i3TOUCH Excellence User manual

i3TOUCH Excellence
Installation guide
Version 3.5.1

I 42”~ 70” Wall mount Installation Guide
Step 1 : Choose the siding appropriate for mounting.
• The thickness of siding is 5 cm at least or above.
• Please conrm the material and strength of the wall is appropriate to mounting.
• Use the expansion bolts (A) or wood screw (B) to x the hanging bracket (C) on the wall.
Step 2 : Mounting the hanging plate (C) on the display.
• Please power o the display between mounting.
• Use screw to x the hanging plate (C) on the display.
Screw D M6*L20mm+spring washer, 4PCS For 42”~55”
Screw E M8*L20mm+spring washer, 4PCS For 65”~70”
Step 3 : Suspend the display on the hanging bracket.
• Two adult prop up the display.
• Put down the display slow on the hanging bracket.
• Please confirm the hook with hanging plate to be joined on the hanging bracket.
i3TOUCH EXCELLENCE Installation guide Version 3.5.1
2
A
B
CC

3

II 75”~84” Wall mount Installation Guide
Step 1 : Choose the siding appropriate for mounting.
• The thickness of siding is 5 cm at least or above.
• Please conrm the material and strength of the wall is appropriate to mounting.
• Use the expansion bolts (B) to x the hanging bracket (A) on the wall.
Step 2 : Mounting the hanging plate (C) on the display.
• Please power o the display between mounting.
• Use screw to x the hanging plate (C) on the display.
i3TOUCH EXCELLENCE Installation guide Version 3.5.1
4
A
B
S C R E W M8 x20mm + Spr i ng wa s h e r , 4 PCS

Step 3 : Suspend the display on the hanging bracket.
• Two adult prop up the display.
• Put down the display slow on the hanging bracket.
• Please conrm the hook with hanging plate to be joined on the hanging bracket.
IV’42”~ 55” Stand Installation Guide
Step 1 : Open the package and to take out the stand.
• Check the parts and that amount, please see the bellow picture.
5
1 . Stand .1PCS 2 . Screw M6 L20mm+Washer . 4 PCS

Step 2. Mounting the display (A) on the stand.
• Use screw (B) to x the display on the stand (C) .
V 65”~ 84” Stand Installation Guide
Step 1 Open the package and to take out the stand.
• Check the parts and that amount, please see the bellow picture.
i3TOUCH EXCELLENCE Installation guide Version 3.5.1
6
A
c
B M6 L20mm+Washer 4pcs
1 . Stand .1PCS 2 . Screw M8 L20mm+Washer . 4 PCS

Step 2 Mounting the display (A) on the stand.
• Use screw (B) to x the display on the stand (C).
VI 42”~84” Stand Assembly Guide
Step 1 Open the package and to take out the stand.
• Check the parts and that amount, please see the bellow picture.
7
A
c
B M8 L20mm+Washer 4pcs
1 Stand R case 1PCS. 2 Stand L case 1PCS. 3 Stand B case 1PCS. 4 Screw M4 L8mm 4PCS.

Step 2 Use screw (A) to x the stand (B) case between (B) and (C) .
i3TOUCH EXCELLENCE Installation guide Version 3.5.1
8
A
B
c
Stand B case

9
