequency
When you are out of the communication range of the repeater and within the
communication range of your group member, you can talk with your group member by
reverse frequency when your group member is still within the communication range of
the repeater.
Press programmed “Repeater/Reverse Frequency” key to select between “repeater” and
“reverse frequency”. An alert tone indicates that radio operates in reverse frequency
mode. A different alert tone indicates that the radio is out of the reverse frequency mode.
Note: “Repeater/Talk Around” and “Repeater/Reverse Frequency” cannot be set
simultaneously within one radio.
Power Level
Each channel of the radio can have different power levels that are user selectable.
•High power allows you to transmit greater distances.
•Low power helps to save battery life.
Press the programmed “power select” key to select high/low power. An alert tone
indicates when the power level is toggled.
Scan
Scan feature allows you to monitor all channels for activity.
When scan feature is enabled, the radio will detect all channels. If an active channel is
detected, the radio will remain on that channel while receiving (The dealer can program
a channel as scan item or non-scan-item).
Disable/Enable Scan Feature
1. Press the scan key to begin scanning.
2. Press the scan key again to stop scanning.
The LED flashes green in scan mode.
Callback
The radio will transmit on the callback channel if the PTT button is pressed while
scanning.

19
Please contact your dealer for more details about callback channel.
Nuisance Channel Delete
Nuisance channel delete feature allows you to temporarily delete an unwanted channel
from the scan list.
When the radio stops on the nuisance channel, press the programmed “nuisance delete”
key until an alert tone sounds to delete this channel.
When scan feature is enabled again, the deleted channel will return to the scan list.
Note: Priority channel cannot be deleted.
Priority Channel Scan
This feature allows you to scan important channels. The dealer can program a channel
as priority channel through the programming software.
Note: The radio will constantly monitor the priority channel when it stops on a
non-priority channel. If activity is detected on the priority channel, the radio will revert to
the priority channel and remain there as long as the channel stays active.
Please contact your dealer for more details.
Call
Press the programmed call key and the radio will send a preprogrammed signaling code
to compatible receivers with the same code. The compatible receiver sounds an alert
tone to draw the user’s attention.
Emergency ANI/Emergency Alert
The radio can be programmed to transmit an emergency ANI or emergency alert. ANI
can be DTMF or five-tone (set by your dealer).
If emergency alert is enabled, the radio will sound an audible alert at high volume.
1. Press the Emergency Alert key to enable Emergency Alert feature.
2. Press and hold the Emergency Alert key to disable Emergency Alert feature.
If the radio is programmed to transmit emergency ANI, press emergency key and then:
1. The radio transmits emergency ANI on the preprogrammed emergency channel. The
times of transmission and the interval time between every two transmission can be
set by your dealer.
2. The radio can receive signals during the interval time.

20
3. Emergency ANI will not be sent any more when emergency ANI transmission is
completed or when PTT key/Disable Emergency Key is pressed.
4. The radio will transmit/receive only on the emergency channel (set by your dealer)
after exit from the emergency ANI transmission mode until the radio is turned off and
back on.
5. In emergency mode, the radio can receive signals, and only PTT and Monitor key
are enabled.
6. In emergency mode, if vibration mode is set, the radio will toggle vibration off
automatically and output receiver audio through the speaker.
7. If the current transmit power is set as low, it will switch to high power automatically.
Record
Record and play can be performed when the radio is in receiving mode and no signal
appears.
Record
1. Press Record key or select Record feature in the menu to begin record.
2. When the memory is full and a new message is received, the oldest unprotected
message will be deleted. Unread message will not be deleted.
3. The radio stops recording when the record time elapses or any valid key is pressed
or when signal appears.
4. The radio can be set to delete all messages after power off (set by your dealer).
Play
1. Press Play key, the radio can play all the messages continuously starting from
newest to oldest. In the menu mode, you can select any message to play.
2. There is a one-second interval and an alert tone between two messages.
3. The radio stops playing when any valid key is pressed or signal appears. When all
the messages are played, the radio stops playing.
4. Press Delete key during playing to delete the selected message and continue to play
next one. You can select and delete a message through the menu mode.
The radio will sound an alert every two minutes to remind you of the new message.
Unread icon will be displayed. When all the new messages are played, the Unread icon
