Hyundai HCBEN40V-A User manual

English |
1
CORDLESS LAWN TRIMMER
HCBEN40V-A
WARNING: Read thoroughly the instruction manual before use.

Safety
2
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
Safe operating practices
Training
a) Read the instructions carefully. Be familiar with the
controls and the correct use of the machine.
b) Never allow children or people unfamiliar with these
instructions to use the machine. Local regulations can
restrict the age of the operator.
c) Keep in mind that the operator or user is responsible for
accidents or hazards occurring to other people or their
property.
Preparation
a) Before use, always visually inspect the machine for
damaged, missing or misplaced guards or shields.
b) Never operate the machine while people, especially
children, or pets are nearby.
Operation
a) Wear eye protection and stout shoes at all times while
operating the machine.
b) Avoid using the machine in bad weather conditions
especially when there is a risk of lightning.
c) Use the machine only in daylight or good artificial light.
d) Never operate the machine with damaged guards or
shields or without guards or shields in place.

Safety
3
e) Switch on the motor only when the hands and feet are
away from the cutting means.
f) Always disconnect the machine from the power supply
(i.e. remove the plug from the mains, remove the disabling
device or removable battery)
1) Whenever the machine is left unattended;
2) Before clearing a blockage;
3) Before checking, cleaning or working on the machine;
4) After striking a foreign object;
5) Whenever the machine starts vibrating abnormally.
h) Take care against injury to feet and hands from the
cutting means.
i) Always ensure that the ventilation openings are kept
clear of debris.
Maintenance and storage
a) Disconnect the machine from the power supply (i.e.
remove the plug from the mains, remove the disabling
device or removable battery) before carrying out
maintenance or cleaning work.
b) Use only the manufacturer’s recommended
replacement parts and accessories.
c) Inspect and maintain the machine regularly. Have the
machine repaired only by an authorized repairer.
d) When not in use, store the machine out of the reach of
children.
- never allow children, persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge or people unfamiliar with these instructions
to use the machine, local regulations may restrict the
age of the operator;

Safety
4
- Never operate the machine while people, especially
children, or pets are nearby. Keep them at least 15 m
away from the machine during its operation.
- Stop using the tool when a risk might occur (people are
nearby, dangerous material on the working area,
problem with the tool, etc.). Check the working area
before working and stay in alert when operating the tool.
- Follow the provided instructions for assembly, use,
repairs, maintenance and storage
- Never replace the non-metallic cutting means with
metallic cutting means;
- Do not overreach and keep the balance at all times, to
always be sure of the footing on slopes and to walk,
never run.
- Do not to touch moving hazardous parts before the
machine is stopped and the moving hazardous parts
have come to a complete stop;
- Always wear substantial footwear and long trousers
while operating the machine;
- This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
- Children should be supervised to ensure that they do
not play with the appliance.
- Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a
power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention

Safety
5
while operating power tools may result in serious
personal injury.
- Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal
injuries.
- Prevent unintentional starting. Ensure the switch is in
the off-position before connecting the battery pack,
picking up or carrying the tool.
- A moving cutting attachment can cause severe injury.
Maintain proper control of the machine with both hands
until the cutting attachment has completely stopped
rotating.
- Replace any cutting attachment that has been
damaged. Always make sure that the cutting
attachment is installed correctly and securely fastened
before each use.
- Use only accessories recommended by manufacturer.
Non-recommended accessories can cause injuries and
accidents. Contact your dealer or our service agent.
- Always use the harness provided when operating the
tool.
- Do not expose the tool to rain and humidity.
- In case of abnormal vibrations, stop immediately to use
the tool and remove the battery; check if all screws are
firmly tighten, if the cutting mean are correctly
assembled. In case of doubt, bring the tool to our agent
service for inspection.
- Always start the tool safely, tools correctly and fully
assembled, foot and body far from the cutting means,
harness installed and used.

Safety
6
- Always inspect the tool before and after the operation
for signs of damage such as cracks in the cutting
attachment or ageing. In case of damages or ageing,
bring the tool to our agent service for inspection and
reparation.
- Check the tool for loose fasteners. Tighten safely loose
fasteners.
- Never operate the machine with defective guards or
shields, or without safety devices.
- Always use the tool with the battery fully charged.
Before use, check the charge level and charge the
battery if necessary.
- In case of accident or breakdown, stop immediately the
tool and remove the battery. Check the breakdown or
accident, repair the tool if necessary. Bring the tool to a
service agent if necessary.
- Do not replace the blade with metal multi-piece pivoting
chains and flail blades; this type of blade must not be
used with this tool.
- Stop the machine and allow it to cool before storing or
transporting. Do not store or transport the machine with
batteries fitted, remove and secure separately
- Clean all foreign material from the product. Store it in a
cool dry and well-ventilated place that is inaccessible to
children. Keep away from corrosive agents such as
garden chemicals and de-icing salts. Do not store
outdoors.
- For transportation, secure the machine against
movement or falling to prevent injury to persons or
damage to the machine.
- Use only original manufacturer’s replacement parts,
accessories and attachments. Failure to do so can

Safety
7
cause possible injury, poor performance and may void
your warranty. You may make adjustments and repairs
described here. For other repairs, contact the
authorized service agent.
- Contact your dealer of manufacturer to know which
parts/accessories can be used with this tool.
- Before any maintenance or adjustment, stop the tool
and remove the battery.
- After extending new cutter line or cleaning, always
return the product to its normal operating position
before starting.
- After each use, clean the product with a soft dry cloth.
- Check all nuts, bolts and screws at frequent intervals
for proper tightness to ensure the product is in safe
working condition. Any part that is damaged should be
properly repaired or replaced by an authorized service
centre.
RESIDUAL RISK
Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual risk
factors. The following hazards may arise in use and the
operator should pay special attention to avoid the
following:
- Injury caused by vibration. Always use the right tool for
the job, use designated handles and restrict working
time and exposure.
- Exposure to noise can cause hearing injury. Wear ear
protection and limit exposure
- Kickback can occur when using the brushcutter. Ensure
proper control by using both hands on the designated

Safety
8
handles. Read and follow the directions elsewhere in
this manual to help reduce the risk of kickback.
- Injuries may be caused, or aggravated, by prolonged
use of a tool. When using any tool for prolonged
periods, ensure you take regular breaks.
RISK REDUCTION
It has been reported that vibrations from hand-held tools
may contribute to a condition called Raynaud’s Syndrome
in certain individuals. Symptoms may include tingling,
numbness and blanching of the fingers, usually apparent
upon exposure to cold. Hereditary factors, exposure to
cold and dampness, diet, smoking and work practices are
all thought to contribute to the development of these
symptoms. There are measures that can be taken by the
operator to possibly reduce the effects of vibration:
Keep your body warm in cold weather. When operating
the unit wear gloves to keep the hands and wrists warm. It
is reported that cold weather is a major factor contributing
to Raynaud’s Syndrome.
After each period of operation, exercise to increase blood
circulation.
Take frequent work breaks. Limit the amount of exposure
per day.If you experience any of the symptoms of this
condition, immediately discontinue use and see your
doctor about these symptoms.

Safety
9
INTENDED USE
The product is only intended for use outdoors. For
safety reasons the product must be adequately
controlled by using two handed operation.
The product is intended for cutting long grass,
pulpy weed, or brush and similar vegetation at or
about ground level. The cutting plane should be
approximately parallel to the ground surface. The
product should not be used to trim hedges, bushes
or other vegetation where the cutting plane is not
parallel to the ground surface.
MAINTENANCE
Servicing requires extreme care and knowledge.
For service we suggest you return the product to your
nearest authorized service center for repair. When
servicing, use only identical replacement parts.
Use only original manufacturer’s replacement parts,
accessories and attachments. Failure to do so can cause
possible injury, poor performance and may void your
warranty.
You may make adjustments and repairs described
here. For other repairs, contact the authorized
service agent.
Before any maintenance or adjustment, disable the
machine by removing the power source.

Safety
10
After extending new cutter line or cleaning,
checking the blade, always return the product to its
normal operating position before starting.
After each use, clean the product with a soft dry cloth.
Check all nuts, bolts and screws at frequent
intervals for proper tightness to ensure the product
is in safe working condition. Any part that is
damaged should be properly repaired or replaced
by an authorized service center.
TRANSPORTATION AND STORAGE
Stop the machine and allow it to cool before storing or
transporting. Do not store or transport the machine with
batteries fitted, remove and secure separately
Clean all foreign material from the product. Store it in a
cool dry and well-ventilated place that is inaccessible to
children. Keep away from corrosive agents such as
garden chemicals and de-icing salts. Do not store
outdoors.
For transportation, secure the machine against movement
or falling to prevent injury to persons or damage to the
machine.
Injuries may be caused, or aggravated, by prolonged use
of a tool. When using any tool for prolonged periods,
ensure you take regular breaks.

Safety
11
SYMBOLS ON THE PRODUCT
Safety alert
Read and understand all instructions before operating
the product, follow all warnings and safety instructions.
Wear eye, ear and head protection.
Wear non-slip safety footwear when using the product.
Wear non-slip, heavy duty gloves.
Wear ocular protection
Wear hearing protection
Do not expose to rain or damp condition.

Safety
12
This unit is not intended for use with a toothed saw type blade.
Beware of thrown or flying object. Keep all bystanders a
safe distance away from the product.
Beware of thrown or flying object. Keep all bystanders, especially children and
pets, at least 15m away from the operating area
Beware of blade thrust
Guarantee sound power level
DESCRIPTION
See on page 11
1. Trigger
2. Lock level
3. Two speed button
4. Handle
5. Connector
6. Cutter guard
7. Rotate button
8. Wire
9. Carter of protection
10. Battery pack（no provided）
11. Battery level
12. Charger （no provided）

13
DELIVERY
x 3 x 3
x 1 x 1
x 1 x 1
x 1
x 1
Note: The battery and charger were not included in pack

14
DESCRIPTION

15
ASSEMBLY
See the following drawings for assembly. Do not install the battery during the
assembly. Wear protective equipment as described in Fig 1.
Fig 1: protective equipment
Fig 2: assembly of the carter of protection
1
2
Fig 3: Assembly of the handle
3
2
1

16
4
5
Fig 4: assembly of cutting bar in the tool
Fig 5: removing the adhesive from the cutting blade
Fig 6: Installing the battery
6

17
USE
Fig 7: Switch on the tool
7
11
2

18

19
1
1
2

20
2
3
