Hyundai HGC-610E User manual

REV. N00
http://www.hei.co.kr
USER MANUAL
USER MANUAL
HGC-610E
HEAD OFFICE & FACTORY
San 136-1, Ami-Ri, Bubal-Eup, Ichon-Si,
Kyoungki-Do, 467-701 Korea
International Sales Team
Mobile Handset Business Unit
9
th
Fl. HEI Bldg., 1451-34 Seocho-Dong,
Seocho-Ku, Seoul, 137-070 Korea
Tel:[phone] Fax:[phone]

TABLE OF CONTENTS
CHAPTER 1 BEFORE USING YOUR PHONE 1
Package Includes 2
Handset Description 3
Basic Functions 4
The Function Keys 4
Display Indicators 5
Screen Status, Display and Function 5
Using the Battery 6
Using the Battery 6
Removing the Battery 6
Charging the Battery 7
Power Connection 7
Charging the Battery Only 7
Charging the Battery with the Handset 8
Charging Completion 8
Status of Charger LED’s 9
Important Battery Information 10
CHAPTER 2 BASIC OPERATION 11
Turning the Phone On and Off 12
Turning the Phone On 12
Turning the Phone Off 12
How to Use the Menu 13
Menu Summary 14
Basic Functions 16
Making a Call 16
Pause Feature 17
How to Answer Calls 18
Auto Answer 18
Caller ID Function 18
Call Waiting Function 18
Missed Call Display 19
How to Adjust Volume 19
Vibrator 19
Functions During a Call 20
Sending Your Number to a Pager 20
Scratch Pad 20
Mute 21
[ i]

[iii][ii]
CHAPTER 3 MEMORY FUNCTION 23
How to Store a Phone Number 24
How to Enter Letters and Characters Using
the Dial Buttons 25
How to Make a Call Using A Stored Phone Number 26
One Touch/Two Touch Dialing 26
How to Find Your Call Logs 27
Missed Calls 27
Answered Calls 28
Dialed Calls 28
How to Find Your Phone Book 29
Recalling by Memory Location Number 29
Recalling by Name (Alpha) 30
CHAPTER 4 MENU 31
Settings 32
Auto Retry 32
Auto Answer 33
Backlight 33
LCD Contrast 34
Logo Display 34
Volume 35
Ring Mode 35
Ring Type 35
Key Pad 36
Ringer Volume 36
Timers 37
Last Call 37
All Calls 37
Roam Calls 37
Alerts 38
Min Alert 38
Roam Alert 38
Low Signal Alert 39
Connect Alert 39
TABLE OF CONTENTS (CONT’D.)
CHAPTER 5 SECURITY FEATURES 41
How to Lock Your Phone 42
Auto Lock 42
How to Change Lock Code 43
How to Change Your Banner 44
Banner change 44
How to Restrict Your Phone 45
Restriction Functions 45
Restrict Incoming Calls 45
Restricting Outgoing Calls 46
Restricting the Phone Book 47
Restricting Long Distance Calls 47
How to Reset Your Phone 48
How to Clear Your Phone Memory 49
Clearing Stored Phone Numbers 49
Clearing Schedule Contents 49
Memory Clearing Function 50
Clearing Dialed numbers in call logs 50
Clearing Roam Calls 50
Phone Info 51
Checking My Number 51
Checking the Phone Version 51
CHAPTER 6 SUPPLEMENTARY FUNCTIONS 53
Schdule 54
List All 54
Input Schedule 55
Pause All 56
My Melody 57
Write Melody 57
Hear Melody 58
Melody Speed 58
Stopwatch 59
Calculator 60
Bio-Rhythm 61
World Time 62
TABLE OF CONTENTS (CONT’D.)

Please read this chapter before using this product.
uPackage Includes
vHandset Description
wBasic Functions
xDisplay Indicators
yUsing the Battery
zCharging the Battery
{Important Battery Information
CHAPTER 1
BEFORE USING YOUR PHONE
[1]
CHAPTER 7 VOICE MAIL AND TEXT MESSAGES 63
Receiving a Message 64
Direct View Set 64
Direct View Release 64
Checking Received Message 65
Checking Received Voice Mail Message 65
Checking Received Text Message 66
Sending a message 67
DIrect View 68
Direct View Setting 68
Bell Type 68
Bell Type Setting 68
CHAPTER 8 SAFETY 69
Safety Information for Wireless Handheld Phones 70
Driving Safety 71
Electronic Devices 72
Other Safety Guidelines 74
Precautions 75
Warning 76
Safety Information for FCC RF Exposure 77
Cautions 77
TABLE OF CONTENTS (CONT’D.)
[iv]

[2] [3]
HANDSET DESCRIPTIONPACKAGE INCLUDES
Thank you for purchasing this product. Please check the product
contents by comparing them with the following pictures.
In case there are any product
defects, please report it to the place
of purchase immediately.
Handstrap
Standard Battery
User Manual
Desktop Charger
Handset
LED
Blinks when you
make a call or
receive a call
Volume Button
Used to adjust
the volume of
the earpiece and
ringer volume.
Antenna
For best call
quality, extend
the antenna
during the call
Earpiece
LCD Screen
Function
Keys
Keypad
Microphone

[4] [5]
DISPLAY INDICATORSBASIC FUNCTIONS
This key is used to make or receive a call.
This key is used to terminate a call or exit the
current menu. This key is used to turn the
handset on or off.
These keys are used to scroll through the
contents of the menu.
(Soft 1) This key is used to access the Menu
(Soft 2) This key is used to access voice or
text messages.
THE FUNCTION KEYS
Signal Strength
Indicates current signal strength. More lines mean
better signal strength.
Roaming
Indicates the Phone is outside of its home area.
Service Indicator
When a call is in progress, is displayed.
When is displayed, the phone is in idle mode.
When is displayed, the phone is not receiving a
signal from the system.
Message
Indicates a text message or voice mail message is
waiting.
Alarm
Indicates that the alarm is activated.
Battery
Indicates battery charge level status. The more black
you see, the greater the charge.
SCREEN STATUS, DISPLAY AND FUNCTION

[6] [7]
CHARGING THE BATTERYUSING THE BATTERY
uInsert the bottom of battery into the groove at
the bottom of the handset. Then vpress in the
top of the battery until it snaps.
USING THE BATTERY
REMOVING THE BATTERY
Push the tab uwith one hand and lift the top
of the battery vto separate.
The battery must be correctly placed in the battery com-
partment. If battery is incorrectly inserted, the handset
will not turn on or the battery may slip out during use.
Connect the charger to a standard 220V AC outlet.
LED will orange when the power is connected.
POWER CONNECTION
CHARGING THE BATTERY ONLY
• Battery is not charged when you purchase the product.
• Fully charge the battery before use.
To charge the battery only, insert the battery pack
charging slot on the charger.
LED will indicate charging status.
lRed indicates charging
lGreen indicates charging is complete
1
1
1
1
u
u
v
v

[8] [9]
CHARGING THE BATTERYCHARGING THE BATTERY
To charge the battery with the handset, insert
the handset into the charger.
CHARGING THE BATTERY WITH THE HANDSET
CHARGING COMPLETION
Charging is completed when the green-colored
LED stays on.
Charging the battery with the handset on
is less efficient than charging it with the
handset off.
1
1
STATUS OF CHARGER LED’S
If the red LED does not come on after the handset or
battery has been inserted into the charging slots, re-
insert or check power.
Charging on Safety Mode Charging in Progress Charging Completion
(Orange Color On) (Red Color On) (Green Color On)

[10] [11]
uTurning the Phone On and Off
vHow to Use the Menu
wMenu Summary
xBasic Functions
yFunctions During a Call
CHAPTER 2
BASIC OPERATION
Use only batteries and chargers approved by the phone manufacturer.
When a charger is not in use, disconnect it from the power source. Do
not leave the battery connected to a charger for longer than a week;
overcharging may shorten its life.
If left unused, a fully charged battery may completely drain (discharge)
in 1 - 4 weeks.
Never use any charger or battery that is damaged or worn out.
Use the battery only for its intended purpose.
Do not short circuit the battery. Accidental short circuiting can occur
when a metallic object (e.g. coin, clip or pen) causes direct connection
of the two terminals of the battery (metal strips on the back of the bat-
tery), for example, when you carry a spare battery in your pocket or
purse. Short circuiting the terminals may damage the battery or the
connecting object.
Leaving the battery in hot or cold places, such as in a closed car in
summer or winter conditions, reduces the capacity and lifetime of the
battery. Always try to keep the battery between 41ºF and 95ºF (5ºC
and 35ºC). A phone with a hot or cold battery may temporarily not work
(or charge) even if the battery is fully charged.
Temperature extremes affect the ability of your battery to charge; allow
it to cool down or warm up first.
When the battery is not in use, store it uncharged in a cool, dark and
dry place.
The battery is a sealed unit with no serviceable parts. Do not attempt
to open the case.
It is recommended that you allow your battery to fully discharge before
you recharge it.
The battery can be charged and discharged hundreds of times but will
eventually wear out. When the operating time is shorter than normal,
it is time to buy a new battery.
Do not dispose of a battery in a fire!
Dispose of used batteries in accordance with local regulations.
Recycle!
IMPORTANT BATTERY INFORMATION

[13][12]
HOW TO USE THE MENU
In the standby screen, press [ ]
In the menu, use scroll keys to view the menu
selections. If you press and hold the scroll
keys, the menu scrolls automatically.
Use the following to scroll:
[ ],[ ],[ ],[ ], volume [+], volume [-],
located on side of handset.
To go back to previous screen, press [ ]
key.To the exit menu, press [ ].
To go into submenu press the corresponding
number.
[ ], [ ], and [ ] can be used while
using the menu.
1
2
3
4
5
TURNING THE PHONE ON AND OFF
lPress and hold [ ].
lThe phone is locked if “LOCKED” is dis-
played on the screen. When “LOCKED” is
displayed, enter the 4-digit lock code to
unlock the phone.
lThe default lock code is the last 4 digits of
your phone number.
lPress and hold [ ] until “Good Bye!” is
displayed.
1
TURNING THE PHONE ON
TURNING THE PHONE OFF
1
• If the “LOW BATTERYWARNING POWER
OFF” is displayed and the power goes off,
there is a possibility of damaging the memory.
Change or charge the battery immediately
• If the battery is removed while the phone is
on, it may erase last call information.

MENU SUMMARY
5 : SPECIAL
6 : ALERT
0 : SECURITY u
u
u
PAUSES
1 : LIST ALL
2 : INPUT SCHEDULE
3 : PAUSE ALL
1 : WRITE MELODY
2 : HEAR MELODY
3 : MELODY SPEED
1 : TODAY
2 : SOMEDAY
3 : BIRTHDAY
1 : INCOMING
2 : OUTGOING
3 : MEMORY
4 : LONG DISTANCE
1 : CLR NUMBER
2 : CLR SCHEDULE
3 : CLR CALL LOGS
4 : CLR ROAM CALLS
1 : SCHEDULE
2 : MY MELODY
3 : STOPWATCH
4 : CALCULATOR
5 : BIORHYTHM
6 : WORLD TIME
1 : MIN ALERT
2 : ROAM ALERT
3 : LOW SIG ALERT
4 : CONNECT ALERT
1 : AUTO LOCK
2 : CHANGE CODE
3 : CHANGE BANNER
4 : RESTRICT
5 : RESET
6 : CLEAR
7 : PHONE #
8 : VERSION
MENU SUMMARY
1 : PHONE BOOK
2 : SETTING
3 : VOLUME
4 : TIMER u
u
u
u1 : MISSED CALL
2 : ANSWERED CALL
3 : DIALED CALL
1 : INTERVAL
2 : REPEAT
1 : CALL LOGS
2 : BY LOCATION
3 : BY NAME
1 : AUTO RETRY
2 : AUTO ANSWER
3 : BACKLIGHT
4 : LCD CONTRAST
5 : LOGO DISPLAY
1 : RING MODE
2 : RING TYPE
3 : KEYPAD
4 : RINGER VOLUME
1 : LAST CALL
2 : ALL CALLS
3 : ROAM CALLS
[15]
[14]

[16] [17]
BASIC FUNCTIONS
Enter phone number,
then press [ ].
Select desired pause.
Pause Definitions
lHARD PAUSE: If you enter
the pause character (P). the
number entered after the
Pause character will be sent
after the number dialed.
lPress [ ] to dial or [1] to
store.
- When Receiving call status;
1 : STORE
2 : SEND PHONE#
3 : SCRATCH PAD
4 : MUTE
5 : VIEW PHONE#
6 : HARD PAUSE
7 : ONE HYPHEN
- When idling status;
1 : STORE
2 : BY NUMBER
3 : HARD PAUSE
4 : ONE HYPHEN
1
PAUSE FEATURE
Pauses are used for automated systems (i.e., voice mail and
calling cards). To insert Pauses:
2
3
BASIC FUNCTIONS
Enter the phone number.
How to modify the phone number you
have entered:
lTo erase the last number entered:
Press [ ].
lTo erase all numbers entered and
start again: Press [ ] and hold
for more than half of a second.
Press [ ].
l“CALL FAILED” message is dis-
played when the call does not con-
nect.
lIf the line is busy, press [ ].
Retry by pressing [ ].
lIf you select the AUTO RETRY
function, the call will be retried
automatically for the time you have
selected.
Press [ ] to end the call.
1
MAKING A CALL
2
00:00:01
XXX-XXX-XXXX
MENU END
00:00:01
XXXPXXXXXXXXXP
MENU END
XXX-XXX-XXXX
CALL

[18] [19]
BASIC FUNCTIONS
Displays the number of missed
calls and the time the call was
missed.
lThe message will be
cleared when you press
the [ ] key or [ ].
1
MISSED CALL DISPLAY
Adjust volume by using the volume control keys
during the following operation.
lDuring a Call : Earpiece volume adjustment.
lStandby Status : Keypad volume adjustment.
lWhen the Phone Rings : Ringer volume
adjustment.
lCall status in hands-free : Hands-free volume
adjustment. Press [ ] when the phone
rings and it will mute the ringer.
1
HOW TO ADJUST VOLUME
You can adjust the volume in two ways: by using the volume
control keys on the side of the handset, or by using the menu.
BASIC FUNCTIONS
When there is an incoming call, the
caller’s phone number is displayed
on the screen.
This function notifies you there is an incoming call when you
are on the phone.
lTo answer the call, press [ ] when you hear the beep.
lTo switch back to the first caller, press [ ] again.
When phone rings or LED blinks press any key
except Volume or [ ].
To end the call, press [ ].
1
HOW TO ANSWER CALLS
AUTO ANSWER
2
If you set up the AUTO ANSWER function in
advance, the call will be answered after the
selected number of rings. (Refer to page 33)
This function allows an incoming.
To enable this function press [ ],[2],[2].
VIBRATOR
This function disables the ringer and vibrates the phone any time
an incoming call is in process. To enable this function press [ ],
[3],[1] and select VIBRATOR or by pressing the “up”and
“down”keys at the left upper side of the phone.
CALLER ID FUNCTION
The Caller ID number is saved in the call log.
CALL WAITING FUNCTION
MISSED
XX CALLS
PM XX:XX
PREV

[20] [21]
FUNCTIONS DURING A CALL
Press [ ], then [3] “Mute”.
1
MUTE
To unmute, press [ ],then[3] “Mute” again.
FUNCTIONS DURING A CALL
After calling a pager, when you are asked to
enter your number, press [ ] then [1]
“SEND PHONE #”.
While in a call press [ ], then [2]
“SCRATCH PAD”.
Enter the phone number, then press [ ].
1
SENDING YOUR NUMBER TO A PAGER
This function enables the phone number of the handset to be
transmitted automatically to a pager, depending on pager ser-
vice.
SCRATCH PAD
2
1
00:00:38
-MUTE-
XXX-XXXX-XXXX
REL
MENU

[23][22]
CHAPTER 3
MEMORY FUNCTION
uHow to Store a Phone Number
vHow to Make a Call Using a Stored Phone Number
wHow to Find Your Call Logs
xHow to Find Your Phone Book

[24] [25]
HOW TO STORE A PHONE NUMBER
HOW TO ENTER LETTERS AND CHARACTERS USING THE DIAL BUTTONS
Key Pad
1
2ABC
3DEF
4GHI
:
9WXYZ
1 Repetition
1
A
D
G
:
W
2 Repetitions
B
E
H
:
X
3 Repetitions
C
F
I
:
Y
4 Repetitions
2
3
4
:
Z
5 Repetitions
:
9
1. Select characters you wish to enter using the key pad.
HOW TO STORE A PHONE NUMBER
1
4
3
2
You can store up to 100 frequently used phone numbers in memory.
LOCATION:XX
XXX-XXXX-XXXX
Enter the phone number you want to store
and press [ ], then[1] “Store”
lThe first available Initial empty mem-
ory location number is displayed. If
there is no empty location,
“MEMORY SPACE IS FULL!” is dis-
played with a warning sound.
lIf there is a desired memory location
number, enter the number.
If the “OVERWRITE?” message appears
after entering the phone number, it means
there is another stored same phone num-
ber in that location already.
Select “YES/NO” and press [ ] “SEL”.
lYes: Deletes the previously stored
number and stores the new one.
lNo: Keeps the previously stored
number.
Enter the person’s name and press[ ].
lSearch mobile/office/home type and
then Press [ ].
To make secret, select Yes. It can then be
displayed only when the lock code is
entered.
lPress [ ] to toggle between upper and lower case.
lWhen entering special characters such as 0!.?,-
()‘’*#$_+[]&@, press [ ] repeatedly. The special charac-
ters will be displayed in order.
2. Press [ ] to enter the next character.
lCuser moves to the next columm automatically in two sec-
onds after the next character.
3. Repeat untill all the characters you want are entered.
lYou can store up to 16 characters.
4. Erasing Entry.
lTo erase one letter, press [ ].
lTo erase the entire entry, press and hold [ ].
OVERWRITE?
YES
MAKE SECRET
YES
PHONE_NUM TYPE
MOBILE
STO CLR
SEL PREV
SEL PREV
SEL PREV
VIEW LIST
▲
▼

[26] [27]
HOW TO MAKE A CALL USING A
STORED PHONE NUMBER HOW TO FIND YOUR CALL LOGS
Press [ ] then [1] then [1] then [1].
Press [ ] to check the detail
information about phone number.
lThe last missed call, its
phone number, time and
date are displayed.
To check your missed calls using the
scroll keys:
l[ ] or [ ]Scrolls up the phone
numbers.
l[ ] or [ ]Scrolls down the
phone numbers.
Press [ ] to dial desired missed call
number.
1
Your phone can display the 10 most recent missed, incoming,
outgoing calls. You can call those numbers without dialing
their whole number.
MISSED CALLS
4
2
3
ONE TOUCH/TWO TOUCH DIALING
This feature allows the phone book entries to be dialed via the key-
pad.
ONE TOUCH DIALING:
0-9 : Press corresponding memory number and hold for more than 1
second.
TWO TOUCH DIALING:
00, 10-99 : press the first digit and second digits of the memory num-
ber short and long respectively.
lIf no phone number is stored in the location depressed, “Empty
Location” will appear on the screen.
lIf a phone number is stored in the secret location, the number is
not displayed when making a call.
[01]XXXXXXXX
[02]XXXXXXXXXX
[03]XXXXX
10/14, 13:14
[01]
XXX-XXX-XXXX
DTAL
DTAL PREV
MISSED CALL

[28] [29]
HOW TO FIND YOUR PHONE BOOK
Press [ ] then [1] then [2].
Enter the memory location number.
Search phone numbers using scroll key.
l[]
/[ ] search for the phone numbers.
l[ ] edit the phone#.
l[ ] erase the phone#.
l[]
/[]
search for mobile/office/home/E-mail.
Press [ ] to dial desired phone book number.
lIf you don’t enter a specific
memory location number,
use the scroll key to search
from the first memory loca-
tion number.
1
RECALLING BY MEMORY LOCATION NUMBER
2
4
3
HOW TO FIND YOUR CALL LOGS
Press [ ] then [1] then [1] then [2].(Refer to previous page)
lThe last answered call, its phone number, time and date
are displayed.
Press [ ] to dial desired dialed call number. (Refer to previ-
ous page)
ANSWERED CALLS
DIALED CALLS
Press [ ] then [1] then [1] then [3].
Press [ ] to dial desired dialed call number. (Refer to pre-
vious page)
lThe last outgoing call, its phone number, time and date
are displayed.
SEARCH
LOCATION?
_
STO PREV
VIEW LIST
▲
▼
DAVID
[01]
XXX-XXX-XXXX
EDIT DEL
MOBILE

[30] [31]
HOW TO FIND YOUR PHONE BOOK
Press [ ] then [1] then [3].
Enter the alpha (or part of the alpha).
Then press [ ].
To locate the phone number using the scroll key.
l[]
/[ ] search for the phone numbers.
l[ ] edit the phone#.
l[ ] erase the phone#.
l[]
/[]
search for mobile/office/home/E-mail.
Press [ ] to dial.
1
RECALLING BY NAME (ALPHA)
2
4
3
SEARCH
RECALL NAME?
STO PREV
Please read this chapter before using this product.
uSettings
vVolume
wTimers
xAlerts
CHAPTER 4
MENU
VIEW LIST
▲
▼

[33][32]
SETTINGS
Press [ ] then [2] then [2].
Select the parameter
(NO USE, 1 , 3 RINGS)
by using the scroll keys.
Press [ ] to set.
lAuto answer function does not
work if you select [silent] or [vibrator]
or [slide bell].
1
2
This function answers an incoming call automatically after a
number of rings that the user sets.
AUTO ANSWER
ANSWER RINGS
NO USE
SEL PREV
SETTINGS
Press [ ] then [2] then [1] then [1].
Select the parameter
(OFF, 5 , 10 , 20 , 30 SECONDS) by using the
scroll.
Key Press [ ].
1
2
When a call is not connected, this function retries the call
automatically at a set interval or amount or retries.
INTERVAL
AUTO RETRY
Press [ ] then [2] then [1] then [2].
Select the parameter
( 1 , 5 , 10 TIMES) by using the scroll.
Key Press [ ].
1
2
REPEAT
Press [ ], then [2], then [3],
Select the parameter (OFF, OFF IN DAY,10 SECS,
5 SECS, 3 SECS) by using the scroll keys.
Press [ ].
1
2
This function allows you to adjust time to light up the screen,
so that you can conveniently use the phone even in dark places.
BACKLIGHT
