I-Tech QPC-DC Series User manual

QPC-DC Series
User Manual
i-Tech Company LLC

QPC-DC Series USER MANUAL i
FCC Statement
This device complies with part 15 FCC rules. Operation is subject to
the following two conditions:
zThis device may not cause harmful interference.
zThis device must accept any interference received including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a class "a"
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at him own expense.

QPC-DC Series USER MANUAL ii
Copyright Notice
This document is copyrighted, 2011 by i-Tech Company LLC The information provided
in this document has been carefully checked for accuracy at the time of publication.
No representations or warranties, either expressed or implied, with respect to the
contents hereof and specifically disclaims any warranties, merchantability or fitness
for any particular purpose.
This User’s Guide requires higher than basic understanding of computer and QPC-DC
SERIES installation and configuration, and provides technical assistance for system
and network administrators deploying the QPC-DC SERIES.
Any software described in this manual is sold or licensed “as is”. Should the programs
prove defective following their purchase, the buyer assumes the entire cost of all
necessary servicing, repair, and any incidental or consequential damages resulting
from any defect in the software.
i-Tech Company LLC reserves the right to revise this publication and to make changes
from time to time in the contents hereof without obligation to notify any person of such
revision or changes.
No part of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form of or via any means without the prior written permission of
i-Tech Company LLC
Trademark Acknowledgement
All brand, company and product names used for identification in this document are
trademarks or registered trademarks of their respective companies.
© Copyright 2011, Version 1.0
All rights reserved.
Printed in Taiwan

QPC-DC Series USER MANUAL iii
Unpacking the QPC-DC SERIES
After unpacking the QPC-DC SERIES carton, check to make sure all the following
items are included and in good condition.
QPC-DC SERIES main system x 1
Accessories:
AC Power Cable x 1
Power Adapter x 1
User guide CD & driver x 1
Wall Mount Bracket (2pc) x 1
In Wall Front Mount Locking Beads x 1
Make sure that all of the items listed above are present. If any of the above items is
missing, contact your supplier immediately.
Warranty
All products are warranted against defective materials for two year starting from the
date of delivery to the original buyer.
Contact your supplier for a copy of the Warranty Policy & RMA Form or go to
http://www.iTechLCD.com

QPC-DC Series USER MANUAL iv
Important Safety Precautions
1. Before getting started, read these instructions and save them for later reference.
2. Please disconnect this equipment from any AC outlet before cleaning. Clean with
a damp or dry cloth only. Do not spray any liquid cleaner directly on the screen.
3. The power outlet socket used to plug in the computer power cord must be
located near the system and easily accessible. Do not use outlets on the same
circuit of the systems that are regularly switched on and off.
4. Do not expose the power cord, extension cord and power outlet to moisture or
traffic intensive walkways.
5. Install the equipment on a sturdy and reliable surface to prevent damage caused
by dropping.
6. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
7. If the Equipment is sharing an extension cord with other devices, make sure the
total ampere rating of the devices plugged into the extension cord does not
exceed the cord’s ampere rating.
8. If an operating system is not installed, an operating system must be loaded first
before installing any software into the equipment.
9. Disconnect the power cord from the computer before any installation of internal
components. Make sure both the computer and the external devices are turned
off.Asudden surge of power may damage sensitive components. Also make
sure the computer is properly grounded.
10. During installation of any internal components, be sure to ground yourself to
discharge any static electricity. Most electronic components are highly sensitive
to static electric charge. Use a grounding wrist strap and place all electronic
components in any static-shielded devices. If a wrist-grounding strap is not
available, ground your self by briefly touching an unpainted piece of metal.
11. The brightness of the flat panel display will decrease with use over long periods
of time. However, hours of use will vary depending on the application
environment.
12. If the equipment is equipped with a touch panel, avoid using sharp or metallic
objects to operate the touch panel. Scratches on the touch panel may cause
mal-calibration or serious damage to the panel.
13. The LCD panel display is not resistive to shock or vibration. When disassembling
the equipment, make sure the LCD panel is properly and securely installed.

QPC-DC Series USER MANUAL v
Contents
CHAPTER 1INTRODUCTION......................................................1-7
1.1 General Information.................................................................1-7
1.2 Specifications ..........................................................................1-8
CHAPTER 2USING THE SYSTEM.............................................2-11
2.1 Identifying the System...........................................................2-11
2.1.1 Back Top view.................................................................................... 2-11
2.1.2 Back Bottom view .............................................................................. 2-11
2.2 First Time System Setup .......................................................2-12
2.2.1 Hardware Installation Procedure .......................................................2-12
2.2.2 System BIOS Setup...........................................................................2-12
2.2.3 Operating System and Driver ............................................................2-13
2.3 Installation Memory Module...................................................2-13
CHAPTER 3TOUCH SCREEN ..................................................3-15
3.1 Introduction............................................................................3-15
3.2 Specifications ........................................................................3-15
3.3 Touch Screen Software Driver...............................................3-15
3.4 Touch Screen Care and Clean ..............................................3-16
3.5 Troubleshooting.....................................................................3-16
3.5.1 Display Problems...............................................................................3-16
3.5.2 Video Alignment Problems.................................................................3-16
3.5.3 Software Troubleshooting..................................................................3-16
3.5.4 Hardware Troubleshooting.................................................................3-17
CHAPTER 4INTERFACE..........................................................4-18
4.1 External Connector on Main System Box..............................4-18
4.2 Detach Main System Box from System.................................4-19
4.3 Install/Upgrade Memory ........................................................4-20
4.4 Install/Swap HDD ..................................................................4-21
4.5 Install Half Slim SSD (For D2550 only)..................................4-23

QPC-DC Series USER MANUAL vi
4.6 Install 3GS Sim Card (Optional) ............................................4-24
4.7 VGA1: VGA CRT Connector: 15 pin D-SUB Connector.........4-25
4.8 COM2: RS232/RS422/RS485 9 pin D-SUB Connector.........4-25
4.8.1 COM3: RS232 Serial Port Connector: 9 pin D-SUB Connector........4-26
4.9 USB1: USB 2.0/3.0 Port 1,2: USB Type-A Connector ...........4-26
4.10 LAN1: Giga bit Ethernet Connector: RD-45 with LED............4-27
4.10.1 LAN2: Giga bit Ethernet Connector: Standard RD-45 with LED........4-27

QPC-DC Series USER MANUAL 1-7
Chapter 1 INTRODUCTION
This chapter includes the QPC-DC SERIES system background information.
zGeneral Information
zSpecification
zDimensions
1.1 General Information
The QPC-DC SERIES is a fanless mini size panel PC with a compact aluminum
chassis as a heat sink, which delivers reliable performance and offers easy
maintenance when service is required.
Featuring Atom Cedar Trail processor, QPC-DC SERIES combines enhanced digital
media performance with unique thermal solution, and minimizes power consumption
to as little as 24 watts when running at the speed of Dual Core 1.8GHz, bringing up a
quieter and cooler system.
The versatile QPC-DC SERIES can support one 2.5” HDD drive bay (SATA DOM is
available for option) and DDR3 memory up to 4GB. The myriad of I/O ports located on
the main system box includes two 10/100/1000 Ethernet LAN ports, four USB ports
(2x USB 3.0, 2x USB 2.0), four serial ports for QPC-DC 1500/1850 (3x RS232, 1x
RS232/422/485), VGA, Audio-In, built-in camera (optional for 12”/15”/18.5”), built-in
RFID (By Project) and one built-in SATA DOM for flexible expansion capability. For
QPC-DC 150/185, two RS-232 Ports can be optioned to four RS-232 Ports when
required.

QPC-DC Series USER MANUAL 1-8
1.2 Specifications
SYSTEM
CPU
•Support Intel Atom D2550 Processors (Dual Core 1.8 GHz/ 1M Cache)
•Intel D2550+NM10 Express Chipset
System Memory
•1 x 204 pin 1.5V DDRIII SODIMM socket, total up to 4GB
Graphics
•Intel Graphics Media accelerator 3650
•Support dual display mirroring/multiple mode
Network
•2x Realtek RTL8111C 10/100/1000 Base-T fast Ethernet
•802.11g Wireless LAN module (Optional)
•Built in 3GS Module (Optional)
Audio
•AC97 Codec (Line-in/Line-out/Mic) / 2W AMP Output
Power Supply
•DC 12V~24V Wide Range Input
OS
yWindows XP/XPE/VISTA /WinCE/Win 7/Linux
LED
•Power
DISLAY
LCD & Max. Resolution
•8.4” LED TFT LCD: 800 x 600
•10.4” LED TFT LCD: 800 x 600
•12.1” LED TFT LCD: 800 x 600 (Optional 1024 x 768)
•15” LED TFT LCD: 1024 x 768
•18.5” LED TFT LCD: 1366 x 768

QPC-DC Series USER MANUAL 1-9
Touch Type
•5-wire Analog resistive
Brightness
•8.4” LCD: 450 cd/m²
•10.4” LCD: 400 cd/m²
•12.1” LCD: 300 cd/m²
•15” LCD: 400 cd/m²
•18.5” LCD: 300 cd/m²
STORAGE DEVICE
HDD
•1x 2.5” SATA HDD
SATA DOM
•16GB/32GB/64GB Half Slim SSD (Optional)
I/O PORTS
USB
•QPC-DC A 0840/1040/1210/1500/1850, B 0840/1040
•4 x USB (2x USB 3.0 & 2x USB 2.0 ports)
•QPC-DC B 1500
•8 x USB 2.0 ports (2x USB 3.0 & 6X USB 2.0 ports)
•QPC-DC B 1210
•6 x USB 2.0 ports (2x USB 3.0 & 4X USB 2.0 ports)
Serial Ports
•QPC-DC A 1500
•4 x DB-9 (COM1/2/3/4)
•RS232: COM1/3/4
•RS232/422/485: COM2
Support pin9 +5V/12V selection by jumper
•QPC-DC B 0840/1040/1210, A 0840/1040/1210

QPC-DC Series USER MANUAL 1-10
•2x DB-9 (COM 1/2)
•RS232: COM 1
•RS232/422/485: COM2
Support pin9 +5V/12V selection by jumper
LAN
•2 x LAN port (Gigabit LAN 10/100/1000)
Audio
•1 x Line-in
VGA
•1 x DB15 VGA Interface for dual display
MECHANICAL & ENVIRONMENTAL
Dimension
•QPC-DC 0840: 218.5 x 284 x 45.4 (L x W x H mm)
•QPC-DC 1040: 218.5 x 284 x 45.4 (L x W x H mm)
•QPC-DC 1210: 264 x 330 x 48 (L x W x H mm)
•QPC-DC 1500: 307 x 390 x 51 (L x W x H mm)
•QPC-DC 1850: 307 x 495 x 55 (L x W x H mm)
Weight
•QPC-DC 840:3.5 KG
•QPC-DC 104:3.5 KG
•QPC-DC 120: 4 KG
•QPC-DC 150: 5.5 KG
•QPC-DC 1850: 6.5 KG
ENVIRONMENT
EMC & Safety
•CE, FCC
Temperature & Humidity
•QPC-DC 0840/1040/1210/1500/1850
Operating: -10~70°C/Storage: -30~80°C
Humidity: 10%~90%
Specifications are subject to revision or update without notice.

QPC-DC Series USER MANUAL 2-11
Chapter 2 USING THE SYSTEM
2.1 Identifying the System
2.1.1 Back Top view
QPC-DC 1500
2.1.2 Back Bottom view
QPC-DC 1500 A

QPC-DC Series USER MANUAL 2-12
2.2 First Time System Setup
To set up QPC-DC Series for the first-time, you should have the following items
ready. These items are either included in the accessory box or available from your
local computer parts store.
•QPC-DC Series Utility CD (Included)
•Power cord (Included)
•PS/2, AT or USB Keyboard (Not included)
•PS/2 or USB Mouse (Not included)
•USB CD-ROM Drive (Not included)
•Operating System (OS) Installation CD (Not included)
2.2.1 Hardware Installation Procedure
(Prior to turning the power on)
1. Connect a PS/2 keyboard or AT keyboard to the PS/2 keyboard port, or a
USB keyboard to a USB port. If you are using an AT keyboard, you need
an adapter (AT to PS/2 KB) for this connection.
2. Connect the PS/2 mouse to the PS/2 mouse port, or a USB mouse to a
USB port.
3. Connect the male end of the power cord to an electrical outlet.
4. Connect the USB CD-ROM drive.
5. Connect the female end of the power adapter cord to the AC inlet located
at the rear side of the QPC-DC Series.
2.2.2 System BIOS Setup
If you are a commercial user, the QPC-DC SERIES should have been set up and
configured by your distributor already. In the case where you may find it necessary to
change some system configuration information, you will need to run the Basic Input
Output System (BIOS) setup program. Under the following conditions, the CMOS
settings may be changed:
1. The system is starting and being configured for the first time with new
components.
2. The hardware devices attached to the QPC-DC SERIES system have
been changed.
3. The CMOS memory has lost power and the configuration information has
been erased.
The BIOS setup program is stored in ROM, which can be accessed by pressing
<DEL> key on the keyboard immediately when the system is powered on. In order to

QPC-DC Series USER MANUAL 2-13
retain the specified setup information when the system power is turned off, the
system setup information is stored in a battery-backed CMOS RAM. The battery is to
ensure the settings will not be erased when the computer is turned off or reset. When
the computer is powered on again, the system will read the settings stored in the
CMOS RAM and compare them to the equipment check conducted during the power
on self-test (POST). If any error or mismatch occurs, an error message will be shown
on the screen and the computer will be prompted to run the setup program.
2.2.3 Operating System and Driver
The standard QPC-DC Series system may not be equipped with an operating
system (OS). If you are a commercial user, the system is likely to have been
pre-installed with a proper operating system and software drivers by your dealer or
system integrator. If the system is not pre-installed with any system OS and drivers
or you intend to install your preferred ones, you will need to load an OS and software
into the system.
1. Use the External USB CD-ROM/DVD-ROM Drive to load an OS from a
bootable CD. Recent releases of operating systems include setup programs
that load automatically and guide you through the installation. You can also
refer to your OS user manual for instructions on formatting or partitioning the
hard disk drive before any software installation.
2. Install software drivers for your operating system and any peripherals that are
connected. The QPC-DC Series Utility CD includes software drivers for
Chipset,Audio, LAN, Touch screen, VGA Display, Camera, 3GS Module and
Wireless drivers. See driver installation chapters for more information.
2.3 Installation Memory Module
The QPC-DC Series main board provides one 204-pin SODIMM slot. The socket
supports up to 4GB DDR3. When installing the Memory device, please follow the
steps below:
1. Detach the main system box from the system.
2. Locate the SODIMM slot in the back side of the system box.
3. Unlock a SODIMM slot by pressing the retaining clips outward.
4. Align a SODIMM on the socket such that the notch on the SODIMM matches
the break on the slot.
5. Firmly insert the SODIMM into the slot until the retaining clips snap back in
place and the SODIMM is properly seated.

QPC-DC Series USER MANUAL 2-14
Available DDR3 configurations refer to the table below for available DDR3
configurations on the mainboard.
Slot Module Size Total
SODIMM1 1GB, 2GB, 4GB 1GB-4GB
Maximum supported system memory 4GB

QPC-DC Series USER MANUAL 3-15
Chapter 3 TOUCH SCREEN
3.1 Introduction
The QPC-DC Series are installed with a 5-wire analog resistive touch screen. The
touch screen panel turns the flat-panel display into a dynamic graphical user interface
(GUI) and data entry device. The touch screen represents a replacement to needing a
keyboard and mouse to interface with the computer. People associate actions or
functions with visual images better than a combination of keystrokes or button clicks.
Using a touch panel is more entertaining for the operator and actually requires less
brain activity than traditional control devices.
The built-in touch screen system has three main components: a clear solid glass
screen formed to match the shape of a display, a sophisticated electronic controller,
and a software driver.
3.2 Specifications
QPC-DC Series supports HIGGSTEC touch panel. Please check specifications as
following.
Input Method Finger, gloved hand, or touch stylus.
Optical Transmittance 80% ± 3%
Operating Force Stylus=R0.8, ≦50g
Environmental/
Relative Humidity
Operating: -10°C to 70°C, 20 ~ 80% RH.
Storage: -40°C to 80°C, 10 ~ 85% RH.
Constant
Temperature/
Humidity
70°C /90%RH, 500 hrs, allow panel stays in normal
environment for 4 hrs
Surface Durability 3H pencil, pressure 1N/45°
Durability Knock Test: 35,000,000 times
3.3 Touch Screen Software Driver
Touch screens configured with the QPC-DC Series will require software drivers to be
installed to enable the touch screen functionality. The driver software scales the
absolute coordinates received from the touch screen controller into translated screen
coordinates, using the calibration points obtained with the Video Alignment program
included with the driver software. The driver also performs other operations as

QPC-DC Series USER MANUAL 3-16
directed by the application.
3.4 Touch Screen Care and Clean
Only use soft non-abrasive lint free wipes with Isopropyl 99% to clean dirt or stains
found on the touch panel. Always dampen the wipes and then clean the touch panel.
Chemical liquids with strong acidic base will damage the touch screen and void the
warranty.
3.5 Troubleshooting
If you experience operational difficulties with the touch screen system either during or
after installation, the following sections will help you to determine the source of
problems.
The first step in troubleshooting is to determine whether the problem is related to the
display, software, or hardware.And please pay attention to special notes as follows.
•Do not confuse display problems with touch screen problems, as the two
issues are unrelated.
•Software problems are determined by a basic hardware functionality test. If the
hardware transmits touch coordinates correctly, then the problem is probably
with the driver or application software.
•Hardware problems may be caused by the touch screen, controller, cabling,
power supply, or the integration of the touch screen components in the display.
3.5.1 Display Problems
If the display has some problems (such as no video, no horizontal or vertical
synchronization, raster non-linearity, etc.), remember that the video function of the
display and the touch screen installed on the display are separated systems.
Therefore, problems with the display should be treated as display problems, not
touch screen problems. Diagnostic procedures and any possible corrections for
display problems should be performed.
3.5.2 Video Alignment Problems
If the touch screen is responding and the data is linear, but it does not respond at the
appropriate zone, try to align the video. Use Touchkit program.
3.5.3 Software Troubleshooting
Before beginning software troubleshooting, verify that the touch screen hardware is
working normal for serial controllers by running the touchscreen program. If the

QPC-DC Series USER MANUAL 3-17
touch screen is operating, then the problem may be with the driver software, the
application software, or a conflict with other hardware or software. (The problem may
also be due to incorrect Video Alignment of touch screen).
3.5.4 Hardware Troubleshooting
The touch screen system hardware troubleshooting may require analysis of the
touch screen, controller, cables, power supply, and the integration process. To start
with the controller would be the best. Use the controller power-on diagnostics that
are displayed when the touch panel utility driver software is loaded to check for
specific faults. Also check whether the controller is transmitting any touch data.
No touch data:
When no touch data is reported, the problem may be the touch screen, controller, or
cabling. If the features of controller power-on or LED do not identify the problem, you
can use individual system components what are available to be instead.
Intermittent touch data:
If the system is reporting touch data at a slow or varying rate, the problem may be
caused by a low signal strength or excessive noise in the system. And when the
touch screen is not touched but it shows the touch data often caused by excessive
system noise.

QPC-DC Series USER MANUAL 4-18
Chapter 4 INTERFACE
This chapter describes the design features of the system.
4.1 External Connector on Main System Box
yMouse and Keyboard
USB Mouse and Keyboard are to be used unless PS/2 ports are specifically
requested for project use.
ySerial Port
The serial port is a 16550a high speed communications port that sends/receives
16 bytes FIFOs. You can attach a serial mouse or other serial devices directly to
the connector.
yVGA Port
The DB15-pin female connector is connecting to LCD panel.
yUSB Ports
USB ports are for attaching USB devices such as keyboard, mouse, or other
USB-compatible device.
yLAN
The standard RJ-45 LAN jack is for connection to Local Area Network. You can
connect a network cable to it.
yAudio Ports
Line In is used for external CD player, or other audio devices. Rear-Surround Out
in 4/5.1/7.1 channel mode. Line out, is a connector for speakers or headphones.
Mic, is a connector for microphones. Center/Subwoofer Out in 5.1/7.1 channel

QPC-DC Series USER MANUAL 4-19
mode.
4.2 Detach Main System Box from System
1) Flip the System to the back and have the system box face towards you.
2) Remove L and R screw in the side of the system box like shown in the
following picture.
3) Once the locking screws are removed, pull the main system box
downwards until the connector is separated like the following picture.
This manual suits for next models
2
Table of contents
Other I-Tech Touch Panel manuals
