Hyundai P230E User manual

1
HYUNDAI PCS CELLULAR PHONE
P230E
USER’S MANUAL
HYUNDAI ELECTRONICS INDUSTRIES., Ltd.
Mobile Telecommunications Division

2
Chapter 1
Prior to Use
➀Names and function of each part
➁Screen status display and function

3
Role of the function buttons
[TALK] This button is used when you make a call or receive a call.
.
[END] This button is used when you terminate a call or exit the current menu in the menu
[RCL] This button is used when you look up the list of stored phone numbers or names or
the phone number you just called.
[CLR] This button is used to clear the digits and/or text from the display or Memory.
[STO] This button is used to go to a lower level menu or to store the set parameter; put
phone number and names into memory or erase those that were input.
[*][# ] These buttons are scroll buttons which you use to select screen contents.
[PWR] This button is used to turn the handset on or off
[MENU] This button is used to select menu.
This button is used to select SMS service .
.

4
Screen status display and function
Signal strength
The strength of current signal is displayed with the number (0-5) of bar.
Roaming
This icon shows the user is outside the normal service area .
Service possible/impossible
When you are in an area where service possible, displayed.
When you are in an area where service is impossible, is displayed. Also when you are in
service, “in service icon” is displayed.
Voice or Character message service
Blinks when character or voice messages have been received.
Alarm
Blinks when alarm was played if user set alarm.
Balance of battery power
The balance of battery power available is displayed with the number (0~4) of bar.

5
Chapter 2
Basic operation
➀
➀➀
➀Menu structures
➁How to use menu function
➂How to use handset
➃Function in the call

6
●MENU STRUCTURE
Menu Submenu
1: BILLING
2: SETTING 1: AUTO RETRY
2: AUTO ANSWER
3: AUTO HYPHEN
4: DTMF LENGTH
5: ONE TOUCH
1: INTERVAL
2: REPEAT
1: SHORT
2: LONG
3: DISPLAY 1: DSPLY TIME
2: BANNER
3: LCD CONTST
4 :BACK LIGHT 1: AUTO LIGHT
2: LENGTH
4: VOLUME 1: RING TYPE
2: RINGER
3: EARPIECE
4: KEYPAD VOL
5: HANDSFREE
6: CONNECT V.
7: MY MELODY
LED
LED+BACKLIGHT
VIBRATOR
SILENT
VOLUME
1: EDIT
2: LISTEN
5: CALL TIMER 1: CALL TIME
2: ALARM
1: LAST CALL
2: ALL CALLS
3: HOME CALLS
4: ROAM CALLS
1: ACTIVATE
2: ALARM ONLY
3: ALARM CALL

7
Menu Submenu
6: BIO RHYTHM 1: TODAY BIO
2: SOMEDAY BIO
3: BIRTHDAY
7: ALERTS1: MIN ALERT
2: FADE ALERT
3: ROAM ALERT
4: LOW SIGNAL
8: PHONE INFO 1: PHONE #
2: PHONE VERSION
3: EVRC MODE
9: SECURITY 1: LOCK
2: RESTRICT
3: RESET
4: CLEAR
1: AUTO LOCK
2: CHANGE CODE.
1: INCOMING
2: OUTGOING
3: DIAL #
4: MEMORY ONLY
5: LONG DIST
6: 900#
1: STORED #S
2: ALARM
3: HOME CALLS
4: ROAM CALLS

8
Menu
RECALL MENU 1: PHONE BOOK
2: CALL LOGS
MENU IN CALLS 1: SEND PHONE #
2: SCRATCH PAD
3: MUTE
DIAL MENU
( DIAL BUTTON + [MENU]
BUTTON)
1:HARD PAUSE
2:TIME PAUSE
3:ONE HYPHEN
DIAL MENU IN CALLS 1:SEND PHONE #
2:HART PAUSE
3:TIME PAUSE
4:ONE HYPHEN

9
How to use Menu function
1. In a standby screen, press [MENU] button.
2. To move around the menu, use scroll buttons.
If you press the scroll button continuously, the menu
passes by automatically.
.
3. To go back to previous screen, press [CLR] button.
To exit menu screen, press [END] button.
4. To go to a lower menu, press appropriate number, or select
desired item by scroll button, and then press[STO]button.
5. [SMS],[RCL],[SEND] buttons can be used while using menu
function
♣
Please read this before you use your handset
Scroll buttons:[*▲],[#▼],volume[+],volume[-]
If there is lower menu, the lower menu will be
newly displayed.

10
How to use handset
How to turn the handset on
•Press [PWR]button until the lamp turn on
How to turn the handset off
•Press [PWR]button until the lamp turn on
!“REGISTERING...”message is displayed when the user presses PWR button.
This message indicates that the handset is registering the power off
information, and that
means mobile telecommunications service system does not have to search the
user.
!
!!
!
If the “LOW BATTERY WARNING POWER OFF”message is displayed and the
power goes off,
there is a possibility of damaging the memory. Therefore, in that
case, do not turn the power on, and change or charge the battery
immediately.
!
!!
!
When the power goes off when the battery is separated while it was
power on status,
the calling time, phone number previous call, and frequently used area
code might not get stored properly.
!Handset is in locking status if “Lock code”
is displayed on the screen.
When the lock code is displaying, enter a 4-digit
lock release number to unlock the handset.
then use.
!The default value of lock code is “0000”..
!If there is a lot of stored information, it
takes
