i3-TECHNOLOGIES i3TOUCH E10r User manual

i3TOUCH E10r
Quick start guide

Thank you.
Enjoy the purchase of your i3TOUCH interactive touch display.

Lets see what’s in the box.
i3-Technologies is conscious about the environmental impact of the products that we produce. Therefore we would
like you to support us in this mission by disposing all packaging according to any local regulations.
To check if we packed your product correctly, please verify if all these items are present:
i3TOUCH E10r |WHAT’S IN THE BOX
1x Sl01 WIFI MODULE
2x Passive pens
1x Touch cable (5m)
1x User guide
1x HDMI cable (3m)
1x Wall mount (separate)
1x EU/US Power cable
Is something missing
or does it look damaged?
We’re so sorry, please contact our support service
on [email protected], or contact your
local reseller.

Time to set things up.
Use your favourite applications during meetings.
i3TOUCH E10r |SETUP
On the right side you’ll find the power button, it’s located
at the top of the display connections.
Once you’ve got the power cable connected switch on the
power supply by turning the button to the "1" position.
Connect the power cable to the power socket located
centrally at the bottom of the display. USB C
USB 3.0

i3TOUCH E10r |PEN
Start writing.
Our passive pens have been designed to write as comfortable as possible
during long-term usage. Some more things you can expect:
Good things come in small packages
In the display packaging you can find two pens
included with your display.
Red and blue
Because of the thickness of the tip, the software will
recognise the pen and write in red or blue.
No batteries needed
Thanks to the passive nature of our pens, you’ll never
have to worry about changing a battery again.
Soft, natural writing
The passive pen has a soft tip for smooth and
pressure-free writing.

i3TOUCH E10r |NAVIGATION MENU
Let the menu guide you.
Use your favourite applications during meetings.
Clicking the hamburger button will make the menu
appear with a number of options:
1. Exit the menu and navigate back.
2. Navigate to the homescreen.
3. Start the Whiteboard application.
4. Start the Present application.
5. Work with Annotate and make annotations on everything that
appears on the screen.
6. Switch between the input sources of the display.
7. Adjust volume of the display.
1
2
3
4
5
6
7

i3TOUCH E10r |START WHITEBOARDING
Start whiteboarding.
The whiteboard button opens an interactive whiteboard that allows you to take notes, make drawings or facilitate
workshops. The output can be shared very easily with all participants.
WHITEBOARD
1. Tap the whiteboard button.
2. Start writing in the active
tab.
3. Activate the writing
options by tapping the
eraser.

i3TOUCH E10r |START PRESENTING
Start presenting.
Content from other devices can be streamed to the display with a push of a button.
Also source switching to another input channel is just a click away.
PRESENT
1. Tap the present button.
2. Choose your platform of
choice.
3. Follow the setup guide on
screen.

Important warranty information.
Our i3TOUCH E10r devices are equipped by default with a 5 year warranty. If you however have acquired the
interactive display for educational purposes, this warranty can be extended.
i3TOUCH E10r |WARRANTY
WARRANTY EXTENSION FOR SCHOOLS
You can register your product for an extended warranty if you are an educational insitution.
If you are a corporate institution, please contact your reseller.
Please note that the warranty extension must be registered within 30 days after delivery of
the i3 product through the form found on this page:
i3-technologies.com/en/get-support/warranty/

[email protected]www.i3-technologies.com
VERSION:20200609
