I-Tech UltraView HAP15AV User manual

UserManual
InnovativeLCDDisplaySolutions
HAP 15AV Series
HDP 15AV Series
HOP 15AV Series
ltraView

Jan 05
P.1
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual
1.TableofContent Page.1
2.Introduction
A)OverviewPage.2
B)FeaturesPage.2
C)Dimension DiagramsPage.3-5
D)TechnicalSpecificationsPage.6
3.Installation
A)Package ContentsPage.7
B)Cautiontothe userPage.7
C)Cleaning Page.7
D)PrecautionsPage.8-9
4.Using theSystem
A)Product ViewsPage.10-12
B)I/O OutletPage.13
C)Installation ProceduresPage.14
D)Setup Touchscreen(Optional)Page.15
i) ForWindows Page.15
ii) ForDOS Page.16-18
E)OSDSwitchPage.19
F)OSDControl(VGAVersion)Page.20-22
G)OSDControl(Video Version)Page.23-27
Disclaimer
Thisinformation issubjecttochange withoutnotice.Theproducerofthismanual acceptsno
responsibilityfordamage orclaims,resulting frommisuseormisinterpretation.
1. Tableof Content

Jan 05
P.2
Disclaimer
Thisinformation issubjecttochange withoutnotice.Theproducerofthismanual acceptsno
responsibilityfordamage orclaims,resulting frommisuseormisinterpretation
A.Overview
B.Features
2.Introduction
ThisLCD monitorincorporates15 coloractivematrixthin-film-transistor(TFT)
liquidcrystaldisplaytoprovide superiordisplayperformance.Amaximum
resolution of1024 x768 isidealfordisplaying complexgraphics and high
definition images.Otheroutstanding designsthatenhancethisLCD monitor’s
performancearePlug&PlaycompatibilityandOSD(OnScreenDisplay)
controls.
UltraHigh Brightness TFT LCD Displayup to1400 Cd/m2.
ViewableUnderDirect Sun Light
High contrastcolorTFT LCD displaysupportresolution up to1024x
768.
Advanced OSDcontrolforpicturequalityadjustment.
Detachablestand forwall-mounting application.
OptionalCompositeandS-Video input
Slimand compact size
Wide Viewing Angle
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

Jan 05
P.3
HAP-15AVseries
C.DimensionDiagrams
2.Introduction
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

Jan 05
P.4
HDP-15AVseries
C.DimensionDiagrams
2.Introduction
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

Jan 05
P.5
HOP-15AVseries
C.DimensionDiagrams
2.Introduction
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

Jan 05
P.6
Technical Specifications
Monitor
Panel15" LCD Panel
DisplayType TFT LCD activematrixcolour
Resolutions1024 x768
ResponseTimeTr=5ms, Tf=20ms
Contrast Ratio500:1typical
Brightness 1400 cd/m2typical
PixelPitch0.297(H)x0.297(V)
PanelColour16.2Mdisplaycolour
Viewing Angle70 / 70 / 60 / 65(L/R/ U/ D)
Storage Temp.-25°to60°C
OperatingTemp.0°to50°C
MTBF50,000 hours(Min.)
PowerSupply
RemoteAdapter110V-220VACInput
AdapterSize108(L)x64 (W)x30 (D)mm
CableLengthfrom
mainsplug toadapter 182cm
CableLengthfrom
adapterUnit 180cm
PowerSocket12V(+)female
Connectors VGAHDDB15-pin(female)x1
Video StandardsSupportsNTSC, PALorSECAM
Product
Dimension
AP Series: 390(W)x300(H)x51(D)mm
DPSeries: 374(W)x284(H)x47(D)mm
OPSeries:398(W)x308(H)x51(D)mm
Packing
DimensionAP / DP/ OPSeries: 555(L)x470(W)x90(H)mm
2.Introduction
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

Afterunpacking the carton,check and see ifthefollowingitemsareincluded in
good condition.Contactyoursupplierassoonaspossibleforreplacingthe
missing / damaged items.
15 TFT LCD monitor
RCACable(ForAV VersionOnly)
S-Video Cable(ForAV Version Only)
VGACable(MaletoMale)
DC 12VAdapter
PowerCord
Mounting Bracket (AP Seriesonly)
UserManual
CD Disc
ToassurecontinuedFCC compliance,pleaseusegrounded powersupply
cordand the provided shielded video interfacecablewithbonded ferritecores.
If aBNC cableisgoingtobe used,useonlyashielded BNC (5)cable.Also,
TheFederalCommunicationsCommissionwarnstheuserthatany
unauthorized changesormodificationstothe unitifnot expresslyapprovedby
thepartyresponsibleforcompliancecouldvoidtheuser'sauthorityof
operatingthe equipment.
1.Gentlywipe screen withaclean camelhairlensbrush,orasoft,clean,
lint-free cloth.Thisremovesdustand otherparticlesthatcan scratchthe
screen.
2.Donotapplyexcessivepressuretothescreensurfacewhen wiping itclean
becausethismaydamage the LCD.
3.Donot pourorsprayanyliquiddirectlyontothescreen orcaseof the LCD
monitor.Chemicalcleanershavebeenreported todamage thescreen or
caseof theLCD monitor.
A.PackageContents
Jan 05
P.7
B.Caution toTheUser
C.Cleaning
3.Installation
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

Jan 05
P.8
Read allof theseinstructionsandsavethemforlateruse. Followallwarnings
and instructionson the product.
Product
Donot coverorblock the vent holesinthe case.
Donotinsertsharpobjectsorspillliquidintothe LCD monitorthrough
cabinet slots.Theymaycauseaccidentfire,electricshock orfailure.
Disconnect thepowerplug fromthe ACoutletif you willnot useit foran
indefiniteperiod oftime.
Donotattempttoservicethisproductyourself,asopening orremoving
coversmayexposeyou todangerousvoltage pointsorotherrisks.
Donottouchthe screendirectlywithyourfingers.You maydamage the
screen, and oilfromyourskinindifficult tomove.
Donot applypressuretoscreen. TheLCD isverydelicate.
D.Precautions
Power
1.Usethe type of powerindicatedon the markinglabel.
Plugs
1.Donotremoveanyof the prongsofthemonitor’sthree-pronged power
plug.
2.DisconnectthepowerplugfromtheACoutletunderfollowing
conditions
If the product willnot be used foran indefiniteperiod time.
Whenthe powercordorplug isdamaged orfrayed.
Iftheproductdoesnotoperatenormallywhentheoperating
instructionsarefollowed.
Adjustonlythosecontrolsthatarecoveredbytheoperating
instructions.Improperadjustment of othercontrolsmayresult in
damageandwilloftenrequireextensiveworkbyaqualified
technician torestoretheproduct tonormaloperation.
If the producthasbeen dropped orthe cabinet hasbeen damaged.
If the productexhibitsadistinctchangeinperformance,indicatinga
need forservice.
3.Installation
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

Jan 05
P.9
D.Precautions(Cont.)
Powerandextensioncords
1.Donot allowanything torest onthe powercord.
2.Donotlocatethisproduct wherepersonswillwalkon the cord.
3.Usethe properpowercordwithcorrectattachmentplug type.If the
powersourceis120VAC,useapowercordthathasULand C-UL
approvals.If the powersourceisa240VACsupply,usethe tandem
(Tblade)type attachmentplug withground conductorpowercordthat
meetsthe respectiveEuropeancountry’ssafetyregulations,suchas
VDEforGermany.
4.Donot overloadwall outletsorpowercords. Ensurethat the totalof all
unitspluggedintothe walloutlet doesnot exceed 10 amperes.
5.Ensurethatthetotalampereratingsonallunitspluggedintothe
extension cordisnotabovethe cord’srating.
6.Ifthepowersupplycord,whichcamewithyourmonitor,istobe
connected tothePCinstead ofthe walloutlet,thisequipmentistobe
usedwithUL/TÜVapprovedcomputerswithreceptaclerated
100~240VAC, 50/60Hz,1.0A(minimum).
Environment
1.Placethemonitoronaflatand leveledsurface.
2.Placethemonitorinawell-ventilated place.
3.Keep the monitorawayfrom Overlyhot, coldorhumidplaces,places
directlyundersunlight, dustysurroundings,equipmentthatgenerate
strong magneticfields.
3.Installation
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

A.ProductViews
HAPSeries-FrontView
HAPSeries-RearView
Jan 05
P.10
4. Usingthe System
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

A.ProductViews(Cont.)
HDPSeries-Front View
HDPSeries-RearView
Jan 05
P.11
4. Usingthe System
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

A.ProductViews(Cont.)
HOPSeries-Front View
HOPSeries-Rear View
Jan 05
P.12
4. Usingthe System
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

Jan 05
P.13
B.I/OOutlet
Front
APSeries
DPSeries
OPSeries
(2)
(1)DC IN Connect topowercable.
(2)PCIN Connect toD-Sub15 pinsignalconnector.
(3)S-VideoIN Connect tothe S-Video cableconnector.(forAV seriesonly)
(4)RCAIN Connecttothe compositecableconnector.(forAV seriesonly)
(1) (3) (4)
4. Usingthe System
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

Jan 05
P.14
C.InstallationProcedures
Thismonitorisequipped withanauto-sensingpowersupplyfor
voltageranges100~240V,50~60Hz.Pleasefollowthe following
instructiontoinstall LCD monitor.
1.Makesure that the systempower isturnedoff.
2.Plug the signalcabletothe signalconnector atthe rear of
PCandtherearof theLCD monitor.
3.PlugadapteroutputcabletothejackattherearofLCD
monitorand the powercord tothe adapter.
4.Connectthepowercord topower source.
5.Turn onthe computerand the monitor.
6.Then pushtheOSDmenu buttonandusetheAutoAdjust
function tofinethebest mode ofyourcomputer.
4. Usingthe System
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

D.Setup Touchscreen
Touchscreen used forUltraViewproductsaremanufactured by3M. Hereprovide
TouchWareTM Softwareincludestouchscreen driversforyourinstalling.
For Windows95, 98, Me,NT4.0, 2000 & XP
1.Open the driverCD providedalongwiththe product ordownloadthe driver
fromourWebsite.
2.Makesureyou havecompleted the appropriatehardwareconnections.
3.Poweron yoursystem. Makesureno otherapplicationareopened.
4.Doubleclickthe “TW564SR4.exe files.
5.Unzipthe fileand saveitinadefault folder
6.Followthe onscreen instructionstobeginthe installation.
Jan 05
P.15
Note: ChooseExpressoptionforautomaticallyinstallsthe required TouchWareTM
softwarefiles, createaTouchWareTM softwareprogramfiles,and placea
TouchWareTM softwareicon ontheWindowsdesktopandcontrol panel.
TouchWareTM willalsodetermine multiplemonitorconfigurationsatthistime.
Note: Rememberthe pathof the default folderorcreateanew folderbyyourdecision.
Note: FordetailsofCustomoption,pleaserefertothe websiteof3Mand download the
userguide of TouchWareTM software.
(http:// www.3m.com/3MTouchSystems/downloads/tecdoc.jhtml)
Note: If you haveaMicrosoft®IntelliPoint®orKensington®Mousework®PS/2
mouse, installingTouchWareTM softwarewilldisablethe specialmouse
functionallyofthesedevices
Note: Toconfigurethesettingsofthetouchscreen,pleaserefertothe
TouchWareTM UserGuideline
4. Usingthe System
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

Jan 05
P.16
D.Setup Touchscreen
For Windows95, 98, Me,NT4.0, 2000 & XP(Cont.)
7.Onceinstallationiscomplete, restart the system. Asthe systemrestarts,
Windowsdetectsand loadsthe driver.
Forserialcontrollers,restart the system. Asthesystemrestarts,Win-
dowsdetectsand loadthe driver
ForUSB controllers, connect thetouchscreencabletotheUSB portin
yourcomputer. Afterafewseconds, the systembeepstoindicateit has
detected the touchscreen andloaded the driver.
For DOS
Whenyou installTouchwarefromDOS, the Installprogramonlyloadsthe
touchscreenfilesspecifictoDOS. Theinstallationincludesthe following files:
Touchscreen driverforDOS
Touchscreen controlpanelforDOS
Pen Configuration utilityforDOS
MicrocalDiagnosticutility
ThruGlasscontrolpanelforDOS
DOShelpfiles
If you do not plantouseanyofthe touchscreen filesforwindows, you maywant
toinstalljust the DOStouchscreen files.
1.Open the driverCD providedalongwiththe product ordownloadthe driver
fromourWebsite.
2.Makesureyou havecompleted the appropriatehardwareconnections.If
not, the Installprogramcannot properlyconfigurethe touchscreen.
3.Closeallapplicationsand exitfromWindows.
4.Insert theTouchWareDisk intoadiskettedrive.
5.Access the DOScommand line prompt.
6.Change tothe drivethathastheTouchWarediskette. Forexample, enter A:
if youinserted the TouchWaredisketteinDriveA.
Note: Thisstep isnotnecessary forWindows2000 orabovesystem,The driverloads
automatically.
4. Usingthe System
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

Jan 05
P.17
D.Setup Touchscreen
For DOS(Cont.)
7.Type INSTALL followed bythe sourcedisk drive,the destination drive,and
the destination directory.
Forexample,the followingcommand copiesthe filesfromDriveA(source
drive)toDriveC(destinationdrive)and the \MTS\TOUCH directory:
INSTALL A:C:\MTS\TOUCH
8.Press Enter.The systemreportsthatitisabouttocopytheDOStouchscreen
filesand prompt forconfirmation that you want tocontinue.
9.Press C tostart the installation.
First,theInstallprogramcopiesallDOStouchscreenfilesfromthe
TouchWarediskettetothespecified destinationdriveanddirectory.
Next, the Installprogramautomaticallysearched through the system
and configuresthetouchscreentothe properCOMport,interrupt,and
communication rate.
Finally,the Install programpromptsifyou wantittoautomaticallymodify
yourAUTOEXEC.BATfile
If you letthe InstallprogrammodifyyourAUTOEXEC.BATfile,thesystem
automaticallyloadsthe DOStouchscreendriverwheneveryoustartyour
computer.
If you do notletthe InstallprogrammodifyyourAUTOEXEC.BATfile,you
mustload theDOStouchscreen driverbeforeusingaDOStouchapplication.
Formoreinformation,referto “Loading the DOSTouchscreen Driver inthe
next page
4. Usingthe System
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

D.Setup Touchscreen
For DOS(Cont.)
LoadingtheDOSTouchscreenDriver
Afteryou installthe filesfortheDOStouchscreen driver, you must loadthe driver
beforeyou can run aDOStouchapplication oropen the DOSTouchscreen
controlpanel.
You can runthe DOStouchscreendriverfromafull-screen DOSsession within
Windows. However, the Windowstouchscreendrivercannotbe running. Error
message reads: “Windowsx.xisrunningin386Enhanced mode. Devicenot
found.
Thismeanseitherthe WindowsTouchscreen driverisloaded orthe COMport/
IRQ designationsareincorrect.
You can manuallyload the DOStouchscreen driverwhen needed, oryou canlet
the systemautomaticallyload the driverwhenyou startup yourcomputer.
Tomanuallyload the DOStouchscreendriver:
1.Closeallapplicationsand exitfromWindows.
2.Access the DOScommand line prompt.
3.Usethe Change Directory(cd)command toswitchtothe directorythat
hasthe DOStouchdriverfiles. Bydefault, the Installprogramloads
TouchWareintothe C:\MTS|TOUCH directory.
4.Type DOSTOUCH andthenpress Enter.The systemdisplays amessage
that the driverisnowinstalled. Forexample:
MicroTouch Mouse Emulator - Version x.x
Copyright ©1990 - 1997 MicroTouch Systems, Inc.
Driver Installed
Toautomaticallyloadthe DOStouchscreen driverwhen you startup your
computer, add the followingline toyourAUTOEXEC.BATfile:
drive-designator:\directory\DOSTOUCH
wheredrive-designatorand directorydefinethelocation (disk and path)of
the filesforthe DOStouchscreen. Forexample:
4. Usingthe System
Jan 05
P.18
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual

Jan 05
P.19
E.OSDSwitch
Input Select: Thisbutton isusedtoselect CVBS forcomposite
videoinput, RGBforVGAinputandS-Videofor
Super-Video input
OSDMenu:Thisbuttonisused toenterOSDmainMenu
Increase(à):Thisbuttonisused toadjusttheincreasingor
next value of selectedOSDcontroloption.
Decrease(ß):Thisbutton isused toadjustthe decreasingor
next value of selectedOSDcontroloption.
PowerSwitch: Thisbuttonisused topowerON/OFF theLCD
4. Usingthe System
Left Right Exit
Menu/SelectionPower
HAP-15AV / HDP-15AV /HOP-15AVSeriesUserManual
