I.CH Motion SS5 User manual

Page
1
OWNER’S GUIDE
SS5 STEPPER SERVO MOTOR DRIVER
©2020 by I.CH Motion Co.,Ltd..
All Rights Reserved
TECHNICAL DOCUMENT

©I.CH Motion® 2020
ichmo.com
Specifications subject to change without notice.
Owner's Guide: SS5 Stepper Servo Motor Driver
Page 2
TECHNICAL DOCUMENT
Content
Note:if you have any problems,please
email [e-mail] to to contact us.
1. Introduction················································································································································································3
2. Feature·······················································································································································································3
3. Specification··············································································································································································4
4. Connections ··············································································································································································5
Power Connector··········································································································································································6
Encoder Signal Connector ··························································································································································6
Control Signal Connector ····························································································································································6
Output Signal Connector ·····························································································································································7
Control Signal Input Example Follow·········································································································································7
ALM/INPOS Output diagrams follow ·········································································································································8
5. Switch Selection ·······································································································································································9
Running Current············································································································································································9
Microstepping··············································································································································································10
Self Test························································································································································································10
Control Mode···············································································································································································10
6. Auto Tunning···········································································································································································10
7. Status Indicator·······································································································································································11
8. Mechanical Outline·································································································································································12
9. Safety Precautions·································································································································································13

©I.CH Motion® 2020
ichmo.com
Specifications subject to change without notice.
Owner's Guide: SS5 Stepper Servo Motor Driver
Page 3
TECHNICAL DOCUMENT
1. Introduction
Thanks for choosing the SS serial motor drive.The CL5 is a new digital step servo motor drive based on a 32-bit DSP with advanced control
algorithm.It brings a unique level of system smoothness, providing optimum torque and nulls mid-range instability.Motor self-test and parameter
auto-tunning technology offers optimum responses with different motors and easy-to-use. The motors can run with much smaller noise,less heat,
smoother movement.
2. Feature
Brand new 32-bit DSP
16 settings of microstep resolution
Servo control algorithm, accurate speed position control and good responsiveness
Minimize heat generation by adjusting current in real time based on load
Auto Setuped motor parameters
Step&Direction/CW&CCW pulse
1Mhz digital filter for high speed inputs
Self Test-the drive will perform a 2rev,3rps,CW/CCW move test

©I.CH Motion® 2020
ichmo.com
Specifications subject to change without notice.
Owner's Guide: SS5 Stepper Servo Motor Driver
Page 4
TECHNICAL DOCUMENT
3. Specification
Parameters
Min
Typical
MAX
Unit
Supply voltage
24
-
75
VDC
Output current（Peak）
1.0
-
9.8
A
Control signal input current
6
10
15
mA
STEP/DIR Input Signal Voltage
4.0
5.0
28.0
VDC
Step Frequency
2
-
1M
Hz
STEP Minimum Pulse Width High and
Low
250
-
-
Ns
DIR Minimum Pulse Width
50
-
-
us
Drive initialization time
-
-
2
S

©I.CH Motion® 2020
ichmo.com
Specifications subject to change without notice.
Owner's Guide: SS5 Stepper Servo Motor Driver
Page 5
TECHNICAL DOCUMENT
4. Connections

©I.CH Motion® 2020
ichmo.com
Specifications subject to change without notice.
Owner's Guide: SS5 Stepper Servo Motor Driver
Page 6
TECHNICAL DOCUMENT
Power Connector
Pin
Details
V+
24~75VDC input positive
V-
24~75VDC input negative
A+,A-
Motor phase A
B+,B-
Motor phase B
Encoder Signal Connector
Pin
Details
+5V
Encoder power supply interface
GND
EA+
Encoder A phase differential input
EA-
EB+
Encoder B phase differential input
EB-
EI+
Encoder I phase differential input
EI-
Control Signal Connector
Pin
Details
STEP+
In step&direction mode, this input represents pulse signal, each falling edge
active; 5-28V when PUL-HIGH, 0-0.5V when PUL-LOW. In CW&CCW mode ,this
input represents clockwise (CW) pulse，For reliable response, pulse width should
be longer than 1.5μs.
STEP-
DIR+
In step&direction mode, this signal has low/high voltage levels,representing two
directions of motor rotation; In CW&CCW mode, this signal is counter-clock (CCW)
pulse，For reliable motion response, DIR signal should be ahead of PUL signal by
5μs at least. 5-24V when DIR-HIGH,0-0.5V when DIR-LOW.
DIR-
EN+
The EN input enables or disables the drive amplifier. It is an optically isolated input
that accepts a 5 to 24 volt single-ended or differential signal. The maximum
voltage that can be applied to the input is 28V.
When EN input is closed, the drive amplifier is deactivated, all the MOSFETs will
shut down, and the motor will be free. When EN input is open, the drive is
activated.
When the drive has encountered an error and the fault is removed from system, a
falling signal into the EN input will reset the error status and activate the drive
amplifier again.
EN-

©I.CH Motion® 2020
ichmo.com
Specifications subject to change without notice.
Owner's Guide: SS5 Stepper Servo Motor Driver
Page 7
TECHNICAL DOCUMENT
Output Signal Connector
Pin
Details
INP+
In-position signal, optocoupler isolated OC output, maximum withstand
voltage 30VDC, maximum saturation current 100mA, output optocoupler
does not conduct when the motor does not go to the target position
INP-
ALM+
Alarm signal, optocoupler isolated OC output, maximum withstand voltage
30VDC, maximum saturation current 100mA, output optocoupler does not
conduct when the drive is working normally
ALM-
Control Signal Input Example Follow

©I.CH Motion® 2020
ichmo.com
Specifications subject to change without notice.
Owner's Guide: SS5 Stepper Servo Motor Driver
Page 8
TECHNICAL DOCUMENT
ALM/INPOS Output diagrams follow

©I.CH Motion® 2020
ichmo.com
Specifications subject to change without notice.
Owner's Guide: SS5 Stepper Servo Motor Driver
Page 9
TECHNICAL DOCUMENT
5. Switch Selection
The SS5 drive uses an 8-bit DIP switch to set the subdivision accuracy, dynamic current, self-test function and pulse mode selection. The detailed
description is as follows:
Running Current
After the drive is matched with the motor model, the running current dialing can set the actual output current to be 40%~100% of the rated current
of the motor.
Rated current
SW1
SW2
40%
ON
ON
60%
OFF
ON
80%
ON
OFF
100%
OFF
OFF

©I.CH Motion® 2020
ichmo.com
Specifications subject to change without notice.
Owner's Guide: SS5 Stepper Servo Motor Driver
Page 10
TECHNICAL DOCUMENT
Microstepping
step/rev
SW5
SW6
SW7
SW8
200
ON
ON
ON
ON
800
ON
OFF
ON
ON
1600
OFF
OFF
ON
ON
3200
ON
ON
OFF
ON
6400
OFF
ON
OFF
ON
12800
ON
OFF
OFF
ON
25600
OFF
OFF
OFF
ON
1000
ON
ON
ON
OFF
2000
OFF
ON
ON
OFF
4000
ON
OFF
ON
OFF
5000
OFF
OFF
ON
OFF
8000
ON
ON
OFF
OFF
10000
OFF
ON
OFF
OFF
20000
ON
OFF
OFF
OFF
25000
OFF
OFF
OFF
OFF
Self Test
Setting switch SW3 to ON after the drive is powered up will cause the drive to perform a self test move of 2 revolutions both CW and CCW at 3rps.
Setting switch SW9 to OFF disables this feature.
Control Mode
SW4 can set the mode of the control signal. When SW4 is OFF, the host computer needs to provide a pulse signal with one direction signal. When
SW10 is ON, two pulses can be used to control the forward and reverse rotation of the motor. At this time, the pulse input to the STEP terminal
controls the movement of the motor in the CW direction, and the pulse input to the DIR controls the movement of the motor in the CCW direction.
6. Auto Tunning
The Auto Tunning button is used to match the motor to the drive. Under normal circumstances, the motor and the drive have been matched
one-to-one, and the customer does not need to match the motor and the drive.

©I.CH Motion® 2020
ichmo.com
Specifications subject to change without notice.
Owner's Guide: SS5 Stepper Servo Motor Driver
Page 11
TECHNICAL DOCUMENT
7. Status Indicator
The green LED is the enable indicator. When the motor is enabled, the LED is always on; when the motor is not enabled, the LED is blinking. The red
LED is a fault indicator. When a fault occurs, the indicator flashes in a cycle; when the fault is cleared by the user, the red LED is always off. The
number of red LED flashes represents different fault information, as shown in the following table:
Alarm code
Details

Long green light
Drive enable

Flashing green light
Drive disenable

Red light off
The drive is normal

Red light flashes
once
Drive overcurrent

Red light flashes 2
times
Power supply voltage is too high

Red light flashes 3
times
Drive over temperature

Red light flashes 4
times
Motor phase line open

Red light flashes 5
times
Drive internal fault

Red light flashes 6
times
Encoder failure

©I.CH Motion® 2020
ichmo.com
Specifications subject to change without notice.
Owner's Guide: SS5 Stepper Servo Motor Driver
Page 12
TECHNICAL DOCUMENT
8. Mechanical Outline
* The amplifiers in the drive generate heat. To operate the drive continuously at maximum power forced air cooling, as from a fan, should be
provided.Never use the drive in a space where there is no air flow or where other devices can cause the surrounding air to be more than 40 °C.
Never put the drive where it can get wet or where metal particles can fall into it.

©I.CH Motion® 2020
ichmo.com
Specifications subject to change without notice.
Owner's Guide: SS5 Stepper Servo Motor Driver
Page 13
TECHNICAL DOCUMENT
9. Safety Precautions
The precautions described below are intended to prevent the occurrence of danger or injury to users and other personnel and to use the product
correctly. Please read and understand these precautions thoroughly before using this product.
If the drive is accidentally damaged during operation, the company is only responsible for the repair and replacement of the drive within the
warranty.
The company does not bear the loss of control or casualties and property damage caused by accidental damage to the drive.
Do not use the product with flammable materials when exposed to explosive, flammable, corrosive gases or water splashes or in a nearby
location. Doing so may result in fire, electric shock or personal injury.
Only qualified personnel should be allowed to install, connect, operate and perform inspection/exclusion of product failures. Handling of
unqualified personnel may result in fire, electric shock, personal injury or equipment damage.
Do not move, install, connect, or inspect the product while the drive is powered, and turn off the power when performing these operations.
Failure to follow these instructions may result in electric shock.
Do not use non-electromagnetic brakes in vertical applications. If the drive's protection function is activated, the motor may not stop and the
moving parts of the device may fall, resulting in personal injury or equipment damage.
Always keep the drive's power supply voltage below the rated value. Failure to do so may result in fire or damage to the drive.
Always turn off the power before performing maintenance/inspection. Failure to do so may result in electric shock.
Do not touch the connection terminals on the drive immediately after turning off the power (within 30 seconds, or until the power LED is
turned off). Residual voltage may cause electric shock.
Regularly check the dust accumulated in the open part of the cleaning drive. Accumulated dust can cause a fire.
Do not disassemble or repair the motor and drive. Doing so may result in electric
